Skytron 1602 ESSENTIA User manual

OWNER'S MANUAL
(Includes Operation, Maintenance and Parts)
Read this manual before operating the table! This information is necessary
for the safe and e󰀩cient operation of the equipment.
1602 ESSENTIA
SURGICAL TABLE
TEC-D-0108 REV5
09/27/2017

The base language for this document is ENGLISH. Any translations must be from the base language document.
Printed copies are not controlled documents.
Although current at the time of publication, SKYTRON'S policy of continuous development makes this manual subject to
change without notice. If current manuals are required, contact your local SKYTRON representative or contact SKYTRON
directly at the distribution addresses listed above.
Distributed by:
US - SKYTRON
5085 Corporate Exchange Blvd. S.E.
Grand Rapids, MI 49512 [phone]
www.skytron.us
SKYTRON EUROPE BV
Floresstraat 52
8022 AD Zwolle
THE NETHERLANDS
Mizuho Corporation
3-30-13 Hongo, Bunkyo-ku
Tokyo 113-0033
JAPAN
Emergo Europe B.V.
Prinsessegracht 20, 2514AP
The Hague, The Netherlands

Page 1
1602 ESSENTIA Owner's • REV5
TABLE OF CONTENTS
TITLE PAGE
SECTION 1. SAFETY INFORMATION ........................................................................................ 3
1-1. Special User Attention........................................................................................................ 3
1-2. Safety Precautions ............................................................................................................. 5
SECTION 2. EQUIPMENT SPECIFICATIONS ............................................................................ 8
2-1. Intended Use...................................................................................................................... 8
2-2. Installation.......................................................................................................................... 8
2-3. Environmental Conditions .................................................................................................. 8
2-4. Certication ........................................................................................................................ 8
2-5. Classication...................................................................................................................... 8
2-6. ElectricalSpecications ..................................................................................................... 9
2-7. MechanicalSpecications.................................................................................................. 9
2-8. Movement Over Threshold................................................................................................. 9
2-9. Dimensions ........................................................................................................................ 9
2-10. Equipment Labels ............................................................................................................. 10
2-11. Label Symbols................................................................................................................... 11
SECTION 3. OPERATION .......................................................................................................... 12
3-1. General ............................................................................................................................. 12
3-2. Power Requirements......................................................................................................... 12
3-3. Pendant Control ................................................................................................................ 13
3-4. Floor Lock/Brake System .................................................................................................. 13
3-5. Electrical Power ................................................................................................................ 13
3-6. AC Operation .................................................................................................................... 14
3-7. Battery Operation .............................................................................................................. 14
3-8. Charging the Batteries ...................................................................................................... 15
3-9. Positioning Functions ........................................................................................................ 15
3-10. Emergency Brake Release ............................................................................................... 18
3-11. Table Top Rotation ............................................................................................................ 19
3-12. Head Section..................................................................................................................... 20
3-13. Pad Sets............................................................................................................................ 21
3-14. Positioning......................................................................................................................... 21
3-15. Positioning and Clearances .............................................................................................. 24

Page 2
1602 ESSENTIA Owner's • REV5
TABLE OF CONTENTS
TITLE PAGE
SECTION 4. MAINTENANCE..................................................................................................... 25
4-1. Cleaning and Disinfecting ................................................................................................. 25
4-2. Routine Inspections........................................................................................................... 26
4-3. Preventive Maintenance.................................................................................................... 26
4-4. Operator Troubleshooting ................................................................................................. 27
4-5. Maintenance Checks & Services ...................................................................................... 28
4-6. Maintenance Matrix........................................................................................................... 30
4-7. Service .............................................................................................................................. 31
4-8. Disposal Instructions ......................................................................................................... 31
4-9. Storage ............................................................................................................................ 31
SECTION 5. REPLACEMENT PARTS ....................................................................................... 32
5-1. Head & Top Section Components ..................................................................................... 32
5-2. Base Components............................................................................................................ 34
SECTION 6. ELECTROMAGNETIC EMISSIONS ...................................................................... 35
SECTION 7. REVISION HISTORY............................................................................................. 39

