SMITH SYSTEM Circulation Desk User manual

Assembly Instructions
for the following workstations:
www.smithsystem.com
For assistance in assembling product, missing or damaged
parts, or to place an order please contact customer service at 800-328-1061.
You may also place your order online at
Circulation Desk™
Bullet
Rectangle
Peninsula
Contour
Form# 179863
2/2007
page 1 of 5Form# 179863

*Our Ciruclation Workstations come in dierent length and shapes, so hardware and screw hole placement will vary.
If you feel you have not received all the hardware necessary, please call us at 800-328-1061.
Cross Brace (1)
Leg Set (1)
(2 legs per set)
Modesty Panel (1)
Table Top (1)
Tinnerman Clips (4)
Wood Screws (13)* 10-32x1/2" Machine Screws (4)* 1/4-20x1/2" Machine Screws (12)*
If you have damaged or missing components or hardware please contact customer service at [phone]
You will need a Phillips head screw driver.
1. Check that all components are accounted for and undamaged before assembling.
2. Please assemble product in a clean and dry area.
3. For larger units you may need another person to help assemble the product.
4. Clean the product with a mild cleaner and a damp cloth.
Brackets (2)
Left or Right Handed
30”d
30”w, or 72”w
Bullet Desk Rectangle Desk Peninsula Desk Contour Desk
2/2007
page 2 of 5
Form# 179863
30”d
36”w, or 48”w,60”w, or 72”w Left or Right Handed
36”d
60”w, 72”w
36”d
60”w, 72”w
Questions? Call Us.
800-328-1061

Step 2 Now adjust the legs to the desired height. (See Drawing 2). Drawing 2B shows the side view of what the
exact length the leg needs to be set at.
Step 1 Locate all the parts needed for assembly. Place the table top face down on a clean, dry surface. Attach
the brackets to the top using the (8) wood screws and a phillips head screw driver. (See Drawing 1A).
Next attach the legs to the brackets using (8) Machine Screws, (4) per leg. (See Drawing 1B).
Assembly Instructions for
Circulation Workstation
Drawing 1A
Drawing 1B
Drawing 2A
2/2007
page 3 of 5
Form# 179863
*7” minimum for
panel clearance*
Drawing 2B
*Be sure to have
at least 5 holes
showing.*
7.0”
Note: For left and right hand
peninsula, and bullets. Verify
the layout and pick your hole
pattern.

www.smithsystem.com
If you have any quesions
contact customer service.
800-328-1061
Drawing 3A
Step 3 Now install (1) Tinnerman Clip per leg, in square hole located inside of the leg. (See Drawing 3A)
NOTE: Tinnerman clip only used if desk is raised to high range, when set to low range threaded hole from
lower leg will be used instead of tinnerman clip.
Step 4 Once the legs are secure, loosely attach the modesty panel to the legs using (4) Machine Screws.
(See Drawing 4A). Now use the remaining wood screws to attach the modesty panel to the table top.
(See Drawing 4B). Once all screws are in go back and tighten screws on the legs.
NOTE: Legs must be adjusted to desired height range before installing modesty panel.
Assembly Instructions for
Acrobat Workstation
Drawing 4A
Drawing 4B
2/2007
page 4 of 5
Form# 179863

www.smithsystem.com
If you have any quesions
contact customer service.
800-328-1061
Step 5 Attach the cross bar to the foot of the legs using (4) 10-32X1/2" Machine Screws. (See Drawing 5A).
Assembly Directions for a
Circulation Workstation
Step 6 With help, tip the desk in the upright position. Your desk is ready for use.
Drawing 5A
2/2007
page 5 of 5
Form# 179863
