ST X-NUCLEO-EEPRMA1 User manual

Getting started with the X-NUCLEO-EEPRMA1 standard I²C and SPI EEPROM
memory expansion board based on M24xx and M95xx series for STM32 Nucleo
Introduction
The X-NUCLEO-EEPRMA1 expansion board is designed for M24xx I²C and M95xx SPI EEPROM for data reading and writing.
The expansion board acts as an external storage device that can be used to store data such as manufacturing traceability,
calibration, user setting, error flags, data log and monitoring data to make applications more flexible and accurate.
The X-NUCLEO-EEPRMA1 expansion board is compatible with the Arduino UNO R3 connector pin assignment and can be
easily plugged to any STM32 Nucleo development board. You can mount the ST morpho connectors if required.
Figure 1. X-NUCLEO-EEPRMA1 expansion board
UM2480
User manual
UM2480 - Rev 1 - October 2018
For further information contact your local STMicroelectronics sales office.
www.st.com

1Acronyms and abbreviations
Table 1. List of acronyms
Acronym Description
EEPROM Electrically erasable programmable read only memory
MHz Mega Hertz
MCU Microcontroller unit
SPI Serial peripheral interface
I2C Inter-integrated circuit
UM2480
Acronyms and abbreviations
UM2480 - Rev 1 page 2/22

2Getting started
2.1 Overview
The X-NUCLEO-EEPRMA1 main features are:
•Easy portability across different MCU families
• Equipped with Arduino™ UNO R3 connector
• Compatible with STM32 Nucleo boards
• Free comprehensive development firmware library and sample implementation available when the X-
NUCLEO-EEPRMA1 expansion board is plugged on top of a NUCLEO-F401RE or NUCLEO-L053R8
development board
• Developer can choose and solder an EEPROM to be tested using the evaluation software provided
• RoHS and WEEE compliant
2.2 Typical applications
The X-NUCLEO-EEPRMA1 expansion board acts as an external storage device that can be used for storing data
such as manufacturing traceability, calibration data, user setting, error flags, data log and monitoring data to make
applications more flexible and accurate.
2.3 Hardware requirements
To use STM32 Nucleo development boards with the X-NUCLEO-EEPRMA1 expansion board, connect the boards
as shown below.
Figure 2. X-NUCLEO-EEPRMA1 expansion board connected to an STM32 Nucleo development board
The EEPROM communicates with the STM32 Nucleo development board host microcontroller through the SPI or
I²C signals available on the Arduino UNO R3 connector.
The X-NUCLEO-EEPRMA1 has been designed to allow using any STM32 Nucleo board, although complete
testing has been performed using the NUCLEO-F401RE and NUCLEO-L053R8 boards.
2.4 System requirements
To use the STM32 Nucleo boards with the X-NUCLEO-EEPRMA1 expansion board you need:
•a Windows PC/laptop (Windows 7 or above) to install the firmware package (X-CUBE-EEPRMA1)
• a type A to Mini-B USB cable to connect the STM32 Nucleo board to the PC
UM2480
Getting started
UM2480 - Rev 1 page 3/22

• an STM32 Nucleo development board (NUCLEO-F401RE or NUCLEO-L053R8)
• an X-NUCLEO-EEPRMA1 expansion board
2.5 Board setup
Step 1. Check the jumper on J1 and J2 connectors are connected.
These jumpers provide the required voltage to the devices.
Step 2. Ensure jumper on J11 is put between VCC and WPn.
Step 3. Ensure jumper on J10 is put between U7_Sn and CN5_3_U7_Sn.
Step 4. Connect the X-NUCLEO-EEPRMA1 to the STM32 Nucleo board as shown in Figure 2. X-NUCLEO-
EEPRMA1 expansion board connected to an STM32 Nucleo development board.
Step 5. Power the STM32 Nucleo development board using the Mini-B USB cable.
Step 6. Program the firmware in the development board.
Step 7. Reset the MCU board using the reset button on the STM32 Nucleo development board.
The evaluation kit is ready-to-use.
UM2480
Board setup
UM2480 - Rev 1 page 4/22

