UM1915
User Manual
STM8AF Safety Manual
Introduction
The STM8A is a family of microcontrollers designed for automotive applications, with different
memory
densities, packages and peripherals.
This document describes how to use the STM8AF series of microcontrollers in the context of
a safety-related system (STM8A-SafeASIL functional safety package), specifying the user's
responsibilities for installation and operation, in order to reach the targeted
safety integrity
level.
This manual applies to the following STM8AF series:
The STM8AF62 line that is the mainstay of the automotive STM8A 8 bit MCU:
– The low density devices with 8 Kbytes of Flash memory:
STM8AF6223/26
– The medium density with 16 to 32 Kbytes of Flash memory
: STM8AF624x,
STM8AF6266/68, STM8AF612x/4x and STM8AF6166/68
– The high density devices with 32 to 128 Kbytes of Flash memory:
STM8AF6269/8x/Ax and STM8AF6178/99/9A
The STM8AF52 line: STM8AF automotive MCUs with CAN:
– The high density devices with 32 to 128 Kbytes of Flash memory: STM8AF52xx and
STM8AF51xx
If the STM8AF microcontrollers are used in adherence to this manual, the system designer
can avoid
going into the details of the functional safety design and validation, to give an
estimation about the impact to
the overall safety function.
This manual is written in compliance with ISO 26262. It also indicates how to use the
STM8AF MCUs in
the context of other functional safety standards such as IEC 61508. This
manual and FMEDA data were
developed in cooperation with the safety expertise company
YOGITECH, using their fault Robust
Methodology(fRMethodology).
The safety analysis summarized in this manual, takes into account the variation in terms of
memory size, number of internal peripherals and the different packages available among
the different part numbers of the STM8A microcontrollers family.
This manual has to be read along with the technical documentation on related part numbers
available on www.st.com/stm8.
www.st.com

Content UM1915
2/59 DocID028066 Rev 1
Content
1 About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Purpose and scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Reference normative . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Annexes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 STM8AFxxxx device development process . . . . . . . . . . . . . . . . . . . . . . 9
2.1 STMicroelectronics standard development process . . . . . . . . . . . . . . . . . . 9
2.2 YOGITECH fRMethodology process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 STM8AF Safety Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.1.1 Definition of the Safety Element out of Context . . . . . . . . . . . . . . . . . . . 10
3.2 STM8AF as a SEooC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.3 Assumed safety requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.3.1 The target safety metrics (ASIL, SPFM, LFM and PMHF) . . . . . . . . . . . 12
3.3.2 The assumed target time intervals (FTTI and MPFDI) . . . . . . . . . . . . . . 13
3.4 Electrical specifications and environment limits . . . . . . . . . . . . . . . . . . . . 14
3.5 Systematic safety integrity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.6 Safety mechanisms/measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.6.1 STM8A CORE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.6.2 Program FLASH memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.6.3 Data EEPROM memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.6.4 RAM memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.6.5 Boot ROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.6.6 Basic enhanced CAN (beCAN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.6.7 LINUART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.6.8 USART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.6.9 I2C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.6.10 SPI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3.6.11 Analog to Digital Converter (ADC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.6.12 Basic timer (TIM 4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.6.13 GPIO – PORT A/B/C/D/E/F/G/H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

DocID028066 Rev 1 3/59
UM1915 Content
4
3.6.14 Address and Data bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3.6.15 Supply voltage system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.6.16 Reset and Clock control subsystems . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.6.17 Auto-wakeup timer (AWU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.6.18 Watchdogs (IWDG, WWDG) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
3.6.19 Debug/ SWIM (single wire interface module) . . . . . . . . . . . . . . . . . . . . 29
3.6.20 Interrupt controller (NVIC and EXTI) . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.6.21 Latent fault detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.6.22 Disable and periodic cross-check of unintentional activation of unused
peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.7 Assumption of Use (AoU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3.7.1 List of Assumptions of Use (AoU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4 Safety Analysis Results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.1 Hardware random failure analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.1.1 Safety analysis result customization . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4.1.2 General requirements for Freedom From Interferences (FFI) . . . . . . . . 36
4.2 Dependent failures analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.2.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4.2.2 Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5 List of evidences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Appendix A Appendix A Overview of fRMethodology . . . . . . . . . . . . . . . . . . . . 40
A.1 The essence of fRMethodology. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
A.2 fRMethodology and its flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
A.3 fRTools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Appendix B Appendix B Change impact analysis for other safety standards . 44
B.1 IEC 60730-1:2010 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
B.2 Architectural categories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
B.3 Safety metrics recomputation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
B.4 Work products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
B.5 IEC 61508 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.6 Architectural categories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
B.7 Safety metrics re-computation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Content UM1915
4/59 DocID028066 Rev 1
B.8 Work products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

