SMC Networks ZXP7 01 X1 Series User manual

Doc. no. TQ1230001-OM101-C
PRODUCT NAME
Vacuum gripper unit
MODEL / Series / Product Number
ZXP7  01-  -X1
The outward appearance showed on this manual is an example of the vacuum gripper unit with
suction cups which is indicated by the product number: ZXP7A01-ZPB25JS-X1. Refer to the suction
cup catalog for the detail of other applicable suction cups.

-1-
No. TQ1230001-OM101-C
Contents
Safety instructions…………………………………………………………………………………………………..2
1. Parts included in the package...............................................................................................................6
2. Names of Parts of the Product..............................................................................................................7
3. Specifications .......................................................................................................................................8
3.1. Specifications...............................................................................................................................8
3.2. Flow rate / Exhaust characteristics ............................................................................................9
3.3. How to calculate theoretical lifting force..................................................................................10
3.4. How to order...............................................................................................................................11
4. Mounting ............................................................................................................................................12
4.1. Mounting.....................................................................................................................................12
4.2. Wiring..........................................................................................................................................14
4.3. Piping..........................................................................................................................................15
4.4. URCap.........................................................................................................................................16
5. Dimensions.........................................................................................................................................21
5.1. Vacuum gripper unit ..................................................................................................................21
5.2. Center of gravity ........................................................................................................................22
5.3. Suction cup with adapter...........................................................................................................23
6. How to change the number of cups ....................................................................................................25
6.1 Change to 1 cup (with flange) ....................................................................................................25
6.2 Change to 1 cup (without flange)...............................................................................................26
6.3 Change to 2 cups ........................................................................................................................27
7.Maintenance........................................................................................................................................28
7.1. Maintenance for vacuum gripper unit.......................................................................................28
7.2. Maintenance for suction cup.....................................................................................................29
8.Precautions .........................................................................................................................................30
8.1 Air supply..................................................................................................................................30
8.2 Vacuum gripper unit precautions............................................................................................30
8.3 Suction cup precautions..........................................................................................................32
9.Trouble shooting..................................................................................................................................35

-2-
No. TQ1230001-OM101-C
Safety Instructions
These safety instructions are intended to prevent hazardous situations and/or equipment damage.
These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.”
They are all important notes for safety and must be followed in addition to International Standards
(ISO/IEC)*1) , and other safety regulations.
*1) ISO 4414: Pneumatic fluid power -- General rules relating to systems.
ISO 4413: Hydraulic fluid power -- General rules relating to systems.
IEC 60204-1: Safety of machinery -- Electrical equipment of machines .(Part 1: General requirements)
ISO 10218: Manipulating industrial robots -Safety.
etc.
Caution
Caution indicates a hazard with a low level of risk which, if not avoided, could result
in minor or moderate injury.
Warning
Warning indicates a hazard with a medium level of risk which, if not avoided, could
result in death or serious injury.
Danger
Danger indicates a hazard with a high level of risk which, if not avoided, will result
in death or serious injury.
Warning
1. The compatibility of the product is the responsibility of the person who designs the equipment
or decides its specifications.
Since the product specified here is used under various operating conditions, its compatibility with specific
equipment must be decided by the person who designs the equipment or decides its specifications based on
necessary analysis and test results.
The expected performance and safety assurance of the equipment will be the responsibility of the person who
has determined its compatibility with the product.
This person should also continuously review all specifications of the product referring to its latest catalog
information, with a view to giving due consideration to any possibility of equipment failure when configuring the
equipment.
2. Only personnel with appropriate training should operate machinery and equipment.
The product specified here may become unsafe if handled incorrectly.
The assembly, operation and maintenance of machines or equipment including our products must be performed
by an operator who is appropriately trained and experienced.
3. Do not service or attempt to remove product and machinery/equipment until safety is
confirmed.
1.The inspection and maintenance of machinery/equipment should only be performed after measures to
prevent falling or runaway of the driven objects have been confirmed.
2.When the product is to be removed, confirm that the safety measures as mentioned above are implemented
and the power from any appropriate source is cut, and read and understand the specific product precautions
of all relevant products carefully.
3. Before machinery/equipment is restarted, take measures to prevent unexpected operation and malfunction.
4. Contact SMC beforehand and take special consideration of safety measures if the product is
to be used in any of the following conditions.
1. Conditions and environments outside of the given specifications, or use outdoors or in a place exposed to
direct sunlight.
2. Installation on equipment in conjunction with atomic energy, railways, air navigation, space, shipping,
vehicles, military, medical treatment, combustion and recreation, or equipment in contact with food and
beverages, emergency stop circuits, clutch and brake circuits in press applications, safety equipment or
other applications unsuitable for the standard specifications described in the product catalog.
3. An application which could have negative effects on people, property, or animals requiring special safety
analysis.
4.Use in an interlock circuit, which requires the provision of double interlock for possible failure by using a
mechanical protective function, and periodical checks to confirm proper operation.

