Speco O2iB3M User manual

O2iB3M
Intensifier IP
®
Full
Bullet
IP Camera
O2iB3M
Full
HD Megapi
xel Indoor/Outdoor
IP Camera
with Motorized Lens
xel Indoor/Outdoor
with Motorized Lens

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 2
Caution
Any changes or modifications in construction of this device which are not explicitly approved by the
party responsible for compliance could void the user’s warranty.
Note
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generate, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into and outlet on a circuit different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV technician for help.
Directions
Be careful not to cause any physical damage by dropping or throwing the camera. Especially keep the
device out of reach from children.
Do not disassemble the camera. No after service is assumed when disassembled.
Use only power adapters compatible with the unit.
Be careful to prevent moisture or water penetration into the unit. Particular attention is needed when
installing the unit. The screw holes for the installation screws and pipe should be maintained water tight
during the whole life time of the product.
All the electrical connection wires running into the unit should be prepared so that water from the outside
cannot flow into the unit through the surface of the wires. Penetration of the moisture through the wire for
extended period can cause malfunction of the unit or deteriorated image.

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 3
Revision History
Date Revision Details
Feb 25
th
, 2015 1.0 First manual revision creation.

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 4
Contents
1. Introduction .................................................................................................................................................... 5
1.1. Overview ............................................................................................................................................... 5
1.2. Specifications ........................................................................................................................................ 6
1.3. Applications of O2iB3M......................................................................................................................... 8
2. Product Description ...................................................................................................................................... 9
2.1. Contents................................................................................................................................................ 9
2.2. Product Preview.................................................................................................................................... 9
2.3. Physical description ............................................................................................................................10
2.3.1. External View............................................................................................................................10
2.3.2. Dimensions ...............................................................................................................................10
2.3.3. External Connector ................................................................................................................... 11
2.3.4. Factory Default Switch.............................................................................................................. 11
2.4. Functional Description ........................................................................................................................12
3. On Site Installation ......................................................................................................................................14
4. Getting Started............................................................................................................................................. 15
4.1. PC Requirement .................................................................................................................................15
4.2. Quick Installation Guide ...................................................................................................................... 16
4.2.1. Connect PC and O2iB3M to network........................................................................................16
4.2.2. Install Speco-NVR and set IP parameters on O2iB3M.............................................................16
4.2.3. Remote video connection to O2iB3M ....................................................................................... 18
4.2.4. Additional settings through connection to the Admin Page ......................................................20
5. Troubleshooting...........................................................................................................................................21
5.1. No power is applied ............................................................................................................................21
5.2. Cannot connect to the Video...............................................................................................................22
5.3. Windows Vista or Windows 7..............................................................................................................23
5.4. Technical Assistance........................................................................................................................... 26
Appendix A – Important Notice in Exchanging SD Card (Micro SD).........................................................................27

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 5
1. Introduction
1.1. Overview
The ONSIP O2iB3M is a state-of-the-art mega-pixel, dual-codec (H.264, MJPEG) IP/network camera built with
embedded software and hardware technology. It enables real time transmission of synchronized video of Full
HD resolution and audio data. Remote clients can connect to ONSIP O2iB3M for the real time video/audio data
through various client solutions running on PC, PDA or mobile phones. Real time 2-way communication is
available through bidirectional audio communication feature.
Intensifier IP® technology is the most optimized solution for indoor and outdoor surveillance in low-light
conditions by using superior CMOS sensor with low-light sensitivity ISP sensor. Intensifier IP® is especially
beneficial in poor lighting environments, efficiently reducing noise and ghosting while maintain a color image
without the use of IR LEDs.
Designed to be a stand-alone streaming audio & video transmission device, ONSIP O2iB3M can be applied to
various application area such as video security, remote video monitoring, distance education, video conference
or internet broadcasting system.
IP66 compliant housing will extend the application area to harsh environments of wide temperature range.
Embedded PoE (Power over Ethernet, IEEE 802.3af) will enable the owner to reduce TCO (Total Cost of
Ownership) by reducing on-site wiring works for the installation.

