Sony LBT-SH2000 User manual

4-273-674-81(1)
LBT-SH2000
Mini HI-FI
Component System
D:\NORM'S JOB\SONY HA\SO120012\LBT-SH2000\4273674811_US\US01COV.fm
masterpage: Cov
LBT-SH2000
4-273-674-81(1)
Operating Instructions
Manual de instrucciones
US
ES

model name [LBT-SH2000]
[4-273-674-81(1)] US
2US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US020REG.fm]
masterpage:Left
To reduce the risk of fire or electric shock, do
not expose this apparatus to rain or moisture.
To reduce the risk of fire, do not cover the
ventilation opening of the apparatus with
newspapers, tablecloths, curtains, etc.
Do not place the naked flame sources such as
lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do
not expose this apparatus to dripping or
splashing, and do not place objects filled
with liquids, such as vases, on the apparatus.
As the main plug is used to disconnect the
unit from the mains, connect the unit to an
easily accessible AC outlet. Should you
notice an abnormality in the unit, disconnect
the main plug from the AC outlet
immediately.
Do not install the appliance in a confined
space, such as a bookcase or built-in cabinet.
Do not expose batteries or apparatus with
battery-installed to excessive heat such as
sunshine, fire or the like.
The unit is not disconnected from the mains
as long as it is connected to the AC outlet,
even if the unit itself has been turned off.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
This appliance is classified as a CLASS 1
LASER product. This marking is located on
the rear exterior.
When unpacking or handling a big and/or
heavy speaker, be sure to handle the unit
with two or more persons. Dropping the unit
may cause personal injury and/or property
damage.
Owner’s Record
The model and serial numbers are located on
the rear of the unit. Record these numbers in
the space provided below. Refer to them
whenever you call upon your Sony dealer
regarding this product.
Model No. __________________________
Serial No. __________________________
This symbol is intended to
alert the user to the
presence of uninsulated
“dangerous voltage” within
the product’s enclosure that
may be of sufficient
magnitude to constitute a
risk of electric shock to
persons.
This symbol is intended to
alert the user to the
presence of important
operating and maintenance
(servicing) instructions in
the literature
accompanying the
appliance.
Important Safety
Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers)
that produce heat.
WARNING

model name [LBT-SH2000]
[4-273-674-81(1)] US
3US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US020REG.fm]
masterpage:Right
9) Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third
grounding prong. The wide blade or the
third prong are provided for your safety.
If the provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
11) Only use attachments/accessories
specified by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
The following FCC
statement applies only to
the version of this model
manufactured for sale in
the U.S.A. Other versions
may not comply with FCC
technical regulations.
NOTE:
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
CAUTION
You are cautioned that any changes or
modifications not expressly approved in this
manual could void your authority to operate
this equipment.
US
Continued
l

model name [LBT-SH2000]
[4-273-674-81(1)] US
4US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US020REG.fm]
masterpage:Left
License and Trademark Notice
• “WALKMAN” and “WALKMAN” logo
are registered trademarks of Sony
Corporation.
• MPEG Layer-3 audio coding technology
and patents licensed from Fraunhofer IIS
and Thomson.
• Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
• This product contains technology subject
to certain intellectual property rights of
Microsoft.
Use or distribution of this technology
outside of this product is prohibited
without the appropriate license(s) from
Microsoft.
• “PlayStation” is a registered trademark of
Sony Computer Entertainment Inc.

LBT-SH2000
4-273-674-81(1)
5US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US030TOC.fm]
masterpage:Right
Table of Contents
Guide to parts and controls ..........6
Getting Started
Hooking up the system
securely ......................................10
Positioning the speakers.............12
Setting the clock.........................12
Disc
Playing an AUDIO CD/MP3
disc .............................................12
Using play mode ........................13
Tuner
Listening to the radio .................14
Receiving RDS broadcasts.........15
USB Device
Before using the USB device
with this system..........................16
Transferring music .....................16
Playing a file ..............................19
Sound Adjustment
Adjusting the sound ...................21
Creating your own sound
effect ..........................................21
Creating a party atmosphere
(DJ EFFECT) .............................22
Other Operations
Singing along ............................ 22
Changing the lighting pattern
on the speakers .......................... 22
Using the timers ........................ 23
Changing the display................. 24
Using optional equipment ......... 25
Deactivating the buttons on the
unit (Child Lock)....................... 25
Additional Information
Playable discs............................ 25
Troubleshooting ........................ 26
Messages ................................... 30
Precautions ................................ 31
Specifications ............................ 32

