Skytron AURORA ASTRO User manual

OWNER'S MANUAL
(Includes Operation, Maintenance, and Parts)
Read this manual before operating this light! This information is necessary for the safe
and efcient operation of the equipment.
AURORA ASTRO SURGICAL LIGHTS
TEC-B-0210 REV3
06/19/2019

Distributed by:
US - SKYTRON
5085 Corporate Exchange Blvd. S.E.
Grand Rapids, MI 49512 [phone]
www.skytron.us
Manufactured by:
DKK Dai-lchi Shomei Co., LTD
32-26 Sakashita 1-Chome
Itabashi-Ku, Tokyo 174-0043
JAPAN
SKYTRON EUROPE BV
Floresstraat 52
8022 AD Zwolle
THE NETHERLANDS
The base language for this document is ENGLISH. Any translations must be from the base language document.
Printed copies are not controlled documents.
Although current at the time of publication, SKYTRON'S policy of continuous development makes this manual subject to
change without notice. If current manuals are required, contact your local SKYTRON representative or contact SKYTRON
directly at the distribution addresses listed above.
Lights manufactured 1-1-2019 and after do not bear the CE mark and do not conform to the CE standard.

Page 1
AURORA ASTRO OWNER'S MANUAL• REV3
TABLE OF CONTENTS
TITLE PAGE
SECTION 1. SAFETY INFORMATION ........................................................................................ 3
1-1. Special User Attention........................................................................................................ 3
1-2. Safety Precautions ............................................................................................................. 3
SECTION 2. EQUIPMENT SPECIFICATIONS ............................................................................ 6
2-1. Intended Use...................................................................................................................... 6
2-2. Installation.......................................................................................................................... 6
2-3. Environmental Conditions .................................................................................................. 6
2-4. Fail Safe Compliance ......................................................................................................... 6
2-5. Certication ....................................................................................................................... 6
2-6. EquipmentLabelsandSpecications ................................................................................ 7
2-7. Label Symbols.................................................................................................................... 8
2-8. ModelIdentication ............................................................................................................ 8
SECTION 3. INFORMATION FOR SERVICE PERSONNEL....................................................... 9
SECTION 4. DOCUMENTATION REQUIREMENTS AND INFORMATION ............................... 10
SECTION 5. FUNCTIONAL CHECK AND OPERATOR INSTRUCTION.................................... 11
SECTION 6. CEILING MOUNTED LIGHTS ............................................................................... 12
6-1. Introduction ....................................................................................................................... 12
6-2. Electrical Requirements .................................................................................................... 13
6-3. Visual Checks Prior to Start-Up ........................................................................................ 13
6-4. Operating the Light ........................................................................................................... 14
6-5. Shutdown Procedure......................................................................................................... 16
SECTION 7. PORTABLE STAND LIGHT (AUA3S) .................................................................... 17
7-1. Introduction ....................................................................................................................... 17
7-2. Power Requirements......................................................................................................... 18
7-3. Prior to Operation.............................................................................................................. 18
7-4. Operation .......................................................................................................................... 20
7-5. Shutdown .......................................................................................................................... 21

Page 2
AURORA ASTRO OWNER'S MANUAL • REV3
TABLE OF CONTENTS
TITLE PAGE
SECTION 8. MAINTENANCE..................................................................................................... 22
8-1. Cleaning and Disinfecting ................................................................................................. 22
8-2. Sterilization........................................................................................................................ 23
8-3. Ultraviolet (UV) Radiation.................................................................................................. 23
8-4. Operator Maintenance ...................................................................................................... 23
8-5. Troubleshooting ................................................................................................................ 25
8-6. Maintenance Procedures .................................................................................................. 26
8-7. Routine Inspections........................................................................................................... 26
8-8. Preventive Maintenance.................................................................................................... 26
8-9. End of Useful Life and Disposal ....................................................................................... 27
8-10. Environmental Protection.................................................................................................. 27
SECTION 9. OPTIONAL ACCESSORIES .................................................................................. 28
SECTION 10. OPTICAL CHARACTERISTICS............................................................................. 28
SECTION 11. ELECTROMAGNETIC EMISSIONS ...................................................................... 29
SECTION 13. REPLACEMENT PARTS........................................................................................ 33
11-1. Light Fixture Components................................................................................................. 34
11-2. Portable Stand Light.......................................................................................................... 35
SECTION 12. REVISION HISTORY ............................................................................................. 36