-3-
No. TQ1230001-OM101-C
Safety Instructions
Caution
The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in manufacturing industries.
If considering using the product in other industries, consult SMC beforehand and exchange
specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
Limited warranty and Disclaimer/Compliance Requirements
The product used is subject to the following “Limited warranty and Disclaimer” and “Compliance
Requirements”.
Read and accept them before using the product.
Limited warranty and Disclaimer
1.The warranty period of the product is 1 year in service or 1.5 years after the product is
delivered,whichever is first.2)
Also, the product may have specified durability, running distance or replacement parts.
Please consult your nearest sales branch.
2. For any failure or damage reported within the warranty period which is clearly our
responsibility, a replacement product or necessary parts will be provided.
This limited warranty applies only to our product independently, and not to any other damage
incurred due to the failure of the product.
3. Prior to using SMC products, please read and understand the warranty terms and disclaimers
noted in the specified catalog for the particular products.
2) Suction cups are excluded from this 1 year warranty.
A suction cup is a consumable part, so it is warranted for a year after it is delivered.
Also, even within the warranty period, the wear of a product due to the use of the suction
cup or failure due to the deterioration of rubber material are not covered by the limited
warranty.
Compliance Requirements
1. The use of SMC products with production equipment for the manufacture of weapons of
mass destruction(WMD) or any other weapon is strictly prohibited.
2. The exports of SMC products or technology from one country to another are governed by
the relevant security laws and regulation of the countries involved in the transaction. Prior
to the shipment of a SMC product to another country, assure that all local rules governing
that export are known and followed.
Caution
SMC products are not intended for use as instruments for legal metrology.
Measurement instruments that SMC manufactures or sells have not been qualified by type approval
tests relevant to the metrology (measurement) laws of each country.
Therefore, SMC products cannot be used for business or certification ordained by the metrology
(measurement) laws of each country.

-4-
No. TQ1230001-OM101-C
■Explanation of Symbols
Sym bol
Definition
Things you must not do.
Instructions are provided as a drawing or sentence next to the symbol.
Things you must do
Instructions are provided as a drawing or sentence next to the symbol.
■Operator
1. This Operation Manual is intended for those who have knowledge of machinery using pneumatic equipment, and
have sufficient knowledge of assembly, operation and maintenance of such equipment.
Only those persons are allowed to perform assembly, operation and maintenance.
2. Read and understand this Operation Manual carefully before assembling, operating or providing maintenance to
the product.
■Safety Instructions
Warning
Disassembly
prohibited
Do not disassemble, modify (including the replacement of board) or repair other than
instructed in this manual.
Otherwise, an injury or failure can result.
Do not
Do not operate the product outside of the specifications.
Do not use for flammable or harmful fluids.
Fire, malfunction, or damage to the product can result.
Please check the specifications before use.
Do not
Do not use in an atmosphere containing flammable or explosive gases.
Fire or an explosion can result.
The product is not designed to be explosion proof.
Do not
Do not use the product in a place where static electricity is a problem.
Otherwise failure or malfunction of the system can result.
Do not
Do not cut off the power and compressed air supplied to this product while it is operating.
Otherwise it can cause injury due to dropping of workpieces or damage to the system.
Instruction
If using the product in an interlocking circuit
- Provide a double interlocking system, for example a mechanical system.
- Check the product for proper operation.
Otherwise malfunction can result, causing an accident.
Instruction
The following instructions must be followed during maintenance
- Turn off the power supply
- Stop the air supply, exhaust the residual pressure in piping and verify that the air is
released before performing maintenance work.
It may cause an injury.

