SMC Networks CY3R Series User manual

ＯＰＥＲＡＴＩＯＮ ＭＡＮＵＡＬ
TITLE：Ｒｏｄｌｅｓｓ Ｃｙｌｉｎｄｅｒ
ＣＹ３Ｒ Ｓｅｒｉｅｓ
ＳＭＣ ＣＯＲＰＯＲＡＴＩＯＮ
○Ｒｅａｄ ｔｈｉｓ ｍａｎｕａｌ ｔｈｏｒｏｕｇｈｌｙ ｂｅｆｏｒｅ ｍｏｕｎｔｉｎｇ ａｎｄ
ｏｐｅｒａｔｉｏｎ．
○Ｅｓｐｅｃｉａｌｌｙ，ｃａｒｅｆｕｌｌｙ ｒｅａｄ ｔｈｅ ｄｅｓｃｒｉｐｔｉｏｎ ｃｏｎｃｅｒｎｉｎｇ
ｓａｆｅｔｙ．
○Ｋｅｅｐ ｔｈｉｓ ｍａｎｕａｌ ｗｈｅｒｅａｃｃｅｓｓｉｂｌｅ ｗｈｅｎ ｎｅｃｅｓｓａｒｙ．
FORMAT No.FOM007-2
No. CY*R-OM0001H- A 1/17
2022-12-2009:32
DC875714

2
ＩＮＤＥＸ
１．Installation to Application ３
２．Actuating Force and Moment １０
３．Vertical Operation １１
４．Immediate Stop １２
５．Operating Air and Piping １３
６．Disassembly and Maintenance １３
７．Other Cautions for Operation １４
８．Made to Order １４
９．Internal Construction and Parts List １５
2022-12-2009:32
DC875714

Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to International Standards
(ISO/IEC)*1) , and other safety regulations.
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems.
ISO 4413: Hydraulic fluid power -- General rules relating to systems.
IEC 60204-1: Safety of machinery -- Electrical equipment of machines .(Part 1: General requirements)
ISO 10218: Manipulating industrial robots -Safety.
etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment or
decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be
performed by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is confirmed.
1.The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2.When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is to
be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4.Use in an interlock circuit, which requires the provision of double interlock for possible failure by using a
mechanical protective function, and periodical checks to confirm proper operation.
付表 3A 3/5
-2-
2022-12-2009:32
DC875714

Safety Instructions
Caution
1. The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC
beforehand and exchange
specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1.The warranty period of the product is 1 year in service or 1.5 years after the product is
delivered,whichever is first.
∗
2)
Also, the product may have specified durability, running distance or replacement parts. Please
consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our responsibility,
a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
∗
2) Vacuum pads are excluded from this 1 year warranty.
A vacuum pad is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the vacuum
pad or failure due to the deterioration of rubber material are not covered by the limited
warranty.
Compliance Requirements
1.
The use of SMC products with production equipment for the manufacture of weapons of mass
destruction(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by the
relevant
security laws and regulation of the countries involved in the transaction. Prior to the
shipment of a SMC product to another country, assure that all local rules governing that export
are known and f
ollowed.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval tests
relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained
by the metrology
(measurement) laws of each country.
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange specifications
or a contract if necessary.
契約などを行ってください｡
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange specifications
or a contract if necessary.
契約などを行ってください｡
! Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval tests
relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.
付表 3A 4/5
-3-
2022-12-2009:32
DC875714

3
The rodless cylinder presented in this manual can operate the load directly mounted on it without other
axes in a range of allowable mounted load, moment and stroke if it is equipped with the switch rail.
(Table1,2) (P8,9) However, without the switch rail, the load needs to be guided by other axes (LM guide
etc.) to prevent rotation of external slider and direct application of the load over the allowable range.
1-1) Installation of cylinder body
Before installation of cylinder body, be sure to fix end covers by bolts (to realize support at both ends).
(Fig. 1)
Also, do not use the cylinder with fixed at external slider to avoid excessive moment applied to
bearing of the cylinder.
Wrong example Correct example
Fig. 1 Installation of cylinder body
1-2-1) Installation of cylinder body
There are two ways to install the cylinder body as shown on Fig. 2-1 and 2-2. For each mounting
face and place, tighten the bolt on the top and bottom faces properly to make no looseness.
Hexagon socket head bolt
Hexagon socket head bolt
Fig. 2-1 Tightening to top face Fig. 2-2 Tightening to bottom face
If tightening of the bolt creates the gap between end cover at each end and corresponding
Mounting face, insert spacer etc. to close the gap without excessive force given to these covers
and faces by the tightening.
１．
Installation to Application
Support at both ends
Support at one end
Cylinder tube External slider Cylinder tube External slider
2022-12-2009:32
DC875714

