Stryker Traditional 4400-883-000 User manual

www.stryker.com4400-883-900 REV C 1
Traditional Bedside Stand, 3-Drawer - Model 4400-883-000
18
18.5
30.5
ASSEMBLY METHOD
The Stryker Med/Surg Beside Stand is constructed using
a locking cam and dowel pin arrangement.
To dismantle the unit, use a #2 Phillips screwdriver
to unlock each cam by rotating the cam in a counter-
clockwise direction.
UNLOCK
LOCK
NOTE:
The product serial number label is located
on the back of the unit.
9
1
3
4
11
7
6
2
5
8
10
12
13
Reference Table
on Back
Reference Table
on Back
D
G
E
F
B
C
A

24400-883-900 REV C www.stryker.com
3800 E. Centre Ave., Portage, MI 49002
[phone] Option 2
Bedside Stand Common Components
Item Part Number Part Name Qty.
1 4400-508-100 Case (see Case Assembly Table) 1
2 3150-001-200 Caster 4
3 3100-052-733 Dowel Pin 6
4 3100-052-732 Cam 6
5 0020-013-000 Wood Screw 12
6 4400-500-205 L-Bracket 3
7 3100-052-737 Plastic Vent 1
8 4400-600-203 Drawer Frame 3
9 3100-052-743 Rivet 18
10 4400-600-204 Drawer Slides 3
11 4400-009-100 Cleaning / Serial Number Label 1
12 3100-200-208 Drawer Liner 3
13 0020-021-000 Wood Screw 28
(1) Case Assembly
Item Part Number Part Name Qty.
A 4400-508-118 Bottom Panel 1
B 4400-500-201 Back Panel 1
C 4400-508-116 Right SIde Panel 1
D 4400-508-117 Left Side Panel 1
E 3100-052-733 Dowel Pin 14
F 3100-052-732 Cam 14
G 4400-500-204
4400-500-224
4400-500-223
Brace (No Lock)
Brace (Slam Lock)
Brace (Key Lock)
1
1
1
DISINFECTION PROCEDURE
The Center for Disease Control recommends a 1:4 mixture of bleach and water for disinfection. Thoroughly rinse the
solution from the product surface. If other hospital-grade cleaning agents are used, follow the instructions provided by
the cleaning solution’s manufacturer. Wipe the surface with a soft, dry cloth to remove any moisture.
WARRANTY
Stryker warrants this product for one (1) year under normal use and proper care. For one year from date of shipment,
Stryker will repair or, at our option, replace defective merchandise free of charge (parts, labor, and shipping included).
Note: LIFETIME warranty on metal drawer frames and glides.
Standard Configuration
Part Number Part Name Qty.
4400-888-101
4400-888-303
Top/Mid. Drw. Front
Bottom Dwr. Front
2
1
Top Panel Option
Part Number Part Name Qty.
4400-010-880 Traditional Top 1
4400-200-210 Solid Spill Cont. Top 1
Key Lock Option
Part Number Part Name Qty.
4400-500-300 Lock 1
4400-888-102 Locking Drawer Front 1
4400-888-101 Middle Drawer Front 1
4400-888-303 Bottom Drawer Front 1
Slam Lock Option
Part Number Part Name Qty.
4400-500-301 Lock 1
4400-888-103 Locking Drawer Front 1
4400-888-101 Middle Drawer Front 1
4400-888-303 Bottom Drawer Front 1
Hardware Option
Part Number Part Name Qty.
4400-700-201 Brass Pull 3
4400-700-202 Chrome Pull 3
Traditional Bedside Stand, 3-Drawer - Model 4400-883-000
