Sound Sation THESIS 740RZ User manual

THESIS 740RZ / 1240RZ
7 x 40W / 12 x 40W LED Moving Head with zoom
Please read this manual carefully and properly take care of it
USER MANUAL
Leggete questo manuale e conservatelo per future consultazioni
MANUALE UTENTE

Dear customer,
First of all thanks far purchasing a SOUNDSATION® product. Our mission is to satisfy
all possible needs of musical instrument and professional audio users oering a wide
range of products using the latest technologies.
We hope you will be satised with this item and, if you want to collaborate, we are
looking for a feedback from you about the operation of the product and possible
improvements to introduce in the next future. Go to our website www.soundsation-
music.com and send an e-mail with your opinion, this will help us to build instruments
ever closer to customer’s real requirements.
One last thing: read this manual before using the instrument, an incorrect operation
can cause damages to you and to the unit. Take care!
The SOUNDSATION Team
Gentile Cliente,
Grazie per aver scelto un prodotto SOUNDSATION®. La nostra missione è quella di
orire ai nostri utenti una vasta gamma di strumenti musicali ed apparecchiature audio
e lighting con tecnologie di ultima generazione.
Speriamo di aver soddisfatto le vostre aspettative e, se voleste collaborare, saremmo
lieti di ricevere un vostro feedback sulla qualità del prodotto al ne di migliorare co-
stantemente la nostra produzione. Visitate il nostro sito www.soundsationmusic.com ed
inviateci una mail con la vostra opinione, questo ci aiuterà a sviluppare nuovi prodotti
quanto più vicini alle vostre esigenze.
Un’ultima cosa, leggete il presente manuale al ne di evitare danni alla persona ed al
prodotto, derivanti da un utilizzo non corretto.
Il Team SOUNDSATION

3
ENGLISH
TABLE OF CONTENTS
1. INTRODUCTION.........................................................................................................6
1.1. UNPACKING .............................................................................................................................................................6
1.2. Accessories...............................................................................................................................................................7
2. OVERVIEW..................................................................................................................7
3. PRODUCT SPECIFICATION........................................................................................7
4. MAINS CONNECTIONS .............................................................................................8
5. DMX CONNECTION...................................................................................................8
5.1. DMX Terminator .....................................................................................................................................................9
5.2. 3-Pin vs 5-Pin DMX cables .................................................................................................................................9
6. INSTALLATION.........................................................................................................10
7. FRONT PANEL DESCRIPTION .................................................................................12
8. REAR PANEL DESCRIPTION....................................................................................13
9. FUNCTIONS DESCRIPTION.....................................................................................14
9.1. Dmx Address Setting..........................................................................................................................................14
9.2. Fixture ....................................................................................................................................................................15
9.3. Manual .....................................................................................................................................................................16
9.4. Information.............................................................................................................................................................18
9.5. Factory......................................................................................................................................................................19
9.6. Fixture Reset...........................................................................................................................................................20
9.7. Display......................................................................................................................................................................20
9.8. Network...................................................................................................................................................................21
10. DMX CHANNEL MODES..........................................................................................21
10.1. STD Mode ( 17CH ) .............................................................................................................................................22
10.2. EXT Mode THESIS 740RZ ( 38CH ) ................................................................................................................23
10.3. EXT Mode THESIS 1240RZ ( 58CH )..............................................................................................................24
10.4. GUI Mode ( 18CH ) THESIS 740RZ ................................................................................................................25
10.5. GUI Mode ( 18CH ) THESIS 1240RZ..............................................................................................................27
10.6. HSI Mode ( 11CH )...............................................................................................................................................29
11. SPECIFICATION ........................................................................................................30
12. WARRANTY AND SERVICE .....................................................................................31
13. WARNING.................................................................................................................32

