THE SPARC SYSTEM
WHAT IS SPARC 16V
No matter whether you encounter
headwinds, rain or hills, with Sparc
as your backup you will always have
the upper hand. Sparc, the new light
electric drive with TwinDrive, gives
you that extra boost whenever you
need it.
Sparc was designed and built to
make life easier and more pleasant
for cyclists. Sparc is a solution that
does not change the character of
the bicycle – its light weight,
features, simple maintenance and
comfort ideally complement modern
lifestyles. Its user-friendliness and
superior help function make Sparc
the No. 1 product on the market.
OPERATING PRINCIPLE
Sparc allows cyclists to choose
between two supplementary drive
options. By simply pressing a button
on the control unit mounted on the
handlebars, you can toggle between
the fast SPEED mode and the ECON
mode, which offers increased range.
RANGE
Depending on the mode selected,
Sparc allows a range of action of
25 – 40 km (15 – 25 miles). This means
increased mobility with little effort.
The range achieved by a single
battery charge depends on various
factors. These include drive mode,
the condition of the battery, the road
conditions and particularly the
cyclist’s own effort.
Motor drive
Average speed 20 km/h in the plain
SPEED mode
SPEED mode
ECON mode
ECON mode
using a 28-inch wheel and assuming
75-watt input by the rider.
(US version: SPEED = 15 miles, ECON = 25 miles)
US version: SPEED = 20 mph, ECON = 16 mph
Range
25 km/h
20 km/h
up to
25 km
up to
40 km

Sparc · July 2004 5
E
THE SPARC SYSTEM
5-gear hub with
electric drive
TwinDrive system, 200 Watt,
allows effective use of energy.
5-gear twist-grip
Changing gears is convenient
and requires little effort.
Handling is simple and intuitive.
Sparc control unit
All control functions are integrated
into one unit with a switch for OFF,
ECON and SPEED mode.
Battery box 16V
Excellent performance,
simple to use, no memory effect,
Battery NiMH, 16,8 Volt, 8 Ah.
Charger 16V
Charge time 4.5 hours,
light indicates
charging in progress.

Off
Econ
Speed
Sparc · July 2004
6
Off
Econ
Speed
OPERATION
The bicycle can be ridden with or
without the help of the electric
drive. Riding without the help of your
Sparc is like riding any ordinary bike
and requires no extra effort.
When the system is switched on,
you start off as usual. The electric
drive actively supports you whilst
you pedal.
» ECON mode works up to a speed of
approx. 20 km/h (US version 16 mph).
» SPEED mode works up to a speed of
approx. 25 km/h (US version 20 mph).
Once these speeds are reached, the
electric drive switches off and you
continue under your own muscle
power. Reducing speed causes the
system to come on again.
Please charge the battery
before your first trip.
Set the mode required, ECON
or SPEED. The system only
becomes active once the bicycle
moves.
In SPEED mode the red light
gleams.
The condition of the battery is
indicated by 3 green lights.
Off
Econ
Speed
1
2
1
2

Sparc · July 2004 7
E
3
OPERATION
When only 1 green light gleams, the
battery needs to be recharged.
STANDBY MODE
Your Sparc system has an energy
saving feature.
Approximately 1 minute after you
stop using the system it will auto-
matically switch off and the lights
on the control unit will go out.
When you continue, the electronic
system will automatically come on
again.
5-GEARSHIFTING
A 5-gear hub shift is integra-
ted into the Sparc system. You shift
gears by turning the right twist-grip
on the handlebars through positions
1 to 5.
» Whilst shifting gear continue
pedalling without exerting force.
» If the desired gear does not
engage immediately, briefly stop
pedalling.
» When approaching inclines shift
down in good time.
» You can also shift gears when the
bike has stopped.
3
Your Sparc bicycle is not for
children!
» Only switch on the Sparc system
when you want to travel on your
bicycle.
» Always switch off the Sparc
system before you stand your
bicycle upside down or hang it up,
also before you carry out cleaning
or maintenance work.

