SolarEdge Power Harvesting System User manual

About This Guide
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
1

About This Guide
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
2
About This Guide
This user guide is intended for Photovoltaic (PV) system owners, installers,
technicians, maintainers and integrators who are authorized to install and
connect a SolarEdge power harvesting system.
This guide describes the process of installing SolarEdge power optimizers
and SolarEdge Three Phase Inverters. This guide does not describe how to
install the PV modules. The inverter models covered in this guide are:
SE8k, SE10k and, SE12k. The power optimizer models covered in the
guide are OP250-LV, OP300-MV, OP400-MV, PB250-AOB, PB350-AOB,
PB250-TFI and PB350-TFI.
The guide includes the following chapters:
Chapter 1, Introducing the SolarEdge Power Harvesting System,
page 9, introduces the components of the SolarEdge power harvesting
solution.
Chapter 2, Installing the Power Optimizers, page 15, describes how
to install the SolarEdge power optimizers.
Chapter 3, Installing the Inverter, page 25, describes the process of
installing and connecting a SolarEdge Three Phase Inverter.
Chapter 4, Commissioning the Installation, page 37, describes how
to activate the system, commission the power optimizers and verify the
proper functioning of the system.
Chapter 5, Replacing and Adding System Components, page 46,
describes how to replace or add various SolarEdge system components
after the initial installation.
Chapter 6, Setting Up Communication, page 50, describes how to
install and set up communication between the inverter and the
SolarEdge Monitoring Server.
Chapter 7, Inverter User Interface, page 61, describes how to
configure the inverter and how to identify its status.

Important Notice
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
3
Appendix A, Errors and Troubleshooting, page 75, lists the error
messages that may appear on the inverter’s LCD panel, describes their
meaning and describes how to troubleshoot each one.
Appendix B, Technical Specifications, page 81, provides the technical
specifications of the SolarEdge system components.
Appendix C, Power Optimizer Mechanical Specifications, page 87,
presents the mechanical specifications for the SolarEdge power
optimizers.
Additional Documentation
The following describes where additional information and manuals can be
accessed. For further information, datasheets and the most up-to-date
certifications for various products in different countries, please visit the
SolarEdge web site: www.solaredge.com
The following additional manuals can be found on the site:
SolarEdge Monitoring Portal User Guide
SolarEdge Configuration Tool Software Guide
SolarEdge Recommended AC Wiring Application Note
Important Notice
Copyright © SolarEdge Inc. All rights reserved.
No part of this document may be reproduced, stored in a retrieval system or transmitted, in
any form or by any means, electronic, mechanical, photographic, magnetic or otherwise,
without the prior written permission of SolarEdge Inc.
This document is solely for the use of SolarEdge customers and employees.
The material furnished in this document is believed to be accurate and reliable. However,
SolarEdge assumes no responsibility for the use of this material. SolarEdge reserves the
right to make changes to the material at any time and without notice. You may refer to the
SolarEdge web site (www.solaredge.com) for the most updated version.
All company and brand products and service names are trademarks or registered trademarks
of their respective holders.
Exclusion of Liability
The general terms and conditions of delivery of SolarEdge shall apply.
The content of these documents is continually reviewed and amended, where necessary.
However, discrepancies cannot be excluded. No guarantee is made for the completeness of
these documents.

Table of Contents
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
4
Table of Contents
Handling and Safety Instructions ...........................................................................6
Support and Contact Information..........................................................................8
Chapter 1, Introducing the SolarEdge Power Harvesting System........9
What is the SolarEdge Power Harvesting Solution?.............................................9
SolarEdge Power Optimizer ............................................................................................ 9
Three Phase Inverter...................................................................................................... 10
SolarEdge Monitoring Portal......................................................................................... 11
Installation Workflow............................................................................................12
Transport and Storage...........................................................................................13
Three Phase Inverter Transport...................................................................................... 13
Three Phase Inverter Storage......................................................................................... 13
Equipment List.......................................................................................................13
Chapter 2, Installing the Power Optimizers..........................................15
Applicable Notes and Warnings............................................................................15
Step 1, Mounting the Power Optimizers ..............................................................17
Step 2, Connecting Each PV Module to a Power Optimizer ..............................18
OP250-LV, OP300-MV and OP400-MV...................................................................... 18
PB250-AOB and PB350-AOB ...................................................................................... 19
PB250-TFI and PB350-TFI ........................................................................................... 20
Connecting Power Optimizers....................................................................................... 21
Step 3, Connecting Power Optimizers in Strings.................................................22
Constructing Strings ...................................................................................................... 22
Verifying Proper Power Optimizer Connection............................................................. 23
Chapter 3, Installing the Inverter...........................................................25
Identifying the Inverter..........................................................................................25
Selecting the Mounting Location ..........................................................................26
Chassis Clearance.......................................................................................................... 26
Mounting the Inverter............................................................................................27
Connecting the Inverter.........................................................................................29
Inverter Connection Overview....................................................................................... 29
Connecting the Three Phase Inverter............................................................................. 30
Completing the Three Phase Inverter Installation.......................................................... 34
Residual Current Device........................................................................................36

