UP-DF750
FilmStationTMDry Film Mammography Imager
The Sony UP-DF750 is a unique and versatile multi-film imager that supports both mammography as
well as a wide variety of radiology film based applications. The UP-DF750 features a high resolution
thermal head resulting in diagnostic quality mammography films. The UP-DF750 is designed to meet
the needs of a busy radiology department or imaging center and is capable of printing 8" x 10",
10" x 12", 11" x 14", and 14" x 17" film sizes for general radiology applications as well as 8" x 10" and
10" x 12" for mammography imaging.
The UP-DF750 is engineered with 3.8 D-max and 604 dpi resulting in an excellent resolution to
compliment any FFDM system. The UP-DF750 is one of the smallest compact imagers available
in the medical industry. The UP-DF750 is unique in its versatile design and can be positioned
horizontally or vertically which makes it ideal for facilities that need to maximize their space.
Sony’s UP-DF750 Mammography Film Imager is the ideal film imager for the digital era.
• Ideal for Digital Mammography (FFDM)as well as CT, MR, CR, DR and
ultrasound film imaging
• igh density thermal head with a D-max of 3.8
• igh resolution film imager at 604dpi
• Compact size and low cost of ownership
• Multi-modality capability allows for cost savings for
any imaging environment
• Dual trays accommodate all film sizes for added convenience
• Built-in DICOM 3.0 Interface
• User-friendly controls located on front panel
• Large view 3.8"LCD panel displays information required for
daily QA testing as well as other critical settings
SONY55278_UP-DF750 3/30/09 3:23 PM Page 1

©2009 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Features and
specifications are subject to change without notice. All non-metric weights and measures are approximate. Sony and FilmStation are
trademarks of Sony.
Caution: Federal (USA)law restricts this device to sale by or on the order of a physician or other appropriately licensed medical professional.
Caution: See product labeling for indications, contraindications, warnings, cautions and directions for use.
ME-UPDF750
Specifications
Power Requirements 100 to 240V AC 50/60 z
Power Consumption 430W
Operating Temperature 50F to 86F (10C to 30C)
Operating umidity 20% to 80% (no condensation allowed)
Operating Pressure 700 hpa to 1060 hpa
Storage & Transport Temperature -4ºF to +140ºF (-20ºC to +60ºC)
Storage & Transport umidity 20% to 80% (no condensation allowed)
Storage & Transportation Pressure 700 hpa to 1060 hpa
Dimensions About 23 5/8 x 12 1/2 x 27 1/8 inches (w/h/d)( 600 x 316 x 686 mm)
Weight 147lbs 11oz
Printing System Thermal
Resolution 604 PPI (42 UM)
Gradation 14 bit
Maximum Print Size 346.7 x 415.3 mm (when using the UPT-517BL)
Picture Elements 8,256 x 9,888 dots (w/h) (UPT-517BL)
Printing Time (Approx.)70 films/hours using (14" X 17" the UPT- 517BL)
90 films/hours using (10" X12" the UPT-M712BL)and (8" X10" the UPT-M710BL)
Maximum Density 3.8 D-Max (using UPT-M710BL /UPT-M712BL high-density mammography film)
Digital Interface Network port X1 (RJ-45 Modular Jack),conforming to1000BASE-TX Gigabit
Film Tray 2* (*Optional trays available to swap up to 6 different types of film on demand)
Supplied Accessories Media Starter Pack – UPT-M710BL (125 sheets)
Cleaning Kit (1), Caster for setting the printer vertically (2),
Stopper Sheet (1), Operating Guide (1), CD-ROM (1), Floppy Disk (1),
Warranty Card (1)(
for customers in the U.S.A. and Canada).
Optional Accessories Blue Thermal Mammography igh Density Film Printing Pack
UPT-M710BL (8" x 10")
Blue Thermal Mammography igh Density Film Printing Pack
UPT-M712BL (10" x 12")
Blue Thermal Film Printing Pack UPT-517BL (14" x 17")
Blue Thermal Film Printing Pack UPT-514BL (11" x 14")
Blue Thermal Film Printing Pack UPT-512BL (10" x 12")
Blue Thermal Film Printing Pack UPT-510BL (8" x 10")
Additional Upper Tray UPDF750/UTRAY
Additional Lower Tray UPDF750/LTRAY
Cleaning Kit UPA-500
Print Media
Sony E ectronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/medical
Sony engineered therma fi m media
was specifica y designed for use with
the Fi mStation imager.
14'' x 17''
11'' x 14''
10'' x 12''
UPT-M710BL Media (8'' x 10'')
B ue Therma Fi m Printing Pack
UPT-M712BL Media (10'' x 12'')
B ue Therma Fi m Printing Pack
UPT-517BL Media (14'' x 17'')
B ue Therma Fi m Printing Pack
UPT-514BL Media (11'' x 14'')
B ue Therma Fi m Printing Pack
UPT-512BL Media (10'' x 12'')
B ue Therma Fi m Printing Pack
UPT-510BL Media (8'' x 10'')
B ue Therma Fi m Printing Pack
8'' x 10''