Sparc · July 2004
8
MAINTENANCE AND CARE
BATTERY
CHARGING THE BATTERY
You can either charge the battery
whilst it is attached to the bicycle or
you can remove the battery box to
enable you to recharge it at home.
» Insert the plug of the charger into
the socket of the battery box.
» Insert the charger into an electric
mains socket.
The LED will glow during charging,
changing to green when the battery
is fully recharged.
Yellow – Battery is not connected or
battery test stage
Red – Battery charge process
Green with Red – Charge optimisation
Green – Battery completely recharged
Red with Green – Failure
Recharge the battery at
least every 3 months.
» The battery must only be charged
in a temperature range of +5°C to
+30°C.
» Only charge the battery in the
operating position.
» Only use in dry internal areas.
» Do not use in rooms (garages)
with an explosion risk.
» Do not dismantle the charging unit
and battery box yourself.
Incorrect assembly can lead to
electric shock or fire.
» The charging unit should not get
into the hands of children.
» Charging should only be carried
out in sufficiently well ventilated
areas.
» When not in use always withdraw
the mains plug for the charging
unit from the socket (do not pull on
the charging unit’s cable).
» Regularly check the cable and
protect it from sharp edges. If it is
damaged have it renewed imme-
diately by a specialist workshop.
» Protect the unit from oil, grease,
aggressive cleaning agents and
paint thinners since they can
destroy the housing.
» If it falls, from a bench for example,
the unit must immediately be given
a safety check by a specialist
workshop. This is also necessary
if contact pins become loose.
» The battery must never be burned.
Risk of explosion!
» The battery must be disposed of
according to the waste disposal
regulations.
» Only ever use the Sparc charging
unit 16,8V with the Sparc battery
16,8V.
» In the USA only use the ”Sparc
USA charging unit”.

Sparc · July 2004 9
E
pulled
open
MAINTENANCE AND CARE
BATTERY
REMOVE BATTERY BOX
Press the button on the plug of
the battery cable to remove
the cable from the box.
» Turn both quick-release levers to
the “open“ position and then pull
them outwards.
» Remove the battery box from the
luggage carrier.
ATTACH BATTERY BOX
» Pull out both quick-release levers
and then turn them into the
“open“ position.
» Place the battery box onto the
luggage carrier.
» Push in the quick-release levers
and turn them into the “locked“
position.
» Push the plug of the battery cable
into the socket of the box.
Check that the battery box
has been correctly mounted.
» Protect the battery box from
hard jolts.
STORING THE BATTERY
If you intend to not use your bicycle for
a while, remove plug of the battery ca-
ble from the box. Store the batterie box
fully charged in a dry and cool place.
Recharge the battery at
least every 3 months.
REPLACING THE BATTERY
A battery that has become useless
must be replaced by a specialist
dealer.
The old battery must be disposed of
properly and will be accepted by the
dealer for recycling.
4
locked
4

2
1
Sparc · July 2004
10
6
MAINTENANCE AND CARE
REAR WHEEL / WEAR PARTS
ADJUSTING GEARSHIFT
Before adjusting the gearshift
you must set the twist-grip
shift from 4th gear back to 3rd
gear.
» Align the arrows in the inspection
window (1) of the Clickbox by
turning the adjustment screw (2)
on the gearshift cable.
REMOVE REAR WHEEL
Pull the plug of the control unit
off the hub. Push the button on
the plug of the battery cable to re-
move the plug from the Sparc drive.
» Release the knurled screw on the
Clickbox and remove the Clickbox.
» Pull off the red positioning bush
and remove the shift rod/-pipe
from the axle.
» Release the two axle nuts to re-
move the rear wheel.
»The rear wheel is re-fitted in
reverse order.
The cables must not be
squeezed or pinched.
Danger of short-circuit!
WEAR PARTS
Bicycles chains, sprockets, shifting
cables, handlebar grips and batteries
are wear parts.
Take care of regular control and
timely replacement.
5
5
6
