SSV Works RZ34-Q5ARC User manual

SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
RZ34-Q5ARC
RZR 3 and RZR 4 with Ride Command
SSV Works 5 Speaker Audio Kit
Phase 5
Panels, Dash Disassembly,
and Wiring
Glovebox Subwoofer
Installation
Amp Tray
Installation
pg 6
pg 10
pg 13
Cage Mount Speakers
Installation
pg 17
Kick Panel Speakers
Installation
pg 15
RZR3 2014-2018 RZR4 2019+
RED BLUE
FOLLOW THE COLOR CODE ON EACH STEP FOR YOUR VEHICLE’S SPECIFIC INSTRUCTIONS

2
!
Please read and understand these
instructions completely before
installation to avoid possible injury,
or damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All Kicker Speakers are covered by a limited 1
year warranty against defects in material or workmanship. All Kicker Ampliers are covered by
a limited 2 year warranty against defects in material or workmanship. Labor for replacement
of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- T30 & T40 Torx Socket
- 10mm and 5.5mm Socket
& Rachet or Wrench
- 4mm & 5mm Allen Wrench
- #2 & #3 Phillips Screwdriver
PARTS LIST IMAGES
2. B-H1909 Front Speaker Wire
6. M6 x 1.0 Screws and
Washers x 2
10. Battery Terminal Cable x2 11. Connector Cover with
Relief Cut-out
7. Self-Tapping Screw and
Washer x 1
8. Zip Ties x 10
1. Amp Power Wire x2
5. Amp Tray Base Brackets
(Depending on model)
9. Fuse Holder with 40A Fuse x2
3. B-H1912 and B-H1913
Rear Speaker Expansion
4. Amp Tray with pre-loaded
PhaseEQ Amplier
- Drill with 13/64”, 1/8”, 1/4”
& 1/2” Drill bits
- Panel removal tool
- Wire Crimpers
- Wire Strippers
- Scribe or Marker
- Utility Knife
Triangular end
Wiring Installation
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
12. B-H2346 Ride
Command harness
PARTS LIST 1/4

3
!
Please read and understand these
instructions completely before
installation to avoid possible injury,
or damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in material
or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty against
defects in material or workmanship. All SSV Works Speakers are covered by a limited 1 year
warranty against defects in material or workmanship. All Kicker Speakers are covered by a
limited 1 year warranty against defects in material or workmanship. Labor for replacement of
defective components is not covered. Contact SSV Works for further warranty information.
Glove Box Subwoofer Enclosure
9. B-H1173 Audio Signal
Extension Cable - 3ft
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
PARTS LIST IMAGES
3. Glove Box Door Bracket 4. Lower Mounting Bracket
with #14 Screw x1 each
2. 8mm Socket Head Screws &
Washers x14
5. Flat Mounting Bracket “A” 6. Mounting Bracket “B”
1. RZ4-GB10 Enclosure
(door not included)
7. Left & Right Door Hinge
Brackets
8. M6 x 8mm (T30 torx) Screw
x2
TOOLS NEEDED FOR INSTALLATION
- 10mm & 8mm Socket
- Ratchet & Extension
- T-30 & T-40 Torx Driver
- #3 Phillips Screwdriver
- #2 Phillips Screwdriver
- Panel removal tool
L
R
PARTS LIST 2/4

4
Kicker 6.5” Speaker Front Kick Panels
!
Please read and understand these
instructions completely before
installation to avoid possible injury,
or damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All Kicker Speakers are covered by a limited 1
year warranty against defects in material or workmanship. All Kicker Ampliers are covered by
a limited 2 year warranty against defects in material or workmanship. Labor for replacement
of defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION - T-40 Torx Driver - #2 Phillips Screwdriver
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
PARTS LIST IMAGES
2. #14 Screws x4
1. RZ4-F65K Enclosures
(1 pair)
PARTS LIST 3/4

