Sony MAV-555A User manual

MULTI ACCESS VIDEO DISK RECORDER
MAV-555A
AD/DA CONVERTER BOARD
BKMA-513
ASYNCHRONOUS NETWORK BOARD
BKMA-550
MAINTENANCE MANUAL
1st Edition (Revised 1)

MAV-555A
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien.Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
MAV-555A (SY) Serial No. 10001 and Higher
BKMA-513 (SY) Serial No. 10001 and Higher
BKMA-550 (SY) Serial No. 10001 and Higher

MAV-555A
Voor de klanten in Nederland
Dit apparaat bevat een MnO2-Li batterij voor memory
back-up.
Raadpleeg uw leverancier over de verwijdering van de
batterij op het moment dat u het apparaat bij einde
levensduur afdankt.
Gooi de batterij niet weg. maar lever hem in als KCA.
Bij dit produkt zijn batterijen geleverd.
Wanneer deze leeg zijn, moet u ze niet
weggooien maar inleveren als KCA.
Für Kunden in Deutschland
Entsorgungshinweis: Bitte werfen Sie nur entladene
Batterien in die Sammelboxen beim Handel oder den
Kommunen. Entladen sind Batterien in der Regel dann,
wenn das Gerät abschaltet und signalisiert “Batterie
leer”oder nach längerer Gebrauchsdauer der Batterien
“nicht mehr einwandfrei funktioniert”. Um
sicherzugehen, kleben Sie die Batteriepole z.B. mit
einem Klebestreifen ab oder geben Sie die Batterien
einzeln in einen Plastikbeutel.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer’s instructions.
Vorsicht!
Explosionsgefahr bei unsachgemäßem Austausch
der Batterie.
Ersatz nur durch denselben oder einen vom
Hersteller empfohlenen ähnlichen Typ. Entsorgung
gebrauchter Batterien nach Angaben des
Herstellers.
ATTENTION
Il y a danger d’explosion s’il y a remplacement
incorrect de la batterie.
Remplacer uniquement avec une batterie du même
type ou d’un type équivalent recommandépar le
constructeur.
Mettre au rebut les batteries usagées conformément
aux instructions du fabricant.
ADVARSEL!
Lithiumbatteri-Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning måkun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
ADVARSEL
Lithiumbatteri - Eksplosjonsfare.
Ved utskifting benyttes kun batteri som
anbefalt av apparatfabrikanten.
Brukt batteri returneres
apparatleverandøren.
VARNING
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en likvärdig typ
som rekommenderas av apparattillverkaren.
Kassera använt batteri enligt gällande
föreskrifter.
VAROITUS
Paristo voi räjähtää jos se on virheellisesti
asennettu.
Vaihda paristo ainoastaan laitevalmistajan
suosittelemaan tyyppiin.
Hävitäkäytetty paristo valmistajan ohjeiden
mukaisesti.
1 (P)

1 (E)
MAV-555A
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 5 (E)
Related manuals................................................................................................... 5 (E)
Contents ............................................................................................................... 6 (E)
Trademarks .......................................................................................................... 6 (E)
1. Error Message/Maintenance Functions
1-1. Error Message .......................................................................................1-1 (E)
1-1-1. Normal Indication ................................................................1-1 (E)
1-1-2. Error Indication ....................................................................1-2 (E)
1-2. Acquiring the Logs................................................................................1-3 (E)
1-2-1. How to Aquire the Logs of the MAV-555A ........................1-3 (E)
1-2-2. How to Acquire the Logs of the BKMA-550.......................1-6 (E)
1-3. Backing Up and Restoring the Contents of Memory (FM-81 board).... 1-10 (E)
1-4. Upgrading the Software ......................................................................1-13 (E)
1-4-1. How to Upgrading the MAV-555A Software Version ......1-13 (E)
1-4-2. How to Upgrading the BKMA-550 Software Version ......1-16 (E)
1-5. Upgrading the PLD Version................................................................1-24 (E)
2. Service Overview
2-1. Setup when Replacing Board or Battery is Replaced ...........................2-1 (E)
3. Parts and Board Replacement
3-1. Cautions before Servicing .....................................................................3-1 (E)
3-2. Removing the Cabinet...........................................................................3-2 (E)
3-2-1. Removing the Ornamental Bar, Ornamental Plate,
Blank Panel and Ornamental Panel......................................3-2 (E)
3-2-2. Removing the Top Plate and Rear Panel..............................3-4 (E)
3-3. Main Parts and Board Layout Diagram ................................................3-6 (E)
3-4. Replacing the Main Parts ......................................................................3-7 (E)
3-4-1. Power Supply .......................................................................3-7 (E)
3-4-2. Fan ........................................................................................3-7 (E)
3-4-3. Filter .....................................................................................3-8 (E)
3-4-4. Backup Battery.....................................................................3-9 (E)
3-4-5. HDD Unit ...........................................................................3-10 (E)
3-4-6. FL Display Tube (Indicator Tube) .....................................3-11 (E)

