MDR-IF130K
Cordless Stereo
Headphone System
Operating Instructions page 2
Bedienungsanleitung seite 12
Návod k obsluze strana 22
Használati útmutató oldal 32
Instrukja obsługi strona 42
Инструкция по эксплуатации стр. 52

2
WARNING
To prevent fire or shock hazard,
do not expose the unit to rain or
moisture.
To avoid electrical shock, do not
open the cabinet. Refer servicing
to qualified personnel only.
WARNING
You are cautioned that any changes or
modifications not expressly approved
in this manual could void your
authority to operate this equipment.

3
Table of contents
Getting started
Unpacking .......................................... 4
Setting up the transmitter ................ 4
Setting up the headphones .............. 6
Operating the system
Listening to a program ...................... 7
The effective areas of
the transmitter ................................. 8
Replacing the ear pads ...................... 8
Additional information
Precautions ..........................................9
Troubleshooting ...............................10
Specifications ....................................11
Welcome!
Thank you for purchasing the Sony
MDR-IF130K Cordless Stereo
Headphone System. Before operating
the unit, please read this manual
thoroughly and retain it for future
reference.
Some features are:
• Cordless system that allows you to
listen to a program free from the
restriction of a cord.
• Broad horizontal listening area that
gives you superb sound virtually
anywhere in the room.
• Self-adjusting headband for fitting
your head perfectly.
• The VOL control adjusts the volume
level of both channels.
• The power of the headphones turns
on and off automatically every time
you put the headphones on and off
(Auto power on/off function).
(This mark is valid for Russia
version only.)

4
(Getting started
Unpacking
Check that you have the following
items:
• Transmitter
• AC power adaptor
• Connecting cord (phono plugs ˜
stereo mini plug)
• Headphones
TMR-IF130
MDR-IF230
Setting up the
transmitter
1Connect the transmitter to audio/
video equipment.
aWhen connecting to your audio/
video system’s LINE OUT or REC
OUT jacks, connect the cord to the
transmitter’s LINE IN jack only.
Note
If your audio/video equipment has a stereo mini
jack(LINE OUT), connect the stereo mini
jack(LINE OUT) to LINE IN of the transmitter by
using optional connecting cord RK-G136HG.
Connecting the LINE OUT jack of your audio/
video equipment to PHONES IN of the
transmitter will cause low or muffled sound. To
connect to PHONES IN of the transmitter with
the supplied cord, use a headphones jack on the
audio/video equipment.
Stereo system, TV, VCR, etc.
Transmitter
to LINE IN jack
Connecting cord
(supplied)
Left channel
(white) Right channel (red)
to LINE OUT or
REC OUT jacks
RLINE IN
DC IN 9V
L
¥
PHONES IN

5
bWhen connecting to your Discman’s
headphones jack, connect the cord to
the transmitter’s PHONES IN jack
only.
2Connect the transmitter to a power
source.
Notes
•Do not connect to the PHONES IN jacks and
LINE IN jack at the same time. If you do so, the
audio signals may be mixed.
•Use only the supplied AC power adaptor. Do
not use any other AC power adaptor.
•When you connect the connecting cord directly
to an earphone jack, the audio signal will not be
output through the right channel. In such a
case, use the separately sold PC-236HG plug
adaptor.
* WALKMAN is a registered trademark of Sony
Corporation.
Discman,
WALKMAN*,
TV, VCR, etc.
Transmitter
to PHONES
IN jacks
Right channel
(red) Left channel (white)
to a headphones
jack (stereo
mini jack)
to a headphones
jack (stereo
phone jack)
Connecting
cord
(supplied)
Unimatch
plug adaptor
(not supplied)
RLINE IN
DC IN 9V
L
¥
PHONES IN
Polarity of the plug
AC power adaptor (supplied)
Transmitter
to an AC
outlet
to DC IN 9V
jack
RLINE IN
DC IN 9V
L
¥
PHONES IN