DocID028066 Rev 1 5/59
UM1915 List of Tables
5
List of Tables
Table 1. Terms and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Table 2. List of STM8AF Assumed Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table 3. Target safety metric values at the item level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Table 4. List of safety mechanisms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table 5. List of general requirements for FFI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Table 6. Level of detail in fRMethodology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table 7. IEC 60730 required safety mechanism for Class B/C compliance. . . . . . . . . . . . . . . . . . . 46
Table 8. IEC 60730 work product grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Table 9. Some reference architectures for IEC 61508. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Table 10. Mapping between this document content and IEC 61508-2 Annex D
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Table 11. IEC 61508 work product grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Table 12. Document revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

List of Figures UM1915
6/59 DocID028066 Rev 1
List of Figures
Figure 1. Definition of the STM8AF as a SEooC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Figure 2. Relationship between assumptions and SEooC development . . . . . . . . . . . . . . . . . . . . . . 11
Figure 3. STM8AF FTTI allocation and cycle time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 4. The fRMethodology flow for ISO 26262 and IEC 61508. . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Figure 5. Overview of the YOGITECH fRTool suite. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Figure 6. Correlation matrix between SIL and ASIL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

DocID028066 Rev 1 7/59
UM1915 About this document
58
1 About this document
1.1 Purpose and scope
This document describes how to use the STM8AF microcontrollers in the context of a 
safety-related system, specifying the user's responsibilities for installation and operation, in
order to reach the desired safety integrity level.
This document is useful to system designers willing evaluate the safety of their solution.
1.2 Terms and abbreviations
Table 1. Terms and abbreviations
Acronym Definition
AoU Assumptions to Use
ASIL Automotive Safety Integrity Level
CCF Common Cause Failure
COTS Commercial Off-the-Shelf
CPU Central Processing Unit
CRC Cyclic Redundancy Check
DC Diagnostic Coverage
DTI Diagnostic Test Interval
FIT Failure In Time
FTTI Fault Tolerant Time Interval
FMEA Failure Mode Effect Analysis
FMEDA Failure Mode Effect Diagnostic Analysis
HFT Hardware Fault Tolerance
HW Hardware
INTC Interrupt Controller
LFM Latent Fault Metric
MCU Microcontroller Unit
MPF Multiple Point Failures
MPFDI Multiple Point Fault Detection Interval
NVIC Nested vector interrupt controller
PMHF Probabilistic Metric for random Hardware Failures
QM Quality Management
SFF Safe Failure Fraction
SIL Safety Integrity level
SEooC Safety Element Out of Context
SPF Single Point Fault

About this document UM1915
8/59 DocID028066 Rev 1
1.3 Reference normative
This document is written in compliance with the ISO 26262 international standard for
functional safety of electrical and/or electronic (E/E) systems within road vehicles.
The versions used as reference are:
ISO/IS 26262-1 – 9 :2011(E)
ISO/IS 26262-10:2012(E)
This Safety Manual follows the list of recommended contents in Annex A, clause A.3.10 of
ISO 26262-10.
The other functional safety standards considered in this manual are the following:
IEC 61508:1-7 © IEC:2010
IEC 60730-1:2010, ed. 4.0
1.4 Annexes
Annex 1. “STM8AF FMEDA snapshot handling Application Note”:
it provides clarifications, guidelines and examples on how to handle the Failure Mode
Effect Diagnostic Analysis (FMEDA) outcomes related to STM8AF microcontroller
family
Annex 2. “STM8AF FMEDA snapshot”:
it summarizes the common results of FMEDA activities
it provides all the necessary information, which will allow the reader to understand
how
to combine different scenarios, by using the FMEDA outcomes and to evaluate
the
costs and benefits at system-level.
SPFM Single Point Fault Metric
SW Software
Table 1. Terms and abbreviations (continued)
Acronym Definition