Page 3
1602 ESSENTIA Owner's • REV5
SECTION 1. SAFETY INFORMATION
Ensure that the following transportation instructions
are adhered to before moving the 1602 table:
a. Remove the power cord.
b. Place the main power switch in the OFF position.
c. Tighten all handles and knobs.
Ensure that the following packaging guidelines are
adhered to when shipping the 1602 table:
• The 1602 table must be shipped in a
suitable container and sealed from the outside
atmosphere.
• The shipping container must employ
appropriate reinforcement to prevent table
vibration or movement during shipment.
• The table brakes must be locked during
shipment.
Table must always be equipped and operated with
two (2) 12 volt, sealed, lead acid batteries available
only through SKYTRON.
Certain accessories, such as the Uro-Drain Tray,
Arm boards, and X-Ray top, can be damaged when
changing the position of the table top sections.
Alwayslookrsttoseeifadesiredmovementis
going to interfere with any accessories in use.
The operator has the ultimate responsibility of
preventing damage to the table and surrounding
equipmentorpossibleinjurytothepatientorsta󰀨.
The operator must ensure proper positioning is
maintained to prevent compromising respiration,
nerve pathways, or circulation.
In general, use common sense to dictate when
there is a potential hazard.
1-1. Special User Attention
Prior to use, all personnel that may operate this
table must be instructed in the correct operational
procedures. The 1602 ESSENTIAsurgical table is
designedforusebytrainedandqualiedpersonnel
for human medical purposes only.
Initial use should not begin until all personnel that will
operate the surgical table have been instructed in
its proper operation by a clinical in-service protocol
administered by a SKYTRON representative.
Aroutineinstructional program mustbe implemented
by the facility for proper usage instructions for all
personnel that may operate this table.
The maximum lifting capacity of the 1602 table is
500 pounds (227 kg) only when table brakes are
locked .
When lifting or articulating large patients, pay
close attention to the patient position as well as
the positioning guidelines and limitations listed in
the operation instructions.
This equipment is intended for use by healthcare
professionals only. This equipment may cause radio
interference or may disrupt the operation of nearby
equipment. It may be necessary to take mitigation
measures, such as reorienting or relocating the
table or shielding the location. If other devices are
in close proximity to the table, ensure that these
devices comply with electromagnetic compatibility
medical standards.
The extreme positioning capabilities of the 1602
table requires special attention for possible
interference points when using multiple function
positioning. As with the operation of any surgical
table, a certain amount of care should be exercised
to position the patient safely. Although the thick
pads and sheets substantially protect the patient,
pinch points, located at the joints of the top section,
should always be considered. BE SURETHATTHE
ARMS, HANDS,AND FINGERS OF THE PATIENT
AND THOSE OF THE OPERATING ROOM
PERSONNEL ARE CLEAR OF ALL MOVING
PARTS BEFORE MOVING THE TABLE. Refer to
Figure 1-1 for a Pinch/Crush Point Diagram. Proper
restraints should always be used for patient safety.

Page 4
1602 ESSENTIA Owner's • REV5
WARNING
Injury Hazard, Possible Pinch/Crush Points
HEAD AND BACK SECTION
CAN COLLIDE WITH BASE OR FLOOR
LEG SECTION CAN COLLIDE
WITH BASE, COLUMN OR FLOOR
Figure 1. Possible Pinch/Crush Points

Page 5
1602 ESSENTIA Owner's • REV5
1-2. Safety Precautions
The following is a summary of DANGERS,
WARNINGS, and CAUTIONS stated in this manual.
These precautions are found throughout the manual
where applicable. Carefully read this manual before
proceeding to operate or service the equipment.
DANGER
Indicates a hazardous situation that, if not avoided,
will result in death or serious injury.
WARNING
Indicates a hazardous situation that, if not avoided,
could result in serious injury.
Injury Hazard, Possible Pinch/Crush
Points
To avoid risk of electric shock, this
equipment must only be connected
tosupplymains withprotectiveearth.
Prior to operating the table, observe
all table precaution labels andreview
the SPECIAL USER ATTENTION
section in the front of this manual.
Possible explosion hazard exists
if table is used in the presence of
FLAMMABLE ANESTHETICS.
Thesurgicaltablemust bepositioned
in such a way that the operator can
disconnect the power cord at the
table or the electrical outlet.
The operator should remain
positioned for proper patient
observation, as shown in Figure 11.
19-3/4”
(500MM)
180°
BACK
SECTION
HEAD
SECTION
PATIENT’S
HEAD
OPERATOR’S
POSITION
Figure 11. Operator's Position
Ensure brakes are properly set prior
to patient transfer. DO NOTUNLOCK
BRAKES when a patient is on the
table. An uneven patient weight load
may cause instability.
DO NOT use the table to transport
a patient. There is a risk of injury
to the patient and sta󰀨 if the patient
should fall during transport.
DO NOT use the table to transport
heavy objects. There is a risk of
injury to sta󰀨 if the object should
fall during transport.
To maximize patient safety, utilize
proper restraint methods during
extreme Trendelenburg positioning.
To maximize patient safety, utilize
proper restraint methods during
extreme lateral tilt positioning.
The table pad set must be in place
and the patient must be positioned
to avoid touching any of the metal
sectionsofthetabletoprotectagainst
any possible electrical shock injury.
Consult with the manufacturer's
instructions when using high
frequencysurgicalequipment,cardiac
debrillator, and cardiac debrillator
monitors. Improper operation
proceduresmaycause ashockhazard
or cause an equipment malfunction.
When an antistatic pathway is
required, the table has to be used
on an antistatic oor.
The antistatic properties of the table
are dependent on the use of the
originalpad set whichwas furnished
with the table or an alternate
approved replacement.
Personal injury to patient or sta󰀨
may result from a lack of proper
maintenance of this equipment.

