SSV IGW/910 Application guide

Remote Access Gateway IGW/910
with DNP/9535
Hardware Reference
SSV Software Systems GmbH
Dünenweg 5
D-30419 Hannover
Phone: [phone]
Fax: [phone]
Email: [e-mail] Document Revision: 1.0
Date: 2019-12-11

Remote Access Gateway IGW/910 – Hardware Reference
2
Document Revision 1.0
CONTENT
1 INTRODUCTION...............................................................................................................3
1.1 Safety Guidelines ................................................................................................................... 3
1.2 Conventions ........................................................................................................................... 3
1.3 Block Diagram ........................................................................................................................ 4
1.4 Features and Tec nical Data ................................................................................................. 5
2 OVERVIEW.......................................................................................................................6
3 PINOUTS ..........................................................................................................................7
3.1 Et ernet Interface .................................................................................................................. 7
3.2 Screw Terminals ..................................................................................................................... 7
3.3 COM Ports 1..8 (D-Sub DB25 male) ....................................................................................... 8
3.4 COM Port 9 (D-Sub DE9 male) ............................................................................................... 9
3.5 COM Port 10 (D-Sub DE9 male) ............................................................................................. 9
4 LINUX DEVICE MAP ......................................................................................................10
5 HELPFUL LITERATURE ................................................................................................11
CONTACT .............................................................................................................................11
DOCUMENT HISTORY .........................................................................................................11

Remote Access Gateway IGW/910 – Hardware Reference
Document Revision 1.0
3
1 INTRODUCTION
T is document describes t e basic ardware components of t e Remote Access Gateway
IGW/910.
1.1 Safety Guidelines
Please read the following safety guidelines carefully! In case of property or personal
damage by not paying attention to this manual and/or by incorrect handling, we do not
assume liability. In such cases any warranty claim expires.
•T e power supply s ould be in immediate proximity to t e device.
•T e power supply must provide a stable output voltage at 12..24 VDC ±10%. T e
output power s ould be at least 7 W.
•Please pay attention t at t e power cord or ot er cables are not squeezed or dam-
aged in any way w en you set up t e device.
•Do NOT turn on t e power supply w ile connecting any cables, especially t e pow-
er cables. T is could cause damaged device components! First connect t e cables
and THEN turn t e power supply on.
•T e installation of t e device s ould be done only by qualified personnel.
•Disc arge yourself electrostatic before you work wit t e device, e.g. by touc ing a
eater of metal, to avoid damages.
•Stay grounded w ile working wit t e device to avoid damage t roug electrostat-
ic disc arge.
•T e case of t e device s ould be opened only by qualified personnel.
1.2 Conventions
Convention
Usage
bold
Important terms and information
monospace
Filenames, Pat names, program code, command lines
Table 1: onventions used in this document

Remote Access Gateway IGW/910 – Hardware Reference
4
Document Revision 1.0
1.3 Block Diagram
Figure 1: Block diagram of Remote Access Gateway IGW/910
DNP/9535
40 Pin
Socket
EMI-
Filter
LAN
User
LED
Terminal Block
DCin
Power Supply
Vin=12..27VDC
Vout=3.3V/2.0A
100MBit
RJ45
int. Mag
LEDs
USB
+3.3V
1x GPIO
USB
3-Port
HUB
USB2513
USB
Quad-
UART 1
FT4232H
RS232
Terminal Block
Debug Port
1x GPIO
Multi-COM
Connector
D-SUB
DB25
ESD
LAN (10/100 Mbit)
PWR
LED
RX/TX-TTL
USB1 USB2 USB3
USB
Quad-
UART 2
FT4232H
USB
Quad-
UART 3
FT4232H
RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL RX/TX-TTL
RX/TX RX/TX RX/TX RX/TX RX/TX RX/TX RX/TX RX/TX
RS-232
ADM 3311
RS-232
ADM 3311
RS-232
ADM 3311
RS-232
ADM 3311
RX/TX RX/TX
D-SUB
DE9
D-SUB
DE9
TTL
Hub_RST#
Power
Switch
COM_PWRen
COM_VCC

Remote Access Gateway IGW/910 – Hardware Reference
Document Revision 1.0
5
1.4 Features and Technical Data
Processor
Manufacturer / Type
Atmel ATSAM
-
A5D35
SoC
lock speed
528
MHz
Memory
RAM
256
MB
SDRAM
Flash
4
MB NOR memory
Storage media
1x internal microSD card older
Interfaces
Ethernet
1x 10/100 Mbps (RJ45)
Debug Port
1x (screw terminal)
Serial I/Os
1x D
-
Sub DB25 (COM 1..8)
1x D-Sub DE9 (COM 9)
1x D-Sub DE9 (COM 10)
Special Functions
Wat
chdog
1x Timer watc dog ( ardware
-
based, software
-
configurable)
1x Power supervisor ( ardware-based)
Displays / Control Elements
LEDs
1x Power
1x System status (programmable)
1x LAN LED for Et ernet interface
Electrical Characteristics
Power supply
ran
ge
12 .. 2
4
VDC
±10%
from external power supply
Power consumption
<
7
W
Mechanical Characteristics
Protection class
IP20 industrial case for 35 mm DIN
-
rail mounting
Mass
<
2
1
0 g
Dimensions
112 mm x 100 mm x
4
5 mm
Operating temperature
0 .. 60 °C
Sto
rage temperature
-
40 .. 85 °C
Standards and Certifications
EM
CE
Environmental
standards
RoHS, WEEE

Remote Access Gateway IGW/910 – Hardware Reference
6
Document Revision 1.0
2 OVERVIEW
Figure 2: Overview Remote Access Gateway IGW/910