4
1-2) Installation of external slider and load
Same as installation of the cylinder body, there are two ways to install the external slider and load in
a range of allowable mounted load, moment and stroke.
(Ⅰ)With other axes combined
(Ⅱ)Without other axes combined
(Switch rail is used as non-rotation device.)
(Ⅰ)With other axes combined
Consider the following two points for mounting of external slider and load.
Ⅰ-a) The cylinder is deflected by self-weight as shown on Fig. 3-1. This means longer stroke produces
larger displacement of alignment.
Fig. 3-1 Deflection of rodless cylinder by self-weight
X
A
2022-12-2009:32
DC875714

5
Ⅰ-b) The misalignment between cylinder body and guide (orbit) may be caused depending on machining
accuracy of the space for mounting. Therefore, the installation must be performed to
compensate the misalignment. The following two show the example with or without concern
about misalignment respectively.
Wrong example Correct example
The work is directly applied to the cylinder as
excessive moment.
Fig. 4-1 [Ex.-1]
Wrong example Correct example
Detail of A
The load base is directly mounted on the cylinder
by bolt and deflection of the cylinder and
parallelism between the cylinder and guide can’ t
be adjusted.
Clearance
Detail of A’
Fig. 4-2 [Ex.-2]
Produced moment
is absorbed by
bearing.
Work
Work
M(Moment) M
A’
A
Mounting
bracket
Clearance
L0
Guide shaft
Bearing
External
slider
Cylinder
tube
Clearance
Cylinder
tube
External
slider
Guide
Direct mounting by bolt
LM Guide
Cylinder
(Load base)
Center of axis
of cylinder
Arm longer than center
of axis of cylinder
2022-12-2009:32
DC875714

6
Ａ Ｂ
Detail of A
Wrong example Correct example
Detail of A
Detail of B
By tightening of the bolt, the load base and
cylinder body are in the state similar to direct
connection.
Detail of B
Insert the spacer to keep flexibility in cylinder
body and load base even after the bolt is tightened.
＊The installation as shown on Fig. 4-1 and 4-2
are recommended, but if they are not available
due to mounted load, the installation like above
can be substituted. For this installation, check
relationship between actuating force and
moment on page 10 in prior.
Fig. 4-3 [Ex.-3]
Guide shaft
Bearing Load base
External slider Cylinder tube
External slider
Load base Load base
External
slider
Clearance
Spacer
2022-12-2009:32
DC875714

7
Wrong example Correct example
Since the cylinder is subject to direct moment of
load, guide shaft can work as only non-rotation
and operating failure may be caused.
Gap
The load is supported by guide shaft and the
clearance is provided to compensate misalignment.
The bracket is longer than center of axis of cylinder
to prevent moment applied to external slider.
Fig.4-4 [Ex.-4]
In wrong example shown of Fig. 4-2 [Ex.-2] (with external slider mounted directly on load base), the
misalignment between guide (orbit) and cylinder is not compensated and may induce operating failure. To
eliminate the misalignment and deflection of cylinder by self-weight, clearance is provided between
mounting bracket and cylinder as shown on correct example. Additionally, the mounting bracket should
be longer than center of axis of cylinder to minimize the moment applied to the external slider.
If the cylinder is mounted as shown on wrong example from Ex.1 to 4, external slider clamped is cylinder
tube strongly during operation and the wearing is worn so much as to cause operating failure.
As alternative solution for misalignment between cylinder and load, the rodless cylinder with specific
bracket (floating joint) is also by addition of -XC57 to suffix of part no. (Fig. 4-5) However, the floating joint
block obtained by –XC57 can’t be mounted to standard cylinder because –XC57 is adopting specific
external slider. Therefore, if –XC57 spec. is required for standard cylinder purchased independently, the
cylinder needs to be sent to SMC factory for repair with description of request “-XC57 spec.”
φ6,φ10,φ15 φ20,φ25,φ32,φ40,φ50,φ63
Fig. 4-5 [Ex.-5] (-XC57)
Clearance
Specific body
Floating block
Floating block
Specific body
Load Direct fix Guide shaft Load
Guide by linear guide
A
2022-12-2009:32
DC875714