2 (E) MAV-555A
3-5. Replacing the Boards ..........................................................................3-12 (E)
3-5-1. Replacing the Plug-in Boards.............................................3-12 (E)
3-5-2. CN-2180 Board ..................................................................3-12 (E)
3-5-3. SDI-68 Board .....................................................................3-12 (E)
3-5-4. CN-2178 Board ..................................................................3-13 (E)
3-5-5. CN-2179 Board ..................................................................3-14 (E)
3-5-6. CN-1830 Board ..................................................................3-14 (E)
3-5-7. MB-947 Board ...................................................................3-17 (E)
4. Electrical Adjustment
4-1. General Information for Electrical Adjustment ....................................4-1 (E)
4-1-1. Equipment Required.............................................................4-1 (E)
4-1-2. Notes for Adjustment ...........................................................4-1 (E)
4-2. EM-3 Board Adjustment .......................................................................4-2 (E)
4-2-1. Video Monitor Out Level Adjustment .................................4-2 (E)
4-3. SDI-68 Board Adjustment.....................................................................4-3 (E)
4-3-1. SDI Free-Run Adjustment....................................................4-3 (E)
4-4. FM-81 Board Adjustment .....................................................................4-4 (E)
4-4-1. SCH DET Adjustment (525/60 mode) .................................4-4 (E)
4-4-2. SCH DET Adjustment (625/50 mode) .................................4-6 (E)
4-5. ADA-61 Board (BKMA-513) Adjustment ...........................................4-8 (E)
4-5-1. Audio Level Adjustment ......................................................4-8 (E)
4-5-2. Analog Audio Input Adjustment ........................................4-10 (E)
4-5-3. Distortion Adjustment ........................................................4-11 (E)
4-5-4. Preparation before Video Adjustment................................4-12 (E)
4-5-5. D/A Video Level Adjustment ............................................4-15 (E)
4-5-6. Setting upon Completion of Adjustment............................4-16 (E)
4-5-7. A/D Pedestal Video Level Adjustment ..............................4-17 (E)
4-5-8. A/D AGC Video Level Adjustment ...................................4-18 (E)
4-5-9. A/D Manual Video Level Adjustment ...............................4-19 (E)
4-5-10. A/D Video Adjustment 2 ...................................................4-19 (E)
4-5-11. Setting upon Completion of Adjustment............................4-19 (E)
5. Circuit Description
5-1. MAV-555A ...........................................................................................5-1 (E)
5-2. BKMA-550 ...........................................................................................5-4 (E)

3 (E)
MAV-555A
6. Spare Parts
6-1. Notes on Repair Parts..................................................................................6-1
6-2. Exploded Views ..........................................................................................6-2
6-3. Electrical Parts List ...................................................................................6-13
6-3-1. MAV-555A ..............................................................................6-13
6-3-2. BKMA-513 ..............................................................................6-14
6-3-3. BKMA-550 ..............................................................................6-14
7. Block Diagrams and Frame Wiring
Overall ....................................................................................................................7-3
ADA-61A/61B (BKMA-513) ................................................................................7-4
DM-127 ..................................................................................................................7-6
DPR-189A/189B ....................................................................................................7-8
EM-3.....................................................................................................................7-12
FP-128 ..................................................................................................................7-13
FM-81 ...................................................................................................................7-14
IF-837 ...................................................................................................................7-16
IF-860/PG-40A (BKMA-550)..............................................................................7-17
PU-121..................................................................................................................7-19
Frame Wiring........................................................................................................7-20

