SMITH SYSTEM Flowform User manual

Document #: 179689
REVISED: 07/2020
Assembly Instructions
Secondary Surface on Flowform
Round Triangle Table
If you have damaged or missing components,
please contact customer service at 1-800-328-1061

Document #: 179689
REVISED: 07/2020
Hardware and Components
SECONDARY SURFACE BRACKET
(PN: 60013)
QTY. 3
#10-32 X 1/4”UNDERCUT FLAT-HEAD SCREW
QTY. 6
SECONDARY SURFACE PLATE
(PN: 60013)
QTY. 1
ROUND TRIANGLE TABLE WITH LEGS
INSTALLED
QTY. 1
1/8”ALLEN WRENCH
QTY. 1
5/16”-18 X 1/2”BOLT
(ALREADY INSTALLED ON LEG)
QTY. 6

Document #: 179689
REVISED: 07/2020
Special Notes:
xTOOLS REQUIRED:
• 3/16” Allen wrench (included with legs) or 3/16” Allen drill bit.
xCheck that all components are accounted for and undamaged beforeassembling.
xPlease assemble the product in a clean and dry area.
xClean the product with a mild cleaner and a damp cloth.

Document #: 179689
REVISED: 07/2020
Assembly Instructions
1. After assembling the legs to the top and leaving it on a clean smooth surface that will
not harm the top finish, remove the 5/16”-18 x 1/2” Bolts and set to the side.
2. Lay secondary surface plate down on a clean smooth surface that will not harm the
plate finish. Underside of plate should be exposed.

Document #: 179689
REVISED: 07/2020
3. Attach the bracket using two of the #10-32 x 1/4” Undercut Flat-Head Screws,
but do not fully tighten it yet.
4. Attach the other two brackets leaving them loose for positioning.
5. Place plate in the center of the legs on the table aligning the brackets with the gussets on
the legs.

Document #: 179689
REVISED: 07/2020
6. Install two of the 5/16”-18 x 1/2” Bolts into the bracket and the leg gusset. Repeat for the
other brackets. Now tighten all screws.
7. Flip table over.
ASSEMBLY COMPLETE