4
ENGLISH
THESIS 740RZ / 1240RZ User manual
IMPORTANT SAFETY SYMBOLS
The symbol is used to indicate that some hazardous live terminals are
involved within this apparatus, even under the normal operating con-
ditions, which may be sucient to constitute the risk of electric shock
or death.
The symbol is used in the service documentation to indicate that spe-
cic component shall be replaced only by the component specied in
that documentation for safety reasons.
Protective grounding terminal
Alternating current/voltage
Hazardous live terminal
Denotes the apparatus is turned on
Denotes the apparatus is turned o
WARNING: Describes precautions that should be observed to prevent the danger
of injury or death to the operator.
CAUTION: Describes precautions that should be observed to prevent danger of
the apparatus.
To protect the environment, please try to recycle the packing material
as much as possible
The projector is for indoor use only, IP20. Use only in dry locations.
Keep this device away from rain and moisture, excessive heat, humid-
ity and dust. Do not allow contact with water or any other uids, or
metallic objects.
Don’t throw this product away just as general trash, please deal with
the product follow the abandon electronic product regulation in your
country.
0.5m
Locate the xture in a well ventilated spot, away from any ammable
materials and/or liquids. The xture must be xed at least 50cm from
surrounding walls
TAKING CARE OF YOUR PRODUCT
fRead these instructions
fKeep these instructions
fHeed all warning
fFollow all instructions

5
ENGLISH
THESIS 740RZ / 1240RZ User manual
1) Water / Moisture
The apparatus should be protected from moisture and rain and can not be used near
water; for example near a bathtub, a kitchen sink, a swimming pool, etc.
2) Condensation
To avoid condensation to be formed inside, allow this unit to adapt to the surrounding
temperatures when bringing it into a warm room after transport. Condense sometimes
prevents the unit from working at full performance or may even cause damages.
3) Heat
The apparatus should be located away from heat sources such as radiators, stoves or
other appliances that produce heat. Don not use it when maximum ambient tempera-
ture is higher than 40°C This equipment shell temperature around 40°C (104°F) to 50 °C
(122°F) while work, do not touch the shell.
4) Ventilation
Do not block areas of ventilation opening. Failure to do could result in re. Always
install according to the manufacturer’s instructions.
5) Object and Liquid Entry
Objects do not fall into and liquids are not spilled into the inside of the apparatus for
safety.
6) Power Cord and Plug
Protect power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus. Do not defeat the safety
purpose of the polarized or grounding-type plug. A polarized plug has two poles; a
grounding-type plug has two poles and a third grounding terminal. The third prong is
provided for your safety. If the provided plug does not t into your outlet, refer to an
electrician for replacement..
7) Power Supply
The apparatus should be connected to the power supply only of the type as marked on
the apparatus or described in the manual. Failure to do could result in damage to the
product and possibly the user. Check whether the power supply and voltage are normal
before use. If the voltage uctuates greatly, it is recommended to use voltage stabilizer
or voltage regulatorUnplug this apparatus during lightning storms or when unused for
long periods of time.
8) Electrical Connection
Always disconnect from the power source before servicing or replacing fuse and be
sure to replace with same fuse size and type. Cut o power before moving, repairing
and cleaning the unit. Improper electrical wiring may invalidate the product warranty.
To avoid electric shock, all xtures must be connected to circuits with a suitable ground.

6
ENGLISH
THESIS 740RZ / 1240RZ User manual
9) Fuse
To avoid the risk of re and damage to the unit, use only the type of fuse described
in the manual. Before replacing the fuse, make sure the device is switched o and
unplugged.
10) DMX connection
When use DMX controller, please make sure that there is no interference sources (e.g.
intercom, high frequency radio waves and radiation source).
11) Cleaning
Clean only with a dry cloth. Do not use any solvents such as benzene or alcohol.
12) Servicing
Do not implement any servicing other than those means described in the manual. Refer
all servicing to qualied service personnel only. The internal components of the equip-
ment must be purchased from the manufacturer Only use accessories/attachments or
parts recommended by the manufacturer.
1. INTRODUCTION
Thank you for purchasing our THESIS moving head. Enjoy your new equipment and
make sure to read this manual carefully before operation!
This user manual is made to provide both an overview of controls, as well as informa-
tion on how to use them. In order to help you to understand the connections between
the various controls, we have gathered in groups according to their functions.
1.1. UNPACKING
Your THESIS moving head was carefully packed to ensure safe transport. Despite this,
we recommend you to carefully examine the package and its contents for any signs of
physical damage, which can occur during transport. Each unit has the following parts:
fMoving Head
fPower Cord (EU plug – PowerCon)
f1 x DMX Cable (3-Pin XLR Male to Female)
f2 x Omega Clamps
fUser manual
ATTENTION: Packaging bag is not a toy! Keep out of reach of children!!! Keep in
a safe place the original packaging material for future use.
If anything damaged during transport, notify the shipper immediately and keep the
packing material for inspection. Again, please save the carton and all packing materi-
als. If the xture must be returned to manufacturer, it is important that the xture be

