Ultrasonic Estimator
INSTRUCTION MANUAL
Lm
Wm
Hm
Volume
Area
Length
LL
HH
WW
ft
yds
SQ CU
m23
1
2
1
2
3

XXXX
XXXXX1.0 Battery:
2
XXXXXXX
LCD
Area/Volume
measurements
ft/in, yds or Meters
Add Measurements
"On" and distance
measurement
Clear display
Measurement
Zero point
Illustration 1
Lm
Wm
Hm
Volume
Area
Length
LL
HH
WW
ft
yds
SQ CU
m23
1
2
1
2
3

XXXX
XXXXX1.0 Battery:
3
XXXXXXX
Measurement mode indicator
ILLUSTRATION 2
Previous measurement(s)
Active measurement Units
Lm
Wm
Hm
Volume
Area
Length
LL
HH
WW
ft
yds
SQ CU
m23

XXXX
XXXXX1.0 Battery:
4
XXXXXXX
The STANLEY IntelliMeasure™ ultrasonic estimator is a
fast, convenient distance measuring tool. This tool
allows contractors, realtors, homeowners and appraisers
to make fast and easy estimates of distances, areas and
volumes in rooms at work or home. Multiple
measurements may be added to allow for overall
measurements of greater than 40 feet. Automatic
conversion between imperial and metric units of
measurement.
The IntelliMeasure™ ultrasonic estimator is intended for
fast, convenient measurements with a high degree of
accuracy. For precision measurements other measuring
instruments should be used.
The IntelliMeasure™ uses a 9 volt battery (not included)
which is inserted in the bottom of the unit. To install the
battery, remove the battery door from the bottom of the
case and attach the battery connector onto the 9 volt
battery. Reassemble the bottom to the case making sure
it snaps into place. When the battery needs replacement
the Low Battery indicator will appear in the LCD display.
1. For consistent readings hold IntelliMeasure™
perpendicular to and pointed toward the surface being
measured and press,release the "ON" button.
2. To change the units of measurement press the "Units"
button. The display will cycle through the units of
measurement. The reading will be converted with each
of measurement change.
The STANLEY IntelliMeasureTM ultrasonic estimator
with laser pointer combines a fast, convenient distance
measuring tool with a laser pointer which shows exactly
where the measurement is being taken. This tool allows
contractors, realtors, homeowners and appraisers to
make fast and easy estimates of distances, areas and
volumes in rooms at work or home. Multiple
measurements may be automatically added to allow for
overall measurements of greater than 50 feet.
Automatic conversion between imperial and metric units
of measurement. Area and volume are calculated with
the push of a single button.
The IntelliMeasureTM ultrasonic estimator is intended
for fast, convenient measurements with a high degree of
accuracy. For precision measurements other measuring
instruments should be used.
Operating Instructions
Battery Installation:
The IntelliMeasureTM uses a 9 volt battery which is
inserted in the bottom of the unit. To install the battery
remove the base (illustration 2) by pressing the side
buttons and pulling out the bottom of the case. Snap
the battery connector onto the 9 volt battery and
reassemble the bottom to the case making sure it snaps
into place. (illustration 2) When the battery needs
replacement the Low Battery indicator (illustration 3) will
appear in the LCD display.
Operating Controls and Display:
Taking Measurements:
1. For consistent readings hold IntelliMeasureTM
perpendicular to and pointed toward the surface being
measured and press /release "ON" button. Estimator
will display the units of measure (Metric / Imperial)
and where it is measuring from (top or bottom of the
case) showing what was last used. The display will
show ------ while measuring the distance and sound four
beeps after a good reading is taken. The laser pointer
will show where the estimator is pointed and is on only
while a reading is being taken.
Caution: Do not stare into Laser beam. Hold estimator
with beam above or below eye level.
2. To change the units of measurement or case top /
bottom measurement location press the "Mode" button.
With each press the display will cycle through the
display units of measurement and top / bottom
measurement location. The reading will be converted
with each units of measurement change and add /
subtract the case length to show the correct distance.
3. If after three attempts the estimator cannot determine
the correct distance i.e. greater than 50 feet, it will
display "ERROR" and shut off after several seconds.
4. When repeating the reading make certain that the
estimator is perpendicular to the surface,
Operating Instructions
1.0 Battery Installation:
2.0 Taking Measurements:

