SOMFY SITUO RTS User manual

www.somfy.com
Operating and installation guide
Situo RTS
Ref. 5054470A

1. Brief introduction to the Situo RTS control point 3
1.1 What is the Situo RTS for? 3
1.2 A few denitions 3
2. Safety - Important information 4
2.1 Installation and commissioning 4
2.2 Operating 4
2.3 Environment 4
3. Content of the kit and tools required 5
3.1 List of parts 5
3.2 Tools required 5
4. The Situo RTS in detail 5
4.1 Components 5
4.2 Technical data 6
5. Adding a new Situo RTS 6
5.1 Identifying the original control point 6
5.2 One-touch point 7
5.3 Point with up/STOP/down buttons 13
5.4 Timer 16
5.5 Telis 1 RTS/Telis Soliris RTS remote controls 18
5.6 Telis 4 RTS/Telis 4 Soliris RTS remote controls 21
6. Replacing a lost or broken control point 23
6.1 Sole control point lost or broken 23
6.2 One lost or broken control point amongst others 23
7. Mounting the bracket 24
8. Everyday use of the Situo RTS 25
8.1 Up and down buttons 25
8.2 My button 25
8.3 Replacing the battery 25
8.4 Maintenance 26
9. Problems with the Situo RTS? 27
Contents
2
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.

Somfy’s expertise delivers satisfaction guaranteed.
Thank you for choosing a Somfy Situo RTS.
Before installing and using the Situo RTS, please read this guide
carefully.
Somfy solutions animate your windows and entrances to bring your
whole house alive. Somfy solutions are designed so that everyone can
enjoy the benets of the products in their home, based on their specic
requirements.
In this guide, the term ‘product’ can include your awning, blind, curtain,
garage door, gate, projection screen, roller shutter.
Well thought-out and easy to use, Somfy solutions are one of life’s little
daily pleasures, making home life more enjoyable.
1. Brief introduction to the Situo RTS control
point
1.1 What is the Situo RTS for?
The Situo RTS is a wall-mounted, wireless, radio control point. It is
compatible only with products tted with Radio Technology Somfy (RTS)
(e.g. roller shutter motors, blinds motors, etc).
The Situo RTS is used as an individual control to control a single product
(e.g. one roller blind) at a time.
1.2 A few denitions
Installation
All of the Radio Technology Somfy products a house is equipped with.
Favourite position:
The favourite position is your ideal position for your product in certain
common situations, for example, your awning partially extended when
you are dining beneath it in summer but don't want to deprive your
houseplants of sunlight, your awnings or blinds partially closed to shield
your computer from the afternoon sunlight.
3
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved. 3

4
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
2. Safety - Important information
2.1 Installation and commissioning
Before installing and using the Situo RTS, please carefully read these
instructions, which describe how to install, commission and operate the
Situo RTS.
Never begin installing without rst checking the compatibility of the Situo
RTS with the associated equipment and accessories.
Any incorrect use will invalidate the warranty and Somfy's liability.
2.2 Operating
Somfy recommends that at least one control point is located close to -
the product or group of products.
Do not allow children to play with the xed control points. Keep remote
-
controls out of the reach of children.
Monitor the product (especially roller shutter/awning/garage door/gate)
-
while it is moving, especially during commissioning of the Situo RTS
and keep people at a distance until the product is completely closed.
Make sure the power supply to the roller shutter/awning is turned off
-
before any maintenance operation in the vicinity of the product (for
example, when cleaning windows near the blind).
Avoid moving the product if ice has formed in it, unless the motor is
-
tted with anti-freeze protection.
Do not leave the product near a window in full sun: the Situo RTS
-
cannot withstand temperatures above 60°C.
Do not immerse or soak the Situo RTS in any liquid.
-
Only use maintenance products recommended by Somfy (see para--
graph 8.4).
Frequently check the product (e.g. blind) to detect any defects in
-
balance or any signs of wear. Do not use the product if a repair or
adjustment is required.
2.3 Environment
Damaged electrical or electronic products, such as used batteries,
should not be disposed of with household waste. Please take them to
a collection point or an approved centre to ensure they are recycled
correctly.