Page 6
1602 ESSENTIA Owner's • REV5
Supineor proneposition)with thetable
lowered to its lowest height position.
• Maximumpatientweightshouldnot
exceed 500 pounds (227 kg).
• Patient's head must be on the
head section. Head section must be
attached in its normal orientation to
the table's back section.
Prior to unlocking brakes, check
for obstructions on the oor that
might prevent the table from moving
smoothly to a new location. Re-lock
the brakes immediately once the
nal position is reached and before
commencing surgery.
To move the table safely, one sta󰀨
member should be positioned at
the head end and one at the foot
end. If the patient weight exceeds
250 pounds (114 kg), four (4) sta󰀨
members are required to move the
table and ensure patient safety.
DO NOT reverse the patient on the
table without rst consulting with
your SKYTRON representative.
Certain accessories may limit
weight capacities. Check with your
SKYTRON representative.
SKYTRON products are guaranteed
for proper performance with the use
of genuine SKYTRON accessories.
Accessories and products not
furnished by SKYTRON have not
been tested for proper performance
and safety. Such applications or
usageare atthediscretion oftheuser
to ensure patient and sta󰀨 safety.
DO NOT use worn or damaged
accessories; they representan injury
hazard.
Compliance with IEC60601-1 edition 3
has been conrmed without the pad set.
DO NOT use the table if any of the
inspection points fail.
Always follow OSHA/EASHW blood-
borne pathogens standards for
protectiveclothing,including gloves,
masks, and eye protection when
cleaning the surgical table.
DO NOT disassemble or modify the
table. Unauthorizeddisassemblymay
cause electric shock or malfunction.
CAUTION
Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Remove possible obstacles before
loweringortilting theoperatingtable.
DO NOT place objects on the base of
the table, risk of injury and damage
exists during positioning.
AvoidElectricalInjuriesbyobserving
a Lockout / Tag Out Policy Avoid
exposure to electrical hazards and
unexpected Energizing or startup
of the equipment by unplugging the
equipment from the energy source
and by the plug being under the
exclusive control of the employee
performingthemaintenanceorrepair.
The placement of a lock and tag on
the tables plug in accordance with
established procedure indicating
thatthe energy isolatingdevice shall
not be operated until the removal of
the lock / tag is recommended.
DONOTunlockbrakeswhenapatient
is on the table. An uneven patient
weight load may cause instability.
If circumstances demand table
brakes be unlocked:
• The patient must be centered and
evenly distributed on the table top (i.e.

Page 7
1602 ESSENTIA Owner's • REV5
Always inspect the table prior to
use to assure safe and correct
operation. Any table determined to
be malfunctioning must be removed
fromserviceimmediately andlabeled
inoperable.
ReferallserviceissuestoaSKYTRON
authorized service technician.
CAUTION
CAUTION without the safety alert symbol, is used
to address practices not related to personal injury
but with a possibility of damage to equipment.
The combination of minimum elevation
(all the way down) and extreme
Trendelenburg positioning function may
allow the back section to collide with
thebaseoroor.
The leg section may hit the table base
ortheoorifboththelegandelevation
systems are placed in their full down
position.
Caution should be taken when cleaning
thetabletopreventexcessiveuidentry
into electrical connectors.
Thoroughly read and follow the
manufacturer's directions for all cleaning
uids.DONOTusecleanerscontaining
phenolics.
When using spray cleaners, DO NOT
spray fluids directly into electrical
receptacles or components.
Before replacing pads on the table,
make sure the pads and all mating
surfaces are completely dry. Moisture
trapped between the pads and mating
surfaces may cause distortion of table
tops.
Avoid immersing the pendant control
assembly in liquids.
If the table is stored for a period greater
than 6 months, the batteries should
be removed and stored in a dry, clean
condition at a storage temperature
of 68°F (20° C). Batteries should be
re-charged every 6 months of product
storage.
Any parts or assemblies not listed in this
section must be serviced or replaced
by SKYTRON authorized service
personnel only. This is necessary to
avoid the possibility of damage to the
equipment.
NOTICE
Indicates important information not related to
personal injury.