-5-
No. TQ1230001-OM101-C
Caution
Do not touch
Do not touch the terminals and connectors while the power is on.
Otherwise electric shock, malfunction or damage to the switch can result.
Instruction
Perform sufficient trial run.
Otherwise, injury or damage to the system can result due to suction failure depending on
the conditions of the suction of the workpiece or the pressure switch settings.
Perform sufficient verification before using this product.
Instruction
After maintenance is complete, perform appropriate functional inspections and leak test.
Stop operation if the equipment does not function properly or there is leakage of fluid.
If there is leakage from parts other than the piping, the product might be broken.
Cut off the power supply and stop the fluid supply.
Do not supply fluid if there is leakage.
Safety cannot be assured in the case of an unexpected malfunction.
■ Precautions for Handling
Follow the instructions given below for selecting and handling of the vacuum gripper unit.
Product specifications
- It is recommended to use compressed air which purity class is 2:6:3 of ISO8573-1:2010.
- The applicable fluid is air.
Do not use a fluid containing chemicals, synthetic oils including organic solvent, salt and corrosive gases.
Otherwise, damage to the vacuum gripper unit and malfunction can result.
- Use the specified operating pressure.
- Reserve a space for maintenance.
Design the system allowing the required space for maintenance.
- Use the specified voltage. Otherwise failure or malfunction can result.
-Do not exceed the specified maximum allowable load. Otherwise it can cause damage or shorten the life of the product.
- Design the product to prevent reverse current when the circuit is opened or the product is forced to operate for
operational check. Reverse current can cause malfunction or damage the product.
Operating environment
- Do not use in an environment where corrosive gases, chemicals, sea water, water or steam are present.
- Do not use the product in a place where the product could be splashed by oil or chemicals.
If the product is to be used in an environment containing oils or chemicals such as coolant or cleaning solvent, even for a
short time, the solenoid valve or pressure switch/sensor may be adversely affected (damage, malfunction, or hardening
of the lead wires).
- Do not use in an area where surges are generated.
When there are machines or equipment that generate large surge near the pressure switch/sensor (magnetic type lifter,
high frequency inductive furnace, motor, etc.), this can result in deterioration and damage of the internal elements. Take
measures against the surge sources, and prevent the lines from coming into close contact.
- Do not use a load which generates surge voltage.
When a surge-generating load such as a relay or solenoid is directly driven, use the product with a surge absorbing
element built-in.
- Mount the product in a location that is not affected by vibration or impact.
It will cause failure or malfunction.
- Do not use the product in an environment that is exposed to temperature cycle.
Heat cycles other than ordinary changes in temperature can adversely affect the inside of the product.
- Do not expose the product to direct sunlight.
If using in a location directly exposed to sunlight, protect the product from the sunlight.
- Keep within the specified operating fluid and ambient temperature range.
Operation under low temperature may lead to damage or operation failure due to frozen moisture in the fluid or air.
Protection against freezing is necessary. Mounting of an air dryer is recommended for elimination of drainage and water.
Avoid abrupt temperature changes even within the specified temperature range.
- Do not use in a location where the product is exposed to radiant heat from surrounding heat sources.
Insufficient air quality may cause operation failure.
-
3
-

-6-
No. TQ1230001-OM101-C
1. Parts included in the package
Download the URCap from the SMC website and then store it in your USB memory.
Robot mounting flange 1 pc.
Vacuum gripper unit: 1 pc.
Suction cup with adapter: 4 pcs.
(When “ suction cup series” is selected.)
Parallel pin (6x10): 1 pc.
Hexagon socket head cap
screw (M6x10): 8 pcs.
Plug: 4 pcs.
Part No. M-3P
（When “cup mounting flange
shape” is selected.）
Used for decreasing the number of
suction cups.
Polyurethane Tube: 2m
Part No. TU0604BU

-7-
No. TQ1230001-OM101-C
2. Names of Parts of the Product
Parallel pin (6x10)
Robot mounting flange
（Compliant with “ISO9409-1-50-4-M6”）
Hexagon socket head cap
screw (M6x10)
Cover
Hexagon socket head cap
screw (M6x10)
M8 Connector cable
Air pressure supply port
Applicable tubing O.D.: Φ6
O-ring
Parallel pin (6x10)
Cup mounting flange
（Compliant with “ISO9409-1-50-4-M6”）
Hexagon socket head cap
screw (M6x10)
Suction cups with adapter

