Sunjoy A102005804 User manual

Country of Origin: China Production Number: XXXXXXXXXX
A
SSEMBLY IN
S
TRUCTION
ITEM#：A102005804
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
[e-mail]

2 / 36
Country of Origin: China
• This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
• Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as
fences, garages, houses, overhanging branches, laundry lines, or electrical wires.
• This gazebo is not to be regarded as part of a building/house structure. The gazebo is
to be anchored onto the ground for added safety. Do not assemble the gazebo onto
soil/earth ground. It is best advisable to have the gazebo built onto a wooden deck or
concrete ground for stability. If it is to be build onto a wooden deck/ground, do
ensure that the wooden deck/ground has a strong foundation. It is advisable to use
appropriate floor plugs (not provided) to anchor the gazebo onto the wooden/concrete
ground.
• Some structures may require two or more people to install safely. Check for
underground utilities before digging or driving stakes into the ground.
• During installation, follow all safety warnings provided with your tools, and use safety glasses.
• In case you set up more than one gazebo, keep a minimum distance of 10' (3 m)
between the gazebos.
• Any assembly or maintenance of the product must be carried out by adults only.
• Arrange necessary manpower when assembling or moving the product.
• Some parts may contain sharp edges. Wear protective gloves if necessary.
• Keep children and pets away while setting up the gazebo.
• Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
• Repairing and replacing parts should be done by a qualified technician.
• This gazebo is intended for decorative and sunshade purposes only, and it is not
designed to withstand harsh weather, including high winds, rain, and snow.
• Do not light any fires inside or near the product!
• Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
• Do not hang heavy weights on the roof frame.
• Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
• Retain the original packaging to store the gazebo.
Important Safety
Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped. Do
not attempt to assemble the gazebo if any parts are missing.

3 / 36
Country of Origin: China
• Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position them on the floor in front of
you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Needed for assembly:（The following tools are not included）
IMPORTANT:

4 / 36
Country of Origin: China
EXPLODED DRAWING

5 / 36
Country of Origin: China
Parts List
Label Part Number Description Qty Part Image
08 P000200227 Post 4
01 P000400506 Outer Left Long
Beam 2
02 P000400507 Outer Right Long
Beam 2
03 P000400508 Outer Left Short
Beam 2
04 P000400509 Outer Right Short
Beam 2
05 P000400510 Inner Long Beam 4
06 P000400512 Inner Short Beam
(Short) 4
07 P000400511 Inner Short Beam
(Long) 4
10 P005000200 Arc Support 1 4
11 P005000201 Arc Support 2 4
A P00610021602
Base Cover 4
B P00010025802 Base 4
C P00560042801
Middle Decorative
Plate 4
D P00050025102
Middle Beam
Connector 4
E P00560042901
Corner Decorative
Plate 4
F P00050024802
Slanting Beam
Connector 4
G P00050157002
Big Roof Long
Connector Tube 2

6 / 36
Country of Origin: China
J P00050157401
Big Roof Short
Connector Tube 2
K P00060197102 Big Roof Slanting
Beam 4
L P00060198302
Big Roof Middle
Beam 4
M P00050156303
Small Roof
Connector 1
N P00060105901
Small Roof Oblique
Beam 4
P P00060196502
Small Roof Top
Beam(Long Side) 2
Q P00060196201
Small Roof Top
Beam(Short Side) 2
R P005800001 Hook 1
S P00070094501
Small Roof
Panel(Short Side) 2
T P00070094701
Small Roof
Panel(Long Side) 2
U P00080019101
Small Roof Slanting
Beam Cover 4
V P00090015502 Top Cover 1
W P00060198902
Big Roof Top
Beam(Upper) 4
X P00060199003
Big Roof Top
Beam(Upper) 4
Y P00060199902
Big Roof Top
Beam(Middle) 4
AA P00060200003 Big Roof Top
Beam(Middle) 4

7 / 36
Country of Origin: China
AB P00060201202
Big Roof Panel
Flashing(Short
Side)1
2
AC P00060201603
Big Roof Panel
Flashing(Short
Side)2
2
AD P00060201303
Big Roof Panel
Flashing(Long Side
Left)
2
AE P00060201702
Big Roof Panel
Flashing(Long
Side)2
2
AF P00570034502
Left Mosquito
Netting Rod 2
AG P00570034602
Right Mosquito
Netting Rod 2
AJ P00570034703
Left Mosquito
Netting Rod (Long
Side)
2
AK P00570034803
Right Mosquito
Netting Rod (Long
Side)
2
AL P00070103503
Big Roof Middle
Panel 2
AM P00070102102
Big Roof Big Panel
(Left) 4
AN P00070102602
Big Roof Big Panel
(Right) 4
AP P00070101402
Big Roof Small
Panel (Left Middle) 4

8 / 36
Country of Origin: China
AQ P00070101602
Big Roof Small
Panel (Right Middle)
4
AR P00070101002
Big Roof Small
Panel (Left) 4
AS P00070101202
Big Roof Small
Panel (Right) 4
AT P00080034403
Big Roof Inclined
Beam Cap 4

9 / 36
Country of Origin: China
Hardware Pack
Label Part Number Description Qty
Add
Part Image
H1 H100010047 Bolt M6*20 178 9
H2 H100010069 Bolt M6*35 4 1
H3 H100010059 Bolt M6*45 8 1
H4 H010010449 Bolt M10*205 8 1
H5 H100010054 Bolt M8*25 24 2
H6 H100010055 Bolt M8*35 16 1
H7 H030050058 Screw M5*30 64 4
H8 H030050057 Screw M5*40 64 4
H9 H030030013 Bolt M8*35 16 1
H10 H030010031
Screw
M10*80 8 1
H11 H050030002
Flat Washer
M8 16 1

10 / 36
Country of Origin: China
H12 H050030003
Flat Washer
M10 24 2
H13 H040050026
Non-slip Nuts
M10 8 1
H14 H040090004
T-Nut
M8*8 24 2
H15 H040090005
T-Nut
M8*20 16 1
H16 H090990002 M3 Drill 2 0
HS H070010003
Stake
Φ8*180 8 0
HW1 H090010017 M6 Wrench 2 0
HW2 H090030005 Allen Key M8 1 0
HW3 H090010015 M10 Wrench 2 0
