StarTech.com USB110EXT2 User manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 05/09/2012
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1xUSB1.1LocalExtender
• 1xUSB1.1RemoteExtender
• 1xInstructionManual
System Requirements
• USBenabledhostsystemwithavailableUSBport
• SucientlengthofCategory5/5e/6UTPcabling
• Microsoft®Windows®2000/XP(32/64bit)/Server2003(32/64bit)/
Vista(32/64bit)/7(32/64bit)/Server2008R2/8(32/64bit)/
WindowsCE6.0,andApple®MacOSX®,andLinux®
Preparing Your Site
1. Determinewherethelocalhostsystem(i.e.computer)willbelocated.
2. DeterminewheretheremoteUSBperipheralwillbelocated.
3. Ifyouareusingsurfacecabling,ensureyouhaveenoughCat5/6
unshieldedtwistedpair(UTP)cablingtoconnecttheLocal
ExtendertotheRemoteExtender’slocation,andthateachend
isterminatedwithaRJ45connector.Thecablingshouldnotgo
throughanynetworkingequipment(i.e.router,switch).Iftheactual
devicesarenotsetupyet,makesuretoleaveenoughexcesscable
slacktoaccommodateforchangesindeviceplacement.
OR
Ifyouareusingpremisecabling,ensurethattheCat5/6unshielded
twistedpair(UTP)cablingbetweenthelocalExtenderandthe
RemoteExtenderhasbeenproperlyterminatedinawalloutlet/
panelineachlocationandthereisapatchcablelongenough
toconnecttheRemoteExtenderandtheLocalExtenderto
theirrespectiveoutlets.Thecablingshouldnotgothroughany
networkingequipment(i.e.router,switch).
USB110EXT2
1 Port USB 1.1 Extender over Cat5/Cat6 - up to 131ft (40m)
Local Extender
Remote Extender
RJ45connector
USBtypeAfemale
connector
USBtypeAmale
connector
RJ45connector

FCC Compliance Statement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainst
harmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiverisconnected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to
StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)
towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall
trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.
Technical Support
StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess
ourcomprehensiveselectionofonlinetools,documentation,anddownloads.
Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads
Warranty Information
Thisproductisbackedbyathreeyearwarranty.
Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned
forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom
misuse,abuse,alteration,ornormalwearandtear.
Limitation of Liability
InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,
consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow
theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.
Specications
Host Interface USB1.1
Number of Ports 1
Connectors (Local) 1xUSBtypeAmale
1xRJ45female
Connectors
(Remote)
1xUSBtypeAfemale
1xRJ45female
LEDs None
Compatible
Cabling Category5/5e/6/6aUTPcable
Max Distance 131ft(40m)
EDS Protection 8kVContact,16kVAir
Power Adapter USBPowered
Material Plastic
Operating
Temperature 0°C~50°C(32°F~122°F)
Storage
Temperature -20°C~70°C(-4°F~158°F)
Operating
Humidity 20~80%RH
Dimensions
(LxWxH) 85.0mmx40.0mmx25.0mm
Built-in Cable
Length (Local) 18in(45cm)
Built-in Cable
Length (Remote) 6in(15cm)
Weight 1.8oz(50g)
Installation
1. PlacetheLocalandRemoteExtendersatthedesiredlocationsand
connectthemtogetherusingtheRJ45terminatedCat5/6cabling
preparedearlier(see“PreparingYourSite”).
2. ConnecttheLocalExtendertothehostcomputersystemusingthe
built-inUSBcable.ThecomputercanbeeitherpoweredOnorO.
3. USBdevicescannowbeconnectedtotheRemoteExtender
wheretheywillthenbedetectedbythehostsystem.
Local
UTPCable(Up
to131ft/40m)
Remote