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 6
1.2. Specifications
Camera
Image sensor Progressive scan 1/3 inch CMOS 2M pixels
Full resolution 1,920 x 1,080 pixels (Full HD)
Sync System Internal
Lens 2.8 ~ 11mm Motorized Focus & Zoom
Day & Night AUTO, DAY, NIGHT
Sensitivity Intensifier Max – 0.0005 Lux
Back Light Compensation ON / OFF
White Balance ATW(2.000K ~ 10,000K) / MANUAL / PUSH
Exposure DC / ESC
WDR ON / OFF
3D-DNR 0 ~ 20
Intensifier AUTO ON (Max 128x) / OFF
Privacy Mask ON / OFF (10 Programmable Zones)
Motion Detection ON / OFF (4 Programmable Zones)
Digital Zoom 1x ~ 12x
Mirror H / V / Rotate
DEFOG ON / OFF
OSD BUILT IN
Video
Compression method Simultaneous Dual Codec (H.264 / MJPEG)
Resolution 1,920 x 1,080@30fps
Multi-Profile Streaming - 5 simultaneous video profiles
- Select the codec type, resolution and frame rates for each profile.
Intelligent Bit-Rate Control VBR or CBR
PTZ Digital PTZ & Video crop
Image Setting Text overlay, Privacy mask, De-interlace filter
Motion detection 3 regions
Audio
Mono Upstream 32Kbps G.726 ADPCM, 64Kbps 16bit µ-law PCM ~ MIC/Line-in
Mono Downstream 64Kbps 16bit µ-law PCM ~ Line-out

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 7
Network
Network Protocol
- IPv4, TCP, UDP, IGMP, ICMP, ARP, RARP, PPPoE, RTCP
- RTP, RTSP, SDP, HTTP, SMTP, FTP, DHCP, UPnP
- NTP, DNS, DynDNS
Dynamic IP Speco DDNS (free of charge)
Security - User ID & Password protection, IP address filtering
- Digest Authentication, User Access Log
Streaming method
- RTSP streaming with proprietary format for control information
- standard RTSP streaming
- HTTP streaming
External Terminals
LAN 10/100BaseT LAN (auto MDIX)
Analog output 1 channel D1 CVBS output of the encoding video
Alarm input / output Alarm I/O (1 Sensor input & 1 Relay output)
Factory Reset Supported
Audio MIC/Line in, Line out
Power DC 12V input
Alternate Power
Standard PoE IEEE802.3af Supported
Alarm & Event
Intelligent Video Motion Detection
Alarm Triggers Motion Detection + Sensor Input
Alarm Events Video file upload(FTP), Still Image
transmission(Email), Relay output
Alarm Buffer (Audio/Video) Configurable Pre-alarm (5~15 sec) & Post-alarm (10~60 sec)
Client Software
Speco NVR Windows XP/Vista/7 (free of charge)
Speco ONSIP Android™, iPhone®, iPad® (free of charge)
Miscellaneous
Operating Temperature -10
°
C ~ 50
°
C
Operation Humidity 8 ~ 80% RH
Power DC 12V, 0.6A
Dimensions(W x H x D) Ø99.9mm x 254.4mm
Weight 1.1kg
Casing AL, PC, Vandal resistant, IP66
Approvals FCC, RoHS
Package information Unit, CD, mounting screws

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 8
1.3. Applications of O2iB3M
Security surveillance (buildings, stores, manufacturing facilities, parking lots, banks, government facilities,
military, etc.)
Remote monitoring (hospitals, kindergartens, traffic, public areas, etc.)
Teleconference (Bi-directional audio conference). Remote Learning, Internet broadcasting
Weather and environmental observation

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
2. Product Description
2.1. Contents
The product package
contains followings :
Contents
O2iB3M
O2iB3M
Accessories
Screws (
L-
type wrench
CD
Software & User’s Guide
Reference Guide
Quick installation guide
2.2. Product Preview
O2iB3M
Camera Unit
PC software to allocate an IP
address to the IP Camera
contains followings :
Description
Remarks
O2iB3M
main unit
Screws (
2 type)
type wrench
(2 type), CVBS Cable
Software & User’s Guide
Quick installation guide
, Guide pattern
ONSIP Installer VMS Software
PC software to allocate an IP
address to the IP Camera
PC software to view and record the
A/V streaming data transmitted from
IP camera.
(Simultaneous support of up to 64
IP cameras@D1)
Remarks
(Speco NVR)
PC software to view and record the
A/V streaming data transmitted from
(Simultaneous support of up to 64

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 10
2.3. Physical description
2.3.1. External View
Figure 2-1. External view of O2iB3M
2.3.2. Dimensions
Figure 2-2. Dimensions
Unit: mm

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 11
2.3.3. External Connector
Figure 2-3. Connector for external connection
2.3.4. Factory Default Switch
Factory default switch is provided for returning the IP camera to factory default state. The factory default
switch can be found by opening the lower body cap of the camera. There are two functions assigned to
factory default switch.
1. Returning to Factory Default State : Press the switch about 5 seconds while power is applied to
return to factory default state.
2. Safe Removal of Micro-SD Card : Press the switch for 1 second to unmount the Micro SD Card for
safe removal.
Figure 2-4. Factory Default switch and Micro-SD Card slot
Micro SD Card
Video Output (CVBS)
Factory Default Switch /
Network (LAN)
Power Mic/Line Input
Line Output
Sensor Input: white(+), Red(-)
Relay Output: Black(+), Yellow(-)

