SOLTEK SL-75KIV User manual

SL-75KIV
USER MANUAL V1.2
R

• AMD Athlon ThunderbirdTM, and DuronTM processors are trademarks of AMD Corporation.
• VIA, KT- 33A, VT8363A and VT82C686B are trademarks of VIA Corporation.
NOTICE
his Users’ Guide & Technical Reference is to help system
manufacturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer inc. Provides this manual “As is “ without war-
ranty of any kind, either express or implied, including but not limited
to the implied warranties or conditions of merchantability or fitness
for a particular purpose. In no event shall Soltek Computer inc. be
liable for any loss or profits, loss of business, loss of use or data,
interruption of business, or for indirect, special, incidental, or con-
sequential damages of any kind, even if Soltek Computer inc. has
been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Copyright © 2001 So tek Computer Inc. A Rights Reserved.
T
Product Model : SL-75KIV
Manual Revision : V1.2
Release Date : Jul 2001

SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306-3, Ta-Tung Rd, Sec. , Hsi-Chih, Taipei-
Hsien, Taiwan, R.O.C.
Telephone : [phone]
Fax : [phone]
E-mail : [email protected]
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Sydneystraat 52-54 3047 BP Rotterdam, the Nether-
lands
Telephone : 3 - 0-2457492
Fax : 3 - 0-2457493
E-mail : [email protected]
Web site : http://www.soultech-europe.com

75KIV
4
C O N T E N T
CHAPTER 1 INTRODUCTION .................................... 8
- MAINBOARD SPECIFICATION .................................................... 9
- - PROCESSOR ..................................................................................... 9
- -2 CHIPSET ............................................................................................. 9
- -3 ADVANCED HIGH PERFORMANCE DRAM CONTROLLER............. 9
- -4 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP)
CONTROLLER .................................................................................... 9
- -5 MULTI-I/O FUNCTION ........................................................................ 9
- -6 EXPANSION SLOTS ......................................................................... 0
- -7 AWARD BIOS V6.0, SUPPORTING ................................................. 0
- -8 SOUND CONTROLLER .................................................................... 0
- -9 POWER MANAGEMENT .................................................................. 0
- - 0 FORM FACTOR ..............................................................................
- - HARDWARE MONITORING ...........................................................
- - 2 OTHERS .........................................................................................
-2 MOTHERBOARD LAYOUT --- 75KIV ......................................... 2
-3 CHIPSET DIAGRAM--- 75KIV .................................................... 3
CHAPTER 2 HARDWARE SETUP............................ 15
2- CPU INSTALLATION .................................................................. 6
2-2 MEMORY INSTALLATION .......................................................... 8
2-3 HDD/FDD INSTALLATION .......................................................... 9
2-4 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE... 2
2-4- INFORMATION ON AMD SOCKET 462 PROCESSOR ................... 2
2-4-2 CPU EXTERNAL FREQUENCY SETTING (BY SW ) ...................... 22
2-4-3 PROCESSOR CORE VOLTAGE SELECT (BY SW2 DIP -DIP6) .... 23
2-4-4 FREQUENCY RATIO SELECT (BY SW3 DIP -DIP5) ...................... 24
2-5 JUMPER SETTING FOR DEVICES ON BOARD: ...................... 25
2-5- JUMPER JBAT FOR CLEARING CMOS DATA: ............................. 25

