Subaru 602 Installation and operation manual

Technician
Reference
Booklet
ELECTRICAL SYSTEMS
OPERATION & DIAGNOSIS
MSA5P0135C
June 2013
Module 602

© Subaru of America, Inc. 2013 913-924
© Copyright 2013
Subaru of America, Inc.
All rights reserved. This book may not be
reproduced in whole or in part without the
express permission of Subaru of America,
Inc. Specifications in this Guide are based
on the latest product information available at
the time of publication.Some images shown
are for illustration purposes only.
Subaru ofAmerica, Inc.reserves the right at
any time to make changes or modifications
to systems, procedures, descriptions, and
illustrations contained in this book without
necessarily updating this document.
Information contained herein is considered
current as of June 2013.
This Technical Reference Booklet (TRB) is designed to be used in a
classroom environment or as a guide for self study.
The TRB is not intended to be used as a supplement or substitute for the
Subaru Service Manual. Always consult the appropriate Service Manual when
performing any diagnostics, maintenance or repair to any Subaru vehicle.
Product Material Disclosure
© 2013 Subaru of America, Inc. Printed in USA. All rights reserved. Contents may not be reproduced in whole or in part without prior
written permission of publisher. Specifications in this Guide are based on the latest product information available at the time of publication.
Some images shown are for illustration purposes only. Some equipment shown in photography within this Guide is optional at extra cost.
Specific options may be available only in combination with other options. Specific combinations of equipment or features may vary from
time to time, and by geographic area. Subaru of America, Inc. reserves the right to change or discontinue at any time, without notice:
Prices, colors, materials, equipment, accessories, specifications, models and packages, without incurring any obligation to make the same
or similar changes on vehicles previously sold. Colors shown may vary due to reproduction and printing processes. Subaru of America,
Inc. is not responsible for typographical errors. Alcantara® is a registered trademark of Alcantara S.p.A., and Alcantara is produced by
the Toray Group. Audyssey MultEQ® is a registered trademark of Audyssey Laboratories, Inc. BBS® is a registered trademark of BBS
Kraftahrzeugtechnik AG. Bilstein® is a registered trademark of August-Bilstein GmbH & Co. Bluetooth® is a registered trademark of
Bluetooth SIG, Inc. Brembo® is a registered trademark of Freni Brembo S.p.A. CS Auto, Circle Surround Automotive and WOW are
trademarks of SRS Labs, Inc. Ecsaine® is a registered trademark of Toray Industries, Inc. harman/kardon® is a registered trademark of
Harman International Industries, Inc. HD RadioTM is a trademark of iBiquity Digital Corporation. HomeLink® is a registered trademark of
Johnson Controls. iPod® is a registered trademark of Apple Inc. iTunes® is a registered trademark of Apple Inc. Metal-Matrix Diaphragm
(MMD®) is a registered trademark of Harman International Industries, Inc. MOMO® is a registered trademark of Momo S.p.A. Corporation.
SIRIUS® satellite radio is a registered trademark of SIRIUS Satellite Radio, Inc. Smart Way® is a registered trademark of the U.S.
Environmental Protection Agency. SRS(•)® Circle Surround Automotive and WOW are registered trademarks of SRS Labs, Inc. TomTom®
is a registered trademark of TomTom international. TORSEN LSD® is a registered trademark of JTEKT TORSEN North America, Inc. XM®
is a registered trademark of XM Satellite Radio, Inc. / XM NavTraffic® is a registered trademark of XM Satellite Radio, Inc. Added Security,
BRZ, EyeSight, Impreza, Forester, Lineartronic, Legacy, Outback, Subaru, SUBARU BOXER, Tribeca, and WRX, STI, and XV Crosstrek are
registered trademarks.