model name [LBT-SH2000]
[4-273-674-81(1)] US
6US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US04PLA.fm]
masterpage:Left
Guide to parts and controls
This manual mainly explains operations using the unit, but the same operations can also
be performed using the buttons on the remote control having the same or similar names.
Unit
–Front view
–Top view
1454623
7
8
q;
9
qj
qh
9
qg qf qd qs qa44
qk ql

model name [LBT-SH2000]
[4-273-674-81(1)] US
7US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US04PLA.fm]
masterpage:Right
Remote control RM-SCU37B
1
"/1 (on/standby)
Turn on the system, or set it to standby
mode. The STANDBY indicator lights up
in red when the system is turned off.
B
Remote control sensor
C
Display panel
D
Unit: / / /
Select the menu items.
+/– (select folder)
Select a folder on an MP3 disc or a USB
device.
m/M (rewind/fast forward)
Hold down to find a point in a track or file
during playback.
Unit: l/L (go back/go
forward)
Select a track or file.
Remote control: ./>
(go back/go forward)
Select a track or file.
Unit: TUNING +/–
Remote control: +/– (tuning)
Tune to the station you want.
E
Unit: VOLUME/DJ CONTROL
Adjust the volume.
Adjust the DJ EFFECT level (page 22).
You cannot use this knob to adjust the
volume when the DJ EFFECT is
activated.
Remote control: VOLUME +/–*
Adjust the volume.
* The VOLUME + button has a tactile dot. Use
the tactile dot as a reference when operating
the system.
F
Disc slot
G
ZEJECT
Eject a disc.
H
OPTIONS
Enter the option menus.
TUNER/BAND
Select the TUNER function.
Select the FM or AM band during
TUNER function.
CD
Select the CD function.
Unit: USB/USB SELECT
Remote control: USB
Select the USB function.
Select the USB device connected to the
A or B port during USB function.
BAND
w;
wa
4
q;
9
ql
4
4
5
1
wh
wg
wf
wd
8
qj
ws
Continued
l

model name [LBT-SH2000]
[4-273-674-81(1)] US
8US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US04PLA.fm]
masterpage:Left
I
Unit: NX (play/pause)
Remote control: N (play),
X(pause)
Start or pause playback.
To resume playback of the USB device,
press NX or N.
x(stop)
Stop playback.
Press xtwice to cancel resume play of the
USB device.
J
Unit: PC
Select the PC function.
Unit: TV
Select the TV function.
Unit: DVD/SAT
Select the DVD/SAT function.
Unit: GAME
Select the GAME function.
Remote control: FUNCTION
Select a function.
K
TV L/R jacks
Use an audio cord (not supplied) to
connect to the audio output jacks of a TV.
The TV sound is output through this
system.
L
PC L/R jacks
Use an audio cord (not supplied) to
connect to the audio output jacks of an
audio equipment. The audio is output
through this system.
M
B (PLAY/REC) port
Connect and transfer to an optional USB
device.
B indicator
Lights up in red when transferring to the
connected optional USB device.
N
A (PLAY) port
Connect an optional USB device.
A indicator
O
MIC IN jack
Connect a microphone.
MIC LEVEL
Adjust the microphone volume.
P
Unit: FLANGER, ISOLATOR,
SOUND FLASH, PHASER
Activate or select the DJ EFFECT type.
Q
Unit: SEARCH
Enter or exit search mode.
Unit: GROOVE
Reinforce the bass.
Unit: PRESET EQ
Remote control: EQ
Select the sound effect (page 21).
REC TO USB B
Transfer onto the optional USB device
which is connected to the B port.
R
RETURN
Return to previous selection.
S
ENTER
Enter the settings.
T
CLOCK/TIMER SELECT (page 23)
CLOCK/TIMER SET (page 12, 23)
Set the clock and the timers.