Page 8
1602 ESSENTIA Owner's • REV5
2-1. Intended Use
This surgical table is intended for use by healthcare
professionals for human medical purposes only.
The surgical table is not intended to be used for
patient transport.
CAUTION
Avoid Electrical Injuries by observing a
Lockout / Tag Out Policy Avoid exposure
to electrical hazards and unexpected
Energizing or startup of the equipment
by unplugging the equipment from the
energy source and by the plug being
under the exclusive control of the
employee performing the maintenance
or repair. The placement of a lock and
tag on the tables plug in accordance
with established procedure indicating
that the energy isolating device shall
not be operated until the removal of the
lock / tag is recommended.
2-2. Installation
Prior to placing the table into use, the following
itemsmustbeinspected,veried,andcalibrated
by a Skytron authorized representative:
• Final initialization and completion of the
installation report is required for warranty
validation.
• Functional testing and cycling.
• Electricalsafetytestingtoincludeverication
by hospital personnel.
• Digital calibration of the hydraulic system's
pressure relief valve (PRV).
• Inspection of the hydraulic system.
• Table must be allowed to acclimate to usage
climate requirements.
• Vericationofhydraulicuidlevel.
• Table has been wiped down to remove rust
inhibitors.
Items found to be non-conforming must be
addressed prior to placing the table into service.
2-3. Environmental Conditions
a. During Transport and Storage (In Original
Packaging Materials)
• Ambient Temperature: -4° to 122°F (-20° to 50° C)
• Relative Humidity: 20% to 85% (No Condensation)
• Atmospheric Pressure: 21 in-Hg to 31 in-Hg
(700 hPa to 1060 hPa)
b. During Use
• Ambient Temperature: 50° to 104°F (10° to 40°C)
• Relative Humidity: 30% to 75% (No Condensation)
• Atmospheric Pressure: 21 in-Hg to 30 in-Hg
(700 hPa to 1060 hPa)
NOTICE
Operating altitude is 6562 feet (2000
m) max. above sea level.
2-4. Certication
CertiedbyETLtothesestandards:
Medical electrical equipment, Part 1: General
requirements for basic safety and essential
performance ANSI/AAMI ES60601-1:2005 +
C1:2009 + A2:2010 /(R)2012
Medical electrical equipment–Part 1: General
requirements for basic safety and essential
performance CAN/CSA-C22.2 No. 60601-1:08 +
COR 2: 2011/06/01
Medical electrical equipment Part 2-46: Particular
requirements for the basic safety and essential
performance of operating tables IEC 60601-2-46:
2010
2-5. Classication
Class I Equipment
Applied Parts: Table Top/Type B Applied Parts
IPX4 Rated
• Equipment not suitable for use in the
presenceofammableanestheticmixturewith
AIR, OXYGEN, or NITROUS OXIDE.
• This product is not intended for sterilization.
SECTION 2. EQUIPMENT SPECIFICATIONS

Page 9
1602 ESSENTIA Owner's • REV5
2-6. Electrical Specications
Power Requirements:
100-120 VAC, 50 - 60 Hz, two (2) 6 amp fuses
Current Leakage: Less than 500 micro amps
Power Cord: 10.9 foot (3.3 m) w/ hospital grade
connector (removable)
Duty Cycle:3minon,7mino󰀨
Battery Power: 24 VDC (12V17Ah x 2)
Model : NP18-12B YUASA Battery
SKYTRON Part Number : D5-016-03
WARNING
To avoid risk of electric shock, this
equipment must only be connected
tosupplymains withprotectiveearth.
480 mm
(18-15/16”)
555 mm
(21-7/8”)
2027 mm (79-13/16”)
2000 mm (78-3/4”)
649mm
(25-9/16”)
580mm
(22-13/16”)
483mm
(19”)
999 mm
(39-3/8”)
MAX. 1040 mm
(40-15/16”)
MIN. 690
mm
(27-3/16”)
142 mm
(5-5/8”)
500 mm
(19-5/8”)
SIDE VIEW FRONT VIEW
TOP VIEW
90°
60°
216
mm
(8-1/2”)
240mm
(9-7/16
” )
Figure 2. 1602 Table Dimensions
2-7. Mechanical Specications
Maximum Lifting Capacity: 227 kg (500 lbs)
Maximum Articulating Capacity: 227 kg (500 lbs)
Unit Weight: 255 kg (562 lbs)
Maximum Patient Weight: 500 lbs (227 kg)
2-8. Movement Over Threshold
Height 10mm (0.39") /Width 80mm (3.15")
1.312 f/s (.4 m/s)
2-9. Dimensions
Refer to Figure 2 for an illustration of the 1602 table
and its key dimensions.