6
Setting up the
headphones
1Open the battery compartment lid
on top of the left housing.
2Insert one R6 (size AA) battery by
matching the + on the battery to the
+ terminal on the lid.
3Close the battery compartment lid.
Removing the battery
Open the battery compartment lid,
while keeping the housing level and
remove the battery from the battery
compartment as illustrated below.
Battery life
When to replace the battery
Replace the battery with new one when
the POWER indicator on headphone
dims, and a hissing noise increases.
Battery
Sony alkaline battery
LR6/AM3 (N)
Sony battery
R6P/SUM-3 (NS)
Approx. hours
100
50
Housing (left)
Battery Battery
compartment lid

7
(Operating the system
Listening to a
program
1Turn on the audio/video
equipment connected to the
transmitter.
When the audio signals is input,
the transmitter turns on
automatically and the infrared
emitters glow. If the transmitter is
connected to the headphone jack,
set the volume control of the
audio source equipment as high
as possible but not so high that
the audio signal gets distorted.
(Around level 5 or 6 on the
volume control should be
appropriate.)
2Put on the headphones and the
power turns on automatically. The
power indicator glows red when
the power turns on.
3Adjust the volume.
Auto power on/off function
When you remove the headphones, the
power turns off automatically. Do not
pull up the self adjusting band when
not using the headphones, otherwise
the headphones will be switched on.
Mute function
If a hissing noise is heard when the
infrared rays are obstructed, or the
headphones are used outside of the
effective range (see the next section),
the mute function will be activated and
the sound will not be heard from the
headphones. To restore the sound,
move nearer toward the transmitter or
remove the obstruction.
When no audio signal is received at
the transmitter input for more than
approximately five minutes
The transmitter will be turned off
automatically.
After listening to a program
Take the headphones off before the
transmitter turns off. Otherwise you
may hear some noise when the infrared
rays are suddenly cut off.
Note
The infrared emitters light up when the
transmitter is turned on. The brightness of the
emitters may not be uniform, however, this is not
a malfunction.

8
The effective areas
of the transmitter
The illustration below shows the
approximate area covered by the
infrared rays emitted from the
transmitter.
Notes
•If you use the headphones at too great a
distance from the transmitter, you may hear a
hissing noise and if there is an object between
the receiver and the transmitter, the sound may
be interrupted. These phenomena are inherent
to infrared ray communication and do not
mean that there is a problem with the unit
itself.
•The infrared rays will not penetrate walls or
opaque glass, therefore, be sure to stay within
sight of the transmitter.
•When you use the headphones inside the area
illustrated in the diagrams, the transmitter can
be placed in the front, behind or by the side of
the listener.
Replacing the Ear
Pads
When the ear pads become dirty or
damaged, consult your nearest Sony
dealer and replace them as illustrated
below.
Remove the old
ear pad by
pulling it out.
Place the new ear
pad around the
driver unit as
illustrated.
Transmitter
Approx. 3 m
(1181/8 in.)
Approx. 3 m
(1181/8 in.)
Infrared ray
45°
45°
Approx. 7 m
(23 ft.)

9
(Additional information
Precautions
• Before operating the system, check
that the operating voltage of your
system is identical with the voltage of
your local power supply.
• The CE mark on the unit is valid only
for products marketed in the
European Union.
• When the headphones is not to be
used for a long period of time,
remove the battery to avoid damage
caused by battery leakage and
subsequent corrosion.
• When the transmitter is not to be
used for a long period of time,
disconnect the AC power adaptor
from the AC outlet holding the plug.
Do not pull on the cord.
• Do not leave the cordless stereo
headphones system in a location
subject to direct sunlight, heat or
moisture.
Notes on headphones
Preventing hearing damage
Avoid using headphones at high
volume. Hearing experts advise
against continuous, loud and extended
play. If you experience a ringing in
your ears, reduce the volume or
discontinue use.
Caring for others
Keep the volume at a moderate level.
This will allow you to hear outside
sounds and to be considerate to the
people around you.
If you have any questions or problems
concerning the system that are not
covered in this manual, please consult
the nearest Sony dealer.
Be sure to bring the headphones and
the transmitter to the Sony dealer when
requiring repair work.