7
ENGLISH
THESIS 740RZ / 1240RZ User manual
returned in the original manufacturer box and packing. Please do not take any action
without rst contacting us.
1.2. Accessories
SOUNDSATION can supply a wide range of quality accessories that you can use with
your SPIRE Series moving head, like Cables, Splitters, DMX controllers, and a wide range
of other xtures.
All products in our catalogue has been long tested with this device, so we recommend
you to use Genuine SOUNDSATION Accessories and Parts.
Ask your SOUNDSATION dealer or check out our website www.soundsationmusic.com
for any accessories you could need to ensure best performance of the product.
2. OVERVIEW
THESIS series oer two new wash-light moving heads with, respectively, 7 and 12
powerful and reliable 40W OSRAM LEDs. They represent a valid alternative to normal
arch lamps with all the benets of LED technology: low consumption, longer life, lower
temperature dissipation. The light beam ranges from 4.5° to 45°, thanks to the ZOOM
function controlled by three motors simultaneously, which give an extremely soft and
silent adjustment.
The quad-color mixing system, the adjustable color-temperature, the accurate and
linear dimmer, combined with the sophisticated control of the single pixels, make the
new THESIS moving heads a valid tool to enhance the creativity of the most demand-
ing light designers. They oer several Pixel controlling functions: rainbow, single pixel,
circle, full-control of the single colors of each LED, and many others.
Particular attention is paid to precision and noise of mechanical movements. PAN and
TILT are equipped with three-phase motors and 16-bit control. The ZOOM is managed
by three motors, to minimize skating eect and vibrations. The electronic dimmer is ac-
curate and soft. Fan speed is also electronically controlled by the internal temperature,
ensuring the right balance between noise, safety and durability of the LED chips.
3. PRODUCT SPECIFICATION
fLED light: LED 7 x 40W (THESIS 740RZ) / LED 12 x 40W (THESIS 1240RZ) RGBW
OSRAM® with LED lifespan of around 50000 hours
fBeam angle (scan type): 4.5°÷45°
fElectronic smooth Dimmer with 16-bit control
fStrobe: 1-20Hz with instant light ON and OFF work mode
fRGBW smooth color mixing with Pixel eects, like rainbow, single pixel, circle, full
control, xed background light color mixing, xed background light pattern, xed

8
ENGLISH
THESIS 740RZ / 1240RZ User manual
background light pixel control.
fZOOM function 9° ÷ 44° /1.7s, with 3 silent motors at the same time to provide
accurate zooming, stable beam, without skating.
fPAN and TILT with 8-16 bit scanning, photoelectric reset and automatic error cor-
rection function.
fDMX512 / Master-Slave / Auto / Sound control Modes
fFour DMX Channel Modes: 17CH Standard, 38CH Extended, 18CH Pattern, 11CH
HIS
fHigh eciency cooling system with whole-process temperature monitoring. No
risk of LED lamp damage; Intelligent speed control fan and monitoring of rotation
speed
f2.0” LCD color screen with easy user-interface
fExternal power function with USB connection for moving head parameter setting
using display.
fSupport RDM, Art-Net®, Kling-Net and sACN networking protocols (Optionals).
4. MAINS CONNECTIONS
Connect the device to the mains with the supplied power cable. Please note that power
voltage and frequency are the same as the marked voltage and frequency of device
when connecting power. Wire correspondence is as follows:
Cable (EU) Pin International
Brown Live L
Blue Neutral N
Yellow/Green Earth
The earth must to be connected! Pay attention to the safety! Before taking
into operation for the rst time, the installation has to be approved by an
expert.
5. DMX CONNECTION
DMX xtures are designed to receive data through a serial Daisy Chain. A Daisy Chain
connection is where the DATA OUT of one xture connects to the DATA IN of the next
xture. The order in which the xtures are connected is not important and has no eect
on how a controller communicates to each xture. Use an order that provides for the
easiest and most direct cabling.