Page 3
AURORA ASTRO OWNER'S MANUAL• REV3
1-1. Special User Attention
Initial use should not begin until after the users
have been instructed by the manufacturer's
authorized representative. Prior to use, all
personnel that will operate the surgical light must
be instructed in its proper operation by a clinical
in-service protocol administered by a Skytron
representative.
A routine program should be implemented by
the facility for proper usage instructions for all
personnel that may operate the surgical light.
When operating the surgical light, all hospital
personnel should be aware that sensible care
must be taken to maintain patient safety and
keep the surgical light functioning at peak
efciency.
1-2. Safety Precautions
The following is a summary of WARNINGS and
CAUTIONS indicated in this manual. These
precautions are found throughout the manual
where they are applicable. Carefully read the
manual before proceeding to operate or service
the equipment.
WARNING
WARNING with a safety alert symbol
indicates a hazardous situation that,
if not avoided, could result in death or
serious injury.
Prior to initial operation of the light,
electrical supply must be inspected and
approvedbyaqualiedelectrician.
To avoid patient or user injury, do not
modify this device.
Equipment is not suitable for use in the
presence of a FLAMMABLE ANESTHETIC
MIXTURE with OXYGEN or NITROUS
OXIDE.
To ensure patient safety, DO NOT connect
an additional multiple-socket outlet or
extension cord to the system.
To avoid the risk of electric shock, this
equipment must only be connected to a
supply mains with protective earth ground.
Also, if the room has equipment that
allows potential equipotential conductor to
be used, always utilize the equalization.
Protective earth ground and equalization
shall meet the requirements of local,
State, and National rules, standards, and
guidelines, when applicable.
To avoid personal injury, DO NOT attempt
to clean lighthead unless power is turned
off. Power can be turned off at the facility
breaker or the power cord disconnected for
portable stand light.
This equipment/system is intended for
use by healthcare professionals only. As
with all electrical medical equipment, this
equipment may cause radio interference
or may disrupt the operation of nearby
equipment. It may be necessary to take
mitigation measures such as re-orienting or
relocating the Aurora Astro AUA3 Surgical
Light or shielding the location. If an RF
communication device needs to be used
duringtheuseofthexture,thedistance
fromthexturemustbekeptatgreaterthan
0.3 m to prevent malfunction.
California Proposition 65 Warning:
This product may contain a chemical
known to the State of California to cause
cancer, birth defects, or reproductive
harm.
CAUTION
CAUTION with the safety alert symbol
indicates a hazardous situation that, if
not avoided, could result in minor or
moderate injury.
Always inspect product prior to use to
ensure safe and correct operation. Any
product deemed to be malfunctioning
should be removed from service and
labeled inoperable. Refer all service to a
qualiedSKYTRONservicerepresentative.
To avoid equipment damage and personal
injury, use extreme care to avoid collisions
with personnel and/or equipment. Damage
could result to the surgical lights, causing
debristofallintothesurgicaleld.
SECTION 1. SAFETY INFORMATION

