Sony STW-C140GI User manual

4-418-906-04 (1)
© 2012 Sony Corporation
Captioning Glasses
with Audio Assist/
Captioning Glasses
STW-C140GI
STW-C140S
Operating Instructions
Mode d’emploi
Manual de instrucciones
Bedienungsanleitung
Istruzioni per l’uso
GB
FR
ES
DE
IT

GB 2
For STW-C140GI
Before operating the unit, please read this
manual thoroughly and retain it for future
reference.
Owner’s Record
The model and serial numbers are located on
the product. Record these numbers in the
spaces provided below. Refer to these
numbers whenever you call upon your Sony
dealer regarding this product.
Model No._________________
Serial No._________________
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to
qualified personnel only.
CAUTION
The apparatus shall not be exposed to
dripping or splashing. No objects filled with
liquids, such as vases, shall be placed on the
apparatus.
WARNING
Excessive sound pressure from earphones
and headphones can cause hearing loss.
In order to use this product safely, avoid
prolonged listening at excessive sound
pressure levels.
WARNING
Batteries shall not be exposed to excessive
heat such as sunshine, fire or the like.
For the customers in the U.S.A.
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.
This transmitter must not be co-located or
operated in conjunction with any other
antenna or transmitter.
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment and meets the
FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This
equipment has very low levels of RF energy
that are deemed to comply without testing of
specific absorption ratio (SAR).
For the customers in Canada
This Class A digital apparatus complies with
Canadian ICES-003.
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation
is subject to the following two conditions:
(1) this device may not cause interference,
and (2) this device must accept any
interference, including interference that may
cause undesired operation of the device.
This equipment complies with IC radiation
exposure limits set forth for an uncontrolled
environment and meets RSS-102 of the IC
radio frequency (RF) Exposure rules. This
equipment has very low levels of RF energy
that are deemed to comply without testing of
specific absorption ratio (SAR).

3GB
The term “IC:” before the radio certification
number only signifies that Industry Canada
technical specifications were met.
For the customers in Europe,
Australia and New Zealand
WARNING
This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
For the customers in Europe
This product has been manufactured by or
on behalf of Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japan. Inquiries
related to product compliance based on
European Union legislation shall be
addressed to the authorized representative,
Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Germany. For
any service or guarantee matters, please
refer to the addresses provided in the
separate service or guarantee documents.
This apparatus shall not be used in the
residential area.
Dutch
Hierbij verklaart Sony Corporation dat het toestel STW-C140GI/
Ondertitelingsbril met Audio Assist in overeenstemming is met de essentiële
eisen en de andere relevante bepalingen van richtlijn 1999/5/EG. Nadere
informatie kunt u vinden op: http://www.compliance.sony.de/
English
Hereby, Sony Corporation, declares that STW-C140GI/Captioning Glasses with
Audio Assist is in compliance with the essential requirements and other relevant
provisions of the Directive 1999/5/EC. For details, please access the following
URL: http://www.compliance.sony.de/
French
Par la présente Sony Corporation declare que l’appareil STW-C140GI/Lunettes
à sous-titres avec Audio Assist est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive 1999/5/CE. Pour toute information
complémentaire, veuillez consulter l’URL suivante:
http://www.compliance.sony.de/
German
Hiermit erklärt Sony Corporation, dass sich das Gerät STW-C140GI/Brille für
Untertitel mit Audiounterstützung in Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie
1999/5/EG befindet. Weitere Informationen erhältlich unter:
http://www.compliance.sony.de/
Italian
Con la presente Sony Corporation dichiara che STW-C140GI/Occhiali con
sottotitoli con assistenza audio è conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Per ulteriori dettagli,
si prega di consultare il seguente URL: http://www.compliance.sony.de/
Norwegian
Sony Corporation erklærer herved at STW-C140GI/briller for teksting med
lydassistanse er i samsvar med de grunnleggende krav og øvrige relevante krav i
direktiv 1999/5/EF. For flere detaljer, vennligst se:
http://www.compliance.sony.de/
Spanish
Por medio de la presente Sony Corporation declara que el STW-C140GI/gafas
para subtítulos con audio auxiliar cumple con los requisitos esenciales y
cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/
CE. Para mayor información, por favor consulte el siguiente URL:
http://www.compliance.sony.de/
GB