-8-
No. TQ1230001-OM101-C
3. Specifications
3.1. Specifications
■Product specifications
Common
Mechanical interface standard
Compliant with “ISO9409-1-50-4-M6”
Fluid
Air
Operating temperature range[°C]
5 to 50
Connector type
M8/8PIN (Female)
Weight [g]
ZXP7N01-X1
581
ZXP7A01-X1
794
Example)
ZXP7A01-ZPB25JS-X1
850 note1)
Max. workload [kg] Note2)
7
Impact / Vibration resistance [m/s2] Note3)
150 / 30
Air supply port(P)
One touch fitting (Φ6)
Power supply voltage [V]
DC24 ± 10%
Vacuum
ejector
Max. vacuum pressure [kPa] note4)
-84
Max. suction flow [L/min(ANR)] note4)
17
Air consumption [L/min(ANR)] note4)
57
Supply pressure range [MPa]
0.3 to 0.55
Standard supply pressure [MPa] note5)
0.5
Valve
Model
V114
Pressure
sensor
Model
PSE541-R04
Rated pressure range [kPa]
0 to -101
Accuracy [%] (Ambient temperature at 25°C)
±2 F.S. (with rated pressure range)
Linearity [%]
±0.4 F.S.
Repeatability [%]
±0.2 F.S.
Temperature characteristics [%]
±0.2 F.S. (Based on 25°C)
Applicable suction cups
Refer to “3.4. How to order”
Note 1) The weight changes by the selected suction cup. Refer to “3.4 How to order”.
Note 2) Limited by the cup diameter, mounting orientation or workpiece. The weight of the workpiece shall be maximum
workload or less.
Gripping or transfer of workload exceeding the maximum workload leads to the decrease of vacuum due to air leakage.
Note 3) Impact resistance: The characteristics are satisfied after tested one time in each of the X, Y and Z directions without
energization. (Initial value)
Vibration resistance: The characteristics are satisfied after tested a one sweep in each of the X, Y and Z directions at 10
to 500 Hz without energization. (Initial value)
Note 4) Values at the standard supply pressure. Values are based on standard of SMC measurements. They depend on
atmospheric pressure (weather, altitude, etc.) and measurement method.
Note 5) This shows the pressure just before the supply (P) port.
The performance such as vacuum pressure may reduce, depending on supply air capacity, the piping volume (piping
length and diameter) and affection of air consumption of other devices which operate at the same time.

-9-
No. TQ1230001-OM101-C
3.2. Flow rate / Exhaust characteristics
■Flow rate / Exhaust characteristics.
The flow rate characteristics correspond to the standard supply pressure (0.5MPa).
* The actual suction flow at the point of suction varies depending on the piping conditions to the vacuum port.
■How to read the flow rate characteristics Graph
Flow rate characteristics are expressed in ejector vacuum pressure and suction flow. If suction flow changes,
the vacuum pressure will also be changed. Normally this relationship is expressed in ejector standard
operating pressure use. In the graph, Pmax is maximum vacuum pressure and Qmax is maximum suction
flow. The values are specified according to catalog use. Changes in vacuum pressure are expressed in the
below order.
1. When the ejector suction port is covered and made airtight, the suction flow becomes zero and vacuum
pressure is at the maximum value (Pmax).
2. When the suction port is opened gradually, air can flow through, (air leakage), suction flow increases, but
vacuum pressure decreases. (condition P1 and Q1)
3. When the suction port is opened further and fully opened, suction flow moves to the maximum value
(Qmax), but vacuum pressure is near zero (atmospheric pressure).
As described above, the vacuum pressure changes when the suction flow changes. In other words, when
there is no leakage from the vacuum port, the vacuum pressure can reach its maximum, but as the
amount of leakage increases, the vacuum pressure decreases. When the amount of leakage and the
maximum suction flow become equal, the vacuum pressure becomes almost zero.
In the case when a ventilative or leaky workpiece should be gripped, take note that vacuum pressure will
not rise.
Flow rate characteristics
Exhaust characteristics
-90
-80
-70
-60
-50
-40
-30
-20
-10
00 5 10 15 20 25
Vacuum pressure [kPa]
Suction flow [L/min(ANR)]

