Sunjoy L-GZ238PST-11A User manual

Assembly Intruction
Item: L-GZ238PST-11A
IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care directions before
attempting to assemble.
1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved.
2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightening.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury, possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible damage will occur to the
structure.
5. Never barbecue under this gazebo or use lanterns that contain naked flames.
6. This package contains small items and plastic bags that should be kept away from children.
7. Ensure that all connectors & poles are firmly secured in position fully. It is important to do so before use so
as to avoid collapsing or damage to the item, which could result in injury.
8. WARNING: Keep flame and heat sources away from the gazebo fabric. The fabric may burn if it is exposed

to prolonged contact with a source of heat. The application of any foreign substance to the gazebo fabric may
render the flame-resistant properties ineffective.
Tools required: Ladder, Hammer Screwdriver (not included)

Pole 1 A1 2
Pole 2 A2 2
Long screen B 2
Small screen C 2
Corner top beam D 4
Big top connector E 1
Small top connector F 1
Small top bar G 4
Shelf H 2
Supporter I 4
Hook J 1
Small canopy K 1
Big canopy L 1
Parts List

AA M6X20 Bolt 16 PCS
BB M6 Flat washer 28 PCS
CC M6X40 Bolt 8 PCS
DD M6 Nut 8 PCS
Z M6 Wrench 1 PC
Hardware Pack 1
Fig.1: Attach Screen C (B) to Pole A1 (A2) by Bolt (AA) and Flat washer (BB).
Fig.2: Attach Hook (J) to Big top connector (E). Then insert Corner top beam (D) into Big top connector (E).
Fig.3: Connect Corner top beam (D) and Pole 2(A2) by Bolt (CC), Flat washer (BB), and Nut (DD).
Fig.4: Insert Small top bar (G ) into Small top connector (F).
Fig.5: First put the big canopy (L) onto the top of the gazebo (Do not fully spread). Then connect Small top
bar (G ) and Corner top beam (D) by Bolt (CC), Flat washer (BB), and Nut (DD).

Fig.6: Attach Supporter (I) to Shelf (H) by Bolt (EE) and Flat washer (BB).
Fig.7: Attach Shelf (H to Pole A1 (A2) by EE and Flat washer (BB).
Fig.8: Fix Supporter (I) to Pole A1 (A2), then insert the pin on the pole into the hole at the end of the
Supporter (I).
Fig.9: Using the Stake (FF) to fix up the Gazebo.
EE M6X20 Bolt 8 PCS
BB M6 Flat washer 8 PCS
FF Φ8X180MM Stake 12 PCS
GG Touch-paint 1PCS
Hardware Pack 2

USE & CARE
1. This Gazebo is not a permanent structure and should be disassembled & stored away after use.
2. Do not repack your gazebo until completely dry.
3. This Gazebo must be assembled by two adults or more.
4. This Gazebo must not be left erect in windy conditions.
WARNINGS
1. Assembly Instructions must be followed.
2. Pegs supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.