GB 4
For the customers in Italy
Use of the RLAN network is governed:
- with respect to private use, by the
Legislative Decree of 1.8.2003, no. 259
(“Code of Electronic Communications”).
In particular Article 104 indicates when
the prior obtainment of a general
authorization is required and Art. 105
indicates when free use is permitted;
- with respect to the supply to the public of
the RLAN access to telecom networks and
services, by the Ministerial Decree
28.5.2003, as amended, and Art. 25
(general authorization for electronic
communications networks and services) of
the Code of electronic communications
For the customers in Norway
Use of this radio equipment is not allowed in
the geographical area within a radius of
20 km from the centre of Ny-Ålesund,
Svalbard.
For kundene i Norge
Det er ikke tillatt å bruke dette radioutstyret
innen en radius på 20 km fra sentrum av
Ny-Ålesund, Svalbard.
AVERTISSEMENT
Afin de réduire les risques d’incendie
ou d’électrocution, ne pas exposer
cet appareil à la pluie ou à l’humidité.
Afin d’écarter tout risque
d’électrocution, garder le coffret
fermé. Ne confier l’entretien de
l’appareil qu’à un personnel qualifié.
ATTENTION
Eviter d’exposer l’appareil à un égouttement
ou à des éclaboussures. Ne placer aucun
objet rempli de liquide, comme un vase, sur
l’appareil.
AVERTISSEMENT
Une pression acoustique excessive en
provenance des écouteurs ou du casque peut
provoquer une baisse de l’acuité auditive.
Pour utiliser ce produit en toute sécurité,
évitez l’écoute prolongée à des pressions
sonores excessives.
AVERTISSEMENT
N’exposez pas les batteries à une chaleur
excessive, au soleil ou près d’un feu par
exemple.
Pour les clients au Canada
Cet appareil numérique de la classe A est
conforme à la norme NMB-003 du Canada.
Le présent appareil est conforme aux CNR
d’Industrie Canada applicables aux
appareils radio exempts de licence.
L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit
pas produire de brouillage, et (2) l’utilisateur
de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le
fonctionnement.
Cet équipement est conforme aux limites
d’exposition aux rayonnements énoncées
pour un environnement non contrôlé et
respecte les règles d’exposition aux
fréquences radioélectriques (RF) CNR-102
de l’IC. Cet équipement émet une énergie
RF très faible qui est considérée conforme
sans évaluation du débit d’absorption
spécifique (DAS).
La mention « IC: » devant le numéro de
certification/ homologation signifie
uniquement que les spécifications
techniques d’Industrie Canada sont
remplies.
Tu r ki sh
Sony Corporation, STW-C140GI/Ses Destekli AltyazıGözlüğü ürünü için
gerekli tüm testleri 1999/5/EC Direktifine gore yapmışbulunmaktadır. Daha
detaylıbilgi için lütfen web sayfasınıziyaret ediniz:
URL: http://www.compliance.sony.de/

