Instruction Manual
Electric Actuator / Slider type
Series LEKFS**G
Motor: Step motor (servo 24 VDC)
High Performance Battery-less absolute encoder
The intended use of this Electrical Actuator is to convert an electrical
input signal into mechanical motion.
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition
to International Standards (ISO/IEC)*1), and other safety regulations.
*1) ISO 4414: Pneumatic fluid power - General rules relating to systems.
ISO 4413: Hydraulic fluid power - General rules relating to systems.
IEC 60204-1: Safety of machinery - Electrical equipment of machines.
(Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety. etc.
•Refer to the product catalogue, Operation Manual and Handling
Precautions for SMC Products for additional information.
•Keep this manual in a safe place for future reference.
Caution
Caution indicates a hazard with a low level of risk which, if
not avoided, could result in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if
not avoided, will result in death or serious injury.
Warning
•Always ensure compliance with relevant safety laws and standards.
All work must be carried out in a safe manner by a qualified person in
compliance with applicable national regulations.
•Special products (-X#, -D#) might have specifications different from
those shown in the specifications section. Contact SMC for specific
drawings.
2 Specifications
LEKFS25 series
Model
LEKFS25
Actuator specification
Stroke [mm]
50 to 800
Max. work load
[kg]Note 2)
Horizontal
15
28
40
Vertical
3
7.5
15
Speed
[mm/s]
Up to 400 stroke
20 to 1500
12 to 750
6 to 500
401 to 500
20 to 1100
12 to 750
6 to 400
501 to 600
20 to 900
12 to 540
6 to 270
601 to 700
20 to 630
12 to 420
6 to 230
701 to 800
20 to 550
12 to 330
6 to 180
Max. acceleration / deceleration
[mm/s2]
10000
5000
Positioning repeatability [mm]
±0.01 (lead H: ±0.02)
Lost motion [mm] Note 3)
0.05 or less
Screw Lead [mm]
20
12
6
Impact/Vibration resistance [m/s
2
]
Note 4)
50 / 20
Actuation method
Ball screw (LEKFS*)
Ball screw + Belt (LEKFS*R/L)
Guide type
Linear guide
Operating temperature [℃]
5 to 40
Operating humidity [%RH]
90 or less (no condensation)
Electrical
Motor size [mm]
□42
Motor type
Battery-less absolute
(Step motor 24 VDC)
Encoder
Battery-less absolute
Rated Voltage [V]
24 VDC ±10%
Max. Power consumption [W] Note 5) 7)
126
Lock
Lock TypeNote 6)
Non magnetizing lock
Holding force [N]
47
78
157
Power consumption [W] Note 7)
5
Rated voltage [V]
24 VDC ±10%
LEKFS32 series
Model
LEKFS32
Actuator specification
Stroke [mm]
50 to 1000
Max. work load
[kg]Note 2)
Horizontal
40
50
68
Vertical
4
10
18
Speed [mm/s]
Up to 400 stroke
24 to 1300
16 to 1000
8 to 500
401 to 500
24 to 1300
16 to 950
8 to 500
501 to 600
24 to 1200
16 to 800
8 to 400
601 to 700
24 to 930
16 to 620
8 to 310
701 to 800
24 to 750
16 to 500
8 to 250
801 to 900
24 to 610
16 to 410
8 to 200
901 to 1000
24 to 500
16 to 340
8 to 170
Max. acceleration / deceleration
[mm/s2]
10000
5000
Positioning repeatability [mm]
±0.01 (lead H: ±0.02)
Lost motion [mm] Note 3)
0.05 or less
Screw Lead [mm]
24
16
8
Impact/Vibration resistance [m/s
2
]
Note 4)
50 / 20
Actuation method
Ball screw (LEKFS*)
Ball screw + Belt (LEKFS*R/L)
Guide type
Linear guide
Operating temperature [℃]
5 to 40
Operating humidity [%RH]
90 or less (no condensation)
Electrical
Motor size [mm]
□56.4
Motor type
Battery-less absolute
(Step motor 24 VDC)
Encoder
Battery-less absolute
Rated Voltage [V]
24 VDC ±10%
Max. Power consumption [W] Note 5) 7)
222
Lock
Lock TypeNote 6)
Non magnetizing lock
Holding force [N]
72
118
216
Power consumption [W] Note 7)
5
Rated voltage [V]
24 VDC ±10%
2 Specifications (continued)
LEKFS40 series
Model
