SPRT SP-POS76IV User manual

SPRT®
SP-POS76IV Receipt Printer
User’s Manual
（Ver 1.02）
Beijing Spirit Technology Development Co.,Ltd
www.sprt-printer.com

Content
Notes For Use..............................................................................................................1
Chapter 1 Feature and Performance....................................................................... 1
1.1 Print Performance..........................................................................................1
1.2 Print Paper......................................................................................................1
1.3 Ribbon............................................................................................................. 2
1.4 Print Font and Command............................................................................. 2
1.4.1 Print Font.............................................................................................. 2
1.4.2 Print Command....................................................................................2
1.5 Interface.......................................................................................................... 2
1.6 Printing Control Command...........................................................................3
1.7 Power Supply................................................................................................. 3
1.8 Working Environment....................................................................................3
1.9 Outline Dimension......................................................................................... 3
1.10 Model classification..................................................................................... 4
Chapter 2 Operation Specification............................................................................5
2.1 Printer Appearance........................................................................................5
2.2 Ribbon and Paper Installation..................................................................... 6
2.2.1 Ribbon Installation...............................................................................6
2.2.2 Paper Installation.................................................................................6
2.2.3 Paper Jam and Cutter Stuck.......................................................... 6
2.3 Interface.......................................................................................................... 7
2.3.1 Serial Interface.....................................................................................7
2.3.2 Parallel Interface..................................................................................8
2.3.3 Cash Drawer Interface........................................................................9
2.4 Indicators、Buzzer and Buttons............................................................... 10
2.5 Regular Starting Status.............................................................................. 12
2.6 Self-test......................................................................................................... 12
2.7 Hexadecimal Printing..................................................................................13
2.8 the printer parameter set............................................................................14
2.9 Enter into firmware upgrading MODE...................................................... 14
2.10 BID (Bi - direction) bidirectional printing adjust.................................... 14
Appendix A: parameter Settings.............................................................................16

1
Notes For Use
● Don't plug or unplug the interface cable,printer head cabe or power cable under the
state of power on,or else it will cause the damage of printer or control board.
● At any time,don’t take the wastepaper or other attached objects by hard things(such as
tweezers,blades and so on),in order to avoid the permanent damage to the printer head.
● After printing,if open the cover,don’t touch the printer head or motor case by hands, in
order to avoid scald caused by the high temperature of the metal.
Chapter 1 Feature and Performance
1.1 Print Performance
●Print method：9 pin inpact dot matrix
●Print paper width：76±0.5mm or 57.5±0.5mm
●Print density ：385point/line （half point）, 400point/line （half point ）,420
point/line（half point）
●Print speed：76.5mm paper width: 4.4lps；57.5mm paper width：5.6lps
●Feeding speed：120mm/s
●Reliability：
（1) Printing Head life: 7,500,000 lines
（2）Auto Cutter：500,000characters
●Valid print width：42CPL（7×9）/35CPL（9×9）
40CPL（7×9）/33CPL（9×9）
1.2 Print Paper
● High quality commone white paper / impact paper roll 57/76x φ80（MAX）
● Paper Roll inner diameter ---------- ф13mm
Simplex paper thickness ---------- 0.06mm～0.08mm
Warning
This is A level products.In living condition,the products may cause radio
jamming.In this case,may need user to take practicable measures to the
jamming.

2
Impact paper thickness（1 original+2 copies）：0.05mm～0.20mm
● Paper Loading: Auto Feeding Paper
● Paper Cutting: Manual Tear/ Auto Cutter (Full/Partial Cutting optional)
1.3 Ribbon
ERC-39 purple or black
Working Life:3,000,000characters (ASCII 7×9)
1.4 Print Font and Command
1.4.1 Print Font
● ANK character set，7×9dots or 9×9dots
● GB18030，16×16dots
Font description：
7×9dots（W×H）：half point printing，9/10 half points on the horizontal
direction;
9×9dots（W×H）：half point printing，11/12 half points on the horizontal
direction;
Size of a point is：0.318mm（W）×0.353mm（H）。
1.4.2 Print Command
Compatible with the ESC/POS command set of EPSON,please see the
details in developer guide.
1.5 Interface
●RS-232C Serial Interface：
DB-25 socket（male）,support XON/XOFF and DTR/DSR .
Baudrate:1200,2400,4800,9600,19200,38400,57600,115200bps
adjustable.
Data structure：1 start bit ＋ （7 or 8）data bits ＋1 stop bit
Parity checking：no parity or odd,even parity is optional.
●Parallel interface：
36 pin，8-bit parallel interface，support BUSY/ACK hadshaking protocol，
TTL signal level
●Ethernet interface：
Standard ethernet interface.