model name [LBT-SH2000]
[4-273-674-81(1)] US
9US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US04PLA.fm]
masterpage:Right
U
REPEAT/FM MODE
Listen to a disc, a USB device, a single
track or file repeatedly (page 14, 20).
Select the FM reception mode (monaural
or stereo) (page 14).
V
CLEAR
Delete the last step from the program list.
W
TUNER MEMORY (page 15)
Preset the radio station.
X
PLAY MODE/TUNING MODE
Select the play mode of an AUDIO CD,
MP3 disc or a USB device (page 13, 20).
Select the tuning mode (page 14).
Y
DISPLAY
Change the information on the display
panel.
Z
SLEEP (page 23)
Set the Sleep Timer.

model name [LBT-SH2000]
[4-273-674-81(1)] US
10US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US05CON.fm]
masterpage:Left
Hooking up the system securely
AAntennas
Find a location and an orientation that
provide good reception, and then set up
the antennas.
Keep the antennas away from the speaker
cords, the power cord and the USB cable
to avoid picking up noise.
BGAME L/R jacks
Use an audio cord (not supplied) to
connect to the audio output jacks of a
gaming device (such as PlayStation 3).
The audio is output through this system.
CDVD/SAT L/R jacks
Use an audio cord (not supplied) to
connect to the audio output jacks of an
audio/video equipment. The audio is
output through this system.
DLED SPEAKER terminals
Connect the LED SPEAKER connector of
the speaker to this terminal.
The lighting on the speakers will react
according to the music source. You can
select the lighting pattern according to
your preference (page 22).
Getting Started
FM/AM
LED SPEAKER
ANTENNA
L
R
DVD/SAT
RL LR
IMPEDANCE USE 4 Ω
L
R
RL
GAME
IMPEDANCE USE 4 Ω
HIGH CHANNEL
SPEAKERS
LOW CHANNEL
SPEAKERS
DE
C
BE
F
A
Extend the FM lead
antenna horizontally
AM loop antenna

model name [LBT-SH2000]
[4-273-674-81(1)] US
11US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US05CON.fm]
masterpage:Right
Getting Started
ESpeakers
The speaker connectors are color-coded
with their respective speaker terminals on
the unit.
HIGH CHANNEL
LOW CHANNEL
Notes
• Be sure to use only the supplied speakers.
• When connecting speaker cords, insert the
connector straight into the terminals.
FPower
Plug the power cord into a wall socket.
The demonstration appears in the display
panel. Press "/1 to turn on the system and
the demonstration automatically ends.
If the supplied adaptor on the plug does
not fit your wall outlet, detach it from the
plug (only for models equipped with an
adaptor).
Insert the two supplied R6 (size AA)
batteries, matching the polarities shown
below.
Notes
• Do not mix an old battery with a new one or
mix different types of batteries.
• If you do not use the remote for a long period
of time, remove the batteries to avoid damage
from battery leakage and corrosion.
Attaching the speaker foot
Attach the supplied speaker foot at each
corner on the bottom of the speakers to
stabilize the speakers and to prevent them
from slipping.
White
Red
Blue
Grey
Inserting batteries