Page 4
AURORA ASTRO OWNER'S MANUAL • REV3
CAUTION
CAUTION without the safety alert
symbol is used to address practices
not related to personal injury but with
a possibility of damage to equipment.
Sterilizable positioning handles are subject
to normal wear and tear. Always examine
the handles for wear or damage to ensure
proper and safe operation with the surgical
light.
Avoid pulling or attempting to move the
stand light by the positioning handle. The
xturemaybecomeunstableanddamage
may occur.
Exercise caution when moving the stand
light to avoid obstacles such as power
cords or other items in the pathway. DO
NOT transport over rugged or unstable
ooringthatmaydamagethecasters.
Improper use, transport procedures, or
storage of the stand light may result in
damage to the support post or balance
mechanism. Check to be sure there is
no horizontal movement of the balance
mechanism within the support post before
each use.
DO NOT use the sterilizable positioning
handle on the lighthead to pull or push the
stand light base. These adjustments should
be done using the positioning handles on
the support post.
DO NOT use steam, extremely hot water
(over 150°F [65°C]), or high-pressure water
sprays to clean the equipment.
DO NOT pour or spray any cleaning agents
directly onto the lighthead.
The design of the Aurora Astro Series light
does not utilize internal user serviceable
parts. Service must be performed by
SKYTRON authorized service technicians
using SKYTRON authorized replacement
parts and service techniques.
To ensure patient safety, DO NOT touch
any component of the system and patient
simultaneously.
DO NOT look directly into the surgical light
orplacehighlyreectivesurfacesinthe
path of the light beam. There is a risk of
impaired vision.
Be sure the sterilizable handle is properly
secured before use. An improperly installed
handle could fall out, causing possible
injury to the patient or surgical staff.
Due to the high-output capability of the
lightheads, it may be required to decrease
the intensity to reduce the risk of excessive
heat in the surgical site when positioning
multiple lightheads together to form a
single spot.
Risk of hand of injury from pinch points.
To position the lighthead use integrated
handles or sterilizable positioning handle.
The AUA3S stand light is equipped with
locking casters. Make sure the casters
areunlockedpriortomovingthextureto
avoid the risk of damage or personal injury.
Risk of tipping! To avoid injuries or
equipment damage, DO NOT push with
excessive force, lean on, or rest against
the light.
DO NOT forcibly overcome a hurdle. If
needed,usearampandhavearmgrasp
on the support post handles to maintain
balance. A lack of balance would cause a
risk of falling.
Use of incompatible cleaning agents will
damagethexture.Avoidusingcleaning
solutions containing high concentrations of
alcohol, ethylene glycol, phenol, iodophors,
or glutaraldehyde based disinfectants.
Staining, pitting, discoloration, diffuser
cracking, or personal injury may occur if
these are used.
Avoiduseofthelightxtureifthediffuser
lens assembly or main housing are
physically damaged.

Page 5
AURORA ASTRO OWNER'S MANUAL• REV3
Any parts or assemblies not listed in this
section must be serviced or replaced by
SKYTRON authorized service personnel
only. This is necessary to avoid the
possibility of damage to the equipment.
NOTICE
Indicates important information not
related to personal injury.
The sterilizable positioning handle is
provided for light positioning by sterile
personnel. DO NOT allow contact with
non-sterile personnel.

