Subaru monitor system User manual

This supplement contains the descriptions and
instructions for the Monitor System.
Please read this supplement carefully before
using your monitor system.
Please keep this supplement with your Owner’s
Manual and leave it in the vehicle at the time of
resale. The next owner will need the information
it contains.
FUJI HEAVY INDUSTRIES LTD., TOKYO, JAPAN
is a registered trademark of FUJI HEAVY INDUSTRIES LTD.
Copyright © 2006, FUJI HEAVY INDUSTRIES LTD.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM

Contents
1
Safety Warnings.......................................................................2
Before Use ................................................................................3
Control Button Names ............................................................5
Displaying Vehicle Information Screen .................................6
Displaying Vehicle Information and Programming Vehicle
System Functions.................................................................8
Displaying fuel consumption information and programming for
the automatic alarm display ......................................................8
■Displaying fuel consumption information ....................................8
■Programming automatic alarm display for low remaining fuel
level ............................................................................................9
Displaying, retaining, and erasing driving record data ..............11
■Displaying driving record data ..................................................11
■Retaining driving record data ....................................................12
■Erasing driving record data ........................................................14
■Displaying retained driving record data list ..............................16
■Retaining driving record data while viewing a retained driving
record data list ..........................................................................17
■Erasing driving record data while viewing a retained driving
record data list ..........................................................................19
Displaying three meters ................................................................21
Maintenance schedule ..................................................................22
■Programming maintenance schedule ........................................22
Programming vehicle system functions ......................................26
■Programming display and answerback beep ............................26
■Touch panel sensing position adjustment ................................28
■Keyless entry system programming ..........................................30
■Programming other vehicle system functions ..........................31
■Alarm system and shock sensor................................................33
The calculator functions ................................................................34
The calendar functions ..................................................................36
■Displaying calendar ..................................................................36
■Adding a memo ........................................................................37
■Deleting a memo ......................................................................39
Displaying Statellite Radio Source ......................................40
Adjusting Brightness/Contrast ............................................42
Adjusting brightness/contrast ......................................................42
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 1

Safety Warnings
2
You will find a number of WARNINGs, CAUTIONs and
NOTEs in this supplement.
These safety warnings alert you to potential hazards that
could result in injury to you or others.
Please read these safety warnings as well as all other
portions of this supplement carefully in order to gain a
better understanding of how to use your Monitor system
safely.
NOTE
A NOTE gives information or suggestions how to make
better use of your Monitor system.
A WARNING indicates a situation in which serious
injury or death could result if the warning is ignored.
WARNING
A CAUTION indicates a situation in which injury or
damage to your vehicle including Monitor system, or
both, could result if the caution is ignored.
CAUTION
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 2

3
■Precautions when using the system
Before Use
Never disassemble or modify the monitor
Any attempt to disassemble or modify the monitor
could lead to a fire, an electric shock, or some other
type of accident.
Do not continue using the monitor if it malfunctions
If the system shows any sign of malfunctioning (for
example, the monitor gives no picture), stop using it
immediately and contact the nearest SUBARU dealer.
Continuing to use the system could lead to a fire, an
electric shock, or some other type of accident.
If the monitor gets contaminated, emits smoke or an
odd smell, stop using it
If a foreign object gets inside the system, liquid is
spilled onto the system, or the system emits smoke or
an unusual smell, stop using it immediately and
contact the nearest SUBARU dealer. Continuing to use
the system could lead to a fire, an electric shock, or
some other type of accident.
CAUTION
The displays contain mercury. Therefore, the displays
must be removed before vehicle disposal. Once the
displays have been removed, please reuse, recycle or
dispose of them as hazardous waste.
CAUTION
Read this manual first
Read this supplement carefully before using your
monitor system. We are not liable for accidents or
other problems resulting from failure to follow the
instructions in this supplement.
Avoid operating the monitor while driving
You should stop the vehicle in a safe place before
operating the monitor. For safety’s sake, some of the
monitor’s functions cannot be used unless the vehicle
is stationary.
Look at the monitor only when necessary
When you need to look at the monitor, do so for the
shortest time possible. Looking away from the road
for too long could lead to an accident.
Keep the volume low enough for you to hear outside
sounds
Keep the system’s volume level low enough for you to
be able to hear outside sounds while driving. To do
otherwise may mean that you are unable to react
appropriately to traffic conditions thus resulting in an
accident.
WARNING
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 3