LEKFS40
Actuator specification
Stroke [mm]
150 to 1200
Max. work load
[kg]Note 2)
Horizontal
26
60
75
Vertical
4.5
4.5
25
Speed [mm/s]
Up to 400 stroke
30 to 1200
20 to 1000
10 to 500
401 to 500
30 to 1200
20 to 1000
10 to 500
501 to 600
30 to 1200
20 to 1000
10 to 500
601 to 700
30 to 1200
20 to 900
10 to 440
701 to 800
30 to 1140
20 to 760
10 to 350
801 to 900
30 to 930
20 to 620
10 to 280
901 to 1000
30 to 780
20 to 520
10 to 250
1001 to 1100
30 to 660
20 to 440
10 to 220
1101 to 1200
30 to 570
20 to 380
10 to 190
Max. acceleration / deceleration
[mm/s2]
10000
5000
Positioning repeatability [mm]
±0.01 (lead H: ±0.02)
Lost motion [mm] Note 3)
0.05 or less
Screw Lead [mm]
30
20
10
Impact/Vibration resistance [m/s
2
]
Note 4)
50 / 20
Actuation method
Ball screw (LEKFS*)
Ball screw + Belt (LEKFS*R/L)
Guide type
Linear guide
Operating temperature [℃]
5 to 40
Operating humidity [%RH]
90 or less (no condensation)
LEKFS40 series(continued))
Electrical
Motor size [mm]
□56.4
Motor type
Battery-less absolute
(Step motor 24 VDC)
Encoder
Battery-less absolute
Rated Voltage [V]
24 VDC ±10%
Max. Power consumption [W] Note 5) 7)
222
Lock
Lock TypeNote 6)
Non magnetizing lock
Holding force [N]
75
113
245
Power consumption [W] Note 7)
5
Rated voltage [V]
24 VDC ±10%
Note 1) Consult with SMC for non-standard strokes as they are produced as
special orders.
Note 2) The maximum workload at 3000 m/s2.
Speed varies according to the work load. Check the “Speed–Work Load
Graph" as a Guide in the catalogue on the SMC website
(URL: https://www.smcworld.com).
Furthermore, if the cable length exceeds 5 m, then the speed and work
load may decrease by up to 10% for each additional 5 m.
Note 3) A reference value for correcting an error in reciprocal operation.
Note 4) Impact resistance: No malfunction occurred when the actuator was tested
with a drop tester in both an axial and a perpendicular direction to the lead
screw. The test was performed with the actuator in the initialized state.
Vibration resistance: No malfunction occurred in a test ranging between
45 to 2000 Hz. The test was performed in both an axial and a perpendicular
direction to the lead screw. The test was performed with the actuator in the
initialized state.
Note 5) The power consumption including the controller is for when the actuator is
operating.
Note 6) For models with lock only.
Note 7) For an actuator with lock, add the power consumption for the lock.
2 Specifications (continued)
2.1 Product weight
Series
LEKFS25
Stroke [mm]
50
100
150
200
250
300
350
400
Product weight [kg]
1.7
1.8
1.9
2.1
2.3
2.4
2.5
2.6
Lock weight [kg]
0.26
Series
LEKFS25
Stroke [mm]
450
500
600
700
800
Product weight [kg]
2.8
2.9
3.2
3.5
3.8
Lock weight [kg]
0.26
Series
LEKFS32
Stroke [mm]
50
100
150
200
250
300
350
400
Product weight [kg]
3.6
3.8
4.0
4.2
4.5
4.7
4.9
5.1
Lock weight [kg]
0.53
Series
LEKFS32
Stroke [mm]
450
500
600
700
800
900
1000
Product weight [kg]
5.3
5.5
5.9
6.3
6.7
7.1
7.5
Lock weight [kg]
0.53
Series
LEKFS40
Stroke [mm]
150
200
250
300
350
400
450
500
Product weight [kg]
5.5
5.8
6.1
6.4
6.7
7
7.3
7.6
Lock weight [kg]
0.53
Series
LEKFS40
Stroke [mm]
600
700
800
900
1000
1100
1200
Product weight [kg]
8.2
8.8
9.4
10
10.6
11.2
11.8
Lock weight [kg]
0.53
3 Installation
3.1 Installation Warning
•Do not install the product unless the safety instructions have been read
and understood.
•Do not use the product in excess of its allowable specification.
•When installing, inspecting or performing maintenance on the product,
be sure to turn off the power supplies. Then, lock it so it cannot be
tampered with while work is happening.
•Keep the flatness of the mounting surface to within 0.1 mm maximum.
