SYMBOLS
CONTENTS
1. Intended use
2. Safety instructions
3. Know your product
4.Technical specications
5.Troubleshooting
6.Disposal and recycling
7.Warranty
8. Exploded view with parts list
9. CE declaration of conformity
Caution /Warning
Remove plug from the mains
immediately if the cable is
damaged or cut.
This product is of protection class
II.That means it is equipped with
enhanced or double insulation.
The product complies with the
applicable European directives
and an evaluation method of
conformity for these directives
was done.
WEEE symbol.Waste electrical
products should not be disposed
of with household waste. Please
recycle where facilities exist.
Check with your Local Authority
or local store for recycling
advice.
Wear eye protection
Wear ear protection
Wear sturdy, non-slip footwear
To reduce the risk of injury, user
must read instruction manual.
Wear protective gloves
Wear tight-tted protective
clothes.
Do not expose to rain
Always wear head protection
Wear face protection!
Guaranteed sound power level:
103 dB(A)
40
EN

1.INTENDED USE
1.This electric hedge trimmer EHT2-65.3 is designed with a rated power input of 650 W.This
product is intended for cutting and trimming of hedges, bushes and shrubs in domestic
gardens. The maximum cutting capacity must be observed. Do not cut branches exceeding
the stated maximum capacity.
2.Do not use this product in case of rain or in a humid environment.
3.For safety reasons, always read the entire instruction manual before rst operation and
observe all the instructions therein.
4.This product is intended for private domestic use only, not for any commercial trade use. Do
not use the product for any purposes other than those described.
41 EN

2. SAFETY INSTRUCTIONS
0
3
1.Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
2.Do not operate power tools in explosive atmospheres, such as in the
presence of ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3.Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
1.Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will reduce risk of
electric shock.
2.Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators.There is an increased risk of electric
shock if your body is earthed or grounded.
3.Do not expose power tools to rain or wet conditions.Water entering a
power tool will increase the risk of electric shock.
4.Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges
Work area safety
Electrical safety
WARNING!Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term“power tool”in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
General Power Tool Safety Warnings
42
EN

2. SAFETY INSTRUCTIONS
1.Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the inuence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal
injury.
2.Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
3.Prevent unintentional starting. Ensure the switch is in the o-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your nger on the switch
or energising power tools that have the switch on invites accidents.
4.Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
5.Do not overreach. Keep proper footing and balance at all times.This
enables better control of the power tool in unexpected situations.
6.Dress properly. Do not wear loose clothing or jewellery. Keep your hair,
clothing and gloves away from moving parts. Loose clothes, jewellery
Personal safety
or moving parts. Damaged or entangled cords increase the risk of
electric shock.
5.When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk
of electric shock.
6.If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
43 EN

2. SAFETY INSTRUCTIONS
1.Do not force the power tool. Use the correct power tool for your
application.The correct power tool will do the job better and safer at
the rate for which it was designed.
2.Do not use the power tool if the switch does not turn it on and o. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
3.Disconnect the plug from the power source and/or the battery pack
from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
4.Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained
users.
5.Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may aect the
power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power
tools.
6.Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
7.Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations dierent
from those intended could result in a hazardous situation.
Power tool use and care
or long hair can be caught in moving parts.
7.If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
44
EN

2. SAFETY INSTRUCTIONS
1.Have your power tools serviced by a qualied repair person using only
identical replacement parts.This will ensure that safety of the power tool
is maintained.
If the supply cable is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
If the carbon brushes need to be replaced, have this done by a qualied
repair person (always replace the two brushes at the same time).
1.Keep all parts of the body away from the cutter blade. Do not remove
cut material or hold material to be cut when blades are moving. Make
sure the switch is o when clearing jammed material. A moment of
inattention while operating the hedge trimmer may result in serious
personal injury.
2.Carry the hedge trimmer by the handle with the cutter blade stopped.
When transporting or storing the hedge trimmer always t the cutting
device cover. Proper handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
3.Hold the power tool by insulated gripping surfaces only, because the
cutter blade may contact hidden wiring or its own cord. Cutter blades
contacting a «live» wire may make exposed metal parts of the power
tool «live» and could give the operator an electric shock.
4.Keep cable away from cutting area. During operation the cable may be
hidden in shrubs and can be accidentally cut by the blade.
5.Check the hedge for foreign objects before operation, e.g. wire fences.
Take care that the cutting device does not come into contact with wire
or other metal objects.
Service
Hedge trimmer safety warnings
45 EN

