ST9 FAMILY
EVALUATION BOARD GETTING STARTED
1 OVERVIEW
The aim of this Evaluation Board is to provide the user with a ready-to-use hardware environ-
ment for ST9 general purpose microcontrollers. The kit contains the hardware required for
testing the principal peripherals, such as timers, SPI and SCI interfaces, A/D converters and I/
O Ports. This kit, however, does not cover CAN and J1850 devices, but a wire-wrap area,
available for connecting specific components, is included and can be used to connect CAN or
J1850 transceivers. If the same peripheral is present several times on the MCU (e.g. the multi-
function timer on the ST92F120/F124/F150/F250) the board may be used to test at least one
of them, but not always all of them.
1.1 HARDWARE
Two kitsare available: the ST9GP-EVAL and the ST92F150-EVAL. Three boards are included
in each kit. The motherboard contains the entire hardware environment.
The ST90158 daughterboard (ST9GP-EVAL only) is used to support the ST90158 PQFP80
microcontroller or the ST90158 emulator with a PQFP80 connector (supplied with the Emula-
tor Kit).
The ST92F120 daughterboard is used to support the ST92F120/F124/F150/F250 PQFP100
microcontrollers or the ST92F120 and ST92F150 emulators with a PQFP100 connector (sup-
plied with the Emulator Kit).
The ST92F150-TQFP64 daughterboard (ST92F150-EVAL only) is used to support the
ST92F124/F150 TQFP64 microcontroller.
1

4/24
Table of Contents
24
1
1 OVERVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.1 Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
2 GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.1 Kit Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2 Motherboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2.1 Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
2.2.2 Reset Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.2.3 Connector Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.4 Push-button Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.5 Direct 7-segment Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2.6 Memories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2.2.7 I²C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.2.8 A/D Trimmer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2.9 SCI Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.3 ST90158 Daughterboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.3.1 I²C Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.3.2 Current Measurement and Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.3.3 Analog Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.3.4 Watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.3.5 I/O Port Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.4 ST92F120/F124/F150/F250 Daughter boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.4.1 Current Measurement and Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.4.2 Analog Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.4.3 Watchdog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.4.4 I/O Port Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
2.4.5 ISP Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
3 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.1 CONTINUOUS Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.2 Memory Malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
4 APPENDIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

5/24
EVALUATION BOARD GETTING STARTED
2 GETTING STARTED
2.1 KIT CHECKLIST
The ST9 Evaluation Board Kits contain the following material:
■Motherboard for the ST9 Evaluation Board
■ST90158-PQFP80 Daughterboard (ST9GP-EVAL only)
■ST92F120-PQFP100 Daughterboard
■ST92F150-TQFP64 Daughterboard (ST92F150-EVAL only)
■AD/DC Adaptor
■RS232 Serial Cable (male-male)
2.2 MOTHERBOARD
2.2.1 Power Supply
Carry out the following procedure to power-on the ST9 Evaluation Board:
– Connect the jack of the AC/DC adaptor to connector J3 on the motherboard. If the evaluation
board is being used with an emulator, the emulator should always be switched ON first, and
the motherboard afterwards. To switch OFF the evaluation board, first switch OFF the moth-
erboard, and the emulator afterwards.
The output voltage of the AC/DC adaptor is aproximately 12 V. A voltage regulator is used to
control the voltage supply to all board components. The voltage can be adjusted between 2.5
and 6 V. Each time the VCC value is changed, the voltage must be monitored to ensure that the
maximum supply voltage allowed for board components (5.5 V) is not exceeded. The 7-seg-
ment displays may not work properly if voltage VCC is less than 3.5 V. Refer to Section 2.2.5
"Direct 7-segment Display" to configure them correctly.
Memory Information
When using the board at low voltage, all board components will work, except for the memo-
ries. In order to use the board at low voltage, a memory that supports low voltages must be in-
stalled. Refer to Section 2.2.6 "Memories" for more information.

6/24
EVALUATION BOARD GETTING STARTED
Figure 1. Power Supply Diagram
2.2.2 Reset Circuit
A reset circuit located on the motherboard (R1, D1 and C2) is used to guarantee that the reset
pin is pulled LOW until the voltage supply is stabilized at the correct level. A push-button
switch (SW2) is provided to manually reset the device (MCU or emulator) being evaluated.
Figure 2. Reset Diagram
D5
SCHOTTKY
12
C13
10MF-CT-16V
C12
100NF
R8
10K-RV
R6
3K
J3
JACK
2
3
1
IO ADJ
U12
LM317T 3
1
2
Vcc
GND POWER
12V
Vcc
D1
1N4148
12
R1
10K
SW2
SW-PUSHBUTTON
5 4
2
1
3
C2
100NF
Reset

7/24
EVALUATION BOARD GETTING STARTED
2.2.3 Connector Layout
Most of the MCU pins can be monitored or controlled by using the connectors located on the
motherboard. Connectors are directlylinked to parallelI/O ports P0, P1, P4, P5, P6 and P7, as
well as to 3 other ports connected to PA, PB and PC. To know which port is connected to PA,
PB or PC, refer to Section 2.3.5 "I/O Port Connection". In addition, an 8-bit connector is avail-
able for specific signals such as RW, AS, DS, I²C data and clock SCI transmission and recep-
tion signals.
The schematic diagrams for all connectors are available in the appendix.
2.2.4 Push-button Switch
The motherboard has a push-button switch (SW1) thatcanbe used totogglean I/O pin, create
an interrupt, or wake up the microcontroller (wake up is not available on ST90158). The pin
that is controlled bythe push-button switch is selected by removing or placing jumpers on con-
nectors TP14, TP15 and TP16 as shown in Figure 3. "Switch 1 Configuration".
Figure 3. Switch 1 Configuration
2.2.5 Direct 7-segment Display
The 7-segment display can be use to show the I/O port configuration or to display the different
statements of the user application. The display is connected to I/O port 4. When the applica-
tion is running with a supply voltage of less than 3.5 V, a jumper should be installed in connec-
tor TP10 in order to increase the lighting level of the display. This jumper should be removed
whenever a supply voltage greater than 3.5 V is used.
A remote 7-segment display controlled via the I²C interface is also provided. Please refer to
Section 2.2.7 "I²C Interface".
