SOMFY Telis 1 Chronis RTS User manual

Telis®1 Chronis RTS
Included:
A. Telis 1 Chronis RTS
B. Wall mount with screw cover
C. Screw kit
D. 2 -LR03 AAA batteries
Part Number:
1811243
The Telis 1 Chronis RTS remote control and timer provides control of a single or a group
of window coverings in the same room. The Telis 1 Chronis RTS can be used in manual
or automatic mode. Manual mode controls the window coverings paired with the
remote control. Automatic mode allows you to control window coverings paired with
the remote control, using preprogrammed factory settings. Operators can customize
the daily and weekly schedules in the “work” program.
Caution: To avoid damaging the product:
1. Do not drop or strike.
2. Keep away from moisture and liquid.
3. Do not clean with abrasive cleaning products or solvents. Only use a soft, damp cloth.
4. Keep out of the reach of children.
2 x LR03
AAA 1.5v Batteries
page 1 of 8

Introduction
E. Red indicator light
F. Selection button
G. Arrow buttons
H. Up/Switch On/Open/Retract
window coverings
I. “my” button
Stop/Go to favorite “my” position
J. Down/Switch O/Close/Extend
window coverings
K. Programming (PROG) button
L. Battery compartment cover
LCD Screen M. Automatic mode indicator
N. Current time
O. Set mode active: SET
P. Low battery symbol
Q. Days of the week (work or daily/rest or weekend
programming is not displayed in daily programming):
Mo = Monday, Tu = Tuesday, We = Wednesday,
Th = Thursday, Fr = Friday, Sa = Saturday, Su = Sunday
R. Programmed automatic commands (Time 1 and Time 2)
S. Time selected for executing command in automatic mode.
In manual mode, “OFF” is displayed
T. or commands
page 2 of 8

Battery Installation
Wall Mount
1. Select a location for the wall mount.
2. Mark the screw locations (vertical spacing: 40 mm).
3. Attach the wall mount with the included screws
(use anchors if required).
Note: The use of digitally connected appliances
(e.g. Hi-Fi radio headphones) operating on the same
frequency may cause interference and reduce
product performance.
1. Remove the battery cover on back of remote control.
2. Insert 2 AAA (LR3) batteries as indicated inside the compartment.
3. Replace the battery cover.
Replace the batteries when the battery symbol (U) appears on
the display.
Note: If there is no power supply for an extended time
(batteries are depleted or removed), the settings of the
remote control transmitter will need to be reprogrammed.
However, the automatic orders are saved in memory.
Never use rechargeable batteries.
Caution: Never install the Telis 1 Chronis RTS
on or near metal surfaces as this may reduce
the signal range.
page 3 of 8

Programming the remote control
After battery installation, remote control automatically opens the
settings mode, starting with “Year” flashing on the screen. If there is
no power supply for an extended time (batteries are depleted or
removed) selecting automatic mode will activate the “settings” mode.
Settings mode follows this order:
Figure A
1. “YEAR” (current year)
2. “MONTH” (number of the current month)
3. “DAY” (number of the current day)
4. “TIME” (current hour)
5. “TIME” (minutes)
6. “AREA” (country of residence)*
7. “WORK” (daily/weekend)**
Press the arrow buttons (G) to modify settings
(press and hold the button to scroll through the list faster).
To save a setting and move to the next, briefly press the selection
button (F).
Exit the settings mode any time by pressing and holding the
selection button (F). Saved settings will remain.
* “AREA” (country of residence)
Note: The Telis 1 Chronis RTS is pre-programmed at the factory to
automatically switch between summer and winter conditions based
on the country of residence. Select the location of residence such as
the United States (US). Select “OFF” to deactivate automatic time
change functions (daylight savings) and make the change manually.
** “WORK” (daily/weekend)
1. Select the workdays you want to program using the
arrow buttons (G).
2. Briefly press the selection button (F) to confirm the setting; by
default, the days not circled will be vacation or weekend days.
Exit the settings mode any time by pressing and holding the selection
button (F). Saved settings will remain.
Figure A
KPROG
Program
button on
back
Set-Up
The Telis 1 Chronis RTS screen switches automatically to sleep mode after two minutes of inactivity.
When the screen is o or in sleep mode, press any button to turn it on. When editing settings, pressing and
holding the selection button (F) allows you to return to manual or automatic mode.
Only saved settings are retained.
Programming
Continued On Next Page
page 4 of 8

Figure B
Telis 1 Chronis RTS
Programming the days of the week
In automatic mode, the Telis 1 Chronis RTS sends automatic commands to one or more window coverings for
each day of the week.
These automatic commands include:
• The same settings for every day of the week (factory setting).
• Settings divided into two groups of days - workday and weekend. Five workdays have the same
operating times each day. The two weekend or rest days operate on the same schedule, which diers
from the workday schedule.
The preset mode can be deactivated at any time by pressing and holding the selection button (F).
Saved settings will remain.
Modify presets:
• To set the current time for window covering operation, see section “Quick setting of an
automatic command”.
• To set a specific time for window covering operation, see
section “Editing an automatic order”.
Quick setting of an automatic command
1. Using the selection button (F), switch to automatic mode.
2. Press the arrow keys (G) to navigate to the open or close setting
you wish to edit (settings for all days or for groups of days if work
or weekend days have been configured).
3. Press and hold the Up and Down buttons (H/J) for more than
10 seconds the open or close function to modify a command. “SET”
is displayed on the screen, and the order flashes 3 times. Release the
button when “SET” disappears from the screen. The desired open or
close operation will occur at that time automatically.
• To quickly store another automatic order, repeat the procedure
starting at step 1.
Programming Continued
page 5 of 8
Pairing or Deleting a Window Covering to another
RTS Transmitter - Figure B
Pairing or Deleting a window covering is performed in manual mode.
1. Press and hold the PROG button on the window covering control
unit until the window covering moves up and down or jogs. The
programming mode is active for 2 minutes.
2. Press the (PROG) programming button (K) on the Telis 1 Chronis
remote control. The window covering moves up and down or jogs
and is assigned to or deleted from the Telis 1 Chronis remote.
The procedure for pairing or deleting a window covering to the Telis 1
Chronis RTS is the same. It is done only in manual mode.
1. Press and hold the PROG button on the window covering control
unit until the window covering jogs. The programming mode is active
for 2 minutes.
2. Press the (PROG) programming button (K) on the Telis 1 Chronis
remote control. The window covering moves or jogs and is assigned
to or deleted from the Telis 1 Chronis remote.
Continued On Next Page