-10-
No. TQ1230001-OM101-C
3.3. How to calculate theoretical lifting force
This manual shows how to calculate theoretical lifting force only. Refer to the catalog of suction cupsfor further
detail of suction cup selection method.
■How to calculate theoretical lifting force
The theoretical lifting force of a cup can be found by calculation or from the theoretical lifting force table.
Calculation
Theoretical lifting force table
The theoretical lifting force (not including the safety factor) can be determined by the cup diameter and vacuum
pressure.
The required lifting force can then be determined by dividing the theoretical lifting force by the safety factor t.
Lifting force = Theoretical lifting force / t
Theoretical lifting force (Theoretical lifting force = P x S x 0.1)
Cup diameter (Φ8 to Φ32) [N]
Cup diameter [mm]
Φ8
Φ10
Φ13
Φ16
Φ20
Φ25
Φ32
S: Cup area [cm2]
0.50
0.79
1.33
2.01
3.14
4.91
8.04
Vacuum
pressure
[kPa]
-85
4.2
6.6
11
17
26
41
68
-80
4.0
6.2
10
16
25
39
64
-75
3.7
5.8
10
15
23
36
60
-70
3.5
5.5
9.3
14
22
34
56
-65
3.2
5.1
8.6
13
20
31
52
-60
3.0
4.7
8.0
12
18
29
48
-55
2.7
4.3
7.3
11
17
27
44
-50
2.5
3.9
6.7
10
15
24
40
-45
2.2
3.5
6.0
9.0
14
22
36
-40
2.0
3.1
5.3
8.0
12
19
32
W: Lifting force [N]
P: Vacuum pressure [kPa]
S: Cup area [cm2]
t: Safety factor Horizontal lifting: 4 or more
Vertical lifting: 8 or more
Cup

-11-
No. TQ1230001-OM101-C
1) Unit size 3 ) Applicable manufacturer 4) Suction cup series 5) Cupdiameter 6) Cupform 7) Material 8) Attachment *3
Nil
With(Guide) attachment
M
With mesh attachment
－
X1
Symbol
Attachment
Symbol
Form
Symbol
ＮＢＲ
Ｕ
Flat
Ｎ
Nil
Without cup
Silicone rubber (White) 2
Silicone rubber (Blue) 2
Flat withribs
Multi stage bellows
2.5 stage bellows
Without cup
Urethane rubber
Thinflat
Ｆ
ＦＫＭ
Ｃ
S
13
Φ13
SF
Nil
B30
Φ30
32
Φ32
Without cup
Nil
Φ10
B
Bellows
Ｕ
B25
Φ25
ＪT5
5.5 stage bellows
20
Φ20
Ｊ
25
Φ25
ＪT2
Nil
Without cup
16
Φ16
ＵＴ
Symbol
Shape
2) Cup mounting flange
shape
Symbol
Robot manufacturer
Withflange (42㎜x42㎜)
Symbol
Series
Symbol
Dia.
ZP
Standard
08
Φ8
N
None
ZP3P
Bellows for film
adsorption
10
Vacuum gripper unit
Symbol
Size
7
75㎜
Ａ
01
UR: 3(e), 5(e), 10（e), 16（e)
ZXP
7
A
01
－
ＺＰ
20
Ｕ
Ｎ
Material

2Silicone material
compliant with the FDA
(USA Food and Drug
Administration) regulation
21CFR§177.

