SonoSite M-Turbo User manual

Quick Guide
Saving imageS on
SonoSite’S m-turbo®
ultraSound SyStem
First create a folder to save e images in:
1) Switch on e system (power button top le on control panel), press Patient (keyboard)
2) Select New/End from e so keys (bottom of screen)
3) Enter e required patient detail. Under User, enter your initials (is helps wi sorting folders)
4) Press Done (bottom of screen) to continue to e live 2D screen
5) Your folder name will appear in e top le corner
6) Scan your subject and adjust e image accordingly by setting e Gain and Dep
Saving still images:
1) To save e image, press Freeze
2) Wi e overall Gain button, toggle rough e recorded frames (images)
(ese are not saved yet, only recorded retrospectively) and press Save to save
e required frame
Saving clips:
1) To select e time duration of e clip (2 sec to 60 sec): From e so keys on e bottom of
e screen, go to e 2nd page and press Clips, en select Time, or ECG in e case of echo,
and select e required duration
2) Continue live 2D scanning and press Clip each time you wish to save a ‘video’ clip

Quick Guide
Saving imageS on SonoSite’S
m-turbo®ultraSound SyStem
Once all required images/clips have been saved, you need to end e exam (close e folder).
This is done as follows:
1) Select Patient
2) To review e images saved before ending e exam press Review (keyboard) en Review (bottom of screen);
when you’re finished press Done (bottom of screen); select Patient
3) Press New/End to close e folder (once e folder is ended/closed no more images can be added to e folder –
also no post processing is possible)
To transfer images to a USB stick:
1) Press Patient followed by Review (keyboard)
2) From e list of folders, select (by clicking on each one) e folder/s you wish to copy
3) The USB stick (standard non-encrypted) should be inserted into e USB port on e right hand side of e system
4) Press Exp.USB (bottom of screen)
5) The USB stick is identified and Export should be selected (bottom of screen)
6) A message appears above e so keys on e bottom of e screen indicating at e transfer is in progress. Only once
e message disappears, can e USB stick be removed (no need to safety check before removing it)
7) Still images are copied across as jpeg’s and clips as mpeg’s and can be viewed on a Windows or MAC based PC or laptop
Dep
New/End
Power
Gain
Patient
Clip
Save
Review
Freeze