XXXX
XXXXX1.0 Battery:
5
XXXXXXX
Operating Instructions
1.0 Battery Installation:
2.0 Taking Measurements:
3. When repeating the reading make certain that the
estimator is perpendicular to the surface, the distance is
within its’ measuring range and that there are no
obstructions in the way like desks, chairs, half walls
or step ladders to reflect the sound waves.
Caution: Some types of surfaces such as curtains,
padded walls, furniture or carpeting may absorb the
ultrasonic sound waves instead of reflecting them,
making readings difficult to take. These surfaces or
irregular surfaces can also cause variations in
readings. Try taking readings from different angles or
positions to achieve consistent measurements.
4. The displayed reading will be shown for at least 1
minute before the estimator shuts off.
3.0 Addition of Measurements:
4.0 Area and Volume Functions:
If the distance to be measured is greater than 40 feet or
a series of measurements need to be added together the
Add feature can be used.
1. If the reading currently in the display is not to be
included in the added measurements press the "Clear"
button to zero the display.
2. Take the first measurement.
3. Press the "+" button.
4. Take additional reading as described in the Taking
Measurements Section.
5. The new measurement will be displayed along with
the previous.
6. Press the"+" button again to display the sum of the
previous measurements.
7. New measurements can continue to be added by
pressing the "+" button.
The area or volume can be quickly determined by the
following steps. Area and volume are only calculated
from current values of length, width and height and
are displayed in meters, feet or yards, not feet-inches.

XXXX
XXXXX1.0 Battery:
6
XXXXXXX
Operating Instructions
1.0 Battery Installation:
Caution: When repeating the reading make certain that
the estimator is perpendicular to the surface.
1. Press Area button once to display area indicator
(Illustration 2).
2. Press "Read" button to take first measurement.
3. Press "Read" button again to take second
measurement.
4. Calculated area will be shown on bottom of LCD.
5. Press area button twice to return to distance mode.
1. Press Volume button twice to display volume
indicator (Illustration 2).
2. Press "Read" button to take first measurement.
3. Press "Read" button again to take second
measurement.
4. Press "Read" button again to take third
measurement.
5. Calculated volume will be shown on bottom of
LCD.
6. Press volume button once to return to distance
mode.
4.1 Area:
4.2 Volume:
Specifications
Battery: 9 volt, alkaline recommended
Low battery indicator
Auto shutoff: 1 minute after last keystroke
Accuracy: ±0.5% of reading
Range: 2 to 40 feet
Measurement point: defined from bottom edge of
case
Calculates and displays, length, area and volume
Units of measure: Meters, Feet-Inch, Yards
Operating temperature range 10∞C to 49∞C