3Apply to the cup
form "JT" only
ZXP7(A,N)01 - (4) (5) (6) (7) (8) -X1
Mass and part number for suction cup part for separate order
N
（NBR）
S/SF
(Silicone
rubber）
U
(Urethan
rubber）
F
(FKM）
ZP 08 UZPT08U-A6 4 4 4 4 ZP08U
ZP 08 BZPT08B-A6 4 4 4 4 ZP08B
ZP 10 UT ZPT10UT-A6 4 4 4 4 ZP10UT
ZP 13 UT ZPT13UT-A6 4 4 4 4 ZP13UT
ZP 16 UT ZPT16UT-A6 4 4 4 4 ZP16UT
ZP 10 U
ZPG10U-7A-X2 7 7 7 7 ZP10U
ZP 13 U
ZPG13U-7A-X2 7 7 7 8 ZP13U
ZP 16 U
ZPG16U-7A-X2 7 7 7 8 ZP16U
ZP 20 U
ZPG20U-7A-X2 9 10 10 10 ZP20U
ZP 25 U
ZPG25U-7A-X2 10 10 10 11 ZP25U
ZP 32 U
ZPG32U-7A-X2 10 11 11 12 ZP32U
ZP 10 C
ZPG10C-7A-X2 7 7 7 7 ZP10C
ZP 13 C
ZPG13C-7A-X2 7 7 7 7 ZP13C
ZP 16 C
ZPG16C-7A-X2 7 7 7 8 ZP16C
ZP 20 C
ZPG20C-7A-X2 9 10 10 11 ZP20C
ZP 25 C
ZPG25C-7A-X2 10 10 10 11 ZP25C
ZP 32 C
ZPG32C-7A-X2 10 11 11 12 ZP32C
ZP 10 B
ZPG10B-7A-X2 7 7 7 8 ZP10B
ZP 13 B
ZPG13B-7A-X2 7 8 8 8 ZP13B
ZP 16 B
ZPG16B-7A-X2 8 8 8 9 ZP16B
ZP 20 B
ZPG20B-7A-X2 11 11 11 13 ZP20B
ZP 25 B
ZPG25B-7A-X2 11 12 12 14 ZP25B
ZP 32 B
ZPG32B-7A-X2 14 15 15 18 ZP32B
ZP 20 UT 
ZPG20UT-7A-X2 4 4 4 4 ZPT1-A6 ZP2-20UT
ZP 16 J
ZPG16J-7A-X2 8 8 8 9 ZPT2-7A-X2 ZP2-16J
ZP B25 J 
ZPGB25J-7A-X2 14 15 15 18 ZP2-B25J
ZP B30 J
ZPGB30J-7A-X2 18 19 19 25 ZP2-B30J
ZP3P 20 JT2 SF ZP3PG20JT2SF-7A-X2 -21 - - ZP3P-20JT2SF-W
ZP3P 20 JT2 SF MZP3PG20JT2SF-M-7A-X2 -21 - - ZP3P-20JT2SF-WM
ZP3P 32 JT2 SF ZP3PG32JT2SF-7A-X2 -48 - - ZP3P-32JT2SF-W
ZP3P 32 JT2 SF MZP3PG32JT2SF-M-7A-X2 -48 - - ZP3P-32JT2SF-WM
ZP3P 20 JT5 SF ZP3PG20JT5SF-7A-X2 -23 - - ZP3P-20JT5SF-WG
ZP3P 25 JT5 SF ZP3PG25JT5SF-7A-X2 -25 - - ZP3P-25JT5SF-WG
ZP3P 32 JT5 SF ZP3PG32JT5SF-7A-X2 -54 - - ZP3PA-T2JT-7A-X2 ZP3P-32JT5SF-WG
Note) Material symbol ”N”, “S”, “U”, or “F” is put in * of the product number.
ZP3PA-T1JT-7A-X2
Suction cup
Part number
Mass for each material (g/pc.)
ZPT1-A6
ZPT2-7A-X2
ZPT3-7A-X2
Adapter
ZPT2-7A-X2
ZPT3-7A-X2
ZPT2-7A-X2
ZPT3-7A-X2
ZPT3-7A-X2
ZP3PA-T1JT-7A-X2
ZP3PA-T2JT-7A-X2
(4)
Series
(5)
Diameter
(6)
Form
(7)
Material
Suction cup with adapter
(8)
Attachment
3.4. How to order
■Vacuum Gripper unit
1
■Suction cup parts / How to order and Weight
･See the table below for the suction cup part combination.
･Refer to the catalog of suction cup on the SMC website for the detail of suction cup.
Suction cup part 1
With Flange
Without Flange
(42)
）

-12-
No. TQ1230001-OM101-C
4. Mounting
4.1. Mounting
■Mounting procedure
1) Confirm the gasket seal on the adapter, then mount 4 cups with adapter to the vacuum gripper unit.
(Tightening torque: 1N・m or tighten for 45 degrees using a spanner after tightening by hand)
2) Mount parallel pin to the robot tool flange pin hole.
3) Align the parallel pin of the robot tool flange with the robot mounting flange, and assemble them with
bolts included in the accessories. (Tightening torque: 5.2+/-0.5 Nm)
4) Tighten the vacuum Fper to the robot mounting flange.
(Tightening torque: 5.2+/-0.5 Nm)
Removal should be performed by following the mounting procedure in reverse.
Pin hole
Parallel pin
Robot mounting flange
Tool flange
Hexagon socket head cap screw
(M6x10 8 pcs.)
Suction cups with adapter
Vacuum gripper unit
1）
4）
3）
2）
Gasket seal
Adapter
Oval hole

