Contemporary Bedside Stand, 3-Drawer - Model 4400-803-000
18.5
31.0
19.3
ASSEMBLY METHOD
The Stryker Med/Surg Bedside Stand is constructed using a locking cam and dowel pin
arrangement.
To dismantle the unit, use a #2 Phillips screwdriver to unlock each cam by rotating the cam in
a counter-clockwise direction.
Note: The product serial number label is located on the back of the unit.
UNLOCK
LOCK
C
K
G
A
B
D
L
H
M
J
F
E
P
See Table
on Page 2
See Table
on Page 2
A
G
D
E
F
B
C
4400-800-100
4400-803-001

24400-803-900 REV D www.stryker.com
3800 E. Centre Ave., Portage, MI 49002
[phone] | 2014/01 D.0
Bedside Stand Common Components (4400-803-001)
Item Part Number Part Name Qty.
A 4400-800-100 Case (see Case Assembly Table) 1
B 3150-001-200 Caster 4
C 3100-052-733 Dowel Pin 6
D 3100-052-732 Cam 6
E 0020-021-000 Wood Screw 32
F 4400-500-205 L-Bracket 4
G 3100-052-737 Plastic Vent 1
H 4400-600-203 Drawer Frame 3
J 4400-600-204 Drawer Slides (Set of 2) 3
K 4400-009-100 Cleaning / Serial Number Label 1
L 3100-200-208 Drawer Liner 3
M 0020-013-000 Wood Screw 12
P 0020-022-000 Euro Screw 24
Case Assembly (4400-800-100)
Item Part Number Part Name Qty.
A 4400-508-118 Bottom Panel 1
B 4400-800-201 Back Panel 1
C 4400-800-116 Right Side Panel 1
D 4400-800-117 Left Side Panel 1
E 3100-052-733 Dowel Pin 14
F 3100-052-732 Cam 14
G 4400-500-204
4400-500-224
4400-500-223
Brace (No Lock)
Brace (Slam Lock)
Brace (Key Lock)
1
1
1
DISINFECTION PROCEDURE
The Center for Disease Control recommends a 1:4 mixture of
bleach and water for disinfection. Thoroughly rinse the solution
from the product surface. If other hospital-grade cleaning agents
are used, follow the instructions provided by the cleaning solution’s
manufacturer. Wipe the surface with a soft, dry cloth to remove
any moisture.
WARRANTY
Stryker warrants this product for one (1) year under normal use and proper care. For one year from date of shipment,
Stryker will repair or, at our option, replace defective merchandise free of charge (parts, labor, and shipping included).
Note: LIFETIME warranty on metal drawer frames and glides.
Contemporary Bedside Stand, 3-Drawer - Model 4400-803-000
Standard Configuration
Part Number Part Name Qty.
4400-808-101
4400-808-300
4400-808-104
4400-808-304
Top/Mid.Drw. Front
Bottom Drw. Front
Cont Pull Dwr. Front
Bot. Cont. Pull Dwr.
2
1
2
1
Top Panel Option
Part Number Part Name Qty.
4400-010-800 Contemporary Top 1
4400-200-210 Solid Spill Cont. Top 1
3100-200-210 Premier Top 1
Key Lock Option
Part Number Part Name Qty.
4400-800-201 Stainless Steel Pull 3
4400-500-300 Lock 1
4400-808-102 Locking Drawer Front 1
Slam Lock Option
Part Number Part Name Qty.
4400-800-201 Stainless Steel Pull 1
4400-500-301 Lock 1
4400-808-103 Locking Drawer Front 1
Key Lock Option with Continuous Pull
Part Number Part Name Qty.
4400-500-300 Lock 1
4400-808-105 Locking Drawer Front 1
Slam Lock Option with Continuous Pull
Part Number Part Name Qty.
4400-500-301 Lock 1
4400-808-106 Locking Drawer Front 1