5
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
3. Content of the kit and tools required
3.1 List of parts
Before starting installation and commissioning of the Situo RTS, check -
that all parts listed in the table below are present in the correct quantity
(Q):
No. Components Q.
1Front cover of the Situo RTS 1
2Wall support 1
3Plug 2
4Screw 2
3.2 Tools required
Insulated athead electricians•
screwdriver
3 mm drill bit and drill•
Pencil•
4. The Situo RTS in detail
4.1 Components
A. Up button
B. STOP/my button
C. Down button
D. Indicator light
E. PROG button
F. Wall support
1
3
2
4
C
B
A
E
D
F

6
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
4.2 Technical data
Dimensions in mm (H x L x W): 120 x 38.5 x 19.5.
Operating temperature: 0°C to + 60°C.
Index protection rating: Inside use, in a dry room - IP 30.
Frequency: 433.42 MHz.
Range: 20m through two concrete walls; 200m in open space.
Battery: 3 V, type - CR 2430.
5. Adding a new Situo RTS
5.1 Identifying the original control point
5.1.1 Installation recommendations
To add a Situo RTS, use the control point linked to the product -
which controls only this product: pressing the up or down button only
causes movement of the product to which the new Situo RTS must be
connected.
Caution! If there is no longer a control point linked to the product (all the
control points are broken or have been lost), contact the Somfy assis-
tance service.
On some products, inputs in programming mode and adding or dele-
-
ting a control point are signalled by a series of “beeps” emitted by the
motor. On other products this is signalled by a brief movement of the
product.
Caution: if the product does not emit a beep or make a brief movement,
please contact the Somfy assistance service.
Place the product into the midway position before installing the new
-
Situo RTS so that the movements can easily be seen.

7
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
5.1.2 Original control points
F-ind the original control point in the list
below and refer to the relevant para-
graph to add the new Situo RTS:
1) Control point xed to the wall with
a single button, called a One-touch
point, see paragraph 5.2;
2) Control point xed to the wall with
up/STOP/down buttons called a Point
with up/STOP/down buttons, see
paragraph 5.3;
3) Programmer type control point,
called a Timer, see paragraph 5.4;
4a) Telis 1 RTS remote control, see
paragraph 5.6
4b) Telis Soliris RTS remote control,
see paragraph 5.6;
5a) Telis 4 RTS remote controls, see
paragraph 5.7;
5b) Telis 4 Soliris RTS remote controls,
see paragraph 5.7.
5.2 One-touch point
Move close to the product to install the
new Situo RTS.
5.2.1 Identifying the model
Check that the original control point -
has an elongated button.
Bring the product to the midway
-
position.
Remove the front cover from the one-
-
touch point:
One touch point with a white and grey front
cover
Gently remove the front cover with a -
at, pointed tool (such as a athead
screwdriver) where the white
section and the grey section join.
Lever it and lift the cover, without
-
using force, to detach the mounting
lugs from the front cover.
1 2 3
4a 4b 5a 5b

8
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
One-touch point with a white front cover:
Lever it with a at, pointed tool (such -
as a athead screwdriver), without
using force, around the upper section
of the front cover to detach it from its
mounting.
-Turn the front cover over to nd the
model:
If there is a metal plate inscribed
-
PROG next to the battery: model A.
If there is no metal plate inscribed
-
PROG next to the battery: model B.
5.2.2 Adding the Situo RTS
Model A:
-Make a contact between the PROG
metal plate (a) on the electrical circuit
and the battery bracket using a athead
screwdriver until the product moves
briey (or emit a series of 3 beeps):
the programming function of the control
point is activated for approximately
2 minutes.
-Take the front cover of the new Situo
RTS and turn it over to access the
PROG button (E).
Briey press the PROG button (E) on
-
the new Situo RTS: the product will
move briey again (or emit a series of
8 beeps) to indicate that the new Situo
RTS has been programmed.
A B
E

9
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
If the original control point must be dele-
-
ted, go to paragraph 5.2.3 "Deleting an
original control point".
If the original control point is to be kept,
-
ret the front cover:
One-touch point with a white and grey front
cover:
Insert the mounting lugs into their -
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to t the front cover in its bracket.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
One-touch point with a white front cover:
Ret the front cover on its bracket.-
Refer to the “Mounting the bracket” -
section to nish installing the Situo
RTS.
Model B:
-Remove the battery from the original
control point using a plastic object.
Press on the centre section of the one-
-
touch point button.
Ret the battery in the base of its brac-
-
ket (with text legible).

