Starkey Synergy Assembly instructions

QuickTIPS
USER CONTROLS
PRODUCT AVAILABILITY: Synergy Devices with User Controls
Launch Inspire X, then connect hearing devices. Refer to the Initial Fit
Protocol QuickTIPs for information on getting started.
The User Control Configuration demo box will appear upon first fit. Select
Show Demo for demonstration of user control configuration options,
or select Don't Show Again and Close. Select User Controls on the left
navigation bar to adjust user controls during subsequent programming.
USER CONTROL CONFIGURATION
1. Drag any user control you wish to enable from the left and drop it on
a gesture on the right. User control options include:
» Volume
» Memory
» Tinnitus
» Mute
» Balance Control (Muse iQ and Muse BiCROS devices only)
NOTE: An alert icon will appear if the tinnitus user control is enabled
but the tinnitus stimulus is disabled. Refer to the Tinnitus QuickTIP
for additional information.
Select gesture functionality. If fitting a device with a push button,
default gesture options include:
» Right increase, left decrease
» Right increase and decrease
» Left increase and decrease
»Sprinkler decrease
NOTE: Select Preferences, then General to display additional user
control options, if desired.
VOLUME CONTROL RANGE AND STEP SIZE
1. Select VC Range and Step Size, if volume control is enabled.
2. Select pins to adjust VC Range.
3. Select Step Size of 2dB or 4dB.
NOTE: Inspire software will not allow for adjustments to VC Range
and Step Size if volume control is not enabled in User Control
Settings.
User Controls
VC Range and Step Size

TINNITUS OUTPUT RANGE AND STEP SIZE
1. Select Tinnitus Output Range and Step Size, if tinnitus stimulus is
enabled. Refer to the Tinnitus QuickTIP for additional information.
2. Select pins to adjust stimulus level for Tinnitus Output Range.
3. Select Step Size of 2dB or 4dB.
NOTE: Inspire software will not allow for adjustments to Tinnitus
Output Range and Step Size if tinnitus control is not enabled in
User Control Settings.
© 2017 Starkey. All Rights Reserved. 4/17 MISC4727-00-EE-ST
Device Guide
Reset Levels on Memory Change
Tinnitus Range and Step Size
ADDITIONAL CONFIGURATION OPTIONS
1. Select VC Self Learning, then select Automatic to enable Self
Learning, if desired.
NOTE: Self Learning will only operate if a volume control
is enabled. It cannot be enabled at the same time as Auto
Experience Manager. Self Learning defaults OFF.
2. Reset Levels on Memory Change will default on, resetting
Volume, Tinnitus, and Balance (if applicable) on the hearing
devices to their preset levels when a memory change occurs. De-
select to disable this feature, if desired.
DEVICE GUIDE
1. Select Print in User Control Settings to print the Device Guide.
This generates a report with user control information specific to
the connected devices.
Self Learning: Will learn a patient's
volume control preferences and will
automatically make no greater than 2dB
changes at a time based on a patient's
adjustments over a 12 hour learning
period.