Page 10
1602 ESSENTIA Owner's • REV5
2-10. Equipment Labels
16 C610501A
11 C630006A ns C610624A
► PENDANT PACKAGING
3 C630006A
17 C651603A
12 C651606A
2 C651607A
(left)
C651608A
(right)
5 C651615A 6 C656715A 7 C656741A
10 C651618A
1 C651620A
8 C651610A 9 C656738A
2
11
14
4
14 C651605A
15 C656309C
16
15
5
1
12
17
1
10
4
11 3
6
987
13 C651610A
WARNING
TABLE TOP
ALWAYS LOCK THE TABLE TOP IN POSITION AFTER A
FULL RPTATION OF 180°, DO NOT ROTATE THE TOP
WITH AN UNDISTRIBUTED PATENT LOAD AS
INSTABILITY MAY RESULT, EXERCISE CAUTION WITH
THE TABLE TOP ROTATED 90°TO THE BASE SINCE
AN IMPROPERLY DISTRIBUTED PATIENT LOAD MAY
CAUSE THE TABLE TO BE TIPPED OVER.
MISE EN GARDE
PLATEAU DE LA TABLE
TOWOURS MAINTENIR LA TABLE EN POSITION FERMĚE
APRES UNE ROTATION COMPLĚTE À 180°. NE PAS FAIRE
TOURNER LE PLATEAU AVEC UNE CHARGE DE PATIENT
NON RÉPARTIE CAR CELA PURRAIT ENTRAINER UNE
INSTABILITÉ. FAIRE PREUVE DE VIGILANCE LORSOUE
LE PLATEAU DE LA TABLE TOURNE Á90° CAR UNE
CHARGE DE PATIENT NON RÉPARTIE UNIFORMÉMENT
POURRAIT FAIRE BASCULER LA TABLE.
C651610A (left)
C651604A
(right)
Un malada sera mis loin
du rail du cöté plus que 1
cm afin qu'unmalade ne
touche pae le rail du
cöté.
A Patient shall be set up
to more than 1 cm apart
from a side rail so that a
patient does not touch
on side rails.
WARNING
MISE EN GARDE
THIS PRODUCT COMPLIES WITH RADIA-
TION PERFORMANCE STANDARD 21 CFR
AT THE TIME OF MANUFACTURE _______
MANUFACTURED ____________________
MODEL NO. _________________________
Turn “Emergency Override Floor Unlock Device”
counterclockwise to unlock the floor locks.
Turn “Emergency Override Floor Unlock Device”
clockwise carefully and completely to tighten it.
1
2
EMERGENCY BRAKE RELEASE
Before placing table in service plug in
table power cord and recharge batteries
for approximately 8-10 hours.
13
EMERGO EUROPE B.V.
Prinsessegracht 20, 2514 AP
The Hague, The Netherlands
OR
AFTER JULY 2017

Page 11
1602 ESSENTIA Owner's • REV5
Symbol Description Used On
Product
Used In
Manual
NOTICE Indicates important facts or helpful hints. ●
ISO 7010-W001 General warning sign (e.g., WARNING, CAUTION) ● ●
IEC 60417-5840 Type B applied part ●
IPX4 IEC 60529 Enclosure class (Splash-proof) ●
WEEE Indicates waste disposal information ●
ISO 7010-M002 Refer to instruction manual ●
IEC 60417 Alternating current ●
ISO 15223-3.15 Catalogue number ●
ISO 15223-3.16 Serial number ●
EN980-5.13
AUTHORIZED REPRESENTATIVE IN
THE EUROPEAN COMMUNITY ● ●
EN980-5.12 Manufacturer ● ●
ISO 7010-M001 General mandatory action sign ●
IEC 60417-5019 Protective earth (ground) ●
2-11. Label Symbols