3Hardware description and configuration
3.1 Interconnection details
The X-NUCLEO-EEPRMA1 expansion board and the NUCLEO-L053R8 or NUCLEO-F401RE board connection
details are listed in the tables below.
Table 2. X-NUCLEO-EEPRMA1 and NUCLEO-L053R8 connection details (left connector)
Signal name
NC IOREF RESET 3V3 5V GND GND VIN A0 A1 A2 A3 A4 A5
Connector name
CN6 Power CN8 Analog
Pin number
1 2 3 4 5 6 7 8 1 2 3 4 5 6
NUCLEO-L053R8 MCU port
NRST PA0 PA1 PA4 PB0 PC1/PB9 PC0/PB8
NUCLEO-L053R8 MCU signals
3.3 V
REF RESET
3.3 V
input/
output
5 V
output GND GND POWER INPUT ADC_IN0 ADC_IN1 ADC_IN4 ADC_IN8
ADC_IN11(PC1)
or
I2C1_SDA(PB9)
ADC_IN10(PC0)
or
I2C1_SCL(PB8)
X-NUCLEO-EEPRMA1 expansion board signals
NC 3V3 GND GND M95_WPn M24_VCC M95_Hn U8_Sn
UM2480
Hardware description and configuration
UM2480 - Rev 1 page 5/22

Table 3. X-NUCLEO-EEPRMA1 and NUCLEO-L053R8 connection details (right connector)
Signal name
D15 D14 AREF GND D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Connector name
CN5 Digital CN9 Digital
Pin number
10 9 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1
NUCLEO-L053R8 MCU port
PB8 PB9 PA5 PA6 PA7 PB6 PC7 PA9 PA8 PB10 PB4 PB5 PB3 PA10 PA2 PA3
NUCLEO-L053R8 MCU signals
I2C_SCL
I2C_SDA
AVDD
GND
SPI1_SCK
SPI1_MISO
TIM12_CH2 SPI1_MOSI
SPI1_CS
TIM12_CH2
TIM2_CH3
TIM12_CH1
TIM2_CH2
USART2_TX
USART2_RX
X-NUCLEO-EEPRMA1 shield signals
M24_I2C_SCL
M24_I2C_SDA
GND
M95_SCLK
M95_MISO
M95_MOSI
CN5_3_U7_Sn
U6_Sn U5_Sn
Table 4. X-NUCLEO-EEPRMA1 and NUCLEO-F401RE connection details (left connector)
Signal name
NC IOREF RESET 3V3 5V GND GND VIN A0 A1 A2 A3 A4 A5
Connector name
CN6 Power CN8 Analog
Pin number
1 2 3 4 5 6 7 8 1 2 3 4 5 6
NUCLEO-F401RE MCU port
NRST PA0 PA1 PA4 PB0 PC1 PC0
NUCLEO-F401RE MCU signals
3.3 V
REF RESET
3.3 V
input/
output
5 V
output GND GND POWER INPUT ADC1_0 ADC1_1 ADC1_4 ADC1_8
ADC1_11(PC1)
or
I2C1_SDA(PB9)
ADC1_10(PC0)
or
I2C1_SCL(PB8)
X-NUCLEO-EEPRMA1 expansion board signals
NC 3V3 GND GND M95_WPn M24_VCC M95_Hn U8_Sn
UM2480
Interconnection details
UM2480 - Rev 1 page 6/22