model name [LBT-SH2000]
[4-273-674-81(1)] US
12US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Left
Positioning the
speakers
To obtain optimum performance from the
system, we recommend you to place the
speakers as shown below.
AUnit
BSpeaker (left)
CSpeaker (right)
Setting the clock
You cannot set the clock in Power Saving
Mode.
Use the buttons on the remote control to
perform this operation.
1Press "/1 to turn on the system.
2Press CLOCK/TIMER SET.
If “PLAY SET” appears in the display
panel, press ./>repeatedly to
select “CLOCK SET”, then press
ENTER.
3Press ./>repeatedly to set
the hour, then press ENTER.
4Press ./>repeatedly to set
the minutes, then press ENTER.
Playing an AUDIO CD/
MP3 disc
1Press CD.
2Insert a disc with the label side
facing up.
To search a track or MP3 file
(TRACK SEARCH)
1Press SEARCH.
2(MP3 files only)
Press / to select the folder you
want, then press ENTER or NX.
3Press / to select the track or file
you want, then press ENTER or
NX.
The selected track or file starts
playback.
Notes on playing discs
• The system can recognize up to
– 999 folders (including root folder).
– 999 MP3 files.
– 250 MP3 files on a single folder.
– 8 folder levels (tree structure of files).
• CD-TEXT information is not supported.
A
BC
0.3 m
(1 foot)
0.3 m
(1 foot)
Disc

model name [LBT-SH2000]
[4-273-674-81(1)] US
13US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Right
Disc
Using play mode
Press PLAY MODE on the remote control
repeatedly when playback is stopped.
• (blank): a disc
• *: all MP3 files in the folder on the
disc
* When playing an AUDIO CD, “ ”
performs the same operation as normal play
mode.
Press PLAY MODE on the remote control
repeatedly when playback is stopped.
• SHUF: shuffle a disc.
• SHUF*: shuffle all MP3 files in the
folder on the disc
* When playing an AUDIO CD, “ SHUF”
performs the same operation as “SHUF” play
mode.
Note
When you turn off the system, the selected
Shuffle Play is cleared and the play mode
returns to Normal Play.
You can make a program of up to 25 steps
in the order you want them to be played
back.
Use the buttons on the remote control to
perform this operation.
1For CD function:
Press CD.
For USB function:
Press USB.
2When playback is stopped,
press PLAY MODE repeatedly
until “PGM” lights up in the
display panel.
3For USB function:
Press USB repeatedly to select the
USB you want.
4(Audio files only)
Press +/– repeatedly to select a
folder.
If you want to program all files in the
folder, press ENTER.
5Press ./>repeatedly to
select the track or file you want,
then press ENTER.
“--.--” appears when the total playing
time exceeds 100 minutes for an
AUDIO CD or when you program an
audio file.
6Repeat steps 3 to 5 to program
additional tracks or files.
7Press Nto start Program Play.
To cancel Program Play
When playback is stopped, press PLAY
MODE on the remote control repeatedly
until “PGM” disappear from the display
panel.
Playing in original order
(Normal Play)
Playing in random order
(Shuffle Play)
Creating your own program
(Program Play)
Selected track
or file number
Total playing time of
program (including
selected track)
Continued
l

model name [LBT-SH2000]
[4-273-674-81(1)] US
14US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Left
To delete the last step from the
program list
Press CLEAR on the remote control when
playback is stopped.
Notes
• (CD function only) The program list remains
available until you eject the disc.
• (USB function only) The program list is
cleared when you:
– remove the USB device.
– switch the USB memory select.
Press REPEAT on the remote control
repeatedly.
• REP: repeat all tracks or files
• REP 1: repeat a track or file
Listening to the radio
Use the buttons on the remote control to
perform this operation.
1Press TUNER/BAND repeatedly
to select FM or AM band.
2For automatic scanning:
Press TUNING MODE repeatedly
until “AUTO” lights up in the display
panel. Then, press +/–.
Scanning stops automatically when a
station is tuned in, and then “TUNED”
and “STEREO” (for FM stereo
programs only) light up in the display
panel.
If “TUNED” does not light up and
scanning does not stop, press xto stop
scanning. Then, perform manual
tuning (below).
For manual tuning:
Press TUNING MODE repeatedly
until “AUTO” and “PRESET”
disappear from the display panel.
Then, press +/– repeatedly to tune to
the station you want.
Tip
To reduce static noise on a weak FM stereo
station, press FM MODE repeatedly until
“MONO” lights up in the display panel.
To change the AM tuning interval
The default setting for AM tuning interval
is 9 kHz (or 10 kHz for some areas). You
cannot change the AM tuning interval in
Power Saving Mode.
Use the buttons on the unit to perform this
operation.
Playing repeatedly (Repeat
Play)
Tuner