4June 2013
Electrical Systems Operation & Diagnosis Module (602)
Table of Contents
INTRODUCTION ..................................................................................................8
LAN/CAN INTRODUCTION .................................................................................8
HIGH SPEED CAN SIGNAL CONSTRUCTION ................................................ 12
Outline of Data Frame................................................................................ 13
High Speed CAN Communication Circuit................................................... 15
Can High Wire .................................................................................. 16
Can Low Wire................................................................................... 16
Open Circuit in Main Bus ........................................................................... 17
Open Circuit in Branch Bus........................................................................ 18
Ground Short of CAN High Wire ................................................................ 19
Ground Short of CAN low Wire ..................................................................20
Diagnostic Procedure using HS-CAN DTCs ..............................................21
CAN BUS B OR KAC.........................................................................................22
LOW SPEED CAN.............................................................................................. 23
LOCAL INTERCONNECT NETWORK (LIN) .....................................................24
Monitoring of Trouble in the System ...........................................................25
CAN Trouble Codes.......................................................................... 25
Combination Meter.....................................................................................27
Select Monitor............................................................................................28
BIU CUSTOMIZING ...........................................................................................29
Body Integrated Unit Customizing ...................................................30
(New Items)......................................................................................30
KEYLESS ACCESS WITH PUSH BUTTON START SYSTEM ..........................31
Normal Operation ......................................................................................31
Vehicle Entry and Locking .........................................................................31
Ignition and Engine Start ...........................................................................37
Key Warning............................................................................................... 41
Wireless Communications .........................................................................42
Collation and Immobilizer........................................................................... 42
HEADLIGHTS ....................................................................................................43
Lighting Switch.................................................................................43
Headlight Operation .........................................................................43

5June 2013
Electrical Systems Operation & Diagnosis Module (602)
IMMOBILIZER TYPE A ......................................................................................45
System Construction..................................................................................45
Key .............................................................................................................47
BIU.............................................................................................................47
Combination Meter or Engine Control Module .................................48
Registration Process ........................................................................48
ECM Replacement.....................................................................................50
2012 IMPREZA IMMOBILIZER TYPE B ............................................................ 52
Immobilizer System Registration................................................................56
Engine ECU Registration...........................................................................58
Meter/SCU Registration .............................................................................59
The Registration Number Read ................................................................. 60
Immobilizer Key ID Deletion.......................................................................60
Remote Control Engine Starter Registration..............................................61
KEYLESS ENTRY..............................................................................................64
How To Register the Transmitter ................................................................65
Using the Subaru Select Monitor .....................................................65
Security System.........................................................................................67
REMOTE ENGINE START SYSTEM (RES).......................................................69
Tachometer Idle Speed Programming........................................................69
Anti-Grind.........................................................................................75
Starter Motor Operation ................................................................... 76
Accessory Power Supply ...........................................................................77
RES DIAGNOSTICS ..........................................................................................78
2010 AND NEWER LEGACY ............................................................................. 81
OTHER 2010MY AND NEWER ELECTRICAL ADVANCEMENTS.................... 82
MULTI-FUNCTION-DISPLAY (MFD) (2014 FORESTER).................................. 83
POWER REAR GATE (PRG) (2014 FORESTER)..............................................87
Operation Mode .........................................................................................88
PRG Components and Operation ....................................................89
PRG Auto Closer Parked ........................................................................... 97
PRG Auto Closer Opening .........................................................................98
PRG Auto Closer Closing........................................................................... 98
Touch Sensors ......................................................................................... 101
“Memory Height” Learning Procedure...................................................... 103

6June 2013
Electrical Systems Operation & Diagnosis Module (602)
ELECTRICAL................................................................................................... 105
2014 COMBINATION METER.......................................................................... 110
Subaru Select Monitor III (SSMIII) ............................................................110
Instrumentation/Driver Information................................................. 115
SERVICE BULLETINS..................................................................................... 116
TECHTIPS........................................................................................................ 118