8
The misalignment can be checked
by the following procedure.
1) After installation of cylinder to application,
increase pressure of regulator gradually
before checking operation of cylinder at
operating pressure, and then calculate
min. pressure which enables smooth
operation of cylinder over full stroke.
2) The min. operating pressure obtained
after mounting of load (actual min.
operating pressure) is different from
one of independent cylinder, but the
difference should be focused.
3) The actual min. operating pressure is
sum of “sliding resistance of cylinder”,
“force to operate load” and “sliding
resistance of guide”. (Fig. 5)
Fig. 5 (Reference)
This means when misalignment is not
compensated enough, sliding resistance
of guide increases excessively.
Additionally, sliding resistance of external
slider increases and causes wearing to
wear so much as to induce operating failure.
If the load is mounted directly on the cylinder without other axes, ensure that weight of the load,
（Ⅱ）Without other axes combined (Switch rail is used as non-rotation device.)
stroke and moment are within allowable value with reference to Table 1 and 2.
If any of them exceeds corresponding allowable value, add the axis (LM guide etc.) to the cylinder.
(Fig. 4-1 to 4-4)
Table 1 Max. load weight
Cylinder tube
Fig. 6-1 Load mounting direction
I.D. (mm)
Max. load
weight (kg)
φ6 0.2
φ
10
0.4
φ15 1.0
φ
20
1.1
φ25 1.2
φ32 1.5
φ
40
2.0
φ50 2.5
φ
63
3.0
Adjust to minimize this increase.
“
Sliding resistance of cylinder(P1)
”
Sum of “(P1)” and “force to operate load”
Operating pressure
(MPa)
0 0.1 0.2 0.3
Sliding resistance of guide
created by misalignment
Actual min. operating pressure
Thrust (N)
A
2022-12-2009:32
DC875714

9
Table 2 Non-rotation accuracy and max. allowable moment at stroke end (reference)
Note 1) Avoid usage where max. allowable moment is exceeded. In that case, use external guide
together.
Note 2) Above values can be kept within allowable stroke, but longer stroke may increase inclination
(rotation angle) on the way of stroke.
Note 3) The weight of the load allowable for direct mounting on the body is below max. load weight
shown on Table 1.
Note 4) For the specifications where non-rotation accuracy is critical, use LM guide etc. together.
Max. allowable
moment
(N
・
m)
φ6 7.3 0.02 100
φ
10
6.0 0.05 100
φ15 4.5 0.15 200
φ20 3.7 0.20 300
φ
25
3.7
0.25
300
φ32 3.1 0.40 400
φ
40
2.8 0.62 400
φ50 2.4 1.00 500
φ63 2.2 1.37 500
Note 2)
Allowable stroke
Non-rotation
accuracy
(°)
Cylinder tube
I.D. (mm)
Fig.6-2 Non-rotation accuracy direction
A
2022-12-2009:32
DC875714

10
２．Actuating force and moment
2-1) Actuating force
The actuating force of rodless cylinder is ideally equal to
thrust at center of axis of piston but normally, as shown on
Fig. 7-1, it is taken as FnN at the part away from the center
by Locm.
The relationship between Lo and Fn can be figured from Fig. 7-2.
Fig. 7-1 Actuating force
Fig. 7-2 Relationship between Lo and Fn
Sizing In each graph, find the point where 8 of X axis crosses
Ex) Sliding resistance of load：100N with 100 of Y axis. If the point is covered with applicable
Distance between center of axis operating range of the graph, the size making the graph
and point of application：8cm is applicable to exampled requirements. In this case,
CY3R32 or larger are applicable.
L0
Distance from center of axis of cylinder
Fn
Recommended actuating force
Load
A
2022-12-2009:32
DC875714