4
Before Use
■About the monitor
• Subjecting the control buttons or liquid crystal display to
excessive shock could result in monitor deformation or
other damage.
• Keep any heat source (including lighted cigarettes) away
from the monitor. If a heat source is brought into contact
with the monitor’s cabinet and panel, they could be
deformed or otherwise degraded.
• In extreme cold, the monitor may operate sluggishly and
the display may dim. Such conditions do not indicate a
problem. They will disappear when the cabin temperature
rises to a normal temperature.
• Tiny black and white dots may occasionally appear in the
liquid crystal display. These dots are a normal characteristic
of the display. They do not indicate a problem.
• When the monitor’s display requires cleaning, gently wipe it
with a silicone cloth or other soft cloth. If necessary, spray
the cloth with neutral cleaning fluid. Be sure to wipe away
any cleaning fluid left on the display surface. Do not spray
the cleaning fluid directly onto the display surface. Spraying
cleaning fluid directly onto the display surface could cause
an adverse effect on internal components. It is also not a
good idea to wipe the display surface with a stiff cloth or
attempt to clean it using thinners, alcohol, or any other
volatile solvent. Doing so could leave scratches and/or erase
the control button labels.
• Do not allow the monitor to get wet. If it gets wet
(allowing, for example, to a spilled drink or wet umbrella),
its internal electronic circuitry may malfunction.
• In hot weather, cool the passenger compartment down
before using the monitor. The liquid crystal display operates
correctly at temperatures between 32°F and 140°F (0°C and
60°C). When the temperature exceeds 140°F (60°C), the
monitor’s circuit protection function is activated, causing the
display to dim.
Tribeca_Monitor-06.qxd 06.5.29 6:32 PM Page 4

5
Control Button Names
x
This button is used to display the menu screen of your navigation
system.
See the Owner’s Manual Supplement for the navigation system.
c
This button is used to switch the screen to a navigation system
screen from any other screen.
See the Owner’s Manual Supplement for the navigation system.
v
This button is used to zoom in the map displayed on the screen.
b
This button is used to display the Audio or RSE (Rear Seat
Entertainment) screen.
n
This button is used to display the vehicle information screen.
m
This button is used to adjust the brightness and contrast of the image
as well as to display a calendar (see Page 36 through 39, 42).
If the system has automatically turned down the brightness in order
to prevent excessive brightness following the illumination of
headlights or parking lights, pressing this button for more than one
second will return the display to the standard brightness level.
For further details on the MENU, MAP and DEST buttons, refer to the
Owner’s Manual Supplement for the navigation system.
z
This button is used to display the destination screen of your
navigation system.
See the Owner’s Manual Supplement for the navigation system.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 5

6
Displaying Vehicle Information Screen
The vehicle information screen provides a variety of information on your vehicle and driving. It also gives
ways to program certain functions available in your vehicle.
1First, press the button, then select any of the keys on the screen.
The screen displays the current fuel consumption rate, average fuel consumption
rate, and the range you can drive on the remaining fuel. See Pages 8 through 10.
The screen displays the driving record data. The monitor system can retain the record
data. See Pages 11 through 20.
The screen displays the reading of the following three meters: average fuel
consumption rate, current fuel consumption rate and throttle opening percentage.
See Page 21.
You can program your maintenance schedule and other maintenance-related items
from this screen. See Pages 22 through 25.
You can use a calculator. You can also convert units, for example, between miles and
kilometers.
You can program certain monitor and other system functions. See Pages 26 through
33.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 6

7
NOTE
• You can turn the outside air temperature display on or off in the map screen by selecting the key. See Page 26.
• You may not be able to use the vehicle information screen if data cannot be properly retrieved from the relevant vehicle systems.
Displaying Vehicle Information Screen
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 7

8
Displaying Vehicle Information and Programming Vehicle System Functions
Displaying fuel consumption information and programming for the automatic alarm display
■Displaying fuel consumption information
Use the following procedure to display the current fuel consumption rate, average fuel consumption rate,
and range you can drive on the remaining fuel.
1Select .
The fuel consumption information screen will be displayed.
This completes the procedure.
NOTE
• Current and average fuel consumption rates will change all time due to driving and other conditions. The displayed data, including
remaining fuel range data, may be different from the actual values. It is advisable that you refuel well in advance of reaching a displayed
distance.
• Displayed current and average fuel consumption rates are based on estimates during running, not on accurate measurements.
• The average fuel consumption rate is associated with the driving after the last resetting of each trip meter. If the A or B trip meter is
reset, the average fuel consumption rate will also be reset. After resetting the trip meter, the average fuel consumption rate will not be
displayed until the vehicle has been driven approximately 1 mile from the reset point.
Press the button.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 8

9
■Programming automatic alarm display for low remaining fuel level
You can program the display to make it automatically alert you of the correspondingly low fuel level
remaining.
1Select .
2Select for the desired alarm display item (“FUEL“). The selected
should change to .
Displaying Vehicle Information and Programming Vehicle System Functions
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.24 9:33 AM Page 9