Table 5. X-NUCLEO-EEPRMA1 and NUCLEO-F401RE connection details (right connector)
Signal name
D15 D14 AREF GND D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Connector name
CN5 Digital CN9 Digital
Pin number
10 9 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1
NUCLEO-F401RE MCU port
PB8 PB9 PA5 PA6 PA7 PB6 PC7 PA9 PA8 PB10 PB4 PB5 PB3 PA10 PA2 PA3
NUCLEO-F401RE MCU signals
I2C1_SCL
I2C1_SDA
AVDD
GND
SPI1_SCK
SPI1_MISO
TIM1_CH1N SPI1_MOSI
TIM4_CH4 SPI1_CS
TIM3_CH2 TIM2_CH3 TIM3_CH1 TIM2_CH2
USART2_TX
USART2_RX
X-NUCLEO-EEPRMA1 shield signals
M24_I2C_SCL
M24_I2C_SDA
GND
M95_SCLK
M95_MISO
M95_MOSI
CN5_3_U7_Sn
U6_Sn U5_Sn
3.2 Current measurement
J1 can be used to monitor the I²C device power consumption, whereas J2 can be used to monitor the SPI device
power consumption. Connect an ammeter probe between the connector pin 1 and pin 2 for measurements.
UM2480
Current measurement
UM2480 - Rev 1 page 7/22

3.3 X-NUCLEO-EEPRMA1 component placement details
Figure 3. X-NUCLEO-EEPRMA1 component placement details
Figure 4. X-NUCLEO-EEPRMA1 top view layout
UM2480
X-NUCLEO-EEPRMA1 component placement details
UM2480 - Rev 1 page 8/22

Figure 5. X-NUCLEO-EEPRMA1 bottom view layout
UM2480
X-NUCLEO-EEPRMA1 component placement details
UM2480 - Rev 1 page 9/22

4Component description
4.1 M24XX
Table 6. M24C02 details
Feature Description
Sales type M24C02-FMC6TG
Package UFDFPN8
Single supply voltage 1.7 to 5.5 V (full temperature range) and 1.6 to 1.7 V (limited temperature range)
Table 7. M24256 details
Feature Description
Sales type M24256-DFDW6TP
Package TSSOP8
Single supply voltage and high speed 1 MHz clock from 1.7 to 5.5 V
Table 8. M24M01 details
Feature Description
Sales type M24M01-DFMN6TP
Package SO8
Single supply voltage and high speed 1 MHz clock from 1.7 to 5.5 V
4.2 M95XX
Table 9. M95040 details
Feature Description
Sales type M95040-RMC6TG
Package UFDFPN8
Single supply voltage 1.7 to 5.5 V
Table 10. M95256 details
Feature Description
Sales type M95256-DFDW6TP
Package TSSOP8
Single supply voltage 1.7 to 5.5 V
UM2480
Component description
UM2480 - Rev 1 page 10/22

Table 11. M95M01 details
Feature Description
Sales type M95M01-DFMN6TP
Package SO8
Single supply voltage 1.7 to 5.5 V
UM2480
M95XX
UM2480 - Rev 1 page 11/22

5External EEPROMs
You can easily solder a specific EEPROM density I²C or SPI to be used with the X-NUCLEO-EEPRMA1
expansion board. The software can handle any density between 2 Kbit and 1 Mbit.
To use the external EEPROM, you have to apply some changes to the firmware and the hardware, as described
below.
Step 1. Uncomment the macro M24XX (to use the I²C EEPROM) or M95XX (to use the SPI EEPROM) in the
“eeprom_expansion.h” file
Step 2. Comment the macro I²C (to use the external I²C EEPROM) or the macro SPI (to use the external SPI
EEPROM).
Step 3. Open J5 and J6 3V3 and VCC pins and short the EXT and VCC pins
Note: External VCC can be used to power EEPROM with a different VCC for specific evaluations.
Figure 6. I2C and SPI EEPROM soldered on the X-NUCLEO-EEPRMA1 expansion board
UM2480
External EEPROMs
UM2480 - Rev 1 page 12/22