5GB
Pour les clients en Europe, Australie
et Nouvelle-Zélande
AVERTISSEMENT
Il s’agit d’un produit de Classe A. Dans un
environnement domestique, cet appareil
peut provoquer des interférences radio, dans
ce cas l’utilisateur peut être amené à prendre
des mesures appropriées.
Pour les clients en Europe
Ce produit a été fabriqué par ou pour le
compte de Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japon. Toutes
les questions relatives à la conformité des
produits basées sur la législation européenne
doivent être adressées à son représentant,
Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Allemagne.
Pour toute question relative au Service
Après-Vente ou à la Garantie, merci de bien
vouloir vous référer aux coordonnées qui
vous sont communiquées dans les
documents « Service (SAV) » ou Garantie.
Ne pas utiliser cet appareil dans une zone
résidentielle.
Pour les clients en Italie
L’utilisation des réseaux RLAN est régie :
- en ce qui concerne l’utilisation à des fins
privées, par le Décret législatif du 1er août
2003, No. 259 (« Code des
communications électroniques »). En
particulier, l’Article 104 qui stipule quand
l’obtention préalable d’une autorisation
générale est requise, et l’Article 105 qui
précise quand une utilisation libre est
permise ;
- en ce qui concerne la fourniture au public
d’un accès RLAN aux réseaux et services
de télécommunications, par le Décret
ministériel du 28 mai 2003, et de l’Article
25 (autorisation générale pour les réseaux
et services de communications
électroniques) du Code des
communications électroniques ;
WARNUNG
Um die Gefahr von Bränden oder
elektrischen Schlägen zu verringern,
darf dieses Gerät nicht Regen oder
Feuchtigkeit ausgesetzt werden.
Um einen elektrischen Schlag zu
vermeiden, darf das Gehäuse nicht
geöffnet werden. Überlassen Sie
Wartungsarbeiten stets nur
qualifiziertem Fachpersonal.
VORSICHT
Das Gerät ist nicht tropf- und
spritzwassergeschützt. Es dürfen keine mit
Flüssigkeiten gefüllten Gegenstände, z. B.
Vasen, darauf abgestellt werden.
WARNUNG
Zu hoher Schalldruck von Ohrhörern und
Kopfhörern kann Gehörschäden
verursachen.
Um dieses Produkt sicher zu verwenden,
vermeiden Sie längeres Hören bei sehr
hohen Schalldruckpegeln.
WARNUNG
Akkus dürfen keinesfalls übermäßiger
Wärmeeinwirkung ausgesetzt werden, wie
z.B. Sonneneinstrahlung, Feuer o. ä.
Für Kunden in Europa, Australien und
Neuseeland
WARNUNG
Dies ist eine Einrichtung, welche die Funk-
Entstörung nach Klasse A besitzt. Diese
Einrichtung kann im Wohnbereich
Funkstörungen verursachen; in diesem Fall
kann vom Betreiber verlangt werden,
angemessene Maßnahmen durchzuführen
und dafür aufzukommen.
Für Kunden in Europa
Dieses Produkt wurde von oder für Sony
Corporation, 1-7-1 Konan Minato-ku Tokio,
108-0075 Japan hergestellt.
Bei Fragen zur Produktkonformität auf
Grundlage der Gesetzgebung der
Europäischen Union kontaktieren Sie bitte
den Bevollmächtigten Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Deutschland. Für Kundendienst

GB 6
oder Garantieangelegenheiten wenden Sie
sich bitte an die in den Kundendienst- oder
Garantiedokumenten genannten Adressen.
Dieser Apparat darf nicht im Wohnbereich
verwendet werden.
Für Kunden in Italien
Die Verwendung des RLAN-Netzwerkes
wird geregelt:
- in Bezug auf die private Verwendung
durch die gesetzliche Bestimmung vom
01.08.2003, Nr. 259 („Richtlinie über
elektronische Kommunikation“). Im
Einzelnen gibt Artikel 104 an, wann die
vorherige Einholung einer allgemeinen
Genehmigung erforderlich ist und Art.
105, wann die freie Verwendung erlaubt
ist.
- in Bezug auf die Bereitstellung des
RLAN-Zugangs zu Telekomnetzwerken –
und Dienstleistungen für die
Öffentlichkeit, durch die geänderte
amtliche Richtlinie vom 28.05.2003 und
Art. 25 (allgemeine Genehmigung für
elektronische Kommunikationsnetzwerke
und -dienstleistungen) der Richtlinie über
elektronische Kommunikation
Per i clienti in Italia
L’utilizzo della rete RLAN è regolato:
- relativamente all’uso privato, dal Decreto
Legislativo del 1.8.2003, n. 259 (“Codice
delle comunicazioni elettroniche”). In
particolare, l’Articolo 104 indica i casi in
cui è necessario ottenere preventivamente
un’autorizzazione generale, mentre
l’Articolo 105 specifica i casi in cui è
consentito il libero uso;
- relativamente alla fornitura al pubblico
dell’accesso RLAN ai servizi e alle reti di
telecomunicazione, dal Decreto
Ministeriale del 28.5.2003 e successive
modifiche, e dall’Art. 25 (autorizzazione
generale per i servizi e le reti delle
comunicazioni elettroniche) del Codice
delle comunicazioni elettroniche
Para los clientes de Italia
El uso de la red RLAN se rige:
- con respecto al uso privado, por el Decreto
legislativo de 1.8.2003, núm. 259
(“Código de comunicaciones
electrónicas”). En concreto, el artículo 104
indica cuándo se requiere la obtención
previa de una autorización general y el
artículo 105 indica cuándo se permite el
uso libre;
- con respecto al suministro al público del
acceso RLAN a las redes y servicios de
telecomunicaciones, por el Decreto
ministerial de 28.5.2003, según fue
enmendado, y el artículo 25 (autorización
general para redes y servicios de
comunicación electrónica) del Código de
comunicaciones electrónicas

