Hard Plastic Flex Desk Installation Guide
(Model 01362, 01369)
Hardware and Components
#10 X 7/16 Plastite Screw
P/N: 67208
(QTY: 12)
HEX KEY 3/16”
P/N: 77813
(QTY: 2)
3/8”-16 Dog Sckt Screw
P/N: 77741
(QTY: 4)
Modesty Panel
(QTY: 1)
Hard Plastic Table Top
(QTY: 1)
Y Leg Set
(QTY: 2 legs per set)
P/N: 70867 –Connector Bolt ¼-20x23mm
P/N: 70871 –Connector Nut ¼-20x17mm
(QTY: 4 each)
Replacement Hardware Packs:
1. 67204-R –HDWR Pack, HP top Flex/PSD Desk
a. (12) 67208 –Pan Phil THD Roll Plast 10x1/2
2. 69729-R –Y-Leg Hardware Pack
a. (4) 70870 –Connector Bolt ¼-20x23mm
b. (4) 70871 –Connector Nut ¼-20x17mm
c. (2) 77813 –3/16” Allen Wrench Short Arm
d. (17) 70054 –¾” Wood Screw

For Assistance in assembling product, missing or damaged parts,
or to place an order, please contact customer service at 800-328-1061
You may also place your order online at
www.smithsystem.com
Form# 179810 04/2013
Step 1: Place the table top on a smooth, clean surface with the bottom facing up.
Step 2: Loosely attach the panel to the legs using the supplied connector bolts. LEAVE FINGER TIGHT.
(Diagram 2)
Step 3: Align the frame assembly with the predrilled holes in the top and use the supplied #10 screws to
loosely attach the frame to the table top (Diagram #1)
Step 4: Go back to assembly and completely tighten the connector bolts. Once done completely tighten
the frame assembly to the table top.
Step 5: Using the supplied Allen wrench, adjust the height of the legs (Diagram 3). Carefully tip the unit
over onto its legs. Unit is now ready for use.
Diagram #1
Diagram #2
Diagram #3