2. SAFETY INSTRUCTIONS
1. Keep hands and feet away from the cutting device at all times and
especially when switching the product on.
2. Do not try to grasp or remove trimmings when the product is running.
Only remove trimmings when the product is switched o and
disconnected from the power supply.
3. Never hold the product by the guard.
4. Always be sure of a safe and secure operating position, whilst using
the product.
5. Never use the product standing on steps or a ladder. Do not work over
shoulder height.
6. Always ensure the safety guard supplied is tted before using the
product. Never attempt to use an incomplete product or one tted
with an unauthorised modication.
7. Check the cutting device regularly for damage, and if damaged repair
immediately.
8. Do not overload the product.
9. Check immediately if the product starts to vibrate abnormally.
Excessive vibration can cause injury.
10.Switch the product o when the cutting device is blocked. Disconnect
it from power supply and remove the blockage. Inspect the cutting
device for damage before using the product again.
11.Follow the maintenance and repair instructions for this product.
Never carry out any modications of the product. Information about
maintenance and repair is provided in this instruction manual.
6.Hold the hedge trimmer properly, e.g. with both hands if two handles
are provided. Loss of control can cause personal injury.
7.The product should be supplied via a residual current device (RCD) with
a tripping current of not more than 30 mA.
Additional hedge trimmer safety warnings
46
EN

2. SAFETY INSTRUCTIONS
Maintenance and storage
1. Disconnect the product from the power supply(i.e. remove the plug
from the power supply) and check for damage after use.
2. Disconnect the product from the power supply (i.e. remove the plug
from the power supply)before carrying out maintenance or cleaning
work.
3. Use only the manufacturer’s recommended replacement parts and
accessories.
4. Inspect and maintain the product regularly. Have the product repaired
only by an authorised service centre or similar qualied specialist.
5.When not in use, store the product out of the reach of children.
12.Know how to stop the product quickly in an emergency.
13.Do not expose the product to rain. Do not operate the product on a
wet hedge.
14.Use the product only in daylight or good articial light.
15.Prolonged use of the product exposes the user to vibrations that
can cause a range of conditions collectively known as hand-arm
vibration syndrome (HAVS) e.g. ngers going white; as well as specic
diseases such as carpal tunnel syndrome.
To reduce this risk when using the product, always wear protective gloves
and keep your hands warm.
The symptoms of HAVS include any combination of the following:
Tingling and numbness in the ngers; Not being able to feel things
properly; Loss of strength in the hands; Fingers going white (blanching)
and becoming red and painful on recovery (particularly in the cold
and wet, and probably only in the tips at rst). Seek medical advice
immediately if such symptoms are experienced.
47 EN

2. SAFETY INSTRUCTIONS
Vibration and noise reduction
Emergency
Familiarise yourself with the use of this product by means of this
instruction manual. Memorise the safety directions and follow them to
the letter. This will help to prevent risks and hazards.
1. Always be alert when using this product, so that you can recognise
and handle risks early. Fast intervention can prevent serious injury and
damage to property.
2. Switch o and disconnect from the power supply if there are
malfunctions. Have the product checked by a qualied professional and
repaired, if necessary, before you operate it again.
To reduce the impact of noise and vibration emission, limit the time of
operation, use low-vibration and low-noise operating modes as well as
wear personal protective equipment.
Take the following points into account to minimise the vibration and
noise exposure risks:
1. Only use the product as intended by its design and these instructions.
2. Ensure that the product is in good condition and well maintained.
3. Use correct attachments for the product and ensure they are in good
condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these instructions and keep it
well lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool use across a
longer period of time.
48
EN