9
ENGLISH
THESIS 740RZ / 1240RZ User manual
3-Pin XLR
Pin 1: GND
Pin 2: DMX -
Pin 3: DMX +
OUTPUTINPUT
DMX use of 3-Pin XLR Connectors
DMX Termonator
Unit 1 Unit 2 Last Unit
DMX 512
Connect xtures using shielded 2-conductor twisted pair cable with 3-pin XLR male to
female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-), and
pin 3 is Data positive (S+).
CAUTION: Wires must not come into contact with each other; otherwise the
xtures will not work at all, or will not work properly.
5.1. DMX Terminator
DMX is a resilient communication protocol, however errors still occasionally occur.
In order to prevent electrical noise from disturbing and corrupting the DMX control
signals, a good habit is to connect DMX output of last xture in the chain to a DMX
terminator, especially over long signal cable runs.
The DMX terminator is simply an XLR connector with a 120Ω (ohm), 1/4 Watt resistor
connected across Signal (-) and Signal (+), respectively, pins 2 and 3, which is then
plugged into the output socket on last projector in the chain. The connections are
illustrated below.
120ohm, 1/4
W
Resistor
DMX Terminator
Complimentary signal cable can transmits signals to 20 unit xtures at most.
Signal amplier is a must to connect more xtures.
5.2.3-Pin vs 5-Pin DMX cables
DMX connection protocols used by controllers and xtures manufacturers are not stan-
dardized around the world. However, two are the most common standards: 5-Pin XLR
and 3-Pin XLR system. If you wish to connect MOOD 185 WASH to a 5-Pin XLR input
xture, you need to use an adapter-cable or make it by yourself.

10
ENGLISH
THESIS 740RZ / 1240RZ User manual
Following the wiring correspondence between 3-Pin and 5-Pin plug and socket stan-
dards
5-Pins XLR (plug)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-Pins XLR (socket)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-Pins XLR (socket)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-Pins XLR (plug)
Pin 1: GND (Screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
6. INSTALLATION
Pay attention to safety! Please respectively consider the EN 60598-2-17 and
the national standard during the installation. The authorized dealer must
only carry out the installation.
The installation of the xture has to be built and constructed in a way that it can hold
10 times the weight for 1 hour without any harming demolition. The installation must
always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the
installation can fall down if the main attachment fails.
When rigging, de-rigging or servicing the xture staying in the area below the instal-
lation place, on bridges, under high working places and other endangered areas is
forbidden. The operator has to make sure that the safety measure and the machine’s
technical installation is approved by an expert before taking into operation for the rst
time and after changes before taking into operation anther time. He has also to make
sure that an expert approves safety measure and the machine’s technical installation
once a years.
WARNING: The xture should be installed outside areas where persons may
walk by or be seated.
IMPORTANT: Overhead rigging requires extensive experience, including (but
not limited to) calculating working load limits, installation material being
used, and periodic safety inspection of all installation material and the pro-
jector. If you lack these qualications, do not attempt the installation your-
self, but instead use a professional structural rigger. Improper installation can
result in bodily injury or property loss.
If the xture shall be lowered from the ceiling or high joists, professional trussing
systems have to be used. The xture must never be xed swinging freely in the room.
Before rigging make sure that the installation area can hold a minimum point load of
10 times the projector’s weight.
CAUTION: Fixture may cause severe injuries when crashing down. If you have