Page 12
1602 ESSENTIA Owner's • REV5
SECTION 3. OPERATION
HEAD
SECTION BACK
SECTION LEG
SECTION
SEAT
SECTION
SERVICE
ACCESS COVER
HEAD SECTION
LOCKING KNOB
HEAD SECTION
RELEASE BAR
POWER SWITCH
EMERGENCY
BRAKE RELEASE
FLOOR/LOCK BRAKE
POWER
CORD
PENDANT
CONTROL
ACCESSORIES:
POWER CORD
PENDANT CONTROL
DETACHABLE PARTS:
HEAD SECTION
SIDE
RAIL
Figure 3. 1602 Surgical Table
3-1. General
SKYTRON’s 1602 ESSENTIA Surgical Table is
an electro-hydraulic operated, general purpose
surgical table (Figure 3).
Positioning functions operated by the hand-held,
push button, pendant control are:
• Trendelenburg • Lateral Tilt
• Back Section • Elevation
• Leg Section • Flex/Reex
• Floor Lock/Brake • Return-to-Level
• Power Switch (ON/OFF)
Manual controls are provided for head section
positioning, table rotation and emergency brake
release.
3-2. Power Requirements
• 100-120VAC, 50/60Hz electrical power supply.
• 200-240VAC, 50/60Hz electrical power supply.
The table is equipped with a removable 10.9 foot
(3.3 m) long power cord with an approved hospital
grade plug. The AC power switch (ON/OFF) is
located at the front of the table base (Figure 4).
POWER
CORD
POWER
SWITCH
TWO (2)
FUSES
Figure 4. Table Base

Page 13
1602 ESSENTIA Owner's • REV5
3-3. Pendant Control
The hand-held pendant control has a spring clip
hanger is located on the back of the control for
storage. When the pendant control is not in use,
it should be stored on a convenient side or end
rail (Figure 5).
POWER
INDICATOR
BATTERY
INDICATOR
FUNCTION
BUTTONS
SPRING CLIP
HANGER
Figure 5. Pendant Control
Functionbuttonsareidentiedwithinternationally
recognized symbols and abbreviated descriptions
for all functions (Figure 6).
TRENDELENBURG
LATERAL TILT RIGHT
BACK DOWN
TABLE DOWN
LEG DOWN
REFLEX
BRAKE LOCK
LEVEL
POWER ON/OFF
REVERSE
TRENDELENBURG
LATERAL TILT LEFT
BACK UP
TABLE UP
LEG UP
FLEX
BRAKE UNLOCK
Figure 6. Function Buttons
NOTICE
If any button on the pendant control is
pressed continuously for longer than
three (3) minutes, a malfunction may
occur. This will require approximately
seven (7) minutes for the table to recover
and return to normal operation.
3-4. Floor Lock/Brake System
The oor lock/brake system consists of four (4)
self-leveling, hydraulic brake cylinders which raise
and support the table base o󰀨 from the casters
(Refer to Figure 3).
Press the BRAKE LOCK button on the pendant
control to set the table’s brakes.
NOTICE
Activating any function button will
activate the brake system. Using the
TABLE UP function to set the brakes
provides a visual assurance that the
brakes are locked without altering
the table position, except when the
emergency brake is released.
Pressing the BRAKE UNLOCK button on the
pendant control will retract the hydraulic brake
cylinders, lowering the table base back onto the
casters for mobility (Refer to Figure 6).
3-5. Electrical Power
The 1602 table will operate on either AC or battery
power.
WARNING
Apossible explosion hazard exists if
the table is used in the presence of
FLAMMABLE ANESTHETICS.
Prior to operating the table, observe
all table precaution labels andreview
Section 1-1. Special User Attention,
in the front of this manual.

