Soozier A91-262V00 User manual

IN220901382V01_US
A91-262V00
Foldable Abdominal Trainer
Manual
*The maximum user weight is 150 Kg. 30MIN
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

-2-

-3-

-4-

-5-

-6-

-7-

PRODUCT ACCESSORIES DRAWING
1
2
3
4
5
54
6
8
7
Armrest set
Ropes
Slider set
Pulley seat assembly
Front foot tube set
Electronic watch group
-8-
10

LIST OF MAIN PARTS
1. Main frame set x1
Main frame set
2. Electronic watch x1
Electronic watch
3. Armrest set x1
10. Ropes x2
Armrest set
4.Foam x6
Foam
5. Pipe plug x6
Pipe plug
6. Ball plug x2
Ball plug
9.#5 L-Wrench x1
#5 L-Wrench
7. Arc washer x2
Arc washer
8. M8X35 hexagon socket
head cap screw x2
M8X35 hexagon socket
head cap screw
SCREW, TOOL LIST
PARTS LIST
11
2
2
6
1
8
7
9
Ropes 2
10
6
6
4
5
1
2
3
12
No. Part Name Quantity No. Part Name Quantity
-9-

ASSEMBLY INSTRUCTIONS:
Assembly Step (1): Install the main frame.
1. Take the main frame and armrest group out of the carton, and pass
(8-semi-round head socket head cap bolt) and (7-arc washer) through (3-armrest
group) And put it into (1-main frame group), use (9-cross L-shaped wrench) to fix
and lock, and finally insert (6-ball plug) (1-main frame group).
8
7
3
16
-10-

Assembly Step (2): Assemble electronic watch, foam, tube plug.
1. Connect the signal cable connector of (2-electronic meter) with the signal cable
connector of (1-main rack group), and then insert (2-electronic meter) into (1-Main
frame) Inside the electronic watch fixing piece of the main frame.
2. Pass (4-foam) through the foam fixing tube of (1-main frame group), and then put
it in (5-pipe plug).
4
5
4
5
1
2
-11-

OK
-12-
10
Assembly Step (3): Assemble the ropes
1. Take out the pull rope (10), align the corresponding holes to install, the completed
result is shown in the figure, so far the whole machine is assembled.