Page 6
AURORA ASTRO OWNER'S MANUAL • REV3
SECTION 2. EQUIPMENT SPECIFICATIONS
2-5. Certication
LIGHT CERTIFIED BY ETL TO THESE
STANDARDS:
Medical electrical equipment – Part 1: General
requirements for basic safety and essential
performance – ANSI/AAMI ES60601-1: 2005/
C1: 2009/A2: 2010;
Medical electrical equipment – Part 1: General
requirements for basic safety and essential
performance – CAN/CSA-C22.2 No. 60601.1:
2008 COR 2 2011;
Medical electrical equipment – Part 2-41:
Particular requirements for the basic safety and
essential performance of surgical luminaires and
luminaires for diagnosis – IEC 60601-2-41 (2nd
Ed. 2009-08);
Medical electrical equipment – Part 1-6: General
requirements for basic safety and essential
performance – Collateral standard: Usability –
IEC 60601-1-6 (3rd Ed. 2010-01);
Medical electrical equipment – Part 1-2: General
requirements for basic safety and essential
performance – Collateral standard:
Electromagnetic compatibility – Requirements
and tests – IEC 60601-1-2 (3rd Ed. 2007-03).
2-1. Intended Use
SKYTRON Aurora Astro AUA3 series surgical
lights are intended to be used by medical
personnel to provide local surgical site
illumination to any part of the patient's body.
The Aurora Astro AUA3 series surgical light is
suitable for all types of surgical procedures.
The clinical settings include, but are not limited
to: The Operating Room, Labor and Delivery,
Emergency Department, Trauma, Intensive
Care Unit, Minor Procedure Room, etc. This
is inclusive of all patients requiring surgical
intervention.
2-2. Installation
SKYTRON'sInstallationManualspeciesthe
unpacking, installation and testing of the Aurora
Astro AUA3 Light. Review the Installation
Manual prior to beginning the installation of the
light. Review local electrical codes, including
the Occupational Health and Safety Act, for
any requirements that pertain to the proper and
successful installation of this light.
2-3. Environmental Conditions
During
Transport and
Storage*
During Use (for
Dry Locations)
Ambient
Temperature
14° to 140° F
(-10° to 60°C)
60° to 85°F
(15° to 30°C)
Relative
Humidity
10% to 85% (no
condensation)
30% to 60% (no
condensation)
Atmospheric
Pressure
14 inHg to
31 inHg
(500 hPa to
1060 hPa)
20.7 inHg to
31.3 inHg
(700 hPa to
1060 hPa)
*In original packaging materials.
2-4. Fail Safe Compliance
In order for dual systems to maintain fail
safe compliance, a battery back-up (UPS)
or generator back-up power system must be
provided in the mains wiring prior to the power
supplyboxwhichwillrestorepowerinve(5)
seconds or less (not SKYTRON supplied).

Page 7
AURORA ASTRO OWNER'S MANUAL• REV3
2-6. Equipment Labels and Specications
The lighthead data labels contain the lighthead
model number, LED Source, electrical
specications,andproductserialnumber.
AUA3PS (SINGLE LIGHTHEAD) AND
AUA33PS (DUAL LIGHTHEAD) POWER
SUPPLY LABELS
(21)YYYY-MM-XXXX
24V DC 32 VA
B7-010-01
(21)YYYY-MM-XXXX
24V DC 1.4A
AUA3PS
38VA-51VA
1A T1AH, 250V
(21)YYYY-MM-XXXX
24V DC 2.8A
AUA33PS
77VA-102VA
1A x 2 T1AH, 250V
(21)YYYY-MM-XXXX
38VA-51VA
24V DC 1.4A
1A x 2 T1AH, 250V
AUA3 (LIGHTHEAD) AND
AUA3S (STAND) LABELS
(21)YYYY-MM-XXXX
24V DC 32 VA
B7-010-01
(21)YYYY-MM-XXXX
24V DC 1.4A
AUA3PS
38VA-50VA
1A T1AH, 250V
(21)YYYY-MM-XXXX
24V DC 2.8A
AUA33PS
77VA-102VA
1A x 2 T1AH, 250V
(21)YYYY-MM-XXXX
38VA-51VA
24V DC 1.4A
1A x 2 T1AH, 250V
STAND CONTROL
INDICATES DANGEROUS VOLTAGE
100Ｖ～240V, 50/60Hz
INDIQUE UN NIVEAU DE TENSION
DANGEREUX, 100 V, 240 V, 50/60Hz
CAUTION: CONSULT MANUAL
FOR FURTHER INSTRUCTIONS
AVERTISSEMENT:
CONSULTER LE MANUAL POUR
DE PLUS AMPLES INFORMATIONS
SUPPORT POST
T1AH 250V
Afin de prévenir les blessures
ou les dommages matériels,
respectez les exigences en matière
de transport qui se trouvent
dans le manuel du propriétaire.
To avoid injuries or equipment
damage, observe proper
transportation requirements
in owner’s manual.
ATTENTION
CAUTION
AVERTISSEMENT - Pour une protection continue
contre les risques d'incendier, replacer seulement
avec un fusible de valeur nominale identique.
WARNING - FOR CONTINUED PROTECTION
AGAINST RISK OF FIRE, REPLACE ONLY
WITH SAME TYPE AND RATING OF FUSE.
Lights manufactured 1-1-2019 and after do not
bear the CE mark and do not conform to the
CE standard.