6Bill of materials
Table 12. X-NUCLEO-EEPRMA1 bill of materials
Item Q.ty Ref. Part / Value Description Manufacturer Order code
1 1 U1 2 KBIT 400 KHZ
UFDFPN8
2-Kbit serial I²C bus
EEPROM ST M24C02-FMC6TG
2 1 U2 256 KBIT 1 MHZ
TSSOP8
256-Kbit serial I²C
bus EEPROM ST M24256-DFDW6TP
3 1 U3 1 MBIT 1 MHZ
SO8
1-Mbit serial I²C bus
EEPROM ST M24M01-DFMN6TP
4 1 U5 4 KBIT 5 MHZ
UFDFPN8
4-Kbit SPI bus
EEPROM with high-
speed clock
ST M95040-RMC6TG
5 1 U6 256 KBIT 20 MHZ
TSSOP8
256-Kbit serial SPI
bus EEPROM with
high speed clock
ST M95256-DFDW6TP
6 1 U7 1 MBIT 16 MHZ
SO8
1-Mbit SPI bus
EEPROM with high-
speed clock
ST M95M01-DFMN6TP
7 2 U4, U8 SO8 Not mounted Any
8 1 U9 UFDFPN5 Not mounted Any
9 1 U10 WLCSP Not mounted Any
8 1 CN5
10 pin female-male
strip, 2.54 mm
pitch
Header Samtec ESQ-110-24-T-S
9 2 CN6, CN9
8 pin female-male
strip, 2.54 mm
pitch
Header Samtec ESQ-108-24-T-S
10 2 CN7, CN10 19x2 through hole,
2.54 mm pitch Header Samtec ESQ-119-24-T-S
11 1 CN8
6 pin female-male
strip, 2.54 mm
pitch
Header Samtec ESQ-108-24-T-S
12 8
C1, C2, C3,
C4, C5, C6,
C7, C9
100 nF 25 V ±10%
X7R SMD0603 Ceramic capacitor Murata GRM188R71E104KA01D
13 2 J1, J2 2 pin male strip Jumpers Any
14 1 J4 5 pin male strip Jumpers Any
15 4 J5, J6, J10,
J11 3 pin male strip Jumpers Any
16 1 J7 open - 2 pin male
strip Jumpers Any
17 1 J9 4 pin male strip Jumpers Any
18 1 J8 6 pin male strip Jumpers Any
19 5 R1, R2, R8,
R9, R35
10 K ±5% 1/10 W
SMD0603 Resistors Panasonic ERJ-3GEYJ103V
20 2 R5, R6 3.3 K ±5% 1/10 W
SMD0603 Resistors Yageo RC0603JR-073K3L
21 1 R37 1 kohm ±5% 1/10
W SMD0603 Resistors Panasonic ERJ-3GEYJ102V
UM2480
Bill of materials
UM2480 - Rev 1 page 13/22

Item Q.ty Ref. Part / Value Description Manufacturer Order code
22 4 R22, R32,
R33, R34
10 K ±5% 1/10 W
SMD0402 Resistors Panasonic ERJ-2GEJ103X
23 8
S1, S2, S3,
S4, S5, S6,
S7, S20
CLOSE Solder bridge Any
24 2 S11, S15 OPEN Solder bridge Any
25 2 S10, S13 OPEN Solder bridge Any
UM2480
Bill of materials
UM2480 - Rev 1 page 14/22