2. SAFETY INSTRUCTIONS
Residual risks
Even if you are operating this product in accordance with all the safety
requirements, potential risks of injury and damage remain. The following
dangers can arise in connection with the structure and design of this
product:
1. Health defects resulting from vibration emission if the product is being
used over long periods of time or not adequately managed and properly
maintained.
2. Injuries and damage to property due to broken cutting attachments or
the sudden impact of hidden objects during use.
3. Danger of injury and property damage caused by ying objects.
WARNING!
This product produces an electromagnetic eld during operation!
This eld may under some circumstances interfere with active or
passive medical implants!To reduce the risk of serious or fatal injury,
we recommend persons with medical implants to consult their doctor
and the medical implant manufacturer before operating this product!
49 EN

3.KNOW YOUR PRODUCT
1Front handle
2Hand safety switch
3Switch trigger
4Rear handle
5Guard
6Cable strain relief
7Opening
8Blade
9Blade cover
10 LED Indicator
11 Sweep function board
9
511
1
2
4
6
7
10
3
8
50
EN

4.TECHNICAL SPECIFICATIONS
Model EHT2-65.3
Rated voltage 220-240V~50Hz
Rated input power 650W
Rated no-load speed 1700/ min
Cutting length 650mm
Max cutting capacity 17mm
Sound pressure level LpA 89.63 dB(A)
Sound power level LwA 99.36dB(A)
Uncertainty K 2.27dB(A)
Guaranteed sound power level 103dB(A)
Vibration level Rear handle: 3.3 m/s2; Front handle: 2.8m/s2
Uncertainty K 1.5 m/s2
Machine weight 4.4kg
The sound intensity level for the operator may exceed 85dB(A) and protection measures are
necessary.
The declared vibration total value has been measured in accordance with a standard test
method and may be used for comparing one tool with another.The declared vibration total
value may also be used in a preliminary assessment of exposure.
WARNING!The vibration emission value during actual use of the tool can dier
from the declared value depending on the ways in which the tool is used. Identify
safety measures to protect the operator that are based on an estimation of exposure in the
actual conditions of use (taking account of all parts of the operating cycle such as the times
when the tool is switched o and when it is running idle in addition to the trigger time).
Depending on the actual use of the product the vibration values can dier from the declared
total! Adopt proper measures to protect yourself against vibration exposures!Take the whole
work process including times the product is running under no load or switched o into
consideration! Proper measures include among others regular maintenance and care of the
product and application tools, keeping hands warm, periodical breaks and proper planning
of work processes!
51 EN

5.TROUBLESHOOTING
Problems Possible cause Solution
Product does not
start
Not connected to power supply Connect to power supply
Power cord or plug is defective Have it checked by a specialist electrician
Other electrical defect to the
product Have it checked by a specialist electrician
Product does not
reach full power
Extension cord not suitable for
operation with this product Use a proper extension cord
Power source (e.g. generator)
has too low voltage Connect to another power source
Air vents are blocked Clean the air vents
Unsatisfactory
cutting
performance
Blade is worn/damaged Have it replaced with new one
Thickness of branches exceeds
capacity Only cut branches complying with the capacity
Excessive
vibration/noise
Blade is damaged Have it replaced with new one
Bolts/nuts are loose Tighten bolts/nuts
52
EN

6. DISPOSAL AND RECYCLING
The product comes in a package that protects it against damage during shipping.
Keep the package until you make sure that all parts have been delivered and the
product operates properly. And then recycle the package.
CAUTION! This product shall not be discarded with household waste but that
it shall be returned to a collection system which conforms to the European
WEEE Directive. Contact your local authorities or stockist for advice on recycling. It will then
be recycled or dismantled in order to reduce the impact on the environment. Electric and
electronic equipment can be hazardous for the environment and for human health since they
contain hazardous substances.
53 EN