Insufficient flatness of a work piece or actuator mounting surface can
cause play in the guide and increased sliding resistance. In the case
of overhang mounting (including cantilever), use a support plate or
support guide to avoid deflection of the actuator body.
•When mounting the actuator, use all mounting holes.
If all mounting holes are not used, this will not maintain the specified
performance. e.g. the amount of displacement of thetable will increase.
•When mounting the actuator leave a gap of 40 mm or more to allow
for bending of the actuator cable.
•When mounting the actuator or workpiece, use screws with adequate
length and tighten them with adequate torque.
Tightening the screws with a torque higher than recommended may
cause malfunction, whilst tightening with a torque lower than
recommended can cause displacement of the mounting position, or
dropping of the work piece.
ORIGINAL INSTRUCTIONS

LEKF-TF2Z582EN-A
Page 2 of 3
3 Installation (continued)
Work piece Mounting
•In order to prevent the work piece fixing screws from damaging the
table, use screws at least 0.5 mm shorter than the maximum thread
depth. Longer screws can hit the body and cause operation failure.
Model
Screw size
Max. tightening
torque [N.m]
L Max. thread
depth [mm]
LEKFS25
M5 x 0.8
3.0
8
LEKFS32
M6 x 1.0
5.2
9
LEKFS40
M8 x 1.25
12.5
13
3.2 Environment Warning
•Do not use in an environment where corrosive gases, chemicals, salt
water or steam are present.
•Do not use in an explosive atmosphere.
•Do not expose to direct sunlight. Use a suitable protective cover.
•Do not install in a location subject to vibration or impact in excess of
the product’s specifications.
•Do not mount in a location exposed to radiant heat that would result in
temperatures in excess of the product’s specifications.
•Prevent foreign particles from entering the product.
3.3 Mounting Warning
•Observe the required tightening torque for screws.
Unless stated otherwise, tighten the screws to the recommended
torque for mounting the product.
•Do not make any alterations to the product.
Alterations made to this product may lead to a loss of durability and
damage to the product, which can lead to injury and damage to other
equipment and machinery.
Do not scratch or dent the sliding parts of the table or mounting face
etc., by striking or holding them with other objects. The components
are manufactured to precise tolerances, so that even a slight
deformation may cause faulty operation or seizure.
•Do not use the product until it has been verified that the equipment can
be operated correctly.
After mounting or repair, connect the power supply to the product and
perform appropriate functional inspections to check it is mounted
correctly.
•Do not use the product until it has been verified that the equipment can
be operated correctly.
After mounting or repair, connect the power supply to the product and
perform appropriate functional inspections to check it is mounted
correctly.
3 Installation (continued)
3.4 Lubrication Caution
•SMC products have been lubricated for life at manufacture, and do not
require lubrication in service.
•If a lubricant is used in the system, refer to the catalogue for details.
•The recommended grease is lithium grade No.2
Apply for
Grease Pack order No.
Ball screw and Guide
GR-S-010(10g)
GR-S-020(20g)
4 Wiring
4.1 Wiring Warning
•Adjustment, mounting or wiring changes should not be carried out
before disconnecting the power supply to the product.
Electric shock, malfunction and damage can result.
•Do not disassemble the cables.
•Use only specified cables.
Use only specified cables otherwise there may be risk of fire and
damage.
•Do not connect or disconnect the wires, cables and connectors when
the power is turned on. Caution
•Wire the connector correctly and securely.
Check the connector for polarity and do not apply any voltage to the
terminals other than those specified in the Operation Manual.
•Take appropriate measures against noise.
Noise in a signal line may cause malfunction. As a countermeasure
separate the high voltage and low voltage cables, and shorten the
wiring lengths, etc.
•Do not route input/output wires and cables together with power or high
voltage cables.
The product can malfunction due to noise interference and surge
voltage from power and high voltage cables close to the signal line.
Route the wires of the product separately from power or high voltage
cables.
•Take care that actuator movement does not catch cables.
•Operate with all wires and cables secured.
•Avoid bending cables at sharp angles where they enter the product.
Avoid twisting, folding, rotating or applying an external force to the
cable. Risk of electric shock, wire breakage, contact failure and loss of
control of the product can result.
4 Wiring (continued)
•Select “Robotic cables”in applications where cables are moving
repeatedly (encoder/ motor/ lock).
•Confirm correct insulation.
Poor insulation of wires, cables, connectors, terminals etc. can cause
interference with other circuits. Also there is the possibility that
excessive voltage or current may be applied to the product causing
damage.
