WIDE CONVERSION LENS
VCL-07FE
AEP Model
SERVICE MANUAL
Ver 1.0 2002. 10
SPECIFICATIONS
PARTS LIST
Ref. No. Part No. Description
1 3-078-767-01 PORCH, CARRYING
2 3-078-769-01 CAP, FRONT
3 3-078-768-01 LENS (MAIN), WIDE CONVERSION
4 3-067-797-01 STRING (T), CAP
A-1
B-1
A-2
A-3 A-4
B-2
B-3 B-4
C
AAttaching the wide conversion lens
1Open the rear cover of the conversion lens unit fully.
• Do not open the rear cover forcibly. If you try to open too
far, it will be damaged.
2Rotate the lens section of the camera to face the front.
3Mount the conversion lens on the camera, placing it over the
camera lens.
4Close the rear cover.
• Press the rear cover until it clicks to close it firmly. If it is
not properly closed, the camera may drop, resulting in
damage.
• When you close the rear cover, be careful not to catch your
fingers.
BRemoving the lens
1Rotate the lens section of the camera to face the back.
2Release the latch on the rear cover of the conversion lens unit.
3Rotate the lens section of the camera 180 degrees with the
latch released.
4Opentherear coveroftheconversion lens unit fully and remove
it from the camera.
CAbout the lens cap
Attach the lens cap with the supplied strap to the digital still camera
to avoid losing the lens cap.
1
3
4
2