7GB
For STW-C140S
Before operating the unit, please read this
manual thoroughly and retain it for future
reference.
Owner’s Record
The model and serial numbers are located on
the product. Record these numbers in the
spaces provided below. Refer to these
numbers whenever you call upon your Sony
dealer regarding this product.
Model No._________________
Serial No._________________
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To avoid electrical shock, do not open
the cabinet. Refer servicing to
qualified personnel only.
CAUTION
The apparatus shall not be exposed to
dripping or splashing. No objects filled with
liquids, such as vases, shall be placed on the
apparatus.
For the customers in the U.S.A.
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.
For the customers in Canada
CAN ICES-3 (A)/NMB-3(A)
For the customers in Europe,
Australia and New Zealand
WARNING
This is a Class A product. In a domestic
environment, this product may cause radio
interference in which case the user may be
required to take adequate measures.
For the customers in Europe
This product has been manufactured by or
on behalf of Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japan. Inquiries
related to product compliance based on
European Union legislation shall be
addressed to the authorized representative,
Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Germany. For
any service or guarantee matters, please
refer to the addresses provided in the
separate service or guarantee documents.
This apparatus shall not be used in the
residential area.
AVERTISSEMENT
Afin de réduire les risques d’incendie
ou d’électrocution, ne pas exposer
cet appareil à la pluie ou à l’humidité.
Afin d’écarter tout risque
d’électrocution, garder le coffret
fermé. Ne confier l’entretien de
l’appareil qu’à un personnel qualifié.
ATTENTION
Eviter d’exposer l’appareil à un égouttement
ou à des éclaboussures. Ne placer aucun

GB 8
objet rempli de liquide, comme un vase, sur
l’appareil.
Pour les clients au Canada
CAN ICES-3 (A)/NMB-3(A)
Pour les clients en Europe, Australie
et Nouvelle-Zélande
AVERTISSEMENT
Il s’agit d’un produit de Classe A. Dans un
environnement domestique, cet appareil
peut provoquer des interférences radio, dans
ce cas l’utilisateur peut être amené à prendre
des mesures appropriées.
Pour les clients en Europe
Ce produit a été fabriqué par ou pour le
compte de Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japon. Toutes
les questions relatives à la conformité des
produits basées sur la législation européenne
doivent être adressées à son représentant,
Sony Deutschland GmbH, Hedelfinger
Strasse 61, 70327 Stuttgart, Allemagne.
Pour toute question relative au Service
Après-Vente ou à la Garantie, merci de bien
vouloir vous référer aux coordonnées qui
vous sont communiquées dans les
documents « Service (SAV) » ou Garantie.
Ne pas utiliser cet appareil dans une zone
résidentielle.
WARNUNG
Um die Gefahr von Bränden oder
elektrischen Schlägen zu verringern,
darf dieses Gerät nicht Regen oder
Feuchtigkeit ausgesetzt werden.
Um einen elektrischen Schlag zu
vermeiden, darf das Gehäuse nicht
geöffnet werden. Überlassen Sie
Wartungsarbeiten stets nur
qualifiziertem Fachpersonal.
VORSICHT
Das Gerät ist nicht tropf- und
spritzwassergeschützt. Es dürfen keine mit
Flüssigkeiten gefüllten Gegenstände, z. B.
Vasen, darauf abgestellt werden.
Für Kunden in Europa, Australien und
Neuseeland
WARNUNG
Dies ist eine Einrichtung, welche die Funk-
Entstörung nach Klasse A besitzt. Diese
Einrichtung kann im Wohnbereich
Funkstörungen verursachen; in diesem Fall
kann vom Betreiber verlangt werden,
angemessene Maßnahmen durchzuführen
und dafür aufzukommen.
Für Kunden in Europa
Dieses Produkt wurde von oder für Sony
Corporation, 1-7-1 Konan Minato-ku Tokio,
108-0075 Japan hergestellt.
Bei Fragen zur Produktkonformität auf
Grundlage der Gesetzgebung der
Europäischen Union kontaktieren Sie bitte
den Bevollmächtigten Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327
Stuttgart, Deutschland. Für Kundendienst
oder Garantieangelegenheiten wenden Sie
sich bitte an die in den Kundendienst- oder
Garantiedokumenten genannten Adressen.
Dieser Apparat darf nicht im Wohnbereich
verwendet werden.