7June 2013
Electrical Systems Operation & Diagnosis Module (602)
SUPPLEMENTAL INFORMATION .................................................................. 123
AUDIO AND NAVIGATION SYSTEMS............................................................. 123
Subaru Tribeca and Legacy Navigation System (2006) ........................... 123
Navigation Components................................................................. 123
Navigation Operation ..................................................................... 125
Map Screen.................................................................................... 125
Tribeca Rear Entertainment System............................................... 126
Vehicle Information......................................................................... 128
Legacy Audio System (2005-2009) .......................................................... 129
Satellite Audio Controls ............................................................................ 130
2008 Navigation Impreza ......................................................................... 131
Navigation Diagnosis (2008).......................................................... 133
2010 Navigation System........................................................................... 135
2012 Audio and Navigation ...................................................................... 136
2013 Legacy/Outback .............................................................................. 137
COMBINATION METERS ................................................................................ 138
(Legacy 2005).......................................................................................... 138
Subaru Tribeca Combination Meter ......................................................... 141
Combination Meter D Check .......................................................... 141
2012 Impreza Combination Meter ............................................................ 143
REAR VISION CAMERA.................................................................................. 144
SUPPLEMENTAL INFORMATION FOR KEYLESS ENTRY
REGISTRATION OF NEWER VEHICLES........................................................ 147
2012 to 2013 Impreza (Immobilizer Type B) ............................................. 147
Registration of Keyless Transmitter with Subaru Select Monitor .... 147
BRZ Keyless Entry System {Mechanical Key} ......................................... 149
Key Registration....................................................................................... 149
To register a new keyless ID while keeping existing
registered codes............................................................................. 149
BRZ with Keyless Access and Push Button Start (KAC).......................... 151
Key Registration (Additional key ID registration) ............................ 151
Legacy and Outback Keyless Access and Push Button Start (KAC) ....... 155
Key Registration (Additional key ID registration) ............................ 155

8June 2013
Electrical Systems Operation & Diagnosis Module (602)
Introduction
This module will provide information and hands on experience that will provide you with an
understanding of Subaru Electrical System Operation and Diagnosis.
Classroom and lab participation is encouraged so that you may gain the experience needed to
repair Subaru electrical Systems on your first attempt correctly and in a timely manner.
LAN/CAN Introduction
LAN/CAN systems first appeared on the 2005 Legacy vehicles and were phased into new
generations of all existing models. Any new model introduced from 2005 was equipped with LAN/
CAN. The LAN (Local Area Network), a system where multiple computers are linked together with
a single pair of twisted wires, improves equipment operation and functions while reducing the
weight of the vehicle by eliminating a considerable amount of wiring harnesses. LAN (Bus) is a
type of computer network topology or wiring that connects all computers of a system or device.
LAN Topologies
LAN BUS configuration allows communications between computers to continue if one of the other
members of the LAN drops out or malfunctions.
The LAN operates using Controller Area Network (CAN) communications protocol. CAN
communications are frames of vehicle data that deliver and share all vehicle information among
the computers of the LAN. The frames of data are composed of binary code or 0s and 1s that are
coded and decoded by the LAN.The voltage values that represent the 0s and 1s varies depending
on the type of CAN. Two types of CAN will be reviewed in this section of the reference booklet,
the High speed and Low speed CAN. The first LAN/CAN system equipped on Subaru vehicles
was a combination of the High speed and Low speed CAN. As the years progressed a switch to
High speed CAN only was employed.
6

9June 2013
Electrical Systems Operation & Diagnosis Module (602)
A Controller Area Network (CAN) signal is composed of two separate pulses. One pulse is low
voltage changing to high voltage and one pulse is high voltage changing to low voltage. Each pulse
has its own wire. The two pulses are sent simultaneously from one control unit to all the other
control units on the Local Area Network (LAN). A control unit receiving the two pulses compares
the potential difference between them.
Potential Difference
Each control module has a transmitter and receiver, which enables bidirectional communication
among the control modules.
Bidirectional Communication
7
8

10 June 2013
Electrical Systems Operation & Diagnosis Module (602)
The CAN wires are twisted together along the entire length of the LAN. This protects the integrity
of the CAN signal if an unintentional signal is created in the circuit from an overlying circuit that
induces a magnetic field into the CAN wires. This magnetic field will place noise or an unwanted
voltage signal into the CAN signal.
The polarity of the unwanted signal will usually be constant. Superimposed over the CAN signal
the noise will cancel itself out as the control units only view the potential difference between the
two wires. The more twists per meter a wire has the more it reduces noise.
Noise (ARTWORK)
CAN communications are designed to operate at different speed levels dependant on the operating
speeds of the components on different parts of the LAN.The power train side of the LAN operates
at 500 Kbps (500,000 bytes per second). The body side of the LAN operates at a slower rate of
125 Kbps (125,000 bytes per second). The individual sides of the LAN are referred to as bus. Any
references to the high speed bus are referencing to the power train side of the LAN and the low
speed bus is referring to the body side of the LAN. Communications between the high speed and
low speed bus sides of the LAN are not possible unless the data to be shared is adjusted to the
same rate of speed. This adjusting process is referred to as passing through the gateway. The
gateway function is accomplished by the Body Integrated Unit (BIU).Additional functions of the BIU
control and monitor body related electrical circuits such as the rear defogger and door switches.
Components of the high speed bus include the Engine ECM, Transmission Control Module,
ABS/VDC ECM and the Steering Angle Sensor (Vehicles with VDC). The number of control
modules on the CAN continue to increase. The most recent additions are the Keyless Access and
EyeSight™ Control Modules.
Components of the low speed bus include the Combination Meter and A/C Control Unit (Auto A/C).
The twisted wire connecting all components of the CAN to the BIU must maintain its twisted shape
to help with keeping out electrical interference. Repairs to the wire are allowed but the length of
the twisted wire cannot differ more than 3.94 inches (8 cm).
9