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
2.4. Functional Description
Power :
Power input for supplying
Caution : If
O2iB3M
power into DC power connector.
Network (LAN)
100Mbps Ethernet connector (RJ-
45) with PoE standard (
Micro SD Card slot
Please insert SD memory card when you want to use SD memory
card, please push the SD card.
MIC/Line Input
Connect external audio source or microphone.
Line Output
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
audio mode.
Power input for supplying
12V DC power.
O2iB3M
is powered by PoE, do not plug in DC Jack with active DC
power into DC power connector.
45) with PoE standard (
IEEE 802.3af).
Please insert SD memory card when you want to use SD memory
card. In case of pulling out SD memory
Connect external audio source or microphone.
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
is powered by PoE, do not plug in DC Jack with active DC
card. In case of pulling out SD memory
Connect speakers with built in amplifier. Audio from remote site is output through Line out in bi
-directional

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 13
Sensor Input
Connect external alarm sensor. Examples of sensing devices are infrared sensor, motion sensor,
heat/smoke sensor, magnetic sensor, etc. Connect the two wires of the sensors to “Sensor Input”.
The sensor type (NC/NO) can be set in admin page. Multiple sensor devices can be connected in parallel.
Figure 2-6. SENSOR input and connection of the sensor
Relay Output
Relay output is provided for connecting alarm devices or for remote on/off control of devices such as light.
Relay is normal open and it will be closed upon alarm annunciation or remote on. The relay is capable
of switching 30V AC/DC, 2A. For the application which needs power switching beyond this limit, use
additional relay switch as shown in the right of Figure.
* Left : switching requirement below 30V, 2A
* Right : switching requirement higher than 30V, 2A. Apply this connection when either voltage or
current exceed the limit.
Figure 2-7. RELAY Output connection
Alarm
Out
Device
Power
Supply
( ~30V)
( ~ 2A)
(DC/AC)
Alarm
Out
Device
Power
Supply
(30V~ )
( 2A~ )
(DC/AC)
Optional
Relay
Switch
Power
Supply
( ~30V)
( ~ 2A)
(DC/AC)
Relay
Relay
Photo Coupler NO/NC Type Open Collector Type
Sensor1+
Sensor
Device
Sensor1-
Sensor
Device
Sensor
Power
Supply
Sensor
Power
Supply
GND
+12V

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
3. On Site Installation
Use Cables and conduits that are suitable for the installation and that are compliant to IP66. Particular attention
should be paid in the installation so that no moisture is allowed to penetrate into the unit through the cables or
conduits during the life time of the product. Products of which the internal parts are exposed to moisture
because of improper installation are not covered by warranty. Follow the procedure below for proper installation
1. Fix the base on the wall.
2. Adjust the rotational position of the camera for desired viewing of the site.

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 15
4. Getting Started
Brief information for first time operation of O2iB3M is provided in this chapter.
4.1. PC Requirement
Audio/Video streaming data received from O2iB3M can be displayed or stored in a PC running client programs.
Minimum requirement of the PC is described below:
ITEM Minimum Requirement Recommended Specification
CPU Intel Core i3 3Ghz Intel Core i7
Main Memory 2GB 4GB
Operating System
*
Windows XP Windows 7 (64bit)
Web Browser Internet Explorer 8, 9 Internet Explorer 8, 9
Graphic Card Video RAM 256MB
Resolution 1920x1080
Video RAM 1GB
Higher than 1920x1080
Network 10 Base-T Ethernet 100 Base-T Ethernet
* Operating Systems supported: Windows 2000 Professional, Windows XP / Vista / 7

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
4.2. Quick Installation Guide
4.2.1. Connect PC and O2iB3M
to network.
1.
Prepare a PC to run programs for the installation and video connection
(PC is needed to assign IP address to
2.
In the case of using PoE, connect the PC and
If your LAN Switch does not support standard PoE, connect
The DC power is applied through DC adapter.
Figure 4
4.2.2. Install Speco-NVR
and set IP parameters on
Speco-NVR is a multi-
channel VMS program for the IP camera. Install Speco
connect to these products. It is needed to assign connection information to Speco
connection. Insert the CD provided with product into the PC and install Speco
to network.
Prepare a PC to run programs for the installation and video connection
(PC is needed to assign IP address to
O2iB3M)
In the case of using PoE, connect the PC and
O2iB3M
to the network using one of the following ways.
If your LAN Switch does not support standard PoE, connect
O2iB3M as sh
own in dotted line in Figure
The DC power is applied through DC adapter.
Figure 4
-1. Power and network connection
and set IP parameters on
O2iB3M
channel VMS program for the IP camera. Install Speco
-
NVR on remote
connect to these products. It is needed to assign connection information to Speco
-
NVR program before
connection. Insert the CD provided with product into the PC and install Speco
-NVR.
Figure 4-2. Speco-NVR
LAN switch with
standard POE
(802.3af)
LAN switch
DC adaptor
Admin Page Button
ONSIP Installer
to the network using one of the following ways.
own in dotted line in Figure
.
NVR on remote
PC to
NVR program before
Admin Page Button