model name [LBT-SH2000]
[4-273-674-81(1)] US
15US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Right
Tuner
1Press TUNER/BAND repeatedly to
select AM band.
2Press "/1 to turn off the system.
3While holding down ENTER, press
"/1.
“AM 9K STEP” or “AM 10K STEP”
appears in the display panel.
When you change the interval, all the
AM preset stations are erased.
You can store up to 20 FM and 10 AM
stations as your favorite stations.
Use the buttons on the remote control to
perform this operation.
1Tune to the station you want.
2Press TUNER MEMORY.
3Press +/– repeatedly to select
the preset number you want,
then press ENTER.
“COMPLETE” appears in the display
panel. The station is stored.
To tune to a preset station
Press TUNING MODE repeatedly until
“PRESET” lights up in the display panel.
Then, press +/– repeatedly to select the
preset number you want.
Receiving RDS
broadcasts
This system allows you to use Radio Data
System (RDS), which enables radio
stations to send additional information
along with the regular programming
signal. This system offers convenient
RDS features, such as Program Service
name display. RDS is available only for
FM stations.*
* Not all FM stations provide RDS service, nor
do they provide the same type of services. If
you are not familiar with the RDS services in
your area, check with your local radio stations
for details.
Simply select a station on the FM
band.
When you tune to a station that provides
RDS services, the Program Service name
appears in the display panel.
You can check the RDS information by
pressing DISPLAY on the remote control
repeatedly.
Note
RDS may not work properly if the station you
tuned to is not transmitting the RDS signal or if
the signal strength is weak.
Presetting radio stations
Preset number

model name [LBT-SH2000]
[4-273-674-81(1)] US
16US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Left
Before using the USB
device with this system
Check the websites below for the
information about compatible USB
devices.
<http://www.sony.com/shelfsupport>
Note on the maximum number of
audio files and folders on a USB
device
This system cannot transfer or playback audio
files and folders of the USB device in the
following cases.
– When the number of audio files in a folder
exceeds 250.
– When the number of audio files in a USB
device exceeds 3000.
– When the number of folders in a USB device
exceeds 1000.
Note
Do not remove the USB device during
transferring or erase operations. Doing so may
corrupt the data on the USB device or damage
the USB device itself.
To select the playback source or
transferring destination
If the USB device has more than one
memory (for example, internal memory
and a memory card), you can select which
memory to use as a playback source or
transferring destination.
Note
You cannot select a memory during playback or
transferring. Make sure to select a memory
before starting playback or transferring.
1Connect the USB device to the
A or B port on the unit.
2Press USB/USB SELECT
repeatedly to select “USB A” or
“USB B”.
3Press OPTIONS when playback is
stopped.
4Press / to select “USB MEM
SEL”, then press ENTER.
5Press / to select the memory
you want, then press ENTER.
6Start playback the audio files of the
selected memory or start
transferring.
Transferring music
You can transfer music from a sound
source to a USB device.
The audio format of files transferred by
this system is MP3. However, you can
also transfer WMA and AAC files from
USB A to USB B.
Notes
• When transferring from an AUDIO CD, the
tracks are transferred as 128 kbps MP3 files.
When transferring from an MP3 disc, MP3
files are transferred with the same bit rate as
the original MP3 files.
When transferring from a USB device, the
audio files are transferred with the same bit
rate as the original audio files.
• When transferring from TUNER, PC, TV,
DVD/SAT, GAME function, the music are
transferred as 128 kbps MP3 files.
Note on copyright-protected
content
The transferred music is limited to private
use only. Use of the music beyond this
limit requires permission of the copyright
holders.
USB Device