11 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Speed meter, Tachometer
Warning lamp
Fuel gauge,
Coolant temp. gauge
Combination Meter
Clock, Fuel consumption
Clock
Audio & A/C
operation panel
A/C control
Engine control
Radiator fan control
AT-EGI communication
Slope angle estimation
ECM
Coolant
temp.
Engine
speed
CAN
125kbps
Shift range
TCM
CAN
500kbps
Wheel rotation speed
Vehicle speed
calculation
10.4kbps
VDC/ABS
Steering angle
sensor
Keyless entry
control unit
Body integrated
module
Immobilizer
Timer control
(Illumination,
Rear defogger,
Wiper deicer)
Rear fog light
Belt warning
Door lock
Illumination control
Rear wiper
Fuel level
Room lamp
Shift SW
Door SW
Illumination
control
Auto A/C CM
A/C
control
panel
SSM
LAN (ARTWORK)
NOTES:
10

12 June 2013
Electrical Systems Operation & Diagnosis Module (602)
High Speed CAN Signal Construction
When reviewing the service manual you will find references to High Speed CAN and Low Speed
CAN. Each of these has a CAN-High wire and a CAN-Low wire.The differences in operating speed
have already been discussed and now the construction of the two circuits needs to be understood
before fully understanding operational differences.
High Speed CAN (ARTWORK)
When the logic value of the High Speed CAN is 1 there is no potential difference between the
voltage levels of CAN High and CAN Low. The level of both signals is 2.5 volts. When the logic
value changes to a 0 the voltage level of both signals move away from each other. CAN High will
be 3.5 volts and CAN Low will be 1.4 volts.This operation helps to ensure that there is no electrical
interference and the signals received by the various components of the LAN are receiving genuine
signals.
12

13 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Outline of Data Frame
When data is generated, the signal “Frame” comprises of a “start bit” and a “stop bit” to indicate
the beginning and end of a signal. The frame also includes identification data, main data, and an
error detection code.
Example
Outline of Data Frame Example
(1) Bus idle: Idle state
(2) Frame: Data transmission state
(3) Start bit: Transmission starts
(4) ID bit: It shows what kind of data, for example, TCM, ABS, or ECM.
(5) Data bit: It shows what contents of the data, for example, RPM, shift Position, etc.
(6) Error detection code: It is to avoid wrong recognition of data.
(7) Stop bit: Data transmission stops
“Bus idle” refers to the area between data when no information is being transmitted. At this time,
the data logic value is “1”. Therefore, when the High Speed CAN circuit is 2.5 volts, the system is
at “Bus idle”.,
When a CAN High or CAN Low wire of the High speed CAN carries a transmitted signal, the signal
travels in both directions until the signal reaches the end of the respective wire. At this point the
signal is absorbed by the terminator to the opposite CAN wire.
NOTES:
13