7.WARRANTY
1. STERWINS products are designed to highest DIY quality standards. STERWINS oers a
36-month warranty for its products, from the date of purchase. This warranty applies to all
material and manufacturing defects which may arise. No further claims are possible, of
whatever nature, direct or indirect, relating to people and/or materials.
2. In the event of a problem or defect, always refer initially to your STERWINS dealer. In most
cases, the STERWINS dealer will be able to solve the problem or correct the defect.
3. Repairs or the replacement of parts will not extend the original warranty period.
4.Defects which havearisenas a resultofimproperuseorweararenotcovered bythewarranty.
Amongst other things, this relates to switches, protective circuit switches and motors, in the
event of wear.
5.Your claim upon the warranty can only be processed if:
• Proof of the purchase date can be provided in the form of a receipt
• No repairs and/or replacements have been carried out by third parties
• The tool has not been subjected to improper use (overloading of the machine or tting non-
approved accessories).
• There is no damage caused by external inuences or foreign bodies such as sand or stones.
• There is no damage caused by non-observance of the safety instructions and operating
instructions.
6.Warranty terms are applicable combined with our sales and delivery terms.
7. Faulty tools to be returned to STERWINS via your STERWINS dealer will be collected by
STERWINS provided the product is properly packaged. Faulty goods sent directly to STERWINS
by the consumer shall be processed only if the consumer has paid the shipping costs.
8. Products which are delivered in a poorly packaged condition will not be accepted by
STERWINS.
54
EN

8.EXPLODED VIEW WITH PARTS LIST
55 EN

8.EXPLODED VIEW WITH PARTS LIST
POS DESCRIPTION POS DESCRIPTION POS DESCRIPTION
1 Screw 10.11 Screw 20.6 Screw
2 Right housing assy 10.12 Bearing 21 Left housing assy
2.1 Right cover 10.13 Rotor assy 21.1 Left cover
2.2 Right housing 10.14 Bearing 21.2 Left housing
2.3 Screw 10.15 Aluminum bracket 21.3 Screw
3 Plug base assy 10.15.1 Gear shaft 22 Screw
3.1 Plug base 10.16 Screw 23 Guard
3.2 Plug and connection wire assy 11 Gasket 24 Screw
3.3 Fixing base 12 Blade gear assy 25 Nut
3.4 Screw 12.1 Gear 26 Sweep board
4 Rear trigger 12.2 Eccentric gear 27 Blade cover
5 Switch spring 12.3 Blade assy 28 Bottom cover assy
6 Rear rotational rod 12.3.1 Blade protector 28.1 Screw
7 Steel wire rod 12.4 Gasket 28.2 Gasket
8 Rotational rod 12.5 Gasket 28.3 Fixing base
9 Reset spring 12.6 Pin 28.4 Bottom cover
10 Motor and connection wire
assy 13 Gasket 29 Screw
10.1 Switch and connection wire
assy 14 Bolt sleeve
10.1.1 Switch 15 Indicator cover
10.1.2 Connection wire assy 16 Top cover
10.2 Female terminal 17 Screw
10.3 Heat-shrinkable tube 18 Pressing plate
10.4 Copper strip 19 Screw
10.5 Heat-shrinkable tube 20 Front handle assy
10.6 Screw 20.1 Upper handle
10.7 Carbon brush 20.2 Nut
10.8 Carbon brush holder 20.3 Spring
10.9 Stator assy 20.4 Front trigger
10.10 Bracket 20.5 Lower handle
56
EN

9.CE DECLARATION OF CONFORMITY
We
ADEO Services
135 rue Sadi Carnot
CS 00001
59790 Ronchin - France
Declare that the product detailed below:
Electric Hedge Trimmer 650W
Model: EHT2-65.3
Satises the requirement of the Council Directives:
Machinery Directive 2006/42/EC
EMC Directive 2014/30/EU
The Outdoor Noise Directive 2000/14/EC amended by 2005/88/EC
Guaranteed Sound Power Level 103dB(A)
The RoHs Directive 2011/65/EU
and conforms to the norms:
EN 55014-1: 2006+A1: 2009+A2: 2011
EN 55014-2: 2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 60745-1: 2009+A11: 2010
EN 60745-2-15: 2009+A1: 2010
Serial No: Please refer to the back cover page
Last two numbers of the year CE marking applied: 16
Bruno POTTIE
Position of Signatory:
Director of International Buying
ADEO SERVICES
2016-11-30
57 EN