Page 8
AURORA ASTRO OWNER'S MANUAL • REV3
2-7. Label Symbols
Symbol Description
With the word WARNING, indicates a hazardous situation that, if not avoided,
could result in death of serious injury.
With the word CAUTION, indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Indicates waste disposal information.
Indicates consult instructions for use.
Indicates AC power supply.
Indicates authorized representative in the European Community.
Indicates Manufacturer.
Indicates Dangerous Voltage 100-240V ~, 50/60Hz.
Risk of tipping! To avoid injuries or equipment damage, DO NOT push with
excessive force, lean on, or rest against the light.
Equipotentiality: Indicates potential equalization terminal.
2-8. Model Identication
Conguration Model Description
Portable Stand AUA3S
Surgical lighting system consisting of one (1) 17.5" [444.5 mm] Aurora Astro
AUA3 center focus lighthead mounted on a portable stand with locking
casters.
Single Arm AUA3
Ceiling-mounted radial support arm for one (1) 17.5" [444.5 mm] diameter
AuroraAstroAUA3lighthead.Thismodelcanbeconguredwithextended
arm,extendedhub,hybrid,single(LFS)anddual(LFSLFS)lightatscreen
arms, or boom options.
Dual Arm AUA33
Ceiling-mounted radial support arm for two (2) 17.5" [444.5 mm] diameter
AuroraAstroAUA3lightheads.Thismodelcanbeconguredwithextended
arm,extendedhub,single(LFS)anddual(LFSLFS)lightatscreenarms,or
boom options.
SECTION 3. INFORMATION FOR SERVICE PERSONNEL

Page 9
AURORA ASTRO OWNER'S MANUAL• REV3
Competency and installation
requirements
This product is a Class 2 medical device that must be compliant to
medical regulations 21CFR Part 820 (FDA) and a Class 1 medical
device that must be compliant to SOR/98-282 (Canada) and
MDD/93/42EEC(EU).Installationcanonlytakeplacebyqualiedand
trainedindividuals.AnInstallationQualicationReportisrequiredas
proof of system operational validation prior to clinical use. Contact
SKYTRON for installation needs.
Service in accordance with this
service manual
Servicing of the product must be performed according to the
instructions provided in this manual.
Use original Skytron parts only The safety, reliability, and performance of the equipment can only be
ensured if Skytron original replacement parts and accessories are
utilized.
Modications and unauthorized
repairs
Unauthorizedrepairs,temporaryrepairs,ormodicationsarenot
permissible and will void the product’s warranty. Always comply with
the requirements for current regulations and standards.
For additional information and to order spare parts and accessories,
please contact Skytron Service.
Telephone: [phone]
Technical support is available For questions related to repairs, settings, and disassembly, or to order
parts and accessories please contact us at:
Telephone: [phone]
Sales Telephone: [phone]
Service Telephone: [phone]
Visit us on the internet www.skytron.us
AUA33 Dual arm lighthead
system
AUA3 Single arm
lighthead system
AUA3S Portable stand
lighthead system