14 June 2013
Electrical Systems Operation & Diagnosis Module (602)
B, C CAN High Wire and E, F CAN Low Wire
For example the CAN High Wire (B, C) receives a voltage signal ranging from 2.5 volts to 3.6 volts.
The signal originates at point A and travels to point B and point C simultaneously.
The potential difference between B, C and E, F during One state is 0 volts but during the Zero
state, the potential difference is 2.2 volts.
During normal operation this potential difference will remain constant.
The voltage output of B, C during the Zero state is actually higher than 3.6 volts but the terminators
allow paths to E, F and 3.6 is the remaining voltage.
The voltage output of EF during the Zero state is actually lower than 1.4 volts but the voltage from
terminators and BC increase the minimum voltage reading to 1.4 volts.
Fail-safe and driveability conditions resulting from problems with the CAN change from year to
year and model to model. These conditions could result in no engine start, limited Electronic
Power Steering operation, non-operative shifter control and many more conditions that control or
monitor normal vehicle operations.
Diagnostics for CAN issues vary as much as the fail-safe and driveability conditions. However;
all High speed CAN circuits share the same circuit structure for the main CAN bus circuit. This
commonality allows the following checks to be performed regardless of model or year of production:
CAN diagnostic checks
1. Resistance
A. Ohm meter
2. Voltage
A. Voltmeter
B. Oscilloscope
3. Communications
A. CAN diagnostic
B. K line
14

15 June 2013
Electrical Systems Operation & Diagnosis Module (602)
High Speed CAN Communication Circuit
The high speed CAN communication circuit is configured as shown in the illustration.
The communication line connecting the ECM and the VDC is called the main bus, and the
communication lines connecting the main bus and the other control modules are called the branch
buses. Main bus and branch buses are connected by joint connectors.
There is a 120 Ohm resistor in the ECM and VDC CM. They are connected to the circuit as
terminator resistors.
Main bus
Branch bus
ELECTRIC
POWER
STEERING CM
COMBINATION
METER
BODY
INTEGRATED
UNIT
STEERING
ANGLE
SENSOR
VDC CM
120Ω120Ω
TCM
DATA LINK
CONNECTOR
A/C CM
ELECTRONIC
PARKING
BRAKE CM
ECM
High Speed CAN Resistance Check
The DLC is the most accessible connector to measure the resistance of the main bus. If the DLC
is correctly connected to the main bus, the total circuit resistance of the main bus should be 60
ohms. Two 120 ohm resistors wired in parallel provide two paths for the CAN circuit. Since the
resistors have the same value this simple formula determines the total circuit resistance:
RT = V/N RT = 120/2 RT = 60
RT = Resistance total
V = Value of the resistor
N = Number of like resistors
An open, short, or additional resistance added from a malfunction in a control module will affect
the total circuit resistance. This can be measured from the DLC provided no electrical power is
flowing through the CAN.
Note: The total circuit resistance of a parallel circuit is always lower than the
smallest value resistor in the circuit.
15

16 June 2013
Electrical Systems Operation & Diagnosis Module (602)
High Speed CAN Voltage Check
Voltage checks from the DLC are possible with the CAN active (Ignition on, Engine off). The
normal voltage readings will vary by year, model, and the amount of data being carried on the
CAN. The CAN high wire and the CAN low wire will always have a different value during normal
circuit operation.
Can High Wire
Checked with an oscilloscope, the pattern of the signals will change from approximately 2.50
volts to 3.60 volts. If you check this value with a voltmeter, the voltage reading will average out to
approximately 2.60 volts.
Can Low Wire
Checked with an oscilloscope, the pattern of the signals change from approximately 2.5 volts to 1.4
volts. If you check this value with a voltmeter, the voltage reading will average out to approximately
2.40 volts.
Note: Any change to the total circuit resistance of the CAN will result in changes to
the volt meter readings for the CAN high and CAN low wire at the same time.
One cannot change without affecting the other.
NOTES:
16

17 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Open Circuit in Main Bus
An open circuit on the main bus can be detected by measuring the resistance between HS-CAN
High and HS-CAN Low. For example, when measuring the resistance between HS-CAN High and
HS-CAN Low at the DLC, the resistance should be 60 Ohms.
When an open circuit occurs on the main bus, the resistance becomes 120 Ohm.
In this case, communication with control modules that are connected after the open circuit becomes
disabled. In the illustration below the BIU cannot communicate with ECM, EPS, and EPB.
Main bus
Branch bus
ELECTRIC
POWER
STEERING CM
COMBINATION
METER
BODY
INTEGRATED
UNIT
STEERING
ANGLE
SENSOR
VDC CM
120Ω120Ω
TCM
DATA LINK
CONNECTOR
A/C CM
ELECTRONIC
PARKING
BRAKE CM
ECM
Open Circuit in Main Bus
RT = ____________________
1 state 0 state
Voltage CAN High _____________ _______________
Voltage CAN Low _____________ _______________
Control Modules that cannot communicate
_______ _______ ______ _______ _______ _______ ______
_______ _______ ______ _______ _______ _______ ______
17