11
ENGLISH
THESIS 740RZ / 1240RZ User manual
doubts concerning the safety of a possible installation, do not install the
xture!
CAUTION: Use two appropriate clamps to rig the xture on the truss. Follow
the instructions mentioned at the bottom of the base. Make sure that the
device is xed properly! Ensure that the structure (truss) to which you are
attaching the xtures is secure.
DANGER OF FIRE! When installing the device, make sure there is no highly
inammable material (decoration articles, etc.) within a distance of minimum
0.5 meter.
The moving head can be placed directly on the oor or rigged in any orientation on a
truss, without altering its operation characteristics. Please refer to the picture below and
strictly follow the instructions.
5
1
2
3
5
5
4
90°
2
6
fUse clamps suitable for the section of the truss on which you want to x the mov-
ing head.
fInsert the screw in the central hole of the bracket n.2, and tighten the nut supplied
with the clamp (and any washers always supplied with the clamp).
fPlace the plugs with wings n.3 in the direction of the holes n.5 placed under the
base of the moving head. Screw them clockwise for about 90°, until you hear a click
that indicates the achievement of the correct and safe position.
fHook the moving head to the truss through the two clamps now perfectly xed to
the base, and screw the wing-screw n.4 so as to tighten the moving head and avoid
as much as possible vibrations during the use of the xture.
fFor overhead use, always install a safety rope that can hold at least 10 times the
weight of the xture. Hook the safety cable to the hole n.6 located under the base
of the moving head.

12
ENGLISH
THESIS 740RZ / 1240RZ User manual
7. FRONT PANEL DESCRIPTION
UPDATE
UP
ENTER INVERTESC
DOWN
12345
6
7
001
STD Mode: 17CH
Temp: 23 C FanSpeed:0000RPM
1) LCD GRAPHIC DISPLAY
It shows the operating mode and other system information.
2) POWER USB Connection
External power function with USB connection (for power bank, Laptop, etc.) for moving
head parameter setting using display without the device being turned on using the
power button.
3) ESC BUTTON
Press to exit from the functions without parameters variation or press repeatedly to go
back to the main display.
4) UP BUTTON
It scrolls up individual items in the selection menu and sub-menus for system settings
(DMX address, Fixture, Manual, etc.) and increases the values/settings of parameters.
5) INVERT BUTTON
Pressing this button, the display will be rotate by 180°. This can be useful for overhead
installation. After switching o the device, the display will return to the normal position
at the next switch-on.
6) DOWN BUTTON
It scrolls down individual items in the selection menu and sub-menus for system set-
tings (DMX address, Fixture, Manual, etc.) and decreases the values/settings of param-
eters.
7) ENTER BUTTON
Press ENTER to access the menu levels and conrm the parameters value changes.

13
ENGLISH
THESIS 740RZ / 1240RZ User manual
8. REAR PANEL DESCRIPTION
DMX OUT DMX IN
POWER OUT
mAX. 800W
POWER IN
100-240VAC
50-60h
Z
350w
FUSE
ON OFF
65 4
3
21
1) POWER IN SOCKET
Plug the power-cord into an AC socket properly congured for your particular model.
2) POWER ON/OFF SWITCH
3) FUSE HOLDER
Fuse holder with F7AL / 250 V fuse (5 x 20 mm). In case of fuse burn, to prevent the risk
of re and damaging the unit, please use only a spare of the recommended fuse type
as described. Before replacing the fuse, make sure the unit turned o and disconnected
from the AC outlet.
4) POWER OUT SOCKET
Power output socket for power supply to additional SOUNDSATION lights. Ensure that
the total current consumption of all connected devices does not exceed the value spec-
ied on the device in amperes (A).
5) DMX INPUT
Male 3-pin and 5-pin XLR sockets for connection to a DMX control device
6) DMX OUTPUT
Female 3-pin and 5-pin XLR socket for sending the DMX control signal.