Page 10
AURORA ASTRO OWNER'S MANUAL • REV3
SECTION 4. DOCUMENTATION REQUIREMENTS AND INFORMATION
Please read this manual with care and attention to detail. Compliance with the safety information and
requirements for installation and servicing will ensure product performance, reliability, and longevity.
Regulatory classication Thisproductisclassiedbythefollowingregulatorybodiesas:
FDA: Class 2 Medical Device.
Canada SOR/98-282: Class 1 Medical Device.
Degree of protection provided
by the enclosure
IPX0
Degree of protection against
electric shock
Class I Medical Equipment. No applied parts.
Method of operation Continuous Operation.
Conformity The manufacturer declares that this product conforms to the requirements
according to:
LIGHT FIXTURE CERTIFIED BY ETL TO THESE STANDARDS:
• Medical electrical equipment – Part 1: General requirements for
basic safety and essential performance – ANSI/AAMI ES60601-1:
2005/C1: 2009/A2: 2010;
• Medical electrical equipment -– Part 1: General requirements for
basic safety and essential performance – CAN/CSA-C22.2 No.
60601.1: 2008 COR 2 2011;
• Medical electrical equipment – Part 2-41: Particular requirements
for the basic safety and essential performance of surgical luminaires
and luminaires for diagnosis – IEC 60601-2-41 (2nd Ed. 2009-08);
• Medical electrical equipment – Part 1-6: General requirements
for basic safety and essential performance – Collateral standard:
Usability – IEC 60601-1-6 (3rd Ed. 2010-01);
• Medical electrical equipment – Part 1-2: General requirements
for safety – Collateral standard: Electromagnetic compatibility –
Requirements and tests – IEC 60601-1-2 (4th Ed. 2014-02).
Copyright and labeling All information contained in this service manual are the intellectual property
of Skytron and are protected by national and international laws for the
protection of intellectual property. Duplication, reproduction, translation,
microlmingstorage–ineitherelectronicormagneticform–processingas
electronically or magnetically stored data, copying or distribution of these
documents and the Information contained herein or parts thereof without the
prior written approval of Skytron LLC is prohibited. Printed copies are not
controlled documents.
Right to make changes Although current at the time of publication, Skytron’s policy of continuous
development makes this manual subject to change without notice. For
current manuals, please contact your local Skytron representative or contact
Skytron directly at the distribution addresses listed.
Translations and base
language
The base language for this document is ENGLISH. Any translations must be
from the base language document.
Accompanying and related
documents
OnlyqualiedpersonneltrainedandauthorizedbySkytronmayinstalland
commission the product. For installation instructions and wiring diagrams
please refer to the Aurora Astro AUA3 Installation Manual.
Interference Care must be taken when operating this equipment around other equipment
to avoid reciprocal interference.
Contraindications There are no known contraindications.

Page 11
AURORA ASTRO OWNER'S MANUAL• REV3
SECTION 5. FUNCTIONAL CHECK AND OPERATOR INSTRUCTION
WARNING
Prior to initial operation of the lighting
system, electrical supply must be
inspected and approved by a qualied
electrician.
A functional check must be performed after
completing installation and prior to placing
into use.
• The Skytron light must be tested and
commissioned prior to clinical use.
• Testing and commissioning is a documented
process provided by an authorized Skytron
representativeandincludeswrittenconrmation
by the customer.
• Upon completion of testing and commissioning
approval and prior to use, all users must be
instructed on the function, adjustment, care,
and cleaning of the light.
5-8-1. Operator Inspections
Personnel operating the light are responsible for
the thorough inspection of the equipment prior
to and after each use. Should any problems or
decienciesarise,theresultsmustbereported
to the facilities maintenance personnel. The
safety of personnel and patients relies on
the proper and routine maintenance of this
equipment. User-performed inspections prior
to and after each use should observe for the
following conditions or problems and report to
the SKYTRON authorized representative:
• Missing warning or usage labels
• Excessive wear, gouges, damaged handles,
missing covers, and other physical problems
• Drifting out of position
• Difcultyduringroutinepositioningrequiring
excessive push/pull force
• Missing or loose screws and fasteners
• Electrical burns
• Evidence of high temperature traces, indicating
a possible concentration of heat
• Accumulation of lint
• Evidenceofingressofuid