7Schematic diagrams
Figure 7. X-NUCLEO-EEPRMA1 circuit schematic (1 of 4)
M95_MOSI
C2
D
3
4V
W
SS 5
J11
M95M01-DFMN6TP
M95_VCC
U6
10K
M95_VCC
3V3
U8_EXT_SUPPLY
A3
J6
100nF
3
4V
W
SSD 5
10K
M95_SCLK
CON3
10K
U6_Sn
C6
3V3
2
9
Ex.PAD
M95_Hn
M95_MISO
M95_SCLK
C6
1
2
3
J4
HOLD
VCC 8
M95_Hn
U9
EEPROM_WLCSP
M95_VCC
7
HOLD
M95_WPn
U8_VCC
A1
M95_SCLK
CON5
7
HOLD
U5_Sn
M95_Hn
M95_VCC
FOR CURRENT MEASUREMENT
R1
CON3
Q
2
C1
C5
U10
VCC 8
7
M95_VCC
M95_MISO
CN5_3_U7_Sn
U8_Sn
E15
2
4
1
2
3
4
M95_Hn
U8_VCC
10K
M95256-DFDW6TP
S
1
1
2
3
M95_VCC
CON3
10K
R34
100nF
M95_MISO
EEPROM_UFDFPN5
U8_VCC
(4Kb, DFN8 )
(256Kb, TSSOP)
(1Mb, SO8N)
EEPROM_SPI_SO8N
U8_VCC
M95_VCC
R2
M95_VCC
M95_VCC
M95_VCC
M95_WPn
C3
J10
1
2S
Q
S
1
B2
R22
10K M95_MOSI
1
2
3
4
5
C6
M95_VCC
U8
M95_MOSI
M95_MISO
2
3Q
W
VSS
4
R8
U7
R9
HOLD
8
VCC
M95_MISO
D5
C3
C6
10K
C6
M95040-RMC6TG
3
4V
W
SSD 5
100nF
10K
1
2S
Q
M95_SCLK
U5
U7_Sn
M95_WPn J9
M95_WPn
U8_Sn
1
D2
10K M95_VCC
1
2
3
M95_Hn
1
2
3
7
M95_MOSI
R33
R35
M95_WPn
E3
M95_WPn
R32
100nF
J2
M95_VCC
M95_MOSI
U7_Sn
8
VCC
M95_SCLK
UM2480
Schematic diagrams
UM2480 - Rev 1 page 15/22

Figure 8. X-NUCLEO-EEPRMA1 circuit schematic (2 of 4)
M24_I2C_SCL
M24_WC
WC 7
9
Ex.PAD
M24_VCC
U1
1
(2Kb, DFN8 )
(256Kb, TSSOP)
(1Mb, SO8N)
EEPROM_I2C_SO8N
FOR CURRENT MEASUREMENT
3V3
M24_WC
M24_WC
100nF
M24_VCC
1K R37
M24_WC
U3
M24_WC
5
3
OPEN
5
VSSSDA
SCL 6
2
3.3K
M24_VCC
C7
M24_I2C_SDA
VSSSDA
SCL 6
M24_I2C_SDA
M24_I2C_SCL
3V3
VSS SDA
6
SCL
M24_I2C_SCL
M24_I2C_SDA
E1
2
U4
JJ11
R5
U2
4
M24M01-DFMN6TP
M24_VCC
5
M24_VCC
E0
1
M24_WC
5
JJ88
C4
M24256-DFDW6TP
R6
J5
M24_VCC
U4_VCC
M24C02-FMC6TG
1
U4_VCC
U4_EXT_SUPPLY
3.3K
2
3E
E
1
2
4
1
2
3
4
5
6
VCC 8
100nF
M24_I2C_SCL
CON6
1
2E
E
0
1
E2
3
WC 7
WC 7
VCC 8
2
3E
E
1
2
4
CC11
M24_I2C_SCL
100nF
M24_I2C_SDA
VCC 8
4E
V
2
SSSDA
SCL 6
1
2
3
CON3
2
DU
1
J7
8
VCC
100nF
C9
M24_I2C_SCL
M24_I2C_SDA
M24_VCC
M24_I2C_SDA
U4_VCC
WC 7
M24_VCC
M24_VCC
E0
1
M24_VCC
M24_VCC
Figure 9. X-NUCLEO-EEPRMA1 circuit schematic (3 of 4)
21
27
38
25
2
4
6
8
1
12
24
30
3V3
5V
31
RESET
1817
A5
14
D1
D0
35
CN7
36
26
23
D8
1
3
5
7
9
AREF
D6
17
A0
16
A2
A3
D4
13
SCL
D2
Vin
29
1
3
5
7
9
11
30
32
34
12
29
20
21
13
15
D13
28
22
0
33
26
3V3
19
34
CN10
22
D10
D9
0
15
31
33
D12
D7
A4
28
D5
14
24
SDA
35
37
D3
A1
37
2
4
6
8
1
36
38
27
D11
16
18
23
25
32
20
11
19
UM2480
Schematic diagrams
UM2480 - Rev 1 page 16/22