5 (E)
MAV-555A
Manual Structure
Purpose of this manual
This manual is the maintenance manual of the MAV-555A Multi Access Video Disk
Recorder.
This manual is intended for use by trained system and service engineers, and
describes the information that premise the service based on components replacement
(error message/maintenance functions, service overview, parts and board replace-
ment, electrical alignment, circuit descriptions, spare parts, block diagrams, and
frame wiring).
Moreover, describes the information for the following optional board.
.AD/DA Converter Board : BKMA-513
.Asynchronous Network Board : BKMA-550
Related manuals Besides this maintenance manual, the following manuals are available for the
MAV-555A.
..
..
.MAV-555A Operation Manual (Supplied with MAV-555A)
This manual describes the operation and function of the MAV-555A.
..
..
.MAV-555A Installation Manual (Supplied with MAV-555A)
This manual describes the information regarding the installation of the MAV-555A.
..
..
.BKMA-505 Operation Manual (Supplied with BKMA-505)
This manual describes the operation and function of the BKMA-505.
..
..
.BKMA-505 Installation Manual (Supplied with BKMA-505)
This manual describes the information regarding the installation of the optional
control panel BKMA-505.
..
..
.BKMA-513 Installation Manual (Supplied with BKMA-513)
This manual describes the information regarding the installation of the optional
board BKMA-513.
..
..
.BKMA-550 Operation Manual (Supplied with BKMA-550)
This manual describes the operation and function of the BKMA-550.
..
..
.BKMA-550 Installation Manual (Supplied with BKMA-550)
This manual describes the information regarding the installation of the optional
board BKMA-550.
..
..
.BKMA-570 Installation Manual (Supplied with BKMA-570)
This manual describes the information regarding the installation of the optional
analog audio expansion unit BKMA-570.

6 (E) MAV-555A
Contents The following is a summary of all the section for understanding the contents of this
manual.
Section 1 Error Message/Maintenance Functions
This section describes the menu and error message, etc.
Section 2 Service Overview
This section describes the setting when the circuit board, memory, or battery is
replaced.
Section 3 Parts and Board Replacement
This section describes the removal of cabinet, replacement of main parts and boards.
Section 4 Electrical Adjustment
This section describes the electrical alignment when maintenance.
Section 5 Circuit Descriptions
This section describes the circuit description of main boards
Section 6 Spare Parts
This section describes spare parts.
Section 7 Block Diagrams and Frame Wiring
This section describes the overall block diagram, main board block diagram, and
frame wiring.
Trademarks Trademarks and registered trademarks used in this manual are follows.
.Ethernet is a registered trademark of Xerox Corporation.
.IBM is a registered trademark of International Business Machines Corporation.
.Windows is a registered trademark of Microsoft Corporation.

1-1 (E)
MAV-555A
1-1. Error Message
This section describes the error messages that are dis-
played on the 8-bit LED on the board.
Board name Ref. No.
DM-127 D50 (MSB) to D57 (LSB) For R1, P1 ports
D58 (MSB) to D65 (LSB) For R2/P3, P2/R3
ports
FM-81 D301 (MSB) to D308 (LSB) FM block
D751 (MSB) to D758 (LSB) TM block
EM-3 D501 (MSB) to D508 (LSB)
1-1-1. Normal Indication
n
When the main power is turned on, the indication of the 8-
bit LED changes as shown below.
( : Turns on. : Turns off.)
1. Indication during booting
MSB LSB
2. Version and release date indication
When boot-up is complete, the version and release date are
displayed. Two digits of these data are displayed at one
time respectively in binary notation.
Example : V2.20 on December 25th, 2001
MSB LSB
Section 1
Error Message/Maintenance Functions
3. Normal Indication
When the version indication terminates, the display
changes to the normal indication.
(1) For the FM-81 (FM, TM) and EM-3 boards
All of the 8 bits turn on one after another.
MSB LSB
(2) For the DM-127 board
The higher 4 bits turn on one after another and the
lower 4 bits indicates the operating status.
MSB LSB
*: Operating status of the board (lower 4 bits)
: ROM version
(higher two digits) “02”
: ROM version
(lower two digits) “20”
: Calendar year
(higher two digits) “20”
: Calendar year
(lower two digits) “01”
: Month: “12”
: Day: “25”
*
: CLOSE (when UNLOAD is completed)
: STOP (including the status of UNLOAD
being in progress)
:REC
: MUTE
: STILL
: JOG
: PLAY
: VAR
: SHUTTLE
: SEND
: RECEIVE
: COMPILE
: COPY