Table of Contents
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
5
Chapter 4, Commissioning the Installation...........................................37
Commissioning –Workflow ..................................................................................37
Step 1, Activating the System........................................................................................ 38
Step 2, Pairing Power Optimizers to the Inverter .......................................................... 39
Step 3, Verifying Proper Operation ............................................................................... 41
Step 4, Reporting and Monitoring Installation Data...................................................... 42
Chapter 5, Replacing and Adding System Components ......................46
Modifying an Existing Installation........................................................................46
Replacing the Fans .................................................................................................48
Chapter 6, Setting Up Communication..................................................50
Communication Dataflow......................................................................................50
Communication Types ...........................................................................................50
Creating an RS232 (UART) Connection..............................................................52
Creating an Ethernet (LAN) Connection.............................................................53
Creating an RS485 Bus Connection......................................................................56
Verifying the Connection.......................................................................................59
Troubleshooting Communication .................................................................................. 60
Chapter 7, Inverter User Interface.........................................................61
Inverter LCD Panel and LEDs..............................................................................61
Inverter LCD Panel and User Buttons ........................................................................... 62
Configuring the Inverter Using the LCD Panel and User Buttons....................67
Inverter Configuration Menu Options ........................................................................... 71
Configuring the Inverter Using the SolarEdge Configuration Tool..................74
Appendix A, Errors and Troubleshooting.............................................75
Appendix B, Technical Specifications....................................................81
Three Phase Inverter..............................................................................................81
OP250-LV, OP300-MV andOP400-MV..................................................................83
PB250-AOB and PB350-AOB ...............................................................................84
PB250-TFI and PB350-TFI Power Optimizer.....................................................85
Appendix C, Power Optimizer Mechanical Specifications ..................87
OP250-LV, OP300-MV, OP400-MV Power Optimizers.....................................88
PB250-AOB and PB350-AOB Power Optimizers................................................89
PB250-TFI and PB350-TFI Power Optimizer.....................................................90

Handling and Safety Instructions
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
6
Handling and Safety Instructions
During installation, testing and inspection adherence to the following
handling and safety instructions is mandatory.
Safety Symbols
The following safety symbols are used throughout this document.
Familiarize yourself with the symbols and their meaning before installing
or operating this instrument.
WARNING!
Denotes a hazard. It calls attention to a procedure that, if not correctly performed or
adhered to, could result in injury or loss of life. Do not proceed beyond a warning
note until the indicated conditions are fully understood and met.
CAUTION:
Denotes a hazard. It calls attention to a procedure that, if not correctly performed or
adhered to, could result in damage or destruction of the instrument. Do not
proceed beyond a caution sign until the indicated conditions are fully understood
and met.
NOTE:
Denotes additional information about the current subject.
IMPORTANT SAFETY FEATURE:
Denotes information about safety issues.

Handling and Safety Instructions
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
7
Instructions
WARNING!
Do not remove the inverter cover before five minutes have elapsed after
disconnecting all sources of power. Only use lockable connectors for DC input.
Otherwise, there is a risk of electric shock form energy stored in the capacitor.
WARNING!
Before operating the Three Phase Inverter, ensure that the power cable and wall
outlet have been grounded properly.
WARNING!
The cover must only be opened after shutting off the AC power, disconnecting the
DC cables and waiting five minutes.
WARNING!
Repairs or testing under power must only be performed by qualified SolarEdge
technicians who are familiar with and qualified to work with this Three Phase
Inverter.
WARNING!
This unit is not intended to be opened by a user. It must only be opened by a
qualified technician for installation and maintenance purposes.
CAUTION:
This unit must be operated under the specified operating specifications, as
described in the technical specification document.

Support and Contact Information
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
8
Support and Contact Information
If you have technical problems concerning our products, please contact us:
USA & Worldwide Support Line: +1.650.319.8843
Germany: +49.89.4161703-30
France: +33.(0)970.465.662
Israel: +972.73.2403118
Fax: [phone]
Email to: [e-mail]
Before contact, please gather the following information:
Inverter and power optimizer type.
Serial number of the inverter and the power optimizer in question.
The error indicated on the inverter screen or on the SolarEdge
Monitoring Portal.
System configuration information, including the type and number of
modules connected and the number and length of strings.
The communication method to the SolarEdge server.
The Support option on the top right of the SolarEdge Configuration
Tool’s main window can be used to automatically collect all relevant
information to be sent to SolarEdge Professional Services for support. This
option is described in detail in the SolarEdge Configuration Tool Software
Guide.