5
!
Please read and understand these
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects
in material or workmanship. All SSV Works Electronics are covered by a limited 1 year
warranty against defects in material or workmanship. All Kicker Speakers are covered
by a limited 1 year warranty against defects in material or workmanship. All Kicker
Ampliers are covered by a limited 2 year warranty against defects in material or
workmanship. Labor for replacement of defective components is not covered. Contact
SSV Works for further warranty information.
INSTALLATION NOTES
It is recommended to wrap the bag that the clamps come in around the cage before you slide the clamp onto the cage to prevent scratching.
TOOLS NEEDED FOR INSTALLATION
PARTS LIST IMAGES
1. US-C65 Enclosures (1 pair)
5. M6 Hex Head Bolts &
Washers x4
6. M6 Allen Socket Head Bolts
& Washers x4
3. Ring Clamp x 4
7. M6 Set Screws x 4
2. Dual Mounting Ring
Adapter x 2
- 5mm Allen Key - 8mm Open End Wrench
Placement of the pod depends on what type of roll
cage you have (factory or aftermarket) and your
preference of where you want the pods to be installed.
In these instructions, we have installed them on the
outside vertical bars at the back of the roll cage.
4. Rear B-H2195 Speaker
Harness
SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: [phone] | Fax: [phone]
Cage Mount
Kicker 6.5” Speaker Enclosures
PARTS LIST 4/4

6
A
PANELS AND DASH DISASSEMBLY (ALL MODELS)
B
A. Remove all seats by releasing the handle behind each seat,
push forward slightly while lifting up.
B. Disconnect the negative battery cable from the battery.
C C C
C. Remove all of the center console push pins and T-40 Torx screws. For 4-seat models, disconnect the harness attached to the 12v accessory socket.
D EE
D. Remove hood by turning locking pins and lifting up. E. Remove center dash by unscrewing the (2) T-40 Torx screws and push center
dash forward to unclip.
PANELS AND DASH DISASSEMBLY (RZR3)

7
PANELS AND DASH DISASSEMBLY (RZR4)
D1 D2
D1. Remove hood by turning locking pins and lifting up. D2. Unscrew the (4) T40 torx screws and extract the (2) push pins from
the top-center Ride Command bezel. Lift and remove the top-center
Ride Command bezel. From inside the machine, pull the dash
towards you to unclip. Once unclipped remove the dash.
RUNNING WIRING AND CABLES (RZR3)
A
A. Unwrap the tape and pull the rubber wire grommet out of the rewall.
B1 B2 B3
B. Starting from under the hood compartment, feed the connector of the power wire and B-H1912 & B-H1913 rear harness female connector through
the grommet into the dash cavity. In order to connect to the amplier in a later step, pull about 18” of the amp power wire and B-H1912 & B-H1913
into the dash cavity (B1). Route the additional length of the (ring terminal end) power/ground wire and B-H1912 & B-H1913 down the exterior of the
rewall along the factory wiring (B2). Pull the power/ground wire through to the center of the vehicle to the battery compartment. DO NOT CONNECT TO
THE BATTERY (B3). **NOTE** B-H1912 & B-H1913 is used for the addition of rear speakers - sold separately.

8
RUNNING WIRING AND CABLES (RZR4)
D
B
C
A. Extract the (4) T40 surrounding the ride command system OR top-center dash
compartment (for non-Ride Command vehicles) and (2) push pins found in the
dash pocket. Unclip the dash surrounding the glovebox. Once unclipped, gently
pull the dash forward and remove the upper dash pocket.
D. Unwrap the tape and pull the rubber wire grommet out of the rewall.
B. Extract the (1) T40 torx that secures the lower dash pocket.
Disconnect the USB and unclip the LED from the lower dash pocket.
Remove the lower dash pocket.
C. Label / take photos of the harnesses connected to the dash. Once
recorded, disconnect harnesses, and remove dash.
A
E1 E2 E3
E. Starting from under the hood compartment, feed the connector of the power wire, MRB3 power connector, and B-H1912 & B-H1913 rear harness
female connector through the grommet into the dash cavity. In order to connect to the amplier in a later step, pull about 18” of the amp power
wire and B-H1912 & B-H1913 into the dash cavity (E1). Route the additional length of the (ring terminal end) power/ground wire and B-H1912 &
B-H1913 down the exterior of the rewall along the factory wiring (E2). Pull the power/ground wire through to the center of the vehicle to the battery
compartment. DO NOT CONNECT TO THE BATTERY (E3). **NOTE** B-H1912 & B-H1913 is used for the addition of rear speakers - sold separately.