10
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
Press the button again until the product -
moves briey (or emits a series of 3
beeps): the programming function
on the control point is activated for
approximately 2 minutes.
Take the front cover of the new Situo
-
RTS and turn it over to access the
PROG button (E).
-Briey press the PROG button (E) on
the new Situo RTS: the product will
again move briey (or emit a series of
8 beeps) to indicate that the new Situo
RTS has been programmed.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
If the original control point must be dele-
-
ted, go to paragraph 5.2.3 "Deleting an
original control point".
If the original control point is to be kept,
-
ret the front cover:
One-touch point with a white and grey front
cover:
Insert the mounting lugs into their -
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to t the front cover in its bracket.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
One-touch point with a white front cover:
Ret the front cover on its bracket-
Refer to the “Mounting the bracket” -
section to nish installing the Situo
RTS.
E

11
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
5.2.3 Deleting an original control point
(optional)
N.B.: Only follow this procedure if use
of the original control point is no longer
required.
Model A:
Wait 5 minutes.-
-Take the front cover of the new Situo
RTS and turn it over to access the
PROG button (E).
Press the PROG button (E) on the new
-
Situo RTS until the product moves brie-
y (or emits a series of 3 beeps): the
programming function of the control
point is activated for approximately
2 minutes.
-On the original control point make a
contact between the PROG metal plate
on the electrical circuit and the battery
bracket using a athead screwdriver:
the product moves briey (or emits a
series of 8 beeps) to indicate that the
original control point has been deleted.
Press the one-touch point button: the
-
product does not move.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Remove the one-touch point.
-
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
E

12
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
Refer to the “Mounting the bracket” -
section to nish installing the Situo
RTS.
Model B:
Wait 5 minutes.-
-Take the front cover of the new Situo
RTS and turn it over to access the
PROG button (E).
Press the PROG button (E) on the new
-
Situo RTS with the tip of a pencil until
the product moves briey (or emits a
series of 3 beeps): the programming
function of the control point is activated
for approximately 2 minutes
-Remove the battery from the original
control point using a plastic object.
Press on the centre section of the one-
-
touch point button.
Ret the battery in the base of its
-
housing (with text legible).
Press the button on the front cover
-
again: the product moves briey (or
emits a series of 8 beeps) to indicate
that the original control point has been
deleted.
Press the one-touch point button: the
-
product does not move.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Remove the one-touch point.
-
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
E

13
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
5.3 Point with up/STOP/down
buttons
Move close to the product to install the
Situo RTS.
5.3.1 Checking the compatibility
Bring the product to the midway -
position.
Cut off the mains power supply.
-
Remove the front cover of the control -
point:
Gently remove the front cover with a
-
at, pointed tool (such as a athead
screwdriver) where the white section
and the grey section join.
Lever it and lift the cover, without
-
using force, to detach the mounting
lugs from the front cover.
-Turn the front cover over: the
PROG button is located next to the
battery (b).
Caution! Once the front cover has been
removed, if there is no PROG button
then the control point is not compatible:
the Situo RTS cannot be linked to the
product.
5.3.2 Adding the Situo RTS
Switch the mains power supply back -
on.
-Press the PROG button (b) on the origi-
nal control point until the product moves
briey (or emits a series of 3 beeps):
the programming function of the control
point is activated for approximately
2 minutes.
Take the front cover of the new Situo
-
RTS and turn it over to access the
PROG button (E).
b
b

14
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
-Briey press the PROG button (E) on
the new Situo RTS: the product will
again move briey (or emit a series of
8 beeps) to indicate that the new Situo
RTS has been programmed.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
If the original control point must be dele-
-
ted, go to paragraph 5.3.3 "Deleting an
original control point".
If the original control point is to be kept,
-
ret the front cover:
Insert the mounting lugs into their
-
notches on one side of the front
cover.
Press on the other side until it clicks,
-
to t the front cover in its bracket.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
5.3.3 Deleting an original control point
(optional)
N.B.: Only follow this procedure if use
of the original control point is no longer
required.
Wait 5 minutes.
-
-Take the front cover of the new Situo
RTS and turn it over to access the
PROG button (E).
Press the PROG button (E) on the new
-
Situo RTS until the product moves brie-
y (or emits a series of 3 beeps): the
E
E
14

15
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
programming function of the control
point is activated for approximately
2 minutes.
-On the original control point, briey
press the PROG button (b): the product
moves briey (or emits a series of 8
beeps) to indicate that the original
control point has been deleted.
Press the down button on the original
-
control point: the product does not
move.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Removing the original control point.
-
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
b