1-2 (E) MAV-555A
1-1-2. Error Indication
If an error is detected during boot-up, the error message
“EM Board Not Respond”appears on the front panel. If
this message appears, reboot the MAV-555A. If the same
error message appears again, check the 8-bit LED on the
following boards.
Board Name Indication Error contents
DM-127 FPGA Config Error
SDI Encoder Reset Error
FM-81 DM1 Communication Error
(TM block) DM2 Communication Error
FM Communication Error
EM Communication Error
EM-3 Dual Port Memory Read/
Write Inspection Error
OS Resource Generation
Error
Initialize Timeout Error
Video/Audio-Router
Initialization Error
1-1. Error Message

1-3 (E)
MAV-555A
Cover
1-2. Acquiring the Logs
In this manual, the letters to be entered are differentiated from those that appear on the display, as shown
in the example below when using a personal computer.
Font and style of letters Display example Reference for distinction
Times font UTY> Automatically displayed message by a program
Helvetica regular
SDC-UTY Characters to be entered
(Italic)
Symbols "Enter key
\Space equivalent to a character
1-2-1. How to Aquire the Logs of the MAV-555A
This section describes how to acquire the logs using the macro function of Tera Term.
m
.Before starting to acquire the logs, set all ports to the stop mode.
.If an error occurs, acquire the logs and the memory contents of the FM-81 board.
Table of Required Files
c:\Program File\TTERMPRO\TTERMP32.EXE : Tera Term Pro execution file
c:\Program File\TTERMPRO\LogMacro\Log_PU.ttl : Log acquiring macro of PU-121 board
c:\Program File\TTERMPRO\LogMacro\Log_ALL.ttl : Log acquiring macro of five boards (excluding
PU-121)
c:\Program File\TTERMPRO\LogMacro\Log_DM1.ttl : Log acquiring macro of DM-127 board (R1/P1
port)
c:\Program File\TTERMPRO\LogMacro\Log_DM2.ttl : Log acquiring macro of DM-127 board (R2/P3,
P2/R3 ports)
c:\Program File\TTERMPRO\LogMacro\Log_FM.ttl : Log acquiring macro of FM-81 board (FM)
c:\Program File\TTERMPRO\LogMacro\Log_TM.ttl : Log acquiring macro of FM-81 board (TM)
c:\Program File\TTERMPRO\LogMacro\Log_EM.ttl : Log acquiring macro of EM-3 board
c:\Program File\TTERMPRO\GCD.ini :
Connection (PU-121 board)
1. Remove the cover of the system top panel and connect the Ethernet cross cable to the Ether terminal.
2. Connect the other connector of the Ethernet cross cable to a personal computer.
1-2. Acquiring the Logs

1-4 (E) MAV-555A
Microsoft(R) Windows 95
(C)Copyright Microsoft Corp 1981-1995.
C:\>ping\192.168.0.1"
C:\>ping\192.168.0.1"
Pinging 192.168.0.1 with 32 bytes of data:
Reply from 192.168.0.1: bytes=32 time=2ms TTL=254
Reply from 192.168.0.1: bytes=32 time=1ms TTL=254
Reply from 192.168.0.1: bytes=32 time<10ms TTL=254
Reply from 192.168.0.1: bytes=32 time=1ms TTL=254
C:\>
C:\>ping\192.168.0.1"
Pinging 192.168.0.1 with 32 bytes of data:
Request timed out
Request timed out
Request timed out
Request timed out
C:\>
Connection (excluding PU-121 board)
Connect the Ethernet terminal of the rear panel to a personal computer using an Ethernet cross cable.
Preparation
1. Set the IP address and the sub-net mask of the MAV-555A to the factory settings.
m
.The IP address and sub-net mask can be confirmed in set-up menu No. 220.
.The factory settings are as follows:
IP address : 192.168.0.1
Sub-net mask : 255.255.255.0
2. Set the IP address and the sub-net mask of the personal computer as follows:
IP address : 192.168.0.2
Sub-net mask : 255.255.255.0
3. Start up the personal computer.
4. Wait for the MS-DOS prompt (or command prompt) to appear.
5. Input [ping 192.168.0.1].
6. Confirm that the reply is returned normally.
Message example (normally)
Message example (abnormally)
7. If the reply is not returned normally, input [arp -d 192.168.0.1] and perform from step 5 again.
(There can be a case that the APR table information is left remained when two or more MAV-555As
are connected continuously.)
1-2. Acquiring the Logs