9
A. Start by removing the four (4) 10mm bolts securing the Dynamix
brain tray.
A
B. Tilt the brain back, unsnap the perimeter of the connector cover as it will be
replaced by the provided cover that has a cable relief cut-out.
BB
These following steps are needed to ensure clearance for the sub enclosure and allow proper performance for vehicles with Polaris Dynamix.
C. Run a zip tie through the provided connector cover as shown in
gure C.
D. Snap the connector housing back into place over the connector.
DC
E. Bend harness towards zip tie and close the tie. F. Cinch down zip tie as show in gure (F). Put the Dynamix brain
tray back in place but DO NOT REINSTALL THE BOLTS.
E F

10
E. With the dash removed, extract the (2) 10mm bolts retaining the
glovebox and remove the glovebox.
E
B. Install door latch onto enclosure with the provided (2) T30
M6x8mm screws.
B
A. Using (4) 8mm screws and washers, attach Bracket “B” to the
enclosure.
D. Install lower mounting bracket onto enclosure with the provided
(2) 8mm screws and washers.
C. Install left and right door hinge brackets using (2) 8mm screws and washers
for each side.
C DC
A
GLOVE BOX SUBWOOFER ENCLOSURE (BOTH VEHICLES)

11
F. Lift the enclosure into place. Using the factory glove box mounting hardware, fasten the enclosure into place. Pull sub enclosure wiring towards the center
of the vehicle to avoid being pinched by the chassis.
F F F
G. Place Bracket “A” into place towards the rewall, and fasten
it into place with the (4) 8mm socket head screws and washers
provided with the kit.
H. Fasten the provided #14 screw to secure the enclosure lower
mounting bracket.
G H
A. Attach the factory glovebox door.
A
B. Connect the sub enclosure to the 800.5 amplier output (sub)
B
GLOVE BOX SUBWOOFER ENCLOSURE (RZR3)

12
The next steps will either be for
RZR’s with OR without factory Ride
Command door speakers.
If you do not have factory Ride
Command door speakers,
proceed to page 14.
If you do have factory Ride
Command door speakers,
proceed to page 14.
STOP

13
AMP TRAY INSTALLATION - WITH FACTORY RIDE COMMAND (ALL MODELS)
Follow these steps if you currently have the Polaris factory door speakers already installed. This process
will deactivate the factory amp and speakers. If you want to continue to use the factory system with this
audio system, please contact SSV Works at 818-991-1778 x2 or email [e-mail]
Disconnect and uninstall the
factory amplier. Discard as it
will not be needed anymore. We
always recommend e-recycling
any unwanted electronics.
RIDE COMMAND HARNESS
1. Amp Input - B-H2591
2. Amp Output
3. Speaker Out FR2
4. Amp Turn-On
1
2
3
4
5
67
8
9
10
808000.5 AMP.5 AMP800.5 AMP
1
2
3
4
1. INPUT (FRONT)
2. INPUT (REAR)
3. INPUT (SUB)
4. OUTPUT (SUB)
5. B-H2701
6. OUTPUT (FRONT)
7. OUTPUT (REAR)
8. EXT SWITCH
9. AMP TURN-ON
10. TO POWER INPUT

14
AMP TRAY INSTALLATION (RZR3)
Place the pre-assembled amp plate on the frame of the dash and line up the hole on the top of the amp plate to the factory
hole where the pocket bracket was previously installed (1). Loosely screw in the factory 10mm screw in this hole location that
was previously removed. Next loosely screw in the T30 screw with washer from underneath the steering column into the amp
plate (2). Lastly hand tighten both screws.
11
2
2
Connect the 800.5 amplier “Front Input” to the Ride Command
“Audio Amp 1” factory harness. Connect the 800.5 amplier “Rear
Input” for rear speakers to “Audio Amp 2” factory harness. Connect
the 800.5 input for the subwoofer to “Audio Amp 3” factory harness.
A. Place the amp tray base bracket at the location of the (2) removed
factory 10mm bolts. Re-fasten the bolts through both the amp tray
base bracket and factory plate to secure to the chassis.
A
AMP TRAY INSTALLATION - WITHOUT FACTORY AUDIO (RZR4)
B. Place the amp tray into the mounting location by lining up the amp
plate screw holes to the factory holes on the chassis and base
bracket.
B
If you have factory speakers, you can remove the factory amplier and
plug our harness into the factory 16 pin plug, which will allow for our
800.5 amp to be installed