Remote Access Gateway IGW/910 – Hardware Reference
Document Revision 1.0
7
3 PINOUTS
3.1 Ethernet Interface
Pin
Name
Function
1
TX+
10/100 Mbps LAN, TX+
2
TX
-
10/100 Mbps LAN, TX
-
3
RX+
10/100 Mbps LAN, RX+
4
---
Bob
-
Smit Termination
5
---
Bob
-
Smit Termination
6
RX
-
10/100 Mbps LAN, RX
-
7
---
Bob
-
Smit Termination
8
---
Bob
-
Smit Termination
Table 2: Pinout Ethernet interface
LED
Function
Green (top)
10/100BASE
-
T link/activity
Yellow (bottom)
Not Co
n
nected
Table 3: Ethernet LED functions
3.2 Screw Terminals
Terminal
Function
A1
Debug Port
TXD
A2
Debug Port
RXD
A3
Vin
12..
2
4 VDC ±10%
A4
Ground
Table 4: Pinout screw terminals
T e debug port allows to access t e DIL/NetPC DNP/9535 wit a serial console.

Remote Access Gateway IGW/910 – Hardware Reference
8
Document Revision 1.0
3.3 COM Ports 1..8 (D-Sub DB25 male)
Pin
Name
Function
1
GND
Ground
14
R
XD1
COM1
Serial Port: RS
232
R
X
D
2
T
XD
1
COM
1
Serial Port: RS
232
T
X
D
15
GND
Ground
3
RXD2
COM2
Serial Port: RS
232 R
X
D
16
TXD2
COM2
Serial Port: RS
232 T
X
D
4
GND
Ground
17
RXD3
COM3
Serial Port: RS
232 R
X
D
5
TXD3
COM3
Serial Port: RS
232 T
X
D
18
GND
Ground
6
RXD4
COM4
Serial Port: RS
232 R
X
D
19
TXD4
COM4
Serial Port: RS
232 T
X
D
7
GND
Ground
20
RXD5
COM5
Serial Port: RS
232
R
X
D
8
TXD5
COM5
Serial Port: RS
232 T
X
D
21
GND
Ground
9
RXD6
COM6
Serial Port: RS
232 R
X
D
22
TXD6
COM6
Serial Port: RS
232 T
X
D
10
GND
Ground
23
RXD7
COM7
Serial Port: RS
232 R
X
D
11
TXD7
COM7
Serial Port: RS
232 T
X
D
24
GND
Ground
12
RXD8
COM8
Serial Por
t: RS
232 R
X
D
25
TXD8
COM8
Serial Port: RS
232 T
X
D
13
---
Not connected
Table 5: Pinout OM Ports 1..8

Remote Access Gateway IGW/910 – Hardware Reference
Document Revision 1.0
9
3.4 COM Port 9 (D-Sub DE9 male)
Pin
Name
Function
1
---
Not connected
2
RXD
9
COM
9
Serial Port: RS
232
RX
D
3
TXD
9
COM
9
Serial Port: RS
232 T
X
D
4
---
Not conn
ected
5
GND
Ground
6
---
Not connected
7
---
Not connected
8
---
Not connected
9
---
Not connected
Table 6: Pinout OM Port 9
3.5 COM Port 10 (D-Sub DE9 male)
Pin
Name
Function
1
---
Not connected
2
RXD10
COM10
Serial Port: RS
232
RX
D
3
TXD10
COM10
Serial Por
t: RS
232 T
X
D
4
---
Not connected
5
GND
Ground
6
---
Not connected
7
---
Not connected
8
---
Not connected
9
---
Not connected
Table 7: Pinout OM Port 10

Remote Access Gateway IGW/910 – Hardware Reference
10
Document Revision 1.0
4 LINUX DEVICE MAP
T is table s ows w ic Linux device name is assigned to w ic interface of t e IGW/910.
Interface Name
Linux Device
Name
Note
LAN 1 eth0
Debug Port ttyS0
Linux console for debug, RS232 on DNP
COM 1 ttyUSB0
Serial port on quad UART 1
COM 2 ttyUSB1
Serial port on quad UART 1
COM 3 ttyUSB2
Serial port on quad UART 1
COM 4 ttyUSB3
S
erial port on quad UART 1
COM 5 ttyUSB4
Serial port on quad
UART 2
COM 6 ttyUSB5
Serial port on quad
UART 2
COM 7 ttyUSB6
Serial port on quad
UART 2
COM 8 ttyUSB7
Serial port on quad
UART 2
COM 9 ttyUSB8
Serial port on quad
UART 3
COM 10 ttyUSB9
Seri
al port on quad
UART 3
Table 8: Linux device map

Remote Access Gateway IGW/910 – Hardware Reference
Document Revision 1.0
11
5 HELPFUL LITERATURE
•DNP/9535 ardware reference
•SSV Web ConfigTool User Manual
CONTACT
SSV Software Systems GmbH
Dünenweg 5
D-30419 Hannover
P one: +49 (0)511/40 000-0
Fax: [phone]
E-mail: [email protected]
Internet: www.ssv-embedded.de
Forum: www.ssv-comm.de/forum
DOCUMENT HISTORY
Revision
Date
Remarks
Name
Review
1.0 2019-12-11 First version WBU FKI
T e content of t is document can c ange any time wit out an
nouncement. T ere is taken over no guaran-
tee for t e accuracy of t e statements. T e user assumes t e en
tire risk as to t e accuracy and t e use of
t is document. Information in t is document is provided ‘as is’ wit out warranty of any kin
d. Some names
wit in t is document can be trademarks of t eir respective olders.
© 2019 SSV SOFTWARE SYSTEMS GmbH. All rights reserved.