16
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
5.4 Timer
Move close to the product to install the
Situo RTS.
5.4.1 Checking the compatibility
-Bring the product to the midway
position.
Cut off the mains power supply.
-
Remove the front cover of the original -
control point:
Lever it with a at, pointed tool
-
(such as a athead screwdriver),
without using force, around the
upper section of the front cover to
detach it from its mounting.
-The PROG button is located on top
of the screen and is shaped like a
tab (c).
Caution! Once the front cover has been
removed, if there is no PROG button
then the control point is not compatible:
the Situo RTS cannot be linked to the
product.
5.4.2 Adding the Situo RTS
Switch the mains power supply back -
on.
-Press the tab (c) until the product moves
briey (or emits a series of 3 beeps):
the programming function of the control
point is activated for approximately
2 minutes.
Take the front cover of the new Situo
-
RTS and turn it over to access the
PROG button (E).
-Briey press the PROG button (E) on
the new Situo RTS: the product will
again move briey (or emit a series of
8 beeps) to indicate that the new Situo
c
c
E

17
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
RTS has been programmed.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
If the original control point must be dele-
-
ted, go to paragraph 5.4.3 "Deleting an
original control point".
If the original control point is to be kept,
-
ret the front cover:
Insert the front cover on its brac-
-
ket, allowing the buttons to come
through their housings.
Press the front until it clicks, to x
-
the front cover in its bracket.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
5.4.3 Deleting an original control point
(optional)
N.B.: Only follow this procedure if use of
the original timer is no longer required.
Wait 5 minutes.
-
Take the front cover of the new Situo -
RTS and turn it over to access the
PROG button (E).
-Press the PROG button (E) on the
Situo RTS until the product moves brie-
y (or emits a series of 3 beeps): the
programming function of the control
point is activated for approximately
2 minutes.
-On the original timer, briey press the
tab (c): the product moves briey (or
emits a series of 8 beeps) to indicate
that the original control point has been
E
c

18
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
deleted.
Press the down button on the timer: the
-
product does not move.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Remove the timer.
-
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
5.5 Telis 1 RTS/Telis Soliris
RTS remote controls
The Telis 1 RTS has 1 indicator light (4a)
and the Telis Soliris RTS has 2 indicator
lights (4b).
If the original remote control has more
than 2 indicator lights, refer to the section
"Telis 4 RTS/Telis 4 Soliris RTS remote
controls".
Move close to the product to install the
Telis 1 RTS.
5.5.1 Adding a Situo RTS
Bring the product to the midway -
position.
-Turn the original Telis over: the PROG
button (e) is located on the rear cover.
Press the PROG button (e) with the
-
tip of a pencil until the product moves
briey (or emits a series of 3 beeps):
4a 4b
g

19
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
the programming function of the control
point is activated for approximately
2 minutes.
Take the front cover of the new Situo
-
RTS and turn it over to access the
PROG button (E).
-Briey press the PROG button (E) on
the new Situo RTS: the product will
again move briey (or emit a series of
8 beeps) to indicate that the new Situo
RTS has been programmed.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
If the original Telis must be deleted, go
-
to paragraph 5.6.2 "Deleting the origi-
nal Telis".
If the original Telis is retained, please
-
refer to the “Mounting the bracket”
section to nish installing the Situo
RTS.
5.5.2 Deleting the original Telis
(optional)
N.B.: Only follow this procedure if use of
the original Telis is no longer required.
Warning! Before deleting a Telis Soliris,
contact the Somfy assistance service
to check the compatibility of the control
point with the product.
Wait 5 minutes.
-
-Take the front cover of the new Situo
RTS and turn it over to access the
PROG button (E).
Press the PROG button (E) on the new
-
Situo RTS until the product moves brie-
E
E

20
Situo RTS
Copyright © 2008 Somfy SAS. All rights reserved.
y (or emits a series of 3 beeps): the
programming function of the control
point is activated for approximately
2 minutes.
-Briey press the PROG button (e) on
the original Telis using the tip of a pencil:
the product moves briey (or emits a
series of 8 beeps) to indicate that the
original Telis has been deleted.
Press the down button on the original
-
Telis: the product does not move.
-Press the down button on the new
Situo RTS:
If the product is lowered, the Situo
-
RTS is operational.
If the product does not move, contact
-
the Somfy assistance service.
Do not dispose of the original control
point with household waste, see para-
graph 2.3.
Refer to the “Mounting the bracket”
-
section to nish installing the Situo
RTS.
g