9GB
Table of Contents
Overview
About this manual .............................10
Supplied Items ................................... 10
System Configuration (Example) ..... 11
Precautions ......................................... 12
Location and Function of
Controls ............................................ 13
Captioning Glasses ........................ 13
Receiver Box
(STW-C140GI only) ................... 14
Instructions to Theater Staff
Charging ............................................. 16
Mode Selection: Captioning or
Audio ................................................ 16
Preparation ........................................ 17
Screen Position Alignment Check
(Captioning Mode) ...................... 17
Channel and Audio Selection ........ 17
Language Selection (Captioning
Mode) ..........................................18
Providing Customers with Units
(Captioning Mode) .......................... 19
Providing Customers with Units
(Audio Mode) ................................... 19
Turning Off ........................................ 20
Cleaning ............................................. 20
Wiping the Captioning Glasses ..... 20
Sterilization ................................... 21
Instructions to Customers
Adjustments ....................................... 23
Setting Screen .................................... 24
Setting Screen Operation .............. 24
Appendices
Specifications ..................................... 25
License ................................................ 26

GB 10
BOverview
About this manual
In this manual, we mention two models; STW-C140GI and STW-C140S. Each model is
structured as follows:;
* The receiver box is not included with the STW-C140S. Refer to the description of the receiver box
in the discussion of a captioning glasses connected to a receiver box.
Supplied Items
Captioning glasses (1)
Receiver box (1) (STW-C140GI only)
Operating Instructions (1)
Model name Captioning glasses Receiver box
STW-C140GI
(Captioning Glasses with Audio
Assist)
Supplied Supplied
STW-C140S
(Captioning Glasses) Supplied Not supplied*

11GB
Overview
System Configuration (Example)
Closed caption data is transmitted from a D-Cinema (digital cinema) server by the Data
Transmitter and received by the receiver box to be displayed on the captioning glasses.
Audio data for the visually impaired and/or the hearing impaired can be also transmitted, for
listening through headphones.
*1 The receiver box outputs to only one device at a time; either the captioning glasses or the
headphones.
*2 The receiver box is not included with the STW-C140S.
Receiver box*2
Captioning glasses*1
Headphones*1
(not supplied)
Captions and audio
(wireless network)
Movie contents
Digital cinema projector
Digital Audio
AES/EBU
RJ-45
Analog Audio
Phono cable
D-Cinema server
Data Transmitter
Caption
SMPTE
RJ-45
*1
This unit

GB 12
Precautions
• Do not drop or subject to impact.
• Do not stretch the cable.
• Avoid exposing the units to water. If water
enters the units, a malfunction may occur,
which may not be repairable.
• The units are neither dust-proof, nor
splash-proof.
• Do not allow condensation to form in the
unit, or use the unit near water.
• Stop using the unit immediately if it gets
wet. In an attempt to resume use of the
unit, do not charge the battery or dry the
unit forcibly using heating apparatus
(microwave, etc.).
• Do not leave the unit in a humid place.
An environment where a humidifier's
vapor is emitted (as a result of sudden
temperature change) may cause
condensation in the unit.
• Do not place the unit near the vents of an
air conditioner. If the unit is brought
directly from a cold to a warm location,
condensation may occur inside.
• The minimum age for wearing the
captioning glasses is seven years old.
• The lenses of the captioning glasses are
made of glass. If the glass cracks or
breaks, contact your dealer and refrain
from touching it or attempting to repair it
yourself. Damage may be incurred if the
captioning glasses sustain a shock or if
they are dropped; therefore, be careful
when handling them. Damages resulting
from inappropriate handling of the
captioning glasses are not covered under
warranty.
• Hold the connector when disconnecting
the cable from the unit; do not hold the
cable, as it may be damaged and closed
captions may not be displayed.
• Hold the connector when connecting the
cable to the receiver; do not bend the cable
at the connector/cable junction, as it may
be damaged and closed captions may not
be displayed.
• Do not loop the cable around the unit.
The cable may be damaged and closed
captions may not be displayed.