11
2-2) Moment at stroke end
If the rodless cylinder is used for the load
with large inertia, the following operating
failures may be caused at stroke end.
As shown on Fig. 8-1, such a large inertial
load tries to keep on linear motion on the
guide thought the cylinder body stops at
stroke end. This produces the moment
applied to the cylinder body.
Fig. 8-1 Moment produced at stroke end
If the cylinder is kept operating in such a
condition, the wearing of external slider is
worn so much as to cause operating failure.
To avoid occurrence of the failure, as shown
on Fig. 8-2, use both of shock absorber and
stopper at the mounting space for the load
to absorb kinetic energy of the load and
adopt the mounting bracket longer than
center of axis of cylinder to prevent the
moment applied to the cylinder body.
Fig. 8-2 Countermeasure for moment at stroke end
３．Vertical Operation
If the cylinder is operated in vertical direction,
consider the same points as section 2.
3-1) Allowable load
Vertical operation makes the load act to
holding force of magnet and allows the load
less than horizontal operation.
Table 3 shows the allowable load for each size.
Table 3 Allowable load for vertical operation
Cylinder
tube I.D.
(mm) Model Allowable
load (kg)
Max.
operating
pressure
(MPa)
φ
6
CY3R6
1.0
0.55
φ10 CY3R10 2.7 0.55
φ
15
CY3R15
7.0
0.65
φ20 CY3R20 11.0 0.65
φ25 CY3R25 18.5 0.65
φ
32
CY3R32
30.0
0.65
φ40 CY3R40 47.0 0.65
φ
50
CY3R50
75.0
0.65
φ63 CY3R63 115.0 0.65
Note) Operation of cylinder at pressure over
max. operating pressure may cause the
piston to come off (drop of load).
Keep max. operating pressure
A
2022-12-2009:32
DC875714

12
４．Intermediate Stop
4-1) Consider the following point to stop the
load on the way of stroke by external
stopper etc.
a) Operating pressure
Keep operating pressure below the limit
shown on Table 4. The operation at higher
pressure may cause thrust over holding
force to act and separate piston slider
and external slider from each other.
4-2) Consider the following points to realize
intermediate stop in pneumatic circuit.
a) Intermediate stop realized by the rodless
cylinder is not high accurate. If higher
accuracy is required for intermediate stop,
air hydraulic spec. (-X116) which combines
the cylinder with air hydraulic unit is
recommended.
(If it is required, contact SMC Sales division.)
b) Pay attention to kinetic energy generated by
load.
If the kinetic energy generated by the load
exceeds one to enable intermediate stop
shown on Table 5, be concerned about
possible runaway of load due to intermediate
stop by closed center valve.
Table 4 Operating pressure
limit for intermediate stop
Cylinder
tube I.D.
(mm)
Model
Operating
pressure limit
(MPa)
φ
6
CY3R6
0.55
φ10 CY3R10 0.55
φ
15
CY3R15
0.65
φ20 CY3R20 0.65
φ25 CY3R25 0.65
φ
32
CY3R32
0.65
φ40 CY3R40 0.65
φ
50
CY3R50
0.65
φ63 CY3R63 0.65
Table 5 Kinetic energy allowable
for intermediate stop (reference)
Cylinder
tube I.D.
(mm)
Model Kinetic energy
(J)
φ
6
CY3R6
0.007
φ10 CY3R10 0.03
φ15 CY3R15 0.13
φ
20
CY3R20
0.24
φ25 CY3R25 0.45
φ
32
CY3R32
0.88
φ40 CY3R40 1.53
φ50 CY3R50 3.12
φ
63
CY3R63
5.07
A
A
2022-12-2009:32
DC875714