•Refer to the auto switch references in “Best Pneumatics“ when an auto
switch is to be used
4.2 Wiring of Actuator to Controller
4.3 Actuator Ground connection
•The Actuator must be connected to ground to shield the actuator from
electrical noise. The screw and cable with crimping terminal and
toothed washer should be prepared separately by the user.
•The ground wire cross sectional area should be 2 mm2minimum.
•Avoid shared grounding points with other devices.
5 How to Order
Refer to the catalogue on the SMC website
(URL: https://www.smcworld.com) for the How to Order information.
6 Outline Dimensions (mm)
Refer to the drawings / operation manual on the SMC website
(URL: https://www.smcworld.com) for outline dimensions.
7 Maintenance
7.1 General Maintenance Caution
•Not following proper maintenance procedures could cause the product
to malfunction and lead to equipment damage.
•If handled improperly electricity and compressed aircan be dangerous.
•Maintenance of electromechanical and pneumatic systems should be
performed only by qualified personnel.
•Before performing maintenance, turn off the power supply and besure
to cut off the supply pressure. Confirm that the power has been
discharged and the air is released to atmosphere.
•After installation and maintenance, apply operating pressure and
power to the equipment and perform appropriate functional and
leakage tests to make sure the equipment is installed correctly.
•If any electrical or pneumatic connections are disturbed during
maintenance, ensure they arereconnected correctly and safetychecks
are carried out as required to ensure continued compliance with
applicable national regulations.
•Do not make any modification to the product.
•Do not disassemble the product, unless required by installation or
maintenance instructions.
•Incorrect handling can cause an injury, damage or malfunction of the
equipment and machinery, so ensure that the procedure for the task is
followed.
7 Maintenance (continued)
•Always allow sufficient space around the product to complete any
maintenance and inspection.
7.2 Periodical Maintenance
•Maintenance should be performed according to the table below:
Frequency
Appearance
Check
Internal
check
Belt
Check
Before daily operation
✓
Every 6 months*
✓
✓
✓
Every 1,000 km*
✓
✓
✓
Every 5 million cycles*
✓
✓
✓
*whichever of these occurs first.
•Following any maintenance, always perform a system check. Do not
use the product if any error occurs, as safety cannot be assured if
caused by any un-intentional malfunction.
7.3 Appearance Check
•The following items should be visually monitored to ensure that the
actuator remains in goodcondition and there are no concerns flagged;
・Loose Screws,
・Abnormal level of dust or dirt,
・Visual flaws / faults,
・Cable connections,
・Abnormal noises or vibrations.
7.4 Belt Check
•If one of the 6 conditions below are seen, do not continue operating
the actuator, contact SMC immediately.
・Tooth shaped canvas is worn out.
Canvas fibre becomes “fuzzy”, rubber is removed, and the fibre gains
a white colour. The lines of fibre become very unclear.
・Peeling off or wearing of the side of the belt.
The corner of the belt becomes round and frayed, with threads
beginning to stick out.
・Belt is partially cut.
Belt is partially cut. Foreign matter could be caught in the teeth and
cause flaws.
・Vertical line of belt teeth.
Flaw which is made when the belt runs on the flange.
・Rubber back of the belt is softened and sticky.
・Crack on the back of the belt.
Electric Actuator / Slider type
JXC# Controller
Actuator cable
LE-CE-*
(no lock or sensor)
LE-CE-*-B
(with lock and sensor)
Model
Screw size
Max. tightening
torque [N.m]
A [mm]
L [mm]
LEKFS25
M4
1.5
4.5
24
LEKFS32
M5
3.0
5.5
30
LEKFS40
M6
5.2
6.6
31
Actuator Mounting

LEKF-TF2Z582EN-A
Page 3 of 3
8 Limitations of Use
8.1 Limited warranty and Disclaimer/Compliance Requirements
•Refer to Handling Precautions for SMC Products.
9 Product disposal
This product should not be disposed of as municipal waste. Check your
local regulations and guidelines to dispose of this product correctly, in
order to reduce the impact on human health and the environment.
10 Contacts
Refer to www.smcworld.com or www.smc.eu for your local distributor /
importer.
URL : http// www.smcworld.com (Global) http// www.smc.eu (Europe)
SMC Corporation, 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021, Japan
Specifications are subject to change without prior notice from the manufacturer.
© 2021 SMC Corporation All Rights Reserved.
Template DKP50047-F-085M