Page 14
1602 ESSENTIA Owner's • REV5
3-6. AC Operation
To operate the table on AC power:
a. Make sure the power cord is securely attached.
To install the power cord, insert the cord into the base
connector until it locks in place (Figure 7).
I
O
BASE POWER
SWITCH
CONNECTOR
POWER
CORD
Figure 7. Base Electrical Panel
WARNING
The table must be positioned so that
theoperatorcan disconnectthe power
cordatthetableortheelectricaloutlet.
b. Plug the cord into a properly grounded, hospital
grade, AC outlet. Make sure the power cord
is routed to prevent it from being in the way of
operating personnel.
NOTICE
Groundingreliabilitycan onlybe achieved
when the table is connected to a properly
grounded receptacle. Where integrity of
the external ground is compromised, the
table must be operated in battery mode.
Use only SKYTRON replacement parts
for the power cord and pendant control.
Refer to Section 5 Replacement Parts.
c. Place the base power switch to the ON position,
then press the power ON/OFF button at the lower
right hand corner of the pendant control (Figure 8).
POWER
ON/OFF
BUTTON
LEVEL
BUTTON
Figure 8. Level & Power On/O󰀨 Buttons
The power on indicator light, located in the upper
part of the pendant control, will illuminate (Figure 9).
POWER ON
INDICATOR
LIGHT
BATTERY
INDICATOR
LIGHT
Figure 9. Power Indicator Lights
The table is now ready for AC power operation.
Shutdown the table by pressing the pendant LEVEL
button to move the table top to a horizontal position.
Press the pendant ON/OFF button and switch the
base power switch OFF (Refer to Figure 9).
Remove the power cord by pulling the plug out of
the base connector.
3-7. Battery Operation
To operate the table on battery power:
Switch the base power switch OFF and/or
disconnect the power cord (Refer to Figure 8).
NOTICE
Prior to all surgical procedures, make
surethebatterychargeissu󰀩cientfor
anticipated duration and use.
Press the power ON/OFF button at the lower
right hand corner of the pendant control (Refer to
Figure 8).
The battery indicator light, located in the upper
part of the pendant control, will illuminate (Refer
to Figure 9).
The table is now ready for battery operation.

Page 15
1602 ESSENTIA Owner's • REV5
To shutdown the table and extend battery charge
life when not in use, press the power ON/OFF
button on the pendant control, the battery indicator
light will darken.
NOTICE
Battery operation must be turned OFF at
the pendant control. It cannot be turned
OFF using the base power switch.
3-8. Charging the Batteries
CAUTION
Batteries must be properly maintained
to ensure table operation in the event
of an AC power supply failure.
Batteries should be charged:
• When the table is placed into initial service
• As indicated by the pendant battery indicator light
• Every week under normal service conditions
Three (3) green LEDs, on the battery indicator are
turned on according to the charge state.
The following table shows the battery charge level
as indicated by the lighted bars.
Indicator Status Percent Charge
75% ~ 100% (Fully charged)
30% ~ 75% (Charged)
Less than 30% (Charged)
Needs recharging immediately
NOTICE
The charging system operates ONLY
when the table is inAC operation mode.
The table can be operated onAC power
while the batteries are being charged.
To recharge the batteries, make sure the power
cord is connected to the table and plugged into a
AC wall outlet, and the base power switch is ON.
The batteries require 8 to 12 hours of continuous
recharging to reach a full charge. The charging
system will automatically reduce input amperage
as capacity reaches 90% to avoid over charging.
It is recommended to charge the batteries at the end
of each week to establish a normal routine. The
batteries last longer if they are not permitted to fully
discharge. The batteries require no maintenance,
and should provide an approximate normal life of
4 years under a proper charging program.
3-9. Positioning Functions
The hand-held pendant control activates the
following table positioning functions (Figure 10):
TRENDELENBURG
LATERAL TILT RIGHT
BACK DOWN
TABLE DOWN
LEG DOWN
REFLEX
BRAKE LOCK
LEVEL
REVERSE
TRENDELENBURG
LATERAL TILT LEFT
BACK UP
TABLE UP
LEG UP
FLEX
BRAKE UNLOCK
Figure 10. Pendant Control Function Buttons
CAUTION
The operator should remain
positioned for proper patient
observation, as shown in Figure 11.
19-3/4”
(500MM)
180°
BACK
SECTION
HEAD
SECTION
PATIENT’S
HEAD
OPERATOR’S
POSITION
Figure 11. Operator's Position
Press pendant function button to start positioning.
Release the button to stop positioning.
NOTICE
With an evenly distributed patient weight
load up to 500 lbs (227 kg), all table
functions will operate smoothly and quietly.