Content
5
2-5-2 USB SELECT (BY JP 3/JP 5) ....................................................... 26
2-5-3 USB2 HEADER SELECT (BY JP 2/JP 4) ...................................... 26
2-5-4 USB WAKE UP (BY JUSB ) ............................................................. 27
2-5-5 ONBOARD AC97 CODEC SELECT (BY JCOD ) ............................ 27
2-6 CONNECTORS CONFIGURATIONS ......................................... 28
2-6- ONBOARD FAN CONNECTOR (FAN /FAN2/FAN3)........................ 28
2-6-2 WAKE ON LAN (WOL ) .................................................................... 29
2-6-3 CD-ROM AUDIO CONNECTOR (CD-IN /CD-IN2) ........................... 29
2-6-4 THERMAL SENSOR CONNECTOR (RT2) ....................................... 30
2-6-5 COMPLEX HEADER J2&J3 ............................................................. 3
2-6-6 CHASSIS PANEL CONNECTOR ..................................................... 32
2-6-7 ATX POWER SUPPLY CONNECTOR ............................................. 33
2-6-8 PS/2 MOUSE AND PS/2 KEYBOARD ............................................. 33
2-6-9 COMMUNICATION AND NETWORKING RISER SLOT (CNR) ........ 34
2-6- 0 SECOND USB HEADER (USB2) .................................................... 35
2-6- IRQS DESCRIPTION FOR VARIOUS DEVICES ............................ 36
CHAPTER 3 SOFTWARE SETUP ............................ 38
ABOUT SUPPORT CD ..................................................................... 38
3- VIA CHIPSET DRIVER INSTALLATION (4-IN- DRIVER) ......... 39
3-2 AC97 AUDIO CODEC DRIVER INSTALLATION ........................ 42
3-3 HARDWARE MONITOR INSTALLATION ................................... 44
CHAPTER 4 BIOS SETUP ........................................ 47
THE BIOS ......................................................................................... 47
4- WHAT IS BIOS SETUP ............................................................... 48
4-2 HOW TO RUN BIOS SETUP ...................................................... 48
4-3 WHAT IS CMOS ......................................................................... 48
4-4 WHAT IS POST .......................................................................... 48
4-5 BIOS UPGRADE......................................................................... 48
4-5- BEFORE UPGRADING BIOS ........................................................... 49
4-5-2 UPGRADE PROCESS ...................................................................... 49

75KIV
6
4-6 BIOS SETUP--- CMOS SETUP UTILITY.................................... 53
4-6- STANDARD CMOS SETUP .............................................................. 54
4-6-2 ADVANCED BIOS FEATURES ......................................................... 57
4-6-3 ADVANCED CHIPSET FEATURES .................................................. 62
4-6-4 INTEGRATED PERIPHERALS ......................................................... 67
4-6-5 POWER MANAGEMENT SETUP ..................................................... 7
4-6-6 PNP / PCI CONFIGURATION ........................................................... 78
4-6-7 SMARTDOC ANTI-BURN SHIELD ................................................... 82
4-6-8 FREQUENCY/VOLTAGE CONTROL ................................................ 85
4-6-9 LOAD OPTIMIZED DEFAULTS......................................................... 86
4-6- 0 SET SUPERVISOR / USER PASSWORD ...................................... 88
4-6- SAVE & EXIT SETUP ...................................................................... 89
4-6- 2 EXIT WITHOUT SAVING ................................................................ 89
APPENDICES ................................................................. 91
APPENDICES- TECHNICAL TERMS INTRODUCTION ............... 92
APPENDICES-2 IDENTIFYING BIOS VERSION AND BIOS PART
NUMBER............................................................... 93
APPENDICES-3 IDENTIFYING MAINBOARD \ MODEL NUMBER .. 95

Content
7
Motherboard
Support CD
User’s Manual
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable
ATA66/ 00 IDE Cable
RS232 Cable
FDD Cable
ITEMLIST CHECKUP

75KIV
8
CHAPTER 1
INTRODUCTION
• This chapter briefly introduces the characteristics of this mainboard. It
includes the information regarding the chipset, CPU types, built-in
functions and layout. Users will have more ideas about mainboards after
reading this chapter.
NJN=MAINBOARD SPECIFICATION
NJO=MAINBOARD LAYOUT
NJP=CHIPSET DIAGRAM
THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :

Chapter 1 Introduction
9
1-1 MAINBOARD SPECIFICATION
1-1-1 PROCESSOR
• Supporting AMD Athlon Thunderbird processors up to .5GHz.
• Supporting AMD Athlon Duron processors up to .2GHz.
• Supporting AMD Athlon4 processors.
• Supporting processor VID (voltage ID) and FID (frequency ID) auto detection.
• Supporting AMD Athlon processor with 200 and 266MHz Front Side bus.
1-1-2 CHIPSET
• North Bridge VIA VT8363A (KT- 33A) system controller High Performance
Athlon CPU Interface.
• South Bridge VIA VT82C686B.
1-1-3 ADVANCED HIGH PERFORMANCE DRAM
CONTROLLER
• Supporting PC 33 and PC 00 SDRAM and Virtual Channel Memory (VCM)
SDRAM up to 3 DIMMs.
• 64-bit data width and 3.3V DRAM interface.
• Supporting up to .5 GB memory space.
• Supporting Different DRAM types used in mixed combinations.
• PCI-2.2 compliant, 32 bit 3.3V PCI interface with 5V tolerant inputs.
1-1-4 FULL FEATURED ACCELERATED GRAPHICS PORTS
(AGP) CONTROLLER
• Synchronous and pseudo-synchronous with the host CPU bus with optimal
skew control PCI AGP Mode 33MHz/66MHz/ 00MHz DDR 3x synchronous.
• Supporting 66MHz x, 2x and 4x modes for AD and SBA signaling.
• AGP v2.0 compliant.
1-1-5 MULTI-I/O FUNCTION
• Two UARTs for complete Serial Ports.
• One dedicated IR connector supporting:
--A third serial port dedicated to IR function either through the two complete serial
ports or the third delicated port Infrared-IrDA (HPSIR) and ASK( Amplitude Shift
Keyed) IR.

75KIV
10
• Multi-mode parallel connector supporting:
--Standard mode, ECP and EPP.
• Floppy Disk connector supporting:
--Two FDDs with drive swap function.
• Universal Serial Bus connector supporting:
--USB v . and Intel Universal HCI v . compatible.
--2 built-in USB connectors, in addition to one internal USB header which requires
a USB cable to support 2 more optional USB ports.
• PS/2 keyboard connector.
• PS/2 Mouse connector.
1-1-6 EXPANSION SLOTS
• Three PCI bus Master slots.
• One CNR slot.
• One AGP 4x mode slot.
• Three DIMM slots.
1-1-7 AWARD BIOS V6.0, SUPPORTING
• Plug & Play V .0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• BIOS writing protection.
• SMARTDOC ANTI-BURN SHIELD.
• RedStorm Overclocking Tech.
1-1-8 SOUND CONTROLLER
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1-9 POWER MANAGEMENT
• ACPI .0 compliant (Advanced Configuration and Power Interface).
• APM V .2 compliant (Advanced power management).
• Supporting ACPI suspend STR mode (Suspend To RAM) and POS mode
(Power On Suspend).
• Supporting Wake On LAN (WOL) & Wake On Modem.
• Supporting real time clock (RTC) with date alarm, month alarm, and cen

Chapter 1 Introduction
11
tury field.
• Supporting USB boot-up Function.
1-1-10 FORM FACTOR
• Micro ATX form factor, 4 layer PCB.
• Motherboard size: 2 .0cm x 24.3cm.
1-1-11 HARDWARE MONITORING
• Programmable control, status, to provide monitoring and alarm for flexible
desktop management of hardware temperature. (software included in sup-
port CD)
• 5 positive voltage statuses monitoring.
• 2 temperature statuses monitoring.
• 2 fan speeds statuses monitoring.
1-1-12 OTHERS
• Clock generator supporting MHz linear clock setting.