13GB
Overview
Location and Function of Controls
aNose piece
Slide the nose piece up or down and
adjust the angle for a comfortable fit.
bTemple frames
Place the temple frames over your ears,
as you would regular glasses. Similarly,
handle the captioning glasses by the
temple frames.
cOptical engines
Use to raise or lower the position of the
closed captions. The optical engines and
lenses are integrated into one component
and can rotate back and forth.
dPhoto sensor
Detects the screen image brightness to
adjust the closed caption brightness
automatically.
eLenses
Keep the lenses clean and avoid
touching or staining them.
Captioning Glasses

GB 14
aAntenna (inside)
Avoid covering the antenna.
bPOWER button
Press this button to turn on the receiver
box. After turned on, channel and audio
selection is available.
While turned on, press and hold this
button for about two seconds until the
POWER indicator starts blinking in
amber, and press this button once more
to turn off the receiver box.
While turned off and while pressing and
holding the SEL button, press this button
to call up the screen position alignment
check image.
cPOWER indicator
Displays the status of the receiver box.
Lit in green: The unit is turned on and
the battery can last more than three
hours.
Lit in amber: The unit is turned on but
the battery may run down in less than
three hours.
Blinks in red five times at power-on:
The battery may have reached its end of
usable life. Contact your Sony sales
representative to have the battery
replaced with a new one. The unit may
still work with the old battery, though
the battery may have lost one half its
initial capacity, which means that it may
not last three hours even if the indicator
lights in green.
Blinking: The unit is in the channel or
audio selection mode.
Off: The power of the unit is turned off.
d– button
Use this button to select an item or adjust
a value in a setting screen. Also, press
and hold the + and – buttons
simultaneously while the unit is turned
on to display the language selection
menu.
In Audio mode, press and hold this
button to turn down the volume.
Assistive audio is still audible at the
minimum volume.
eSEL (Select) button
Press this button to display a setting
screen, go to the next setting screen or
confirm an adjusted value. Also, press
and hold the button to display the
adjustment screen.
Receiver Box (STW-C140GI only)

15GB
Overview
f+ button
Use this button to select an item or adjust
the value when a setting screen is
displayed.
In Audio mode, press and hold this
button to turn up the volume.
gHI/VI indicator
Indicates the type of audio assistance for
Audio mode.
H: Assistive audio for the hearing
impaired.
V: Audio description for the visually
impaired.
Blinking: HI/VI selection is available.
hChannel indicator
Indicates the wireless channel.
Lit in green: One of the G group
channels (G1 to G7) is selected.
Lit in yellow: One of the Y group
channels (Y1 to Y7) is selected.
Blinking: Channel selection is available.
iRESET button
Press this button with a thin, straight
object (such as an opened paper clip) if
all buttons on the unit (including the
POWER button) become unresponsive.
The power turns off.
Pressing this button has no effect on the
power charge cycle count.
jClips
Attach the unit to the holder of the
carrying case or lanyard (not supplied)
with the clips.
kBattery charger terminals
For details on how to charge the battery
of the unit, refer to the operating
instructions included with the battery
charger.
lHeadphone jack
When using the unit in Audio mode,
connect headphones to this jack.
mCaptioning glasses connector
When using the unit in Captioning
mode, connect the cable of the
captioning glasses to this connector.

GB 16
BInstructions to Theater Staff
Charging
Use the specified battery charger to charge
the battery of the receiver box. (It takes
about three hours.) For details on how to
charge the battery, refer to the operating
instructions supplied with the battery
charger.
Note about the battery terminal
The battery terminal of this unit (the
connector for battery chargers) is a
consumable part.
Power may not be supplied to the unit
properly if the pins of the battery terminal
are bent or deformed by shock or vibrations,
or if they become corroded due to prolonged
outdoor use.
If the unit remains turned off for an extended
period of time, the battery may discharge.
If the unit is not to be used for an extended
period, keep the battery of the unit charged
by the charger if possible. Otherwise, before
resuming use, charge the battery of the unit.
Periodic inspections are recommended to
keep the unit working properly and to
prolong its usable lifetime.
Contact a Sony service or sales
representative for more information about
inspections.
Mode Selection:
Captioning or Audio
The receiver box works in one of two modes:
Captioning mode, or Audio mode. The
receiver box switches between these modes
by detecting whether the captioning glasses
are connected or not.
With the captioning glasses connected, the
receiver box works in the Captioning mode,
and the captioning glasses display captions.
With the captioning glasses not connected,
the receiver box works in Audio mode, and
headphones play audio descriptions for the
visually impaired, or assistive audio for the
hearing impaired. The headphones should be
connected to the headphone jack of the
receiver box.
Captioning mode
Audio mode