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
9
Chapter 1
Introducing the SolarEdge
Power Harvesting System
What is the SolarEdge Power
Harvesting Solution?
The SolarEdge power harvesting solution maximizes the power output from
any type of solar PV installation while reducing the average cost per watt.
The sections below describe each of the system’s components.
SolarEdge Power Optimizer
SolarEdge power optimizers can be connected to existing PV modules in
order to maximize power harvesting by locally performing Maximum
Power Point Tracking (MPPT) at the PV module level.
The power optimizers keep the string voltage fixed, regardless of the length of
the string and of the environmental conditions. Each SolarEdge power
optimizer directly transmits performance data from every PV module over the
power line.
Three types of power optimizers are provided by SolarEdge, as follows:
Module Add-On Solution, connected during installation to one PV
module. P/N: OP250-LV, OP300-MV and OP400-MV, PB250-AOB,
PB350-AOB.
Thin Film Solution (TFI), connected during installation to between
one and four PV modules. P/N: PB250-TFI and PB350-TFI.
Module Embedded Solution (CSI), is supplied embedded into a PV
module.

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
10
You may refer to the SolarEdge power optimizer datasheets in order to
determine which power optimizer is most suitable for you requirements.
Figure 1: Add-On Box Solution
Three Phase Inverter
The Three Phase Inverter efficiently converts DC power received from the
PV modules into AC power that can be fed into the main circuit board of
the site and from there to the grid. The inverter also receives the monitoring
data from each power optimizer and transmits it to a central server (called
the Monitoring Server) through an Ethernet network to an external modem
connection.
Figure 2: Three Phase Inverter
Top
Front
Bottom
Heat Sink
LCD
Mounting Hole
Mounting Hole

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
11
Three Phase Inverter Package Contents
The following lists the contents of the Three Phase Inverter installation
package:
One SolarEdge Three Phase Inverter.
One wall-mounting bracket.
Two flat head screws for fastening the inverter to the wall-mounting
bracket.
User Guide.
Warranty Card.
CD containing literature (manual, application notes and data sheets)
and software.
SolarEdge Monitoring Portal
The SolarEdge Monitoring Portal enables you to monitor the technical and
financial performance of one or more SolarEdge Photovoltaic sites. It
provides information about present and past performance of each PV
module individually and about the system as a whole.
NOTE:
You may refer to the SolarEdge Monitoring Portal User Guide for more information
about this option.

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
12
Installation Workflow
The following provides an overview of the workflow for installing and
setting up a new SolarEdge site. Most of these procedures can also be used
for adding components to an existing SolarEdge site.
Step 1
Step 2
Step 3
Step 4
Step 5
Step 6
Page 15
Page 25
Page 37
Page 42
Page 50
Page 67
Installing the Inverter and
Connecting the String to the
Inverter
Commissioning and Activating
the Installation
Recording Power Optimizer Serial
Numbers
Connecting the Inverter to the
SolarEdge Monitoring Server
Configuring the Inverter
Connecting Power Optimizers
to Panels and to a String

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
13
Transport and Storage
Three Phase Inverter Transport
The Three Phase Inverter should be transported in its original packaging,
facing up and without exposing the Three Phase Inverter to unnecessary
shocks. If the original package is no longer available, a similar box can be
used which can withstand the weight of the Three Phase Inverter (25 kg),
has a handle system and can be closed fully.
Three Phase Inverter Storage
Store the Three Phase Inverter in a dry place where ambient temperatures
are always between -25°C and +60°C.
Equipment List
Standard tools can be used during the installation of the SolarEdge system.
The following is a recommendation of the equipment to be used when
installing a SolarEdge system:
Allen screwdriver for M6 and M5 screw types.
Flat Head screwdriver.
Electrical screwdriver (tester).
Drilling machine and bits suitable for a wall or pole, where the inverter
mounting bracket is installed.
Suitable screws for attaching the inverter mounting bracket to a wall.
M8 screws for attaching the power optimizer to the racking.
Wire cutters.
Wire strippers.
Voltmeter.

Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
14
For installing the communication option, you may also need the following:
For Ethernet:
RJ45 connectors
CAT5 twisted pair Ethernet cable
RJ45 crimping tool
For RS485:
Four- or six-wire twisted pair telephone cable
RJ11 six-pin connector (also known as RJ25)
RJ11 crimping tool

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
15
Chapter 2
Installing the Power
Optimizers
Applicable Notes and Warnings
The following notes and warnings apply when installing the SolarEdge
power optimizers:
NOTE:
The power optimizer is waterproof and has no need for shelter. The power optimizer
can be placed in any orientation, meaning there is no up side.
NOTE:
The power optimizer should be mounted in a location that is either ventilated or that
has a free space of air around it for heat dissipation.
NOTE:
Mounting brackets are suited to either a flat surface or a pole and can be attached
to any surface texture.
CAUTION:
If installing directly on the module or module frame, first consult the module
manufacturer for guidance regarding location and the impact on the module warranty.
IMPORTANT SAFETY FEATURE:
PV modules with SolarEdge power optimizers are safe. They only carry a low safety
voltage before the Three Phase Inverter is turned on.
IMPORTANT SAFETY FEATURE:
As long as the power optimizers are unconnected to the inverter and the inverter is
OFF, the power optimizers will output a safe 1V voltage during installation.

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
16
WARNING!
Before performing this step, turn OFF the Three Phase Inverter byturning off the
ON/OFF switch at the bottom of the inverter and the DC switch of the main circuit board.
All inverters in an installation site should be switched OFF in this manner. This step is
required to verify that the power optimizers will output a safe 1V voltage during
installation.
CAUTION:
The module connectors must be mechanical compatible to the power optimizers.
Otherwise, the installed SolarEdge system may be unsafe or may cause functional
problems, such as ground faults, which can cause the inverter to shut down. The
usage of mechanically incompatible connectors is not covered by the SolarEdge
warranty.
SolarEdge power optimizers and inverters use connectors from the following
manufacturers:
Multi Contact MC4
Amphenol H4
Lumberg LC4
Tyco keyed connector
Huber suhner Raddox
The following must be done in order to ensure mechanical compatibility between
SolarEdge power optimizers and the modules to which they are connected:
Use identical connectors from the same manufacturer and type on both the
power optimizers and on the modules.
or
Verify that the connectors are compatible in the following ways:
▪The connector manufacturer should explicitly verify compatibility with the
SolarEdge connector.
▪A third-party test report must be performed by one of the listed external labs
(TUV, VDE, Bureau Veritas UL, CSA, InterTek), who will verify the compatibility of
the connectors.

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
17
Step 1, Mounting the Power
Optimizers
NOTE:
If you are installing modules with embedded power optimizers, then skip to Step
3, Connecting Power Optimizers in Strings on page 22.
Determine the mounting location of each power optimizer. The power
optimizer should be mounted in a place where it can be mounted
securely using both mounting holes. It must also be located near
enough so that the power optimizer can connect to a single PV module
(for the OP250-LV, OP300-MV, OP400-MV, PB250-AOB and PB350-
AOB models) or the power optimizer can connect to up to four PV
modules for the PB250-TFI and PB350-TFI models, per your plan.
Mark all mounting hole locations.
Each power optimizer must be attached to the rack using both mounting
holes.
Drill the holes.
CAUTION:
Do not drill through the power optimizer or through the mounting holes. The
vibrations created by the drill can damage the power optimizer.
Mount one power optimizer at each location using M8 screws and
washers.
Verify that the power optimizer is securely attached.

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
18
Step 2, Connecting Each PV
Module to a Power Optimizer
OP250-LV, OP300-MV and OP400-
MV
These power optimizers connect to a single PV module via its two inputs (a
plus and a minus).
Figure 3: OP250-LV, OP300-MV and OP400-MV
Input +
Input -
Output -
Output +

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
19
PB250-AOB and PB350-AOB
These power optimizers connect to a single PV module via its two inputs (a
plus and a minus).
Figure 4: PB250-AOB and PB350-AOB
The following shows the required clearance around the power optimizer.
Figure 5: Clearance
1” (2.5 cm)
1” (2.5 cm)
1” (2.5 cm)
Input +
Input -
Output -
Output +

Installing the Power Optimizers
SolarEdge Installation Guide for Three Phase Inverters –EU –Version 1.5
20
The following shows the required clearance on the top and bottom of the
power optimizer.
Figure 6: Clearance –Side View
PB250-TFI and PB350-TFI
These power optimizers connect to up to four PV modules via its inputs.
These power optimizers have four pairs of inputs (each pair comprises one
Plus (+) and one Minus (-) connector) and two outputs (one Plus (+) and
one Minus (-)), as shown below.
Figure 7: PB250-TFI and PB350-TFI
Output -
Output +
Inputs +
Inputs +
Inputs -
Inputs -
1” (2.5 cm)
1” (2.5 cm)