75KIV
12
1-2 MOTHERBOARD LAYOUT --- 75KIV
• Default Setting: 00MHz CPU External clock.
SOCKET A
USB0
USB1
PS/2 MOUSE PS/2 K/B
LPT1
COM1COM2
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
ATX POWER
VIA
VT8363A
DIMM1 DIMM2 DIMM3
IDE1
IDE2
FDD1
SW1
SW3
ON DIP
1 2 3 4 5
SW2
ON DIP
1 2 3 4 5 6
3 1
JUSB1
FAN1
1 3
RT2
AGP 4X
PCI 1
PCI 2
PCI 3
PCI 1
PCI 2
PCI 3
CNR 1
VIA
VT82C
686B
Li
Battery
1 11
FAN3
1 3
1 3
JBAT1
CON1
SAPK RST PLED SLED
HDD/LED IR PWR SUSPEND
++
--
+-
16 30 1 15
RT2
JP12
JP14
JP15
JP13
1 3 1 3
16
1
USB2
1 3
JCOD1
AC'97
Codec
FLASH BIOS
41 41
CD_IN1 CD_IN2
WOL1
FAN2
1 3
1 3
C ock
Generator
ON DIP
1 2 3 4 5
LED1

Chapter 1 Introduction
13
1-3 CHIPSET DIAGRAM--- 75KIV
• The KT- 33A / VT82C686B chipset is a high performance, cost-effective
and energy efficient system controller for the implementation of AGP / PCI
/ CNR desktop personal computer system based on 64-bit Socket-A (AMD
Athlon) processors.
KT133A
VT8363A
North Bridge
552 BGA
South Bridge
352 BGA
VT82C
686B
Power P ane & Periphera Contro
GPIO and ACPI Events
Hardware Monitoring Inputs
Keyboard / PS2 Mouse
Seria Ports 1 and 2
Para e Port
F oppy Drive Interface
MIDI / Game Ports
RTC Crysta
PCLK
SMBus
C ock
Generator
PCISTP#
CPUSTP#
MCLK
In
Data
Address
Out
SDRAM
C ock
Buffer
GCLK
CFWDRST CONNECT
PROCRDY
GCKRUN#
AGP Bus
PCI Bus
SUSCLK,
SUSST1#
PCKRUN#
ATA 33/66/100
USB Ports 0 - 3
CNR
AC97 Link
Memory Bus
CKE
HCLK
PCLK
SYSCLK, SYSCLK#
INTR, NMI, SMI#, STPCLK#,
IGNNE#, FERR#, A20M#,
PWROK, INIT#, RESET#
Ath on
Host CPU
3D Graphics
Contro er
AC97 Audio Codec
BIOS ROM
Diagram of KT133A System B ock Using the VT82C686B South Bridge

75KIV
14
MEMO

Chapter 2 Hardware Setup
15
CHAPTER 2
ATTENTION !!!
1. P ease refer to your processor insta ation or other
documentation attached with your CPU for more
detai ed insta ing instruction.
2. Insta ing a heat sink and coo ing fan is necessary for
proper heat dissipation from your CPU. Incorrect
insta ation may resu t in overheating and damage of
your CPU.
3. Before changing the setting of CPU Vcore from BIOS
program, user SHOULD make sure of correct specifi-
cation both of CPU CLOCK and RATIO. Incorrect set-
ting may cause damage to your CPU.
HARDWARE SETUP
OJN=CPU INSTALLATION
OJO=MEMORY INSTALLATION
OJP=HDD/FDD INSTALLATION
OJQ=FOR CPU FREQUENCY AND VOLTAGE
OJR=FOR DEVICE ON BOARD
OJS=CONNECTORS CONFIGURATION
OJT=VOICE DIAGNOSTIC FUNCTION
THIS CHAPTER CONTAINS THE FOLLOWING TOPICS :

75KIV
16
SOCKET 462
AMD
SOCKET 462
• Pull out the lever from the
socket, and then raise the le-
ver up to a 90-degree angle.
1
2-1 CPU INSTALLATION
• Take notice of the red circles
as shown below. While insert-
ing the CPU into the socket,
you can find out there is a defi-
nite pin orientation for CPU
and socket.
2
WARNING:
• Make sure that +5V DCV and +3.3 DCV capabilities of your power supply are
suitable for the processor.
• Any attempt to operate the AMD Athlon or Duron processor without a suitable
coolin Fan will dama e the processor and other components.