model name [LBT-SH2000]
[4-273-674-81(1)] US
17US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Right
USB Device
You can easily transfer all the music on a
disc to a USB device (CD-USB
Synchronized Transfer). You can also
transfer a single track or MP3 file during
playback (REC1 Transferring).
1Connect a transferable USB
device to the B port as
shown below.
2Press CD.
3Insert the disc you want to
transfer.
4For CD-USB Synchronized
Transfer:
When playback is stopped, press
PLAY MODE on the remote control
repeatedly to select the play mode you
want.
Note
If you start transferring in Shuffle Play or
Repeat Play, the selected play mode is
automatically changes to Normal Play.
For REC1 Transferring:
Select the track or MP3 file you want
to transfer, then start playback.
5Press REC TO USB B.
“PUSH ENTER” appears in the
display panel.
6Press ENTER.
Transferring starts when “DON’T
REMOVE” appears in the display
panel.
For CD-USB Synchronized
Transfer:
When the transferring is completed,
the disc and the USB device stop
automatically.
For REC1 Transferring:
When the transferring is completed,
the disc continues to play.
You can transfer the sound from analog
audio sources (other than CD and USB
function) to a USB device.
1Connect a transferable USB
device to the B port on the
unit (page 17).
2Press FUNCTION repeatedly to
select the source you want to
transfer.
3Press REC TO USB B.
“PUSH ENTER” appears in the
display panel.
4Press ENTER.
Transferring starts when “DON’T
REMOVE” appears in the display
panel.
5Start playback the source.
To stop transferring
Press x.
Transferring music from a disc
USB device
Transferring analog audio
(Analog Transferring)
Continued
l

model name [LBT-SH2000]
[4-273-674-81(1)] US
18US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Left
To create a new MP3 file
Press REC TO USB B.
“NEW TRACK” appears in the display
panel.
If you press REC TO USB B again after a
few seconds, a new MP3 file cannot be
created.
Note
When a new MP3 file is created, transferring is
disabled for the time being.
Tip
A new MP3 file is created automatically after
approximately 1 hour of transferring.
You can easily transfer the audio files
from a USB device to another USB device
(USB A-USB B Synchronized Transfer).
You can also transfer a single audio file
during playback (USB A-USB B REC1
Transferring).
1Connect a transferable USB
device to the B port, then
connect the USB device you
want to transfer to A port.
2Press USB/USB SELECT
repeatedly to select “USB A”.
3For USB A-USB B Synchronized
Transfer:
When playback is stopped, press
PLAY MODE on the remote control
repeatedly to select the play mode you
want.
Note
If you start transferring in “ALL USB”,
“ALL USB SHUF”, “1 USB SHUF” and
Repeat Play, the play mode automatically
changes to “1 USB”.
If you start transferring in “ SHUF”, the
play mode automatically changes to “ ”.
For USB A-USB B REC1
Transferring:
Select the audio file you want to
transfer, then start playback.
4Press REC TO USB B.
“PUSH ENTER” appears in the
display panel.
5Press ENTER.
Transferring starts when “DON’T
REMOVE” appears in the display
panel.
For USB A-USB B Synchronized
Transfer:
When the transferring is completed,
both USB devices stop automatically.
For USB A-USB B REC1
Transferring:
When the transferring is completed,
the audio file continues to play.
When transferring to a USB device, a
“MUSIC” folder is created directly below
the “ROOT”. Folders and files are
generated within this “MUSIC” folder as
follows.
CD-USB Synchronized Transfer
CD-USB REC1 Transferring
Transferring music from USB
device
Folder and file generation
rules
Transferring
source
Folder name File name
MP3 Same as the transferring source
AUDIO CD “CDDA0001”* “TRACK001”*
Transferring
source
Folder name File name
MP3
“REC1-MP3”
Same as the
transferring
source
AUDIO CD “REC1-CD” “TRACK001”*