XXXX
XXXXX1.0 Battery:
7
XXXXXXX
The STANLEY IntelliMeasureTM ultrasonic estimator
with laser pointer combines a fast, convenient distance
measuring tool with a laser pointer which shows exactly
where the measurement is being taken. This tool allows
contractors, realtors, homeowners and appraisers to
make fast and easy estimates of distances, areas and
volumes in rooms at work or home. Multiple
measurements may be automatically added to allow for
overall measurements of greater than 50 feet.
Automatic conversion between imperial and metric units
of measurement. Area and volume are calculated with
the push of a single button.
The IntelliMeasureTM ultrasonic estimator is intended
for fast, convenient measurements with a high degree of
accuracy. For precision measurements other measuring
instruments should be used.
Operating Instructions
Battery Installation:
The IntelliMeasureTM uses a 9 volt battery which is
inserted in the bottom of the unit. To install the battery
remove the base (illustration 2) by pressing the side
buttons and pulling out the bottom of the case. Snap
the battery connector onto the 9 volt battery and
reassemble the bottom to the case making sure it snaps
into place. (illustration 2) When the battery needs
replacement the Low Battery indicator (illustration 3) will
appear in the LCD display.
Operating Controls and Display:
Taking Measurements:
1. For consistent readings hold IntelliMeasureTM
perpendicular to and pointed toward the surface being
measured and press /release "ON" button. Estimator
will display the units of measure (Metric / Imperial)
and where it is measuring from (top or bottom of the
case) showing what was last used. The display will
show ------ while measuring the distance and sound four
beeps after a good reading is taken. The laser pointer
will show where the estimator is pointed and is on only
while a reading is being taken.
Caution: Do not stare into Laser beam. Hold estimator
with beam above or below eye level.
2. To change the units of measurement or case top /
bottom measurement location press the "Mode" button.
With each press the display will cycle through the
display units of measurement and top / bottom
measurement location. The reading will be converted
with each units of measurement change and add /
subtract the case length to show the correct distance.
3. If after three attempts the estimator cannot determine
the correct distance i.e. greater than 50 feet, it will
display "ERROR" and shut off after several seconds.
4. When repeating the reading make certain that the
estimator is perpendicular to the surface,
Operating Instructions
1.0 Battery Installation:
The Stanley Works warrants the IntelliMeasure™ against
defects in material and workmanship for 1 year from the
date of purchase. Deficient products will be repaired or
replaced at Stanley’s discretion if sent to:
The Stanley Works
Customer Service Department
480 Myrtle Street
New Britain, CT 06053
Stanley’s liability under this warranty is limited to repair or
replacement of the unit. Any attempt to repair the product
by other than factory authorized personnel will void this
warranty. Calibration, batteries and maintenance are the
responsibility of the user. Where permitted by law,
Stanley is not responsible for incidental or consequential
damages. Agents of Stanley cannot change this warranty.
Stanley is not responsible for damage resulting from wear,
abuse or alteration of this product. The user is expected to
follow ALL operating instructions.
This warranty may provide you with additional rights that
vary by state, province or nation.
Warranty

XXXX
XXXXX1.0 Battery:
8
77- 018
XXXXXXX
The STANLEY IntelliMeasureTM ultrasonic estimator
with laser pointer combines a fast, convenient distance
measuring tool with a laser pointer which shows exactly
where the measurement is being taken. This tool allows
contractors, realtors, homeowners and appraisers to
make fast and easy estimates of distances, areas and
volumes in rooms at work or home. Multiple
measurements may be automatically added to allow for
overall measurements of greater than 50 feet.
Automatic conversion between imperial and metric units
of measurement. Area and volume are calculated with
the push of a single button.
The IntelliMeasureTM ultrasonic estimator is intended
for fast, convenient measurements with a high degree of
accuracy. For precision measurements other measuring
instruments should be used.
Operating Instructions
Battery Installation:
The IntelliMeasureTM uses a 9 volt battery which is
inserted in the bottom of the unit. To install the battery
remove the base (illustration 2) by pressing the side
buttons and pulling out the bottom of the case. Snap
the battery connector onto the 9 volt battery and
reassemble the bottom to the case making sure it snaps
into place. (illustration 2) When the battery needs
replacement the Low Battery indicator (illustration 3) will
appear in the LCD display.
Operating Controls and Display:
Taking Measurements:
1. For consistent readings hold IntelliMeasureTM
perpendicular to and pointed toward the surface being
measured and press /release "ON" button. Estimator
will display the units of measure (Metric / Imperial)
and where it is measuring from (top or bottom of the
case) showing what was last used. The display will
show ------ while measuring the distance and sound four
beeps after a good reading is taken. The laser pointer
will show where the estimator is pointed and is on only
while a reading is being taken.
Caution: Do not stare into Laser beam. Hold estimator
with beam above or below eye level.
2. To change the units of measurement or case top /
bottom measurement location press the "Mode" button.
With each press the display will cycle through the
display units of measurement and top / bottom
measurement location. The reading will be converted
with each units of measurement change and add /
subtract the case length to show the correct distance.
3. If after three attempts the estimator cannot determine
the correct distance i.e. greater than 50 feet, it will
display "ERROR" and shut off after several seconds.
4. When repeating the reading make certain that the
estimator is perpendicular to the surface,
Operating Instructions
1.0 Battery Installation:
WARNING: Protect Your Eyes, Wear Safety Goggles
ADVERTISSEMENT: Protégez vos yeux, portez des
lunettes de sécurité.
One Year Warranty
Garantie de un an
Garanía de un año
© 2004 Stanley Tools Product Group of
The Stanley Works, New Britain, T 5382