Chapter 2 Hardware Setup
17
AMD
SOCKET 462
• Make sure that the CPU is
placed into the socket tightly.
Then lower down the lever to
complete the CPU installation.
3

75KIV
18
Insta ing DIMM
• Make sure you have the correct memory module type for your mainboard.
• Insert the module(s) as shown below, DIMMs have 68-pins and two notches
that will be matched by the onboard DIMM socket. Memory modules are
installed by inserting them straight into the slot until they “click” in the right
place. They only fit in one direction, so do not force them in by a wrong
direction.
Removing DIMM
• Press down the holding clips on both sides of a DIMM socket and the
module will be released from it.
168-Pin DIMM Notch Key Definitions(3.3V)
DRAM Key Position Vo tage Key Position
Unbuffered 3.3V
WARNING!!!
• Make sure to unplu your power supply before addin or removin memory mod-
ules or other system components. Failure to do so may cause severe dama e to
both your mainboard and expansion cards.
• Be careful when insertin or removin DIMM. Forcin a DIMM in or out of a socket
improperly may dama e the memory module or the socket. Some DIMMs which con-
tain EDO or FTP DRAM are incompliant with the mainboard. The M/B supports 3.
3V true SDRAM DIMMs only.
2-2 MEMORY INSTALLATION

Chapter 2 Hardware Setup
19
2- 3 HDD/FDD INSTALLATION
• To install HDD (Hard Disk Drive), you may connect the cable’s blue
connector to the mainboard’s primary (IDE ) or secondary IDE connector,
and then connect the gray connector to your slave device and the black
connector to your master device. If you install two hard disks , you must
configure the second drive to Slave mode by setting its jumper accordingly.
Please refer to your hard disk documentation for the jumper settings.
black connector
gray connector
blue connector
IDE Cab e
red line
Hard Disk Drive Connector:
Orient the red line on the IDE ribbon
cable to Pin .
1 3
1 3
JP6
JP7
3
1
3
1
JP8 JP9
1 3
1 3 1 3
1 4
1 4
JP3
JP4 JP5
1
3
JP2
3
1
JBAT1
FAN2
FAN1
LPT1
COM2 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
JWOL1
SW1
CD_IN2
CD_IN1
AMR
AGP 4X
ISA
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
DIMM1 DIMM2 DIMM3
FDC1 IDE2 IDE1
SOCKET 370
RT2
JP14
RT1
ATX POWER
FLASH BIOS
Li
Battery
ON DIP
1 2 3 4 5 6
USB2
1
16
AC'97
Codec
C ock
Generator
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
VIA
694X
VIA
VT82C
686B
SPK RST PWR/LED T/LED
HDD/LED IR PWR SMI
J2 J3
++
--
+-
1 15 1 15

75KIV
20
FDD Cab e
To st Floppy Drive To mainboard
To 2nd Floppy Drive
red line
• To install FDD (Floppy Disk Drive), connect the end with single connector
to the mainboard, and connect other end with two connectors to the floppy
drives.
F oppy Disk Drive Connector:
Orient the red line on the
floppy ribbon cable to Pin .
1 3
1 3
JP6
JP7
3
1
3
1
JP8 JP9
1 3
1 3 1 3
1 4
1 4
JP3
JP4 JP5
1
3
JP2
3
1
JBAT1
FAN2
FAN1
LPT1
COM2 COM1
GAME/MIDI PORT
LINE OUT
LINE IN
MIC
JWOL1
SW1
CD_IN2
CD_IN1
AMR
AGP 4X
ISA
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
DIMM1 DIMM2 DIMM3
FDC1 IDE2 IDE1
SOCKET 370
RT2
JP14
RT1
ATX POWER
FLASH BIOS
Li
Battery
ON DIP
1 2 3 4 5 6
USB2
1
16
AC'97
Codec
C ock
Generator
PS/2 MOUSE PS/2 K/B
upper
ower
USB1 USB0
upper
ower
VIA
694X
VIA
VT82C
686B
SPK RST PWR/LED T/LED
HDD/LED IR PWR SMI
J2 J3
++
--
+-
1 15 1 15