-13-
No. TQ1230001-OM101-C
Caution
Install the vacuum gripper unit in the direction of the lower figure where the slack of the M8 connector
cable is small. (the M8 tool I/O connector of the robot comes to the opposite side of the electrical
entry of the vacuum gripper unit)
If the cable is loose, it may be caught by peripheral equipment, workpiece, human body, etc. while
the robot is running, causing unexpected accidents.
M8 tool I/O connector
entry direction
Cable entry direction of
Vacuum gripper unit

-14-
No. TQ1230001-OM101-C
4.2. Wiring
■Mount the M8 connector cable
Mount the M8 connector cable to the M8 connector (male) of the robot tool flange.
*Do not energize while securing the connector.
*Check that the connector is not loose
■M8 Connector pin
M8 connector female angle
M8 connector pin assign
Pin no.
Wire
color
Function
1
White
Pressure sensor output
2
Brown
N.C.(Non connection)
3
Green
N.C.(Non connection)
4
Yellow
N.C.(Non connection)
5
Gray
Power supply voltage (24V)
6
Pink
Release valve 
7
Blue
Pilot valve for supply 
8
Red
Power supply voltage (GND)
* Set the polarity of the robot output to NPN.
M8 connector cable
Tool flange
Tool I/O connector (Male)
White
Brown
Green
Yellow
Gray
Pink
Blue
Red

-15-
No. TQ1230001-OM101-C
4.3. Piping
■Tubing
Connect a tube (applicable tube O.D. Ø6) to the air pressure supply (P) port.
To remove the tube, push the release button and pull out the tube.
Air pressure supply (P) port
Applicable tubing O.D.: Φ6
Release Button

-16-
No. TQ1230001-OM101-C
4.4. URCap
Installation and basic setting
1. Installation of URCap
(1) Tap the "URCap" menu from the robot settings screen.
(2) Insert the USB memory with a copy of the downloaded file into the teaching pad and tap the "+"
button.
(3) Select " SMC-VacuumGripperUnit-xxx.urcap " from the file screen and tap the "open" button.
(1)
(2)
(3)

-17-
No. TQ1230001-OM101-C
(4) Tap the "Restart" button to restart the robot.
Before you make a change to the basic settings after the software installation, set the Tool Output
Voltage to "24V" in the "Tool IO" setting from the "General" menu on the "Installation" tab. Set
"Digital Output 0" and "Digital Output 1" to "Sinking(NPN)".
2. Select "SMC Vacuum Gripper Unit" on the "URCap" menu for basic settings.
(1):“Various status signal output to digital output port”:
Sets the status of the output port. If "Enable" is selected, the signal for “Adsorb success”, “Adsorb
failure”, and “Workpiece drop detection” can be assigned to the output port No. 5 / 6 / 7, respectively.
(1)
(4)

-18-
No. TQ1230001-OM101-C
(2) Select “Disable” when the output port is not used.
Different signals cannot be assigned to the same port.
(2)

-19-
No. TQ1230001-OM101-C
Program setting
Operation program can be set from the “Program” tab.
(1)：“Select operation”
3 types of operation NODEs are available.
1：“ADSORB ONLY NODE” starts adsorption. This does not monitor the pressure sensor signal.
2：“ADSORB AND CHECK VACUUM LEVEL NODE” starts adsorption. In this case, after checking the
pressure sensor signal and confirming the adsorption, the transition of the operation occurs.
3：“RELEASE ONLY NODE” starts vacuum release. This does not monitor the pressure sensor signal.
(2)：“Settings”
1： “Vacuum pressure level for checking” sets the vacuum pressure to output the signal for checking the
adsorption.
2：“Adsorb error detection time” sets the time to recognize an unsuccessful adsorption, that is, vacuum
pressure to output the adsorption signal is not reached.
3：“Blow-off time of release” sets time to supply vacuum release pressure.
4：“Weight of the workpiece” enters the weight of the transferred object for each “Adsorb” command.
(3)：“Monitor sensor signal”
Pressure sensor detection pressure can be confirmed on the screen.
(1)
(2)
(3)
1
2
3
4