Figure 10. X-NUCLEO-EEPRMA1 circuit schematic (4 of 4)
S15
2
D0
S1
S10
A3 4
3
S20
A5 6
D1
SCL
10
A5
TXD/D1
D2
3
CN8
A4
A2
S2
GND 7
S3
CLOSED
U8_Sn
M95_MISO
M95_Hn
AREF
9SDA
2
A4 5
U5_Sn
S13
D4
5
S7
GND 6
CLOSED
MOSI/PWM/D11
5
8
A0 D7
D6
M24_WC
S5
IOREF
AREF
A0 1
D3
4
CN6
VIN 8
MISO/D12
6
D12
D13
A1
A3
D8
S4
D9
D11
D6
7
CN5_3_U7_Sn
SCK/D13
GND
7
M24_I2C_SDA
RESET
M24_I2C_SCL
M95_MOSI
D5
6
A2 3
OPEN
D2
4
3V3
PWM/D10
4
D7
8
D8
1
5V
CN5
S6
RXD/D0
2
D3
A1 2
5V 5
M95_WPn
3V3
NC 1
Vin
M95_SCLK
D10
U6_Sn
S11
1
D5
D4
CN9
RESET
PWM/D9
3
OPEN
OPEN
OPEN
CLOSED
CLOSED
CLOSED
CLOSED
CLOSED
CLOSED
SCL
SDA
UM2480
Schematic diagrams
UM2480 - Rev 1 page 17/22

Revision history
Table 13. Document revision history
Date Revision Changes
04-Oct-2018 1 Initial release.
UM2480
UM2480 - Rev 1 page 18/22

Contents
1Acronyms and abbreviations ......................................................2
2Getting started ....................................................................3
2.1 Overview .....................................................................3
2.2 Typical applications.............................................................3
2.3 Hardware requirements .........................................................3
2.4 System requirements ...........................................................3
2.5 Board setup ...................................................................4
3Hardware description and configuration ...........................................5
3.1 Interconnection details ..........................................................5
3.2 Current measurement...........................................................7
3.3 X-NUCLEO-EEPRMA1 component placement details ................................7
4Component description...........................................................10
4.1 M24XX ......................................................................10
4.2 M95XX ......................................................................10
5External EEPROMs ...............................................................12
6Bill of materials...................................................................13
7Schematic diagrams ..............................................................15
Revision history .......................................................................18
UM2480
Contents
UM2480 - Rev 1 page 19/22

List of tables
Table 1. List of acronyms ....................................................................2
Table 2. X-NUCLEO-EEPRMA1 and NUCLEO-L053R8 connection details (left connector) .......................5
Table 3. X-NUCLEO-EEPRMA1 and NUCLEO-L053R8 connection details (right connector) ......................6
Table 4. X-NUCLEO-EEPRMA1 and NUCLEO-F401RE connection details (left connector) .......................6
Table 5. X-NUCLEO-EEPRMA1 and NUCLEO-F401RE connection details (right connector) ......................7
Table 6. M24C02 details .................................................................... 10
Table 7. M24256 details .................................................................... 10
Table 8. M24M01 details .................................................................... 10
Table 9. M95040 details .................................................................... 10
Table 10. M95256 details .................................................................... 10
Table 11. M95M01 details .................................................................... 11
Table 12. X-NUCLEO-EEPRMA1 bill of materials .................................................... 13
Table 13. Document revision history ............................................................. 18
UM2480
List of tables
UM2480 - Rev 1 page 20/22