DocID028066 Rev 1 9/59
UM1915 STM8AFxxxx device development process
58
2 STM8AFxxxx device development process
The development process of a microelectronic device that is used in safety critical
application, takes into account the adequate management, to reduce the probability of
systematic faults, introduced during the design phase.
ISO 26262-10 Annex A (“A.3.7: Example of techniques or measures to detect or avoid
systematic failures during design of a microcontroller”) acts as a guidance in tailoring the
microcontroller standard design and manufacturer process to the compliance of the ISO
26262 requirements. The checklist reported in the named Annex A (Table A.8) helps to
collect all related evidences of a given real process.
2.1 STMicroelectronics standard development process
STMicroelectronics (ST) serves four industry domains:
Standard products
Automotive products: ST automotive products are AEC-Q100 compliant. They are
submitted to a specific stress testing activity and processing instructions, in order to
achieve the
required quality levels and product stability
Automotive safety: a subset of the automotive domain. ST uses, as a reference, the
ISO 26262 Road vehicles functional safety standard. ST supports customers’ inquiries,
regarding product failure rates and FMEDA, to support hardware system compliance to
established safety goals. ST provides products that are safe in their intended use,
working in cooperation with customers, to understand the mission profile, adopt
common methods and define countermeasures for residual risks
Medical products: ST complies with applicable regulations for medical products and
applies due diligence in the development and validation of these products
STMicroelectronics product development process, compliant with the ISO/TS 16949
standard, is a set of interrelated activities dedicated to transform a customer specification
and a market or industry domain requirements into a semiconductor device with all its
associated elements (package, module, sub-system, application, hardware, software and
documentation), qualified respecting ST internal procedures and able to be manufactured,
using ST internal or subcontracted technologies.
2.2 YOGITECH fRMethodology process
YOGITECH fRMethodology is the “white-box” approach for safety design exploration. It is
proprietary of YOGITECH, including tools and methodology for FMEA/FTA analysis and
fault injection of integrated circuits. Appendix A Overview of fRMethodology reports
additional information.
YOGITECH contribution to ISO 26262 compliance of STMicroelectronics development
process can be summarized in failure rate estimation, based on multiple industry standards
as well as STMicroelectronics manufacturing data.

STM8AF Safety Architecture UM1915
10/59 DocID028066 Rev 1
3 STM8AF Safety Architecture
This section describes the safety architectures that could be implemented, using the
STM8AF microcontroller for automotive applications.
3.1 Introduction
The STM8AF microcontroller described in this document is a Safety Element out of Context
(SEooC), that is, a safety element that can be used in different safety applications.
The aim of this section is to define the context of the analysis, in terms of assumptions with
respect to reference safety requirements as well as assumptions with respect to the design
external to that SEooC.
As a consequence of the SEooC approach, the goal is not to provide an exhaustive hazard
and risk analysis of the system around the microcontroller, but rather to list the 
system-related information (such as the application-related assumptions for dangerousness
factors, frequency of failures and diagnostic coverage already guaranteed by the
application), that have been considered during the consecutive steps of the analysis.
3.1.1 Definition of the Safety Element out of Context
The automotive industry develops generic elements for different applications and for
different customers. These generic elements can be developed concurrently and by
different companies in different tiers of the supply chain, as a distributed development.
Assumptions are made both on the requirements (including safety requirements) on the
element at higher levels of design and also on the design external to the element.
In a safety context, these elements can be developed as a “Safety Element out of Context”
(SEooC), as described in ISO 26262-10, Clause 9.
According to ISO 26262, a “safety element out of context (SEooC)” is a safety-related
element that is not developed for a specific item (i.e. in the context of a particular vehicle). A
SEooC can be a system, an array of systems, a subsystem, a software component or a
hardware component.
This document considers the STM8AF as a SEooC, which is required to have an ASIL
capability, up to and including ASIL level B (i.e. it is to be used in an ASIL level A and ASIL
level B
environment).
3.2 STM8AF as a SEooC
The STM8AF is a general purpose RISC microcontroller, suitable for embedded applications
and, in particular, for safety related applications.
For a detailed description of the STM8AF functionality refers to the microcontroller technical
reference manual (RM0016).
In this document, the SEooC is identified as the STM8AF microcontroller (MCU),
references
as a functional block inserted in a system defined by the following Figure 1: Definition of the
STM8AF as a SEooC. The
MCU acts as the processing unit of the system, acquiring field
data from sensors,
processing according to the implemented algorithm and taking