Page 16
1602 ESSENTIA Owner's • REV5
a. Floor Lock/Brake System
WARNING
Ensure brakes are properly set prior
to patient transfer. DO NOT UNLOCK
BRAKES when a patient is on the
table. An uneven patient weight load
may cause instability.
DO NOT use the table to transport a
patient or heavy objects. There is a
risk of injury to the patient and sta󰀨
if the patient should fall or objects
dislodge during transport.
CAUTION
If circumstances demand table
brakes to be unlocked:
Patient must be centered and evenly
distributedonthetabletop(i.e.,supine
or prone position) with the table
lowered to its lowest height position.
Maximum patient weight should not
exceed 500 pounds (227 kg).
Patient's head must be on the head
section. Head section must be
attached in its normal orientation to
the table's back section.
Prior to unlocking brakes, check
for obstructions on the oor that
might prevent the table from moving
smoothly to a new location.
To move the table safely, one sta󰀨
member should be positioned at
the head end and one at the foot
end. If the patient weight exceeds
250 pounds (114 kg), four (4) sta󰀨
members are required to move the
table and ensure patient safety.
Re-lock the brakes immediatelyonce
the nal position is reached and
before commencing surgery.
Press the BRAKE LOCK button on the pendant
control to activate the brakes (Figure 12).
BRAKE
UNLOCK
BUTTON
BRAKE
LOCK
BUTTON
Figure 12. Brake System Activation
Press the BRAKE UNLOCK button on the pendant
control to release the four (4) self-leveling brake
feet in order to move the table.
b. Trendelenburg
WARNING
To maximize patient safety, utilize
proper restraint methods during
extreme Trendelenburg positioning.
To place the table in a Trendelenburg (head down)
position, press the TREND button. Trendelenburg
positioning up to 28° may be obtained (Figure 13).
To place the table in a reverse Trendelenburg
(head up) position, press the REV TREND button.
Reverse Trendelenburg positioning of up to 28°
may be obtained.
REVERSE
TRENDELENBURG
TRENDELENBURG
TREND
TREND
REV TREND
REV TREND
28°
28°
Figure 13. Trendelenburg Positioning

Page 17
1602 ESSENTIA Owner's • REV5
CAUTION
Acombination of minimum elevation (all
the way down), extreme Trendelenburg
positioning, may allow the back or leg
sectiontocollidewiththebaseoroor.
c. Lateral Tilt
To achieve lateral tilt right (as viewed from the head
end of the table), press the TILT RIGHT button.
Tilt of up to 23° (±2°) may be obtained (Figure 14).
LATERAL TILT
LEFT
LARERAL TILT
RIGHT
23°
(±2°)
23°
(±2°)
Figure 14. Lateral Tilt Positioning
To achieve lateral tilt left, press the TILT LEFT
button. Tilt of up to 20° may be obtained.
WARNING
To maximize patient safety, utilize
proper restraint methods during
extreme lateral tilt positioning.
d. Back Section
To raise the back section, press the BACK UP
button. The back section will raise up to 90° above
horizontal (Figure 15).
90°
30°
BACK
UP
BACK
DOWN
Figure 15. Back Section Positioning
With the optional X-ray cassette top, do not raise
back plate over 30°. When the back is up 90°,
always pay attention when adjusting the tabletop
in reverse Trendelenburg to prevent the head plate
from falling.
To lower the back section, press the BACK DOWN
button. The back section will lower to 30° below
horizontal.
e. Elevation
To raise table top, press the TABLE UP button
(Figure 16). The table will lift a patient weight of
228 kg (500 lbs) up to 1040 mm (40 15/16").
660mm
(26”)
1040mm
(40-15/16”)
TABLE UP TABLE DOWN
Figure 16. Elevation Function
To lower the table top, press the TABLE DOWN
button. The table top will go down to a minimum
height of 26" (660 mm).

Page 18
1602 ESSENTIA Owner's • REV5
f. Leg Section
Press the LEG DOWN button to lower the leg
section. The leg section will go down to a maximum
of 100° below horizontal. Press the LEG UP section
to raise the leg section up to level (Figure 17).
LEG DOWN
100°
LEG UP
Figure 17. Leg Section Positioning
CAUTION
Whenever the leg section is in the down
position,itmayhitthetablebaseoroor
if the table down or reverse trendelenburg
functions are activated.
g. Flex Positioning
To place the table top in a ex position from
horizontal, press the FLEX button (Figure 18).
REFLEX
REFLEX
FLEX
FLEX
REFLEX
FLEX
Figure 18. Flex / Reex Positioning
To return the table top to a horizontal position or
intoareexposition,presstheREFLEXbutton.
h. Return To Level
To return the table top to a level position, press
the LEVEL button. Elevation, and brake system
functions are not a󰀨ected by the level function
(Figure 19).
LEVEL
Figure 19. Return To Level
3-10. Emergency Brake Release
In case of a power failure or electrical problem
in the table, the table can be moved by manually
releasing the brakes with the emergency brake
release.
The control knob (valve) is located located on
the end of the base opposite the power cord, and
identiedbyanEMERGENCYBRAKERELEASE
label. Turn the knob counterclockwise to release
the brakes (Figure 20).
EMERGENCY BRAKE RELEASE
Figure 20. Emergency Brake Release