10
Displaying Vehicle Information and Programming Vehicle System Functions
3Select .
This completes the procedure.
NOTE
• If is displayed for “FUEL“ (remaining fuel level), the automatic alarm display function has been activated for that item. To
deactivate the function, select . The indication should change from to .
• The current fuel consumption rate alarm will be displayed only when the navigation screen is being used.
• The screen displaying an alarm looks like this:
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 10

11
Displaying, retaining, and erasing driving record data
■Displaying driving record data
Use the following procedure to display the current driving record data (distance, time, and average fuel
consumption rate).
1Select .
The driving record screen will be displayed.
This completes the procedure.
NOTE
• If a vehicle’s trip meter is reset, the corresponding drive distance and time display (“TRIP A“ or “TRIP B“) will also be reset.
• The drive time display is associated with the amount of time the ignition switch has stayed on since the trip meter was reset.
• When the vehicle battery is removed for repair or other purposes, the time is reset, but the distance is not reset. To reset the distance,
press the trip meter knob. Please refer to the vehicle owner’s manual for further details.
• The maximum time display possible is 240 hours (10 days).
Displaying Vehicle Information and Programming Vehicle System Functions
Press the button.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 11

12
Displaying Vehicle Information and Programming Vehicle System Functions
■Retaining driving record data
Use the following procedure to retain the current driving record data.
1Select below the trip meter designation (TRIP A or TRIP B) of
the driving record data you wish to keep.
2Select or to specify the number of the history frame (data
storage location) where the driving record data are to be retained.
3Select .
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 12

13
4will appear, requesting you to confirm your selection. Select it.
5Select .
This completes the procedure.
NOTE
• A maximum of three different driving record data sets can be retained for each of the trip meters (TRIP A and TRIP B).
• Driving record data can be retained while viewing the retained driving record data list (see Page 17).
• If the data storage location (history frame) specified in Step 2 is already occupied by data, this data will be replaced with new data once
you have confirmed Step 4.
• When driving record data have been successfully retained in a history frame, the history frame’s heading will change from a number to
the date of data retention.
Displaying Vehicle Information and Programming Vehicle System Functions
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 13

14
Displaying Vehicle Information and Programming Vehicle System Functions
■Erasing driving record data
Use the following procedure to erase retained driving record data.
1Select below the trip meter designation (TRIP A or TRIP B)
about which you wish to erase the driving record data.
2Select or to specify the number of the history frame (data
storage location) where the driving record data to be erased are
retained.
3Select .
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 14

15
4will appear, requesting you to confirm your selection. Select it.
5Select .
This completes the procedure.
NOTE
There is no way to restore erased driving record data. Please use this procedure with caution so as not to accidentally erase any important
data.
Displaying Vehicle Information and Programming Vehicle System Functions
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 15

16
Displaying Vehicle Information and Programming Vehicle System Functions
■Displaying retained driving record data list
Use the following procedure to display a retained driving record data list.
1Select for the trip meter (TRIP A or TRIP B) about which you
wish to display the list.
This completes the procedure.
NOTE
Selecting on a driving record data list screen will cause the monitor system to go back to the driving record screen.
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 16

17
■Retaining driving record data while viewing a retained driving record data list
Use the following procedure if you want to retain driving record data while viewing a relevant data list.
1Select for the trip meter (TRIP A or TRIP B) about which you
wish to retain the driving record data.
2Select .
Displaying Vehicle Information and Programming Vehicle System Functions
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 17

18
Displaying Vehicle Information and Programming Vehicle System Functions
3Select the history frame (data storage location) in which the data are to
be retained.
4will appear, requesting you to confirm your selection. Select it if
the selection is correct.
5Select .
This completes the procedure.
NOTE
• A maximum of three different driving record data sets can be retained for each of the trip meters (TRIP A and TRIP B).
• When the data storage location (history frame) specified in Step 3 is already occupied by data, this data will be replaced with new data
once you have confirmed Step 4.
• When the driving record data has been successfully retained in a history frame, the history frame’s heading will change from a number
to the date of the data retention.
• Data retention is cancelled if you select in the “Select data “ box.
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 18

19
■Erasing driving record data while viewing a retained driving record data list
Use the following procedure if you want to erase retained driving record data while viewing a driving record
data list.
1Select for the trip meter (TRIP A or TRIP B) about which you
wish to erase the driving record data.
2Select .
Displaying Vehicle Information and Programming Vehicle System Functions
Press the button and then select .
Tribeca_Monitor-06.qxd 06.2.22 3:20 PM Page 19