18 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Open Circuit in Branch Bus
When an open circuit occurs on the Branch Bus, communication with the control module connected
to that branch bus becomes disabled. In the example below, the BIU cannot communicate with
the TCM.
When an open circuit occurs in a branch bus, the resistance between HS-CAN High and HS-CAN
Low will be 60 Ohm, the same as under normal conditions.
Main bus
Branch bus
ELECTRIC
POWER
STEERING CM
COMBINATION
METER
BODY
INTEGRATED
UNIT
STEERING
ANGLE
SENSOR
VDC CM
120Ω120Ω
TCM
DATA LINK
CONNECTOR
A/C CM
ELECTRONIC
PARKING
BRAKE CM
ECM
Open Circuit Branch Bus
DLC TCM Connector
RT = ____________________ RT = ___________________
1 state 0 state 1 state 0 state
Voltage CAN High ________ _________ Voltage CAN High_______ ________
Voltage CAN Low ________ _________ Voltage CAN Low _______ ________
An open branch in the CAN results in the loss of communications with a control module. This
will result in the loss of all of the data that the control module supplied to the CAN as well
as the control that the control module provided to the vehicle. Diagnostics using resistance
or voltage will determine that the main CAN bus has no problems so you must check at the
affected control module.
Disconnect the affected control module. Failure to do so will result in the monitoring of signals or
voltage outputted from the control module that is not making contact with the CAN.
18

19 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Resistance checks should show continuity or very low resistance from the DLC to the CAN high
wire and CAN low wire. Check the CAN high wire first. Check from the DLC to the affected modules
electrical connector. Record the value and then check the CAN low wire the same way.
Voltage checks at the affected control module electrical connector should show the same value
monitored at the DLC.
If either resistance or voltage checks indicate that an open circuit exists then the next step is to
locate the CAN Joint Connector that connects the affected control module to the CAN.
Check the CAN Joint Connector for resistance or voltage to the affected module’s CAN wires.
Once the open circuit is located, repair the circuit and recheck the entire CAN operation.
Ground Short of CAN High Wire
When a short to ground occurs on the CAN high wire, the voltage difference between the CAN
high wire and CAN low wire is not high enough for any control module to receive and understand
the data being sent. The voltage level of the CAN high wire must always be higher than the CAN
low wire or communications on the CAN stop.
Main bus
ELECTRIC
POWER
STEERING CM
COMBINATION
METER
BODY
INTEGRATED
UNIT
STEERING
ANGLE
SENSOR
VDC CM
120Ω120Ω
TCM
DATA LINK
CONNECTOR
A/C CM
ELECTRONIC
PARKING
BRAKE CM
ECM
CAN Low
CAN High Wire
RT = ____________________
1 state 0 state
Voltage CAN High _____________ _______________
Voltage CAN Low _____________ _______________
19

20 June 2013
Electrical Systems Operation & Diagnosis Module (602)
Ground Short of CAN low Wire
When a short to ground occurs on the CAN low wire, the voltage and data on the CAN low wire is
not received by the CAN. The voltage of the CAN high wire drops because of the parallel wiring
with the terminators. The voltage levels of the CAN high wire will increase enough to allow data
to be sent and received throughout the CAN. The noise insulating properties of the CAN will be
lost but most vehicle systems will continue to function.
Main bus
ELECTRIC
POWER
STEERING CM
COMBINATION
METER
BODY
INTEGRATED
UNIT
STEERING
ANGLE
SENSOR
VDC CM
120Ω120Ω
TCM
DATA LINK
CONNECTOR
A/C CM
ELECTRONIC
PARKING
BRAKE CM
ECM
CAN Low
CAN Low Wire
RT = ____________________
1 state 0 state
Voltage CAN High _____________ _______________
Voltage CAN Low _____________ _______________
20
