SECTION 3
EXPLODED VIEWS
NOTE:
• -XX, -Xmeanstandardized parts, sotheymay have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• The mechanical parts with no reference number in
the exploded views are not supplied.
• Accessories and packing materials are given in the
last of this parts list.
• Abbreviation
CND: Canadian model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
*34 4-970-326-01 ARM STAND
*35 4-970-301-01 ELEVATOR
*36 4-970-305-01 SPRING ELEVATOR
37 A-4660-773-A ARM ASSY, FEED
*38 4-970-306-01 E-RING
*39 1-654-481-11 EQ BOARD
*40 4-970-290-01 CABINET UPPER (BLACK)
*40 4-970-290-11 CABINET UPPER (SILVER)
*41 4-970-295-01 ELEVATION ARM
42 4-960-209-01 STOPPER CORD
43 4-960-182-01 CUSHION MOTOR
*44 4-970-325-01 MOTOR SETTENG SCREW
45 4-970-308-01 ADAPTOR E.P
46 4-951-290-01 STYLUS (CN-234)
47 A-4660-485-A RING GEAR ASSY
*48 4-970-300-01 CUT LEVER
49 A-4660-772-A SHAFT ASSY, CENTER
50 4-960-222-01 BELT RUBBER
*51 4-971-209-01 PLATTER
52 4-971-208-01 RUBBER SHEET
53 4-970-309-01 COVER DUST
*54 4-970-299-01 LINK CUT
55 A-4660-769-A ARM ASSY, TONE
56 A-4660-774-A HINGE ASSY
!57 1-696-570-21 CORD, POWER (UK)
!58 1-590-074-11 CORD, POWER (E)
!59 1-569-007-11 ADAPTER, CONVERSION 2P (E)
60 4-960-218-01 WASHER SCREW TAP WPH
*61 1-654-921-11 SPEED BOARD
!62 1-777-361-11 CABLE, INTERFACE (MAC) (US, CND)
M901 1-698-210-11 MOTOR
!PT901 1-427-716-11 TRANSFORMER, POWER (AEP,UK)
!PT901 1-427-857-11 TRANSFORMER, POWER (E)
!PT901 1-431-954-11 TRANSFORMER, POWER (US,CND)
!S101 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE (E)
S901 1-692-692-11 LEAF S/W
S902 1-762-224-11 SWITCH, PUSH (SPEED)(1 KEY)
*1 4-970-314-01 FOOT SCREW
2 4-970-312-01 RUBBER FOOT
*3 4-970-328-01 WASHER SCREW TAP WPH
4 4-970-313-01 RUBBER FOOT
!5 1-575-651-11 CORD, POWER (AEP)
6 1-555-116-11 CORD, PHONE
7 4-960-220-01 SCREW TAP WPH
*8 4-970-307-01 COVER BOTTOM
9 4-970-310-01 SCREW TAP WPH
*10 4-970-329-01 STOPPER SPRING
*11 4-970-330-01 ACTUATING ARM SPRING
12 4-960-217-01 WASHER SCREW TAP WPH
*13 4-970-298-01 ACTUATING ARM
14 A-4384-983-A PANEL ASSY, FRONT (SILVER)
14 A-4660-791-A PANEL ASSY, FRONT (BLACK)
15 4-970-322-01 CUE KNOB
*16 4-970-323-01 CUE LINK HOLDER
17 1-572-744-11 SWITCH, PUSH (1 KEY)(ARM LIFTER)
*18 1-654-480-11 LED BOARD
19 4-970-294-01 KNOB REJECT (BLACK)
19 4-970-294-11 KNOB REJECT (SILVER)
*20 4-970-321-01 RETURN
*21 4-970-320-01 HOLDER REJECT
22 4-970-293-01 KNOB SPEED (BLACK)
22 4-970-293-11 KNOB SPEED (SILVER)
*23 4-970-311-01 LINK REJECT
*24 1-654-912-11 POWER BOARD
*25 4-970-303-01 NUT HEX
*26 4-970-302-01 WASHER PLANE
*27 4-970-324-01 QUEING LINK
*28 4-970-316-01 SCREW TAP WPH
*29 4-970-327-01 CUE LEVER
30 4-970-291-01 CUSHION DUST COVER
31 4-970-304-01 PULLEY MOTOR
*32 4-970-297-01 WASHER C.S
*33 4-970-296-01 SPRING ELEVATION
– 7 – – 8 –
The components identified by
mark !or dotted line with mark
!are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque !sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