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Follow the sequence below for setting the IP parameter
i) Run ONSIP installer
ii) Click
(1) in ONSIP installer window.> Double click on (2) > Fill in (4) > make a selection in (5) > Fill
the parameters in (6)
iii) Click on
(9) to apply the settings.
iv) You can connect
to admin page by clicking on (10).
Click on the field in (3)
for sorting and rearranging the list.
Select network mode that best suits from the drop down list in
ADSL and Auto (DHCP), respectively. If ADSL and Auto
deactivated.
In case of ADSL, fill the User Name and Password in (8) with the values provided by your ISP.
If DDNS service is needed, Check at the box and fill the empty field with hostname you want in
(7).
2
4
7
Follow the sequence below for setting the IP parameter
(1) in ONSIP installer window.> Double click on (2) > Fill in (4) > make a selection in (5) > Fill
(9) to apply the settings.
to admin page by clicking on (10).
for sorting and rearranging the list.
Select network mode that best suits from the drop down list in
(5)
. You can choose either Static or
ADSL and Auto (DHCP), respectively. If ADSL and Auto
are selected, the fields in (6)
In case of ADSL, fill the User Name and Password in (8) with the values provided by your ISP.
If DDNS service is needed, Check at the box and fill the empty field with hostname you want in
3
(1) in ONSIP installer window.> Double click on (2) > Fill in (4) > make a selection in (5) > Fill
. You can choose either Static or
are selected, the fields in (6)
are
In case of ADSL, fill the User Name and Password in (8) with the values provided by your ISP.
If DDNS service is needed, Check at the box and fill the empty field with hostname you want in
1
6
9
5
8
10

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
4.2.3. Remote video connection to
O2iB3M
1. Connection through Web Viewer
Web Viewer offers simplest way of video connection to
address of O2iB3M
in the URL window of Internet Explorer as:
Note : Active-
X module should be installed on your PC before actual connection. If your PC is
not connected to the internet, you cannot download Active
installing the Active-
X module is installing
web site.
Default ID and password of Admin Page are
For more detailed information, please refer to the
Connection to Admin Page
[e.g.] Port 80
[e.g.] Port 8080
O2iB3M
Web Viewer offers simplest way of video connection to
O2iB3M
. For video connection, enter the IP
in the URL window of Internet Explorer as:
X module should be installed on your PC before actual connection. If your PC is
not connected to the internet, you cannot download Active
-
X module. Most convenient way of
X module is installing
Speco-NVR which is availab
le from the CD or our
Figure 4-3. Web Viewer
Default ID and password of Admin Page are
“admin”, “1234”.
For more detailed information, please refer to the
“Configuration Guide”.
Connection to Admin Page
Basic Control
Default port 80 can be omitted
. For video connection, enter the IP
X module should be installed on your PC before actual connection. If your PC is
X module. Most convenient way of
le from the CD or our
Default port 80 can be omitted

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
2. Connection through Speco-NVR
Click the camera assignment button for setting the camera address. Input the description, address,
Ch#, User ID, Password and port and then click the save button. After assignment procedure, you must
click the SAVE button. You
can see the live video when you click the live view button as below. When
you exit Speco-
NVR, you have to input the ID/PW, admin/1234. Details for Speco
[Speco-NVR User’s Guide].
Example
Click the camera assignment button for setting the camera address. Input the description, address,
Ch#, User ID, Password and port and then click the save button. After assignment procedure, you must
can see the live video when you click the live view button as below. When
NVR, you have to input the ID/PW, admin/1234. Details for Speco
-
NVR can be found in
Figure 4-4. Speco-NVR
Camera Assignment
Live view
Exit Program
Default ID/PW: admin/1234
Camera Assignment
Example
Save
Click the camera assignment button for setting the camera address. Input the description, address,
Ch#, User ID, Password and port and then click the save button. After assignment procedure, you must
can see the live video when you click the live view button as below. When
NVR can be found in
Camera Assignment

O
O2
2i
iB
B3
3M
M
U
Us
se
er
r’
’s
s
G
Gu
ui
id
de
e
Rev.1.0 (Feb. 2015) 20
4.2.4. Additional settings through connection to the Admin Page
All parameters of the camera are factory default out of the box. For a more sophisticated target application,
parameters need to be changed through the admin page. The admin page can be connected through
“http://IP_Address:Port_Number/admin.htm”
ID and password of the administrator are required. Default ID and password are “admin”, “1234”.
It is highly recommended to change the ID and password to prevent illegal access to the IP camera.
For more detailed information, Please refer to the “Configuration Guide”.
Table of contents
Other Speco IP Camera manuals