14
ENGLISH
THESIS 740RZ / 1240RZ User manual
9. FUNCTIONS DESCRIPTION
At power on, the device resets all the electrical and mechanical parts. Once the start-
up procedure is nished, the display will show the current DMX operating mode, the
current operating temperature and the eventual fan speed. If, for example, the device is
set to GUI mode (18CH Mode channel) and the starting address is set to 1, the display
will show:
001
STD Mode: 17CH
Temp: 23°C FanSpeed:0000RPM
If the device is set in DMX mode and is not connected to a DMX control unit, the main
screen shot will blink. By pressing the [ESC] button twice, the display will show the main
function menu.
MainMenu
Dmx Address 001
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
9.1. Dmx Address Setting
The Dmx Address setting allows you to set the DMX channel of the machine between
1 and 512. To change it, select the parameter using the [UP] / [DOWN] buttons ( gure
above ) and then, press the [ENTER] button to start the edit. Using again the [UP] /
[DOWN] buttons the DMX Address Value will increase or decrease. Use the [ENTER]
button to conrm, or the [ESC] button to exit without conrming.

15
ENGLISH
THESIS 740RZ / 1240RZ User manual
9.2. Fixture
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Fixture
Run Mode DMX
Pan Invert Close
Tilt Invert Close
Dmx Mode GUI
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
Dmx Mode
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, it is possible to select one of the available channel mode.
Using again the [UP] / [DOWN] buttons, you can choose the following modes:
GUI (18CH)
EXT (38CH in the 740RZ model and 58CH in the 1240RZ model)
STD (17CH)
HSI (11CH)
Use the [ENTER] button to conrm, or the [ESC] button to exit without conrming.
Run Mode
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, it is possible to select one of the available run mode. They are, respec-
tively, the DMX control mode, the Master/Slave mode (named HOST), and the Sound
Control with which the machine is controlled by the sound present in the surrounding
environment.
Using the [UP] / [DOWN] buttons, you can choose the desired run mode.
Use the [ENTER] button to conrm, or the [ESC] button to exit without conrming.
Note: When the xture is set to HOST but is not connected with other devic
es, the AUTO mode will be activated.
Pan Invert
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, it is possible to set the PAN Invert parameter. The default setting of this
parameter is “Close”. To invert the Pan, set the parameter to “Open”
Using the [UP] / [DOWN] buttons, you can choose the “Pan Mode”.
Use the [ENTER] button to conrm, or the [ESC] button to exit without conrming.

16
ENGLISH
THESIS 740RZ / 1240RZ User manual
Tilt Invert
Selecting this option using the [UP] / [DOWN] buttons and then pressing the [ENTER]
button, it is possible to set the TILT Invert parameter. The default setting of this param-
eter is “Close”. To invert the Tilt, set the parameter to “Open”
Using the [UP] / [DOWN] buttons, you can choose the “Tilt Mode”.
Use the [ENTER] button to conrm, or the [ESC] button to exit without conrming.
9.3.Manual
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Manual
Pan Fine 000
Tilt 000
Tilt Fine 000
Pan 000
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
P/T Speed 000
Dim 000
Strobe 000
Red 000
To select the sub-menu parameters use the [UP] / [DOWN] buttons and then pressing
the [ENTER] button to access the parameter modication.
Using again the [UP] / [DOWN] buttons the value of each parameter will increase or
decrease. Use the [ENTER] button to conrm, or the [ESC] button to exit without con-
rming.
Pan
Pan adjustment. The range is 0 ÷ 255.
Pan Fine
Fine Pan adjustment. The range is 0 ÷ 255.
Tilt
Tilt adjustment. The range is 0 ÷ 255.
Tilt Fine
Fine Tilt adjustment. The range is 0 ÷ 255.
P/T Speed
Speed adjustment for Pan and Tilt. The range is 0 ÷ 255.
Dim
Adjustment of the light output intensity (Dimmer). The range is 0 ÷ 255.
Strobe
Adjusting the speed of light ashes in the strobe eect. The range is 0 ÷ 255.

