Subaru Ultrasuede Shift Boot (WRX RED) User manual

ShiftBoot（WRXRED）
（Ultrasuede）
InstallationManual
Part Name
ShiftBoot 1
No.
①
！
J1310VC624 ShiftBoot（WRXRED）
WRX（2022MY〜）
GenuinePartNumber：
ApplicableVehicleModel：
ComponentPart
Advice
ForInstallationOperator
Precautions
Installationcompletiondrawing
Qty
1.Forsafety,stopthevehicleonaflatsurfaceandturnofftheengineandensurethat
theparkingbrakeisappliedbeforestartingtheinstallationprocess.
2.Sinceconnectorshavetobedetachedandattachedduringtheinstallationprocess,make
suretodisconnectthepowercordofbattery(-)negativesidebeforehandlingelectricalcomponents.
Followtheinstructionsofthelatestservicemanualfortheremovalandinstallationofthe(-)
negativesidecord.
3.Wheninstallingthispart,becarefulenoughnottoscratchthevehicleorpartswithtools.
4.Followtheinstructionsmarkedwithinthe"InstallationProcedure"fromthenext
sectiononward.
Thethingsthatshouldbefollowedandusefultoknowforthisproduct,aremarkedwith
inthismanual.
ThismanualdescribeshowtoinstallandhandletheShiftBoot.
Beforeinstallation,pleasereadthismanualforproperinstallation.
Afterinstallation,besuretohandthismanualtothecustomer.
Caution
Advice
１
△00
UltrasuedeisaregisteredtrademarkofTorayIndustries,Inc.
Manufacturer CORPORATION
①ShiftBoot

２
Installationprocedure
1.RemoveTrayASSYCenterLower.
（1）RemovetheShiftLever（Figure1）
（2）RemovetheTrayASSYCenterLower
 （Figure2）
（3）RemovetheMatfromtheTrayASSY
CenterLower（Figure3）
Whenremovingparts,becarefulnottodamage
thejointportion.
Mat
TrayASSYCenterLower
TrayASSYCenterLower
ShiftleverNposition
ShiftLever
Caution：Removethegroundterminalfromthebatterybeforehandlingelectricalcomponents.
Reference：Settheshiftleverto"N"positionbeforedisconnectingthenegativeterminalof 
thebattery. Movetheseattothefrontmostpositionbeforeremovingthenegative
terminalofthebattery.
Caution
TrayASSYCenterLowerisfixedat8placesby
clips.Youcaneasilyremoveitbyinsertingyour
handfromthetopoftheboottothefrontside
(arrowportion),andhookingyourhandonthe
parttopullitup.
Advice
2.Theinstallationshallbecompleted
byrestoringthepackagedTrayASSYCenter
Lowerinthereverseorderofremoval.
Figure1
Figure2
Figure3

3
Revisionhistory
MaintenanceMethod
■MaintenanceofUltrasuede ShiftBoot
●Cleaningofdirt
Wipingdirection
Wipingdirection
Regularcleaningaboutonceamonthisrecommended.
WipetheentireShiftBootwithacleanclothsoakedinlukewarmwaterofabout40℃
andsqueezedfirmly.
※Ultrasuede isaregisteredtrademarkofTorayIndustries,Inc.
Ifyouspilltheliquid,lightlyapplytissuepapertoabsorbit.Ifthedirtcannotberemoved,
followtheprocedurebelow.
①Lightlysoakaclothinasolutiondilutedwithaneutraldetergenttoaconcentrationof
5%to10%,andsqueezeittightly,thenwipetheShiftBootwiththeclothbyslidingfrom
toptobottomwhilepressingtheShiftBootdown.(Seefigurebelow).
②Lightlysoakasoftclothinlukewarmwaterofapprox.40℃,squeezeittightly,andwipe
theShiftBootwiththeclothbyslidingfromtoptobottomwhilepressingtheShiftBoot
down.Rinsetheclothwithlukewarmwaterandrepeatthisprocedure3timestoremove
themilddetergent.
△Content IssueDate
NewlyEstablished 2022.3.2500
※