13
5-1) Install air filter.
The rodless cylinder is non-lubrication type.
Install air filter to upstream near the valve and
adjust pneumatic pressure decreased to
desired set pressure by regulator.
5-2) Lubrication to compressed air
The rodless cylinder can be operated only
by initial lubrication at shipment. But if the
lubrication needs to be added due to
specifications, use Turbin oil class 1 (no
additive) ISO VG32. If the operation without
supply of additional lubrication is required
again, the cylinder needs to be sent to SMC
factory to enable re-application of adequate
amount of lubrication (grease).
5-3) For piping at both ends, change the
position of plug suitable for each operating
condition.
The piping port is made on axial direction of
cylinder and side face, but the port on side
face is plugged for shipment.
5-4) For common piping, remain switch
rail and plug installed. Removal of these
components may cause external leakage.
If the cylinder needs to be disassembled for
replacement of piston packing, soft wiper and
wearing, specific tool is required. The specific
tool can be ordered by part no. shown on Table 6.
５．
Operating Air and Piping
６．
Disassembly and Maintenance
Table 6 Part no. of specific tool
Part on.
Applicable cylinder
tube I.D. (mm)
CYRZ-V
6,10,15
､
20
CYRZ-W 25､32､40
CYRZ-X
50
CYRZ-Y
63
6-1) If the cylinder body or piston is removed
from cylinder tube, displace the positions
of external slider and piston forcedly to
eliminate holding force and take out them
individually. If they are removed together with
holding force left, they become unable to
separate from each other by internal and
external magnet force.
6-2) Loosen hexagon socket head female on side
of end cover by hexagon wrench, take off
attachment ring from the end cover with specific
tool and then remove the end cover from
cylinder tube. After that, remove Circular stop
ring mounted on the external face of the cylinder
tube by snap ring pliers. The used magnet
has strong suction force and should be
handled with care when external slider and
piston slider are removed from cylinder tube.
6-3) Never disassembly the parts which compose
the magnet (external slider and piston slider).
The disassembly of them may deprive holding
force from the magnet and cause operating
failure.
6-4) Take off the watch for handling of external
slider and piston slider.
6-5) Handle external slider and piston slider with
care to protect the magnet from drop on the
floor and collision to the metal. And apply
the grease periodically on external face of
cylinder tube. The grease can be ordered
by the following part no.
<φ6, φ10>
1) Inner side of cylinder tube
ＧＲ－Ｓ－＊
０１０
０２０
2) Outer side of cylinder tube and sliding side
of
switch rail
ＧＲ－Ｆ－＊
００５
０５０
２００
５００
<φ15～φ63>
ＧＲ－Ｓ－＊
０１０
０２０
Note）This grease is used for inner and outer side of
cylinder tube.
００５
５ｇ
０５０ ５０ｇ
２００ ２００ｇ
５００ ５００ｇ
０１０ １０ｇ
０２０ ２０ｇ
０１０ １０ｇ
０２０ ２０ｇ
A
2022-12-2009:32
DC875714

14
7-1) Some of internal components of cylinder is made of iron. Protect them from direct splash of water etc.
If such a situation can’t be avoided, contact SMC separately.
7-2) Before piping, perform flashing inside the piping to prevent intrusion of dust and cutting chip inside
the cylinder.
7-3) Do not give any damage including flaw and gouge on external face of cylinder tube. These damage
may be followed by the damage of soft wiper, packing and wearing and finally operating failure may
be caused.
８．Made to Order
The made to order of the rodless cylinder is available depending on operating environment and
conditions. The following shows relation between a certain operating environment or conditions and
applicable type of made to order.
Suffix Spec. Operative environment and conditions
Applicable
cylinder tube I.D.
－Ｘ１１６
(Note) Air hydraulic
Intermediate stop accuracy higher than
one obtained by pneumatic circuit is
required.
φ２５～φ４０
－Ｘ１６０
(Note) High speed Operation at speed higher than
standard spec. is required.
(Speed without load: 1500mm/s)
φ２０～φ４０
－Ｘ３２２
With hard chrome
plating on external face
of cylinder tube
Wear of external wearing needs to be
reduced (to improve durability of the
wearing).
φ１５～φ４０
－Ｘ１４６８
CY1B6 interchangeable
specification
For request to have the same
mounting dimensions as CY1B6.
φ６
－ＸＣ５７ With floating joint
The time to connect cylinder with
guide on other axis (load side) needs
to be reduced.
φ１５～φ４０
(Note) These spec. are available only in both-side piping type (CY3R) with the port in axial direction
of cylinder.
７．Other Cautions for Operation
A
2022-12-2009:32
DC875714

15
9-1) CY3R series (both-side piping)
９．Internal Construction and Parts List
A
2022-12-2009:32
DC875714

16
9-2) CY3RG series (Common piping)
A
2022-12-2009:32
DC875714

17
9-3) If the switch rail needs to be mounted to the cylinder, it can be ordered as accessory in accordance
with the following numbering system.
How to order switch rail as accessory
ＣＹＲ１５Ｅ－
Stroke
Cylinder tube I.D.
A
2022-12-2009:32
DC875714

Revision
4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN
Tel: + 81 3 5207 8249 Fax: [phone]
URL http://www.smcworld.com
Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
© 2011 SMC Corporation All Rights Reserved
2022-12-2009:32
DC875714