model name [LBT-SH2000]
[4-273-674-81(1)] US
19US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Right
USB Device
Analog Transferring
USB A-USB B Synchronized Transfer
USB A-USB B REC1 Transferring
* Folder and file numbers are assigned serially
thereafter.
Notes on transferring
• While transferring from an MP3 disc, AUDIO
CD or USB device, no sound is output.
• CD-TEXT information is not transferred in
the created MP3 files.
• Transferring stops automatically if:
– the USB device runs out of space during
transferring.
– the number of audio files and folders on the
USB device reaches the limit for the number
that the system can recognize.
– the function or tuner band is changed.
• If a folder or file that you are trying to transfer
already exists on the USB device with the
same name, a sequential number is added after
the name without overwriting the original
folder or file.
• You cannot eject the disc, select another track
or file, pause playback or find a point in the
track or file during CD-USB Synchronized
Transfer or REC1 Transferring.
• When transferring music to a Walkman®
using “Media Manager for WALKMAN”, be
sure to transfer in MP3 format.
• When connecting a Walkman®to the system,
be sure to connect after the display “Creating
Library” or “Creating Database” on the
Walkman®has disappeared.
Playing a file
The audio formats that can be played back
by this system are as follows:
– MP3: file extension “.mp3”
– WMA: file extension “.wma”
– AAC: file extension “.m4a”, “.mp4” or
“.3gp”
If the audio files have the above file
extension but are not the respective
formats, the system may produce noise or
may malfunction.
1Press USB/USB SELECT
repeatedly to select “USB A” or
“USB B”.
2Connect a USB device to the
A or B port on the unit.
The display changes as follows:
READING txxxx FOLDER*
* “xxxx” represent number of folders.
3Press NX.
The audio files are played back in
alphabetical order.
To search an audio file
(TRACK SEARCH)
1Press SEARCH.
2Press / to select the folder you
want, then press ENTER or NX.
Transferring
source
Folder name File name
FM “TUFM0001”* “TRACK001”*
AM “TUAM0001”*
PC “EXPC0001”*
TV “EXTV0001”*
DVD/SAT “EXDS0001”*
GAME “EXGA0001”*
Transferring
source
Folder name File name
Audio files
(MP3,
WMA,
AAC)
Same as the transferring source
Transferring
source
Folder name File name
Audio files
(MP3,
WMA,
AAC)
“REC1-MP3”
Same as the
transferring
source
Continued
l

model name [LBT-SH2000]
[4-273-674-81(1)] US
20US
filename[D:\NORM'S JOB\SONY HA\SO120012\LBT-
SH2000\4273674811_US\US06BAS.fm]
masterpage:Left
3Press / to select the audio file
you want, then press ENTER or
NX.
The selected file starts playback.
To erase audio files or folders from
the USB device
1Connect a USB device to the A
or B port on the unit.
2Press USB/USB SELECT
repeatedly to select “USB A” or
“USB B” when playback is stopped.
3Press l/L or +/–
repeatedly to select the audio file or
folder.
4Press OPTIONS.
5Press / to select “USB
ERASE”, then press ENTER.
“FOLDER ERASE” or “TRACK
ERASE” appears in the display panel.
6Press ENTER.
“COMPLETE” appears in the display
panel.
Use the buttons on the remote control to
perform this operation.
Playing in original order (Normal
Play)
Press PLAY MODE repeatedly when
playback is stopped.
• ALL USB: all USB devices
• 1 USB: a USB device
• : all audio files in the folder on the
USB device
Playing in random order (Shuffle
Play)
Press PLAY MODE repeatedly when
playback is stopped.
• ALL USB SHUF: shuffle all USB
devices
• 1 USB SHUF: shuffle a USB device
• SHUF: shuffle all audio files in the
folder on the USB device
Note
When you turn off the system, the selected
Shuffle Play is cleared and the play mode
returns to Normal Play.
Creating your own program (Program
Play)
See page 13.
Playing repeatedly (Repeat Play)
Press REPEAT repeatedly.
• REP: repeat all audio files on a USB
device
• REP 1: repeat an audio file
Notes on the USB device
• The playback order for the system may differ
from the playback order of the connected
digital music player.
• Be sure to turn off the system before removing
the USB device. Removing the USB device
while the system is turned on may corrupt the
data on the USB device.
• You cannot erase audio files and folders in
Shuffle Play or Program Play.
Using play mode