17
ENGLISH
THESIS 740RZ / 1240RZ User manual
Red
Red color intensity adjustment. The range is 0 ÷ 255.
Green
Green color intensity adjustment. The range is 0 ÷ 255.
Blue
Blue color intensity adjustment. The range is 0 ÷ 255.
White
White color intensity adjustment. The range is 0 ÷ 255
Macro
Scrolling of all color combinations. The range is 0 ÷ 255.
Shape
This function replicates all the combinations of channel 13 of the DMX GUI mode for
both models. The range is 0 ÷ 255.
(Please refer to “10.4. GUI Mode ( 18CH ) THESIS 740RZ” on page 25 or to “10.5. GUI
Mode ( 18CH ) THESIS 1240RZ” on page 27).
Speed
Speed adjustment of the dynamic eects contained in the shape option.
The range is 0 ÷ 255.
Color
Selecting the background color for each eect selected in the shape option.
The range is 0 ÷ 255.
BackDim
Adjusting the brightness of the background selected in the “Color” option.
The range is 0 ÷ 255.
Zoom
Zoom adjustment. The range is 0 ÷ 255 ( 9 °÷ 44 °).
Reset
This function replicates the DMX STD mode Channel 17 controls for both models.
The range is 0 ÷ 255.
(Please refer to “10.1. STD Mode ( 17CH )” on page 22)

18
ENGLISH
THESIS 740RZ / 1240RZ User manual
9.4.Information
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Information
Sensor
Temperature
Software Version
Time
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
Time
By selecting this option information on the life cycle of the moving head are shown on
the display:
- Current Time: Partial operating time.
- Total Time: Total operating time.
- Power Count: Number indicating how many times the machine has been
turned On.
Sensor
By selecting this option you will get information on the correct operation of the “Pan,
Tilt, Zoom, Temp and Fan” sensors. When the operation is correct, TRUE is displayed
for each sensor otherwise FALSE will be displayed.
Temperature
By selecting this option, you will have the information concerning the temperature of
the moving head:
- Head Temp: Internal temperature of the moving head.
- Fan Speed: Speed (in RPM) of the fan when it is active. The fan will activate
when the temperature internally exceeds 40 °.
Software Version
Selecting this option, you will get information about the software versions of the
following devices: Panel, Motor, Dimmer e Network. As for Network, the software
version will only be displayed if the optional card is inserted

19
ENGLISH
THESIS 740RZ / 1240RZ User manual
9.5.Factory
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Manual
Pan 127
Tilt 127
Zoom 127
Password 000
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
Red 255
Green 255
Blue 255
White
255
All parameters, once set, will be maintained each time the device is turned on. Only the
password must be entered each time to enable the modication of the parameters
contained in this submenu. To select the sub-menu parameters use the [UP] / [DOWN]
buttons and then pressing the [ENTER] button to access the parameter modication.
Using again the [UP] / [DOWN] buttons the value of each parameter will increase or
decrease. Use the [ENTER] button to conrm, or the [ESC] button to exit without con-
rming.
Password:
The password to be entered is 158. Once the password has been entered, the modica-
tion of all other parameters will be enabled.
Pan
Pan ne adjustment for the initial position after switching on. The default value
is 127. The interval is 0 ÷ 255.
Tilt
Tilt ne adjustment for the initial position after switching on. The default value
is 127. The interval is 0 ÷ 255.
Zoom
Zoom ne adjustment for the initial position after switching on. The default
value is 127. The interval is 0 ÷ 255.
Red, Green, Blue, White
Color brightness adjustment. Il valore di default è 255. L’intervallo è 0 ÷ 255.

20
ENGLISH
THESIS 740RZ / 1240RZ User manual
9.6.Fixture Reset
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Fixture Reset
Factory Cance
Motor Reset Cance
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
Motor Reset
Normally this function is set to “Cance”. Switching to “Run”, using the [UP] / [DOWN]
buttons and then the [ENTER] button, the device will reset the Pan, Tilt and Zoom
motors.
Factory
This function must be used only when you want to reset all the default values. Normally
it is set to “Cance”. Switching to “Run”, using the [UP] / [DOWN] buttons and then the
[ENTER] button, the device will reset all the parameters and functions with the default
values.
9.7. Display
By selecting this option using the [UP] / [DOWN] buttons and then pressing the [EN-
TER] button, you access a submenu consisting of the following options:
Display
Display Flip Normal
Display Mode Show
Language EN
MainMenu
Fixture
Manual
Information
Factory
Fixture Reset
Display
Network
Dmx Address 001
Language
Selects the display language between English and Chinese.
Display Flip
When this parameter is set to “Normal”, the display is in the normal position ;
when “Reverse” is set, the display is in the inverted position.