Programming Continued
Deleting an automatic command
1. Using the selection button (F), switch to automatic mode.
2. Press the arrow keys (G) to select the open or close order that you
wish to edit (settings for all days or for groups of days if work or weekend
days have been configured).
3. Press and hold the selection button (F) until "SET" appears on the
screen: "Automatic command programming" mode is activated
and "EDIT" flashes.
4. Press one of the arrow buttons (G) to change menu until
"Delete" flashes.
5. Briefly press the selection button (F) to confirm the deletion.
Exit "EDIT" mode and return to automatic mode.
• To delete another automatic command, repeat steps 1-5.
page 6 of 8
Continued On Next Page
Figure C
F11:00
07:30 G
yEAR
2021
7 Sec.
Setting the general parameters
of the remote control
transmitter,refer back to
section 4.
Modifying the general settings of the Telis 1 Chronis remote control
Figure C
1. Using the selection button (F), switch to automatic mode.
2. Press and hold the selection button (F) until "SET" and "YEAR" appear on the screen. The
"settings” mode is activated. The year flashes. This is the first setting to program.
3. Follow the steps in the section “Programming the remote control”.

Operation
To activate or deactivate the function:
Figure D
1. Using the selection button (F), switch to automatic mode.
2. Press both arrow buttons (G) simultaneously. The ( ) symbol appears on the screen. The
"simulated presence" function is activated.
3. Press both arrow buttons (G) simultaneously. The ( ) symbol disappears from the screen. The
"simulated presence" function is deactivated.
Figure D
F11:00
07:30 G
EDIT
20 :00
G
14:00
20:12
To switch from manual to automatic mode or from automatic to manual mode,
briefly press the selection button (F).
Manual mode
The manual mode of the Telis 1 Chronis RTS is used to:
• Send an occasional order to the window coverings.
• Deactivate automatic command programming.
Manual control
Briefly press the Up, “my” or Down button corresponding to the desired function.
Automatic mode
The automatic mode of the Telis 1 Chronis RTS is used to:
• Automatically control the window covering, using programmed settings for times or days of the week.
Example of programming for a day: at 6:45 AM, up command to open all products on the ground floor to
take advantage of the sunlight; at 8:00 PM, a down command for all the end-products to protect
the house from the cold.
• Programming automatic commands for each day of the week
(see section “Programming the days of the week”).
• In automatic mode, the current time and the next scheduled automatic command are displayed.
• To view all the automatic commands programmed, scroll from one command to the next using the
arrow buttons (G).
• To stop an automatic command that is currently being executed, press the Stop/my button.
You can also press the Up, “my” or Down buttons in automatic mode.
page 7 of 8
Simulated presence function
In automatic mode, the “Simulated Presence” or “Vacation Mode” function randomly changes the times
preprogrammed window covering operations occur. By varying the closure or opening of window coverings
by 0 to 30 minutes, it simulates your presence in the home while on vacation.
Note: Exit the settings mode any time by pressing and holding
the selection button (F). Saved settings will remain.

Troubleshooting
Observation
The window covering does
not react at all when a button
on the Telis 1 Chronis RTS
is pressed.
A window covering stops
during activation.
The command is being sent at a
dierent time than the
programmed time.
One or more window coverings
systematically does not respond
to a programmed automatic
command.
Possible Causes
The batteries are low.
The remote control
transmitter is not
programmed.
External radio equipment
is interfering with the
radio reception.
The motor(s) or receiver(s)
are in thermal shut-o
mode.
The window covering has
encountered an obstacle.
Another control device is
sending a command to
the motor or receiver
The "Simulated presence"
function is activated.
A signal from another
automatic device in your
home is causing interference.
Solution
Replace the batteries.
See section "Adding/ deleting
a Telis 1 Chronis RTS".
Turn o any nearby radio
appliances.
Wait for the motor to cool
down, then press the desired
button again.
Remove the obstacle
and try again.
Wait until activation of the
window covering has finished,
then try again.
Deactivate "Simulated presence"
function.
Change the programmed time
of the automatic command.
This device is FCC certified and complies with part 15 of the FCC rules.
RTS compatibility: RTS transmitters are capable of operating any RTS motor.
page 8 of 8
BATTERY RECYCLING OR DISPOSAL
Discard batteries and electrical components
following local codes or regulations. Recycle
batteries and electrical components with
designated electronic recycle centers.
Note: Visit https://store.somfysystems.com/ to
purchase an additional or replacement product.