1-5 (E)
MAV-555A
Procedure for acquiring log
1. Start up Tera Term (Tera Term Pro Ver.2.3 or higher).
2. When the Tera Term: New connection dialog box appears, click “Cancel”.
Confirm that “Tera Term _[disconnected]”is displayed in the title bar.
3. Select [Control] _[Macro] from the top menu.
4. Select [Log_**.ttl] file.
n
To acquire all logs of the board, select [Log_ALL.ttl] file.
The dialog box asks whether to acquire the DM2 (R2/P3, P2/R3 ports) log. If this is not to be ac-
quired, click “No”.
5. The log is acquired automatically and saved to a file.
File name (example)
LogFM_2001-12-24 : Log of FM-81 (FM) board (downloaded on December 24, 2001)
LogPuV_2001-12-24 : Log of PU-121 board and video (downloaded on December 24, 2001)
n
Acquiring the same log twice or more on the same day rewrites the file because the file name is the
same as the previous one.
6. Quit Tera Term.
1-2. Acquiring the Logs

1-6 (E) MAV-555A
1-2-2. How to Acquire the Logs of the BKMA-550
Logs of the BKMA-550 (Asynchronous Network Board) are saved in the gateway PC. This section
describes how to acquire the logs using the Setup menu of the gateway PC.
Procedure to Acquire the Logs
In the case of acquiring the logs from the console display of the gateway PC
Log in with the authority of user: setup and acquire the logs as follows.
1. Enter the login name “setup”.
2. Enter the password “setup”.
3. The Setup menu appears.
In the case of acquiring the logs from other PC through network
Log in with the authority of user: setup and acquire the logs as follows.
1. Enter the login name “rsetup”.
2. Enter the password “rsetup”.
3. Enter the password “setup”.
4. The Setup menu appears.
FreeBSD/i386 (gw176) (ttyd0)
login: setup"
Password: setup"
FreeBSD/i386 (gw176) (ttyd0)
login: rsetup"
Password: rsetup"
Last login: Thu Oct 11 11:07:03 from 43.0.181.101
Copyright (c) 1980, 1983, 1986, 1988, 1990, 1991, 1993, 1994
The Regents of the University of California. All rights reserved.
FreeBSD 4.2-RELEASE (G2X) #5: Wed Sep 26 10:04:15 JST 2001
Welcome to FreeBSD!
Before seeking technical support, please use the following resources:
.Security advisories and updated errata information for all releases are
at http://www.FreeBSD.org/releases/ - always consult the ERRATA
section for your release first as it’s updated frequently.
.The Handbook and FAQ documents are at http://www.freebsd.org/ and,
along with the mailing lists, can be searched by going to
http://www.FreeBSD.org/search.html. If the doc distribution has
been installed, they’re also available formatted in /usr/share/doc.
If you still have a question or problem, please take the output of
‘uname -a’, along with any relevant error messages, and email it
as a question to the [email protected] mailing list. If you are
unfamiliar with FreeBSD’s directory layout, please refer to the hier(7)
man page. If you are not familiar with man pages, type “man man”.
You may also use ‘/stand/sysinstall’to re-enter the installation and
configuration utility. Edit /etc/motd to change this login announcement.
Password: setup"
1-2. Acquiring the Logs

1-7 (E)
MAV-555A
Saving logs
1. Select [2 Log] from the menu and press the [ENTER] key.
2. Select [2 System] from the menu and press the [ENTER] key.
3. Select [1 Dump] from the menu and press the [ENTER] key.
4. Press the [ENTER] key.
5. Press the [*] key to select [Cancel] and press the [ENTER] key.
Repeat selecting the [Cancel] and pressing the [ENTER] key three times to quit the menu.
G2xSetup (Ver.1.10) (Mon Oct 22 14:54:24 CDT 2002)
1 Setup : setup system settin
2 Lo : lo and status mana ement
3 Monitor : monitor IO status
4 Admin : administrator control
5 Install : software installation (version up)
R Reboot : system reboot
S Shutdown : system shutdown
e Exit : exit setup
[ OK ] Cancel
Lo and status mana ement
1 Kernel : display kernel lo
2 System : system lo mana ement
3 Ftp : ftp lo mana ement
e Exit : exit this menu
[ OK ] Cancel
System lo mana ement
1 Dump : dump lo to file
2 Clear : delete all lo file
e Exit : exit this menu
[ OK ] Cancel
tar: Removing leading / from absolute path names in the archive.
Loging to log/g2xlog-20021022-0.tgz
hit return to continue >>
1-2. Acquiring the Logs