17GB
Instructions to Theater Staff
Preparation
Before providing customers with units,
make prepare the units as follows.
Captioning mode:
• Screen position alignment check
• Channel selection
• Language selection
Audio mode:
• Channel selection
• Audio selection
If the screen position alignment of the
captioning glasses is incorrect, do not use
them. Contact your dealer for service
information.
1Connect the captioning glasses to the
receiver box, and put the glasses on.
The triangular marks of the plug and
connector should be aligned.
2Make sure that the unit is turned off.
3While pressing and holding the SEL
button, press the POWER button to
turn the unit on.
The screen position alignment check
image appears on the glasses.
4Check that the horizontal line crosses
all the vertical lines, as shown below.
Correct
Incorrect
5Press and hold the POWER button for
about two seconds until the POWER
indicator starts blinking in amber.
Press the POWER button again to turn
off the receiver box. The POWER
indicator goes out.
Set the receiver box and the Data
Transmitter to the same channel, and select
HI (Hearing Impaired) or VI (Visually
Impaired) accordingly.
1Make sure that the unit is turned off.
2Press the POWER button to turn on
the receiver box.
The POWER indicator and channel
indicator start blinking.
Screen Position Alignment
Check (Captioning Mode)
Note
Left screen Right screen
Correct
The combined picture you see with both eyes
Channel and Audio Selection

GB 18
3Press the +/– button repeatedly to
select the channel.
There are two channel groups: “G”
(green indicator) and “Y” (yellow
indicator).
4Press the SEL button to set the
channel.
The channel indicator stays lit.
The HI/VI indicator starts blinking.
5Press the +/– button to choose HI or
VI.
6Press the SEL button again to set the
audio setting.
The HI/VI indicator and POWER
indicator stay lit.
For Captioning mode, follow the
instructions as follows to select language.
Select the closed caption language.
Selectable languages and their order are set
up by the Data Transmitter STWA-C101.
For how to set up, refer to the operating
instructions included with STWA-C101.
1Press and hold the + and – buttons
simultaneously until the language
menu appears on the glasses.
It takes about two seconds.
2Press the +/– button repeatedly to
select the language.
3Press the SEL button to set the
language.
• After 10 seconds of no operation, the menu
disappears and the language setting remains
unchanged.
• The default language setting is “Language
No.1.” When the receiver box is turned on,
the language setting returns to the default
setting.
Language Selection
(Captioning Mode)
Notes

19GB
Instructions to Theater Staff
Providing
Customers with
Units (Captioning
Mode)
Before providing customers with units,
check the screen position alignment and
select the channel and language (see pages
17 to 18).
1Connect the cable of the captioning
glasses to the connector of the receiver
box.
The triangular marks of the plug and
connector should be aligned.
2Have the customer put on the glasses.
• The captioning glasses can be worn over the
customer’s own eyeglasses.
• Hold the captioning glasses by the temple
frames.
• Any BTE (behind-the-ear) hearing aid
should be removed before wearing the
captioning glasses.
Providing
Customers with
Units (Audio Mode)
Before providing customers with units,
select the channel and audio (see pages 17 to
18).
1Connect the headphones to the
headphone jack of the receiver box.
2Have the customer put on the
headphones.
• Any hearing aid should be removed before
wearing the headphones.
• Assistive audio is still audible at the
minimum volume.
Note
Notes
Notes

GB 20
Turning Off
After the receiver box is returned from the
customer, turn it off.
1Press and hold the POWER button for
about two seconds until the POWER
indicator starts blinking in amber.
2Press the POWER button again.
The POWER indicator goes out and the
receiver box turns off.
Cleaning
When cleaning the captioning glasses, hold
them by the bridge, as illustrated below.
Wipe the front and back of each lens with a
microfiber lens cleaning cloth
(recommendation: Lens Cleaning Cloth
9021, by 3M Company).
If the lenses are badly stained by finger
prints, oil, etc., wipe them with pre-
moistened lens tissues (recommendation:
Lens Pre-Moistened Tissues, by Carl Zeiss
Optical Inc.).
If the lens surfaces are dirty, closed captions
may not be displayed clearly.
To ensure they are displayed clearly, it is
recommended to wipe the lenses
periodically, using a pre-moistened lens
tissue.
Do not expose the captioning glasses to
chemical products such as thinner, benzine,
insect repellent, sunscreen or insecticide.
Wiping the Captioning
Glasses
Note