15
E. With the accurate location marked, uninstall the amp tray and use
a 13/64” drill bit to drill your pilot hole.
With your pilot hole drilled, reinstall the amp tray. Use the self-
tapping screw in the drilled hole location.
E
D. Using a scribe or punch, mark the location of the needed pilot hole
on the passenger side of the tray.
D
C. Secure the amp tray by using the 10mm factory bolt at the top, and
two (2) T-30 torx bolts at the bottom mounting locations.
C
F. Connect the amplier “Front Input” to the Ride Command “Audio
Amp 1” factory harness. Connect the amplier “Rear Input” for rear
speakers to “Audio Amp 2” factory harness. Connect the 800.5
input for the subwoofer to “Audio Amp 3” factory harness. Connect
the 800.5 output to the RZ4-GB10 subwoofer.
F
Connections for a RZR w/o factory speakers pre-installed
FRONT KICK PANELS (ALL MODELS)
Route the B-H1909 across the dash cavity. The cable marked as “DRIVER” will route under the dash and down to the driver side footwell, the cable
marked “PASSENGER” will route over the top and down the right side of the RZ4-GB10 enclosure.
PASSENGERDRIVER

16
B
A. Starting at driver side footwell, remove the factory T40 torx
screw as shown. Save this screw for Step D.
B. Place the driver kick pod into location so that both vehicle
screw bosses line up with kick pod brackets.
A
D
C. Using (x2) #14 screw loosely secure the kick pod to the factory
screw bosses.
D. Re-use the factory T40 torx screw previously removed in
Step A to loosely bolt through the lower kick pod bracket to
vehicle panel. Once all three screws are in place go back and
re-tighten.
C
E. Connect the B-H1909 cable to both passenger and driver side
speaker pods and zip tie all cables to the frame.
E
G. Repeat Steps A-F to install passenger kick pod.
F. Connect the B-H1909 speaker harness to the 800.5 amplier
front output.
F

17
A. Find the best orientation for the speaker on your bar and
screw in the Set Screws in the OPPOSITE holes of where the
clamp will install into.
B. Loosely install the clamp base to the cage mount pod with the
two (2) 8mm M6 hex head bolts and washers, place the cage
mount pod in the desired mounting location on the vehicle.
Once the ring adapter is in the desired position, tighten the two
(2) bolts using a 8mm open wrench.
A B
C. Place both ring mounting clamps on the cage using the plastic bag to prevent scratching, place the cage mount pod in its nal mounting location and
secure to the clamps using the two (2) M6 allen socket head bolts and washers with a 5mm allen key.
C C C
CAGE POD KICKER 6.5” SPEAKER (ALL MODELS)
E. From the rear of the center console, route the B-H2195
harness up to each speaker pod and connect.
E
D. Position the speaker to your liking and tighten the hex head
bolts by hand with a 8mm wrench.
D
PLACEMENT OF THE POD DEPENDS ON WHAT TYPE OF ROLL CAGE YOU HAVE (FACTORY OR AFTERMARKET) AND
YOUR PREFERENCE OF WHERE YOU WANT THE PODS TO BE INSTALLED. IN THESE INSTRUCTIONS, WE HAVE
INSTALLED THEM ON THE OUTSIDE VERTICAL BARS AT THE BACK OF THE ROLL CAGE.

18
F. Route the speaker wire away from any moving parts and any
sharp metal, then connect to the amplier
F
G. Connect the B-H1912 & B-H1913 speaker harness to the SSV
Works WP-A360S4 amplier rear output (green/purple).
G
CONNECTING POWER & GROUND CABLE TO BATTERY (ALL MODELS)
CB
A2 A3
B. Unscrew the factory nut on the negative battery terminal. Install
the 2 ground cables to the screw on the ground battery terminal.
Re-install the factory nut.
A1. Remove the bottom cover of the fuse holder
by extracting the 2 screws. Break off the right
and left side tabs on the bottom cover.
A2. Extract both fuse holder screws. A3. Attach both the Power Wire and Battery
Terminal Cable to the fuse holder. Reattach
the bottom cover.
C. Unscrew the factory nut on the positive battery terminal. Install the 2
power cables to the screw on the postive battery terminal. Re-install
the factory nut.
Power
Wire
Battery
Terminal
Cable
A1
Break
off tab
Break
off tab

19
E
D
E. Zip tie all of the electrical cabling (factory and audio) along the center
column away from the drive shaft.
D. Remove the top of the fuse holder and extract the 2 screws. Insert the
40A fuse, screw the 2 screws back in and reattach the fuse holder top.
THIS CONCLUDES THE INSTALLATION PROCESS.
© 2022 SSV Works, Oxnard, CA 93030 RZ34-Q5ARC 7-26-22