1-8 (E) MAV-555A
Acquiring the log file
When the procedure to save the logs is performed, the log file is saved in the /home/setup/log folder of
the gateway PC. The other PC can acquire this log file using FTP.
(example : Acquiring the log file from a Windows PC)
1. Start up the MS-DOS prompt (or command prompt).
2. Enter [ftp 192.168.0.1]. (Enter the IP address of the gateway PC in the underlined characters.)
3. When your PC is connected to other PC with ftp and the user name entry prompt is returned, enter
user: [setup] and password: [setup].
4. Enter [cd log] to move to the /log directory.
5. Enter [ls] and confirm the log file as shown below.
6. Enter [bin] to select the binary mode.
Microsoft Windows 2000 [Version 5.00.2195]
(C) Copyright 1985-2000 Microsoft Corp.
D:\>ftp\192.168.0.1"
Connected to 192.168.0.1
220 192.168.0.1 FTP server (Version 6.00LS) ready.
User (192.168.0.1:(none)) : setup"
331 Password required for setup.
Password : setup"
230 User setup logged in, access restrictions apply.
ftp>
ftp> cd\log"
250 CWD command successful.
ftp>
ftp> ls"
200 PORT command successful.
150 Opening ASCII mode data connection for ‘file list’.
g2xlog-20021022-0.tgz
226 Transfer complete.
ftp: 184 bytes received in 0.01Seconds 18.40Kbytes/sec.
ftp>
ftp> bin"
200 Type set to I.
ftp>
1-2. Acquiring the Logs

1-9 (E)
MAV-555A
7. Enter [get g2xlog-20021022-0.tgz] to acquire the saved logs.
(Enter the log filename that is saved by the menu in the underlined characters.)
ftp> get\g2xlog-20021022-0.tgz"
200 PORT command successful.
150 Opening BINARY mode data connection for
‘g2xlog-20021022-0.tgz’(214593 bytes).
226 Transfer complete.
ftp: 214593 bytes received in 1.58Seconds 135.65Kbytes/sec.
ftp>
1-2. Acquiring the Logs

1-10 (E) MAV-555A
1-3. Backing Up and Restoring the Contents of Memory (FM-81 board)
This section describes how to back up or restore the memory contents of the FM-81 board from the MS-
DOS prompt (or command prompt).
m
.The file management information (file system) and the set-up information are stored in these memories.
Before operating, back up the contents.
.When replacing the FM-81 board
.When replacing the back-up battery of the FM-81 board
.Backing-up is possible when the file is loaded. However, when backing up for restoration when replac-
ing the battery, unload the file and back it up. (If the file is not unloaded, an error occurs during restora-
tion so that restoration cannot be performed.)
.The contents of SRAM are retained by the super capacitor when the battery is replaced. If the operation
does not take a long time (sixty minutes or less), restoration does not need to be performed after
replacing the battery.
If the following symptoms occur, restore the contents.
Date or time is not correct.
The file list does not appear on the display of the control panel.
The settings of the set-up menu have returned to the factory settings.
Connection
Connect the Ether terminal of the rear panel to a personal computer using an Ethernet cross cable.
Preparation
1. Set the IP address of the MAV-555A to the factory setting.
m
.The IP address and sub-net mask can be confirmed in set-up menu No. 220.
.The factory settings are as follows:
IP address : 192.168.0.1
Sub-net mask : 255.255.255.0
2. Set the IP address and the sub-net mask of the personal computer as follows:
IP address : 192.168.0.2
Sub-net mask : 255.255.255.0
3. Start up the personal computer.
4. Wait for the MS-DOS prompt (or command prompt) to appear.
5. Input [ping 192.168.0.1].
6. Confirm that the reply is returned normally.
7. If the reply is not returned normally, input [arp -d 192.168.0.1] and perform from step 5 again.
(There can be a case that the APR table information is left remained when two or more MAV-555As
are connected continuously.)
1-3. Backing Up and Restoring the Contents of Memory (FM-81 board)