3
●USB interface：
Standard USB interface
●Cash drawer control
DC24V，1A，6pin RJ-11 socket
1.6 Printing Control Command
Character printing command: support ANK character, custom character
and Chinese character width, times of high print, can adjust the line space
between characters.
1.7 Power Supply
●Put in (110-220)v±10%,50/60Hz,1.5A, Standard three-wire interface socket.
1.8 Working Environment
●Operation temperature：0℃～50℃Relative humidity：10％～90％
●Storage temperature：-20℃～60℃Relative humidity：10％～90％
1.9 Outline Dimension&Weight
● Outline Dimension: 248 mm（L）×158 mm（W）×140.5 mm（H）
● Weight: 1800g (not including paper roll)

4
1.10 Model classification
Model
Cutter
Interface
SP-POS764-BS
With
RS－232C serial interface
SP-POS764-DS
Without
SP-POS764-BP
With
Parallel interface
SP-POS764-DP
Without
SP-POS764-BE
With
Ethernet interface
SP-POS764-DE
Without
SP-POS764-BU
With
USB interface
SP-POS764-DU
Without

5
Chapter 2 Operation Specification
2.1 Printer Appearance
Fig.2-1 printer appearance
Paper-out Slot
Paper Cover
Upper Cover
Power Indicator
Status Indicator
Paper-out Indicator
Power
Feed
MODE
Interface Socket
Cash Drawer Interface
Power Socket

6
2.2 Ribbon and Paper Installation
2.2.1 Ribbon Installation
Steps of ribbon installation are as below
（1）Open front cover
（2）Put the ribbon into printer head,turn the knob as the direction shown on it
for two~three circles..
（3）Close the front cover
2.2.2 Paper Installation
The installation steps of paper are as below:
(1)Living with your hands on both sides of the paper cover, open the paper
cover.
(2)Put paper into the paper holder(Keep the paper roll in a right direction)
(3)When the printer is on,put the paper into mouth of printer, it will automatic
feed .
(4)Turn off the paper cover, tear off the extra paper.
Notice
1. Attention to the loading direction of paper roll
2. Please do not use hand to make paper go forward or backward.
3. Keep printing head cleaning to avoid affecting printing quality.
2.2.3 Paper Jam and Cutter Stuck
If the cutter was stuck, switch off the power switch, and electricize again, the
cutter can be returned to the original place, then take out the paper. If by
electricizing again, cutter can't back, can open the front cover, show the cutter.
Move the plastic gears on the cutter hand, make cutter back.

7
2.3 Interface
2.3.1 Serial Interface
The serial interface of POS764 printer is compatible with RS-232C, use
DB-25(female) socket, DTR/DSR handshaking protocols.The pin order of the
serial port is as Fig.2-2 shows:
Fig.2-2 Pin Order of Serial Port
The pin assignment of serial interface is shown in Fig. 2-3:
Pin No.
Signal
Name
Direction
Source
Description
1
FG
——
——
Ground
2
TXD
Output
Printer
Printer transmits control code
X-ON/X-OFF and data to host
3
RXD
Output
Host
Printer receives data from host
4
RTS
Output
Printer
The same with 20pins DTR signal
6
DSR
Input
Host
Signal “MARK” means the host is busy
and can not receive data.Signal
“SPACE” means the host is ready to
receive data.
7
GND
——
——
Signal Ground
20
DTR
Output
Printer
Signal “MARK” means the host is busy
and can not receive data.Signal
“SPACE” means the host is ready to
receive data.
For. 2-1 The pin assignment of serial interface
Note: (1)“Source” denotes the source that signal come from;

8
(2)Logical signal level is EIA.
The baud rate and data structure under serial interface mode is 9600bps, 8-bit
data bits, no parity and 1 stop bit.
The serial interface of POS764 can be connected to standard RS-232C
interface. When it is connected with IBM PC or its compatible machine,
connection can accord to Fig.2-3.
Fig.2-3 Sketch Map of Connection between POS764 and PC Serial Interface
2.3.2 Parallel Interface
The parallel interface of POS764 printer is compatible with CENTRONICS,
supports BUSY or ACK handshaking protocol.
The pin assignment of 36PIN parallel interface is as Fig. 2-4 shows:
Pin No.
Signal
Direction
Description
1
STROBE
In
Strobe pulse to latch data, Reading occurs at falling
edge.
2
D1
In
These signals represent the 1st bit to 8th bit of the
parallel data representatively, each signal is at HIGH
level when data is logic 1, and LOW when data is
logic 0.
3
D2
In
4
D3
In
5
D4
In
6
D5
In
7
D6
In
8
D7
In
9
D8
In
10
ACK
Out
Answer pulse, LOW level signal indicates that data
have already been received and the printer gets ready
to receive the next data.
11
BUSY
Out
HIGH level signal indicates that the printer is BUSY
and can not receive data.
12
PE
Out
HIGH level signal indicates that paper is end.
13
SEL
Out
Pulling up to HIGH level signal by a resistor