Page 12
AURORA ASTRO OWNER'S MANUAL • REV3
SECTION 6. CEILING MOUNTED LIGHTS
6-1. Introduction
Aurora Astro AUA3 lights consist of several
modules containing LEDs (light emitting diodes)
andopticalcolorcorrectivereectors.Thelight
features four (4) levels of intensity and OFF.
LEDs offer low heat radiation and increased
illumination longevity.
Light models are available with one (1) or two
(2) lightheads providing high illumination of the
operatingeldatvaryingangles.Combinations
of vertical positioning and multiple rotational
capabilities allow the single- or dual-lighthead
modelstobeconguredintohighlyversatile
arrangements.
Standardxturesaresingle-pointceiling
mountedwithaninnitelycontinuous360°
rotation capability at the ceiling-mount end of
the radial support arm (Figure 1). The balance
mechanism, which is attached to the radial arm
by a vertical support tube, provides the lighthead
anadditionalinnitelycontinuous360°rotation
point. The balance mechanism is an enclosed
spring tension system. This allows vertical
movement of the lighthead while maintaining
the lighthead position without drifting. All Aurora
AstroAUA3ceiling-mountedlightxtureshavea
lighthead vertical travel capability of 110°.
Figure 1. Light Fixture Rotation Capabilities – Two Light Conguration (AUA33) Shown
Aurora Astro AUA3 lightheads have a removable steriliziable positioning handle with an integrated
intensityleveladjustmentcontrol.Thisallowsallnaladjustmentsorchangestobepreciselycontrolled
bythesurgeonfromthesterileeld.
360° Rotation
360°
Rotation
360°
Rotation
110° Vertical
Travel
110° Vertical
Travel
360° Pitch360° Pitch
Ceiling cover
Vertical
support
tube
Balance
mechanism Lighthead
Radial arm
Sterilizable
postioning
handle

Page 13
AURORA ASTRO OWNER'S MANUAL• REV3
6-2. Electrical Requirements
SKYTRON Aurora Astro AUA3 Series Surgical
Lights require that electrical connections are
made by a licensed electrician in accordance
with local, State, and National electrical codes
using UL (Underwriters Laboratory) recognized
materials.
6-3. Visual Checks Prior to Start-Up
CAUTION
Always inspect product prior to use to
ensure safe and correct operation. Any
product deemed to be malfunctioning
should be removed from service and
labeled inoperable. Refer all service
to a qualied SKYTRON service
representative.
• Check light emission from each lighthead.
• Check for cracked, damaged, or broken lens.
Avoid use if such damage is evident.
• Check operation of the intensity control on the
side of the lighthead.
• Check mechanical movements by rotating and
articulating each joint. Ensure proper operation
and emittance of light throughout the range of
movement.

Page 14
AURORA ASTRO OWNER'S MANUAL • REV3
6-4. Operating the Light
The light operating instructions for ceiling-
mounted and stand mounted lights is identical,
unless otherwise indicated.
WARNING
Equipment is not suitable for use
in the presence of a FLAMMABLE
ANESTHETIC MIXTURE with OXYGEN
or NITROUS OXIDE.
CAUTION
To avoid equipment damage and
personal injury, use extreme care to
avoid collisions with personnel and/or
equipment. Damage could result to the
surgical lights, causing broken parts to
fall into the surgical area.
6-4-1. Install Sterilizable Positioning
Handles.
1. Install the sterilized positioning handle.
Insert the handle into the lighthead
attachment ring, then push, twist, and
pull it until a click is heard.
A
Figure 2. Sterilizable Positioning Handle –
Push...
C
B
Figure 3. ... Twist, then pull to lock in place.
NOTICE
The sterilizable positioning handle is
provided for light positioning by sterile
personnel. DO NOT allow contact with
non-sterile personnel.
CAUTION
Be sure the sterilizable handle is
properly secured before use. An
improperly installed handle could fall
out, causing possible injury to the
patient or surgical staff.
Sterilizable positioning handles are removable
for easy cleaning/sterilization.
• To remove the handle: (A) Push the
release button and (B) pull the handle out.
B
A
Figure 4. Push release button (A) to remove.
CAUTION
Sterilizable positioning handles are
subject to normal wear and tear.
Always examine the handles for wear
or damage to ensure proper and safe
operation with the surgical light.

Page 15
AURORA ASTRO OWNER'S MANUAL• REV3
2. Position the lightheads as needed.
Grasp the positioning handles
to do so (Figure 5).
CAUTION
To ensure patient safety, DO NOT touch
any component of the system and
patient simultaneously.
CAUTION
Risk of hand of injury from pinch points.
To position the lighthead use integrated
handles or sterilizable positioning
handle.
CAUTION
DO NOT look directly into the surgical
light or place highly reective surfaces
in the path of the light beam. There is a
risk of impaired vision.
Lighthead intensity
control button on
positioning handle
OFFON (Max Level)
6-4-2. Lighthead Intensity Controls
Use the Intensity/On/Off push button on the side
of the lighthead or at the center of the sterilizable
positioning handle to turn on and cycle the light
xturetothedesiredintensity.Thelightheadhas
4 intensity settings and OFF.
FromOFF,therstpressofthebuttonwillturn
onthelightxtureatthemaximumintensity
setting. Each press of the button will decrease
the intensity one level. Press the side button
again at the lowest setting the light to turn the
light off. If using the button at the center of the
positioning handle, press and hold for about 5
seconds to turn the light off.
Figure 5. Use sterilizable positioning handle
to position lighthead

Page 16
AURORA ASTRO OWNER'S MANUAL • REV3
6-5. Shutdown Procedure
When the light is no longer required, perform
the following steps:
1. Turn off the light at the intensity control
switch on the side of the lighthead until
the light tuns off, or by pressing and
holding the button in the center of the
positoning handle for 5 seconds.
OFFON (Max Level)
2. Return the lighthead to its fully
raised position.
3. Remove the sterilizable handle
from the lighthead.
B
A
NOTICE
SKYTRON products are guaranteed
for proper performance with the use
of genuine SKYTRON sterilizable
positioning handles and other
disposables. After-market competitive
handles, covers, and other disposables
will have varying results that could
ultimately affect the proper performance
and secure engagement of the handle,
cover, or disposable. Such applications
are at the discretion of the user to
ensure patient safety.

Page 17
AURORA ASTRO OWNER'S MANUAL• REV3
SECTION 7. PORTABLE STAND LIGHT (AUA3S)
7-1. Introduction
The Model AUS3S Portable Stand Light consists
of a single Aurora Astro Series lighthead
mounted on a portable stand. The lighthead
has the same rotational positioning and focus
capabilities as the ceiling-mounted light which
includes continuous 360°rotation at the pitch
and roll axis points. Ninety degrees vertical
travel is provided at the support post. Cord wrap
hooks and positioning handles are also located
on the support post.
Figure 7. Portable Stand Light Features
Cord wrap
hooks (2)
Transport/
postioning
handles
Sterilizable/
postioning
handle
Balance mechanism
Lighthead
Base
Support
post

Page 18
AURORA ASTRO OWNER'S MANUAL • REV3
The base contains the power cord, safety fuses,
main switch and equipotential terminal.
Figure 8. Portable Stand Base
The lighthead also has a removable sterilizable
positioning handle (Figure 9). This handle allows
lighthead positioning. The lighthead intensity
controls (Figure 9) on the side of the lighthead
allow brightness adjustment and turn the light
onoroff.Thisallowsallnaladjustments
or changes to be precisely controlled by the
surgeon.
OFFON (Max Level)
Figure 9. Lighthead intensity controls
7-2. Power Requirements
The Aurora Astro portable stand-mounted light
requires a properly grounded 100-240VAC,
50/60Hz electrical power supply. The stand is
equipped with a 13 foot (4 m) long, 16-3 SJT
power cord with a hospital grade plug. The
power cord is located at the rear of the base in
the center. The main power ON/OFF switch is
located on the back of the base.
7-3. Prior to Operation
CAUTION
Always inspect product prior to use to
ensure safe and correct operation. Any
product deemed to be malfunctioning
should be removed from service and
labeled inoperable. Refer all service
to a qualied SKYTRON service
representative.
7-3-1. Visual Checks
Prior to start-up, perform a visual inspection of
the following:
• Check light emission from lighthead.
• Check for cracks, damaged, or broken lens.
Avoid use if damage is evident.
• Check the operation of the intensity control on
the side of the lighthead.
• Check mechanical movements by rotating and
articulating each joint. Ensure proper operation
and emittance of light throughout the range of
movement.
• Check the sterilizable handle by installing and
detaching.
Power
cord Main
switch
Equipotentiality terminal
Safety
fuses
Lighthead
intensity
control
button on
positioning
handle
