Sunjoy L-DNC475PST User manual

Northwood Hard Top Swing
Assembly Instruction
Item# L-DNC475PST

IMPORTANT:
Please read and follow all safety statements, warnings,
assembly instructions, use & care directions before attempting
to assemble.
WARNING:
1. When installing and assembling your swing, it is
recommended that 2 or more adults are involved.
2. This product is intended for outdoor use only and should be
placed on flat, horizontal ground.
3. Ensure enough clearance around the product.
4. This package contains small items and plastic bags that
should be kept away from children.
PREPARATION
Before beginning assembly of product, make sure all parts are
present. Compare parts with package contents list. If any part
is missing or damaged, do not attempt to assemble the
product.

Part List
No#
Description
Qty
L1
Armrest 1
1
L2
Armrest 2
1
M
Back board
1
N
Seating board
1
O
Hanging bar 1
2
P
Hanging bar 2
2
Q
Back horizontal tube
1
R
Side panel
2
S
Stake cover
4
T
Peg slice
4
U
Back cushion
3
V
Seat cushion
1
W
Bloster pillow
2
No#
Description
Qty
A
Cover board
1
B
Top horizontal tube
1
C
Top board
2
D
hook
1
E
Central support part
2
F
Back horizontal beam
1
G
Sidehorizontal beam
2
H
Front beam
1
I
Hanging bar connect
tube
2
J
Big hook
2
K1
Post 1
1
K2
Post 2
1
K3
Post 3
1
K4
Post 4
1

Hardware part list
No#
Name
Qty
AA
M6*15 Hex Bolt
48
BB
Flat washer M6
86
CC
M6*25 Hex Bolt
20
DD
M6*35 Hex Bolt
18
EE
M8*15 Hex Bolt
4
HH
M8 Flat washer
4
FF
M6/M8 Wrench
1
GG
Stake D8*180
8
Step1：
Fig.1: Attach the stake cover (S) to the post
(K1/K2/K3/K4). Then attach the post onto
stake slice (T) by bolt (AA) and flat washer
(BB).

Fig.5: Connect side panel (R) to Post (K1/K2/K3/K4) by hex bolt (CC) and flat
washer (BB).
Fig.6: Connect back horizontal tube (Q) to Post (K1/K4) by hex bolt (AA) and
flat washer (BB).
Fig.7: Connect hanging bar connect tube (I) to back horizontal beam (F) and
front horizontal beam (H) by hex bolt (AA) and flat washer (BB).
Fig.2: Connect back horizontal beam (F) to Post (K1/K4) by hex bolt (CC) and flat
washer (BB).
Fig.3: Connect side horizontal beam (G) to Post (K1/K2/K3/K4) by hex bolt (CC) and
flat washer (BB).
Fig.4: Connect front horizontal beam (H) to Post (K2/K3) by hex bolt (AA) and flat
washer (BB).

Fig.8: Attach hook (D) to top horizontal tube (B).
Fig.9: Attach one end of top board (C) to top horizontal tube (B) by hex bolt (AA)
and flat washer (BB).
Fig.10: Attach the other end of top board (C) to back horizontal beam (F) and front
horizontal beam (H) by hex bolt (AA) and flat washer (BB).
Step 2：

Step 3：
Fig.11: Put the central support part (E) to the middle position of top board (C) and back
horizontal (F) and connect them by hex bolt (AA) and flat washer (BB).
Fig.12: Connect central support part (E) to top board (C) by hex bolt (AA) and flat washer
(BB).
Fig.13: Put cover board (A) onto the top horizontal tube (B) and connect them by hex bolt
(DD) and flat washer (BB).
Fig.14: Put the seat board (N) on the
connection area of armrest
(L1/L2) and connect the seat
board (N) to armrest (L1/L2)
by hex bolt (DD) and flat
washer (BB).
Fig.15: Attach the back board (M) to
armrest (L1/L2) by hex bolt
(DD) and flat washer (BB).

Fig.16: Attach the seat board (N) and back board (M) by hex bolt (DD) and flat
washer (BB).
Fig.17: Attach hanging bar (O) to armrest (L1/L2) by hex bolt (EE) and flat
washer (HH).
Fig.18: Attach hanging bar (P) to armrest (L1/L2) by hex bolt (EE) and flat
washer (HH). (Remark: The hole of hanging bar (P) should face
downward.)
Fig.19: Attach hanging bar (P) to armrest (L1/L2) by hex bolt (DD) and flat
washer (BB).
Fig.20: Attach big hook (J) to hanging bar connecting tube (I).
Fig.21: Hang the hanging bar (O/P) to big hook (J) and tighten.

Fig.22: Put the seat cushion (V) onto the seat board and put the back
cushion (U) onto the seat board. Attach the hook-and-loop tape of back
cushion (U) and seat cushion (V) to the seat board tube. Put the bolster
pillow (W) onto the seat cushion (V).
Fig.23: Lift up the stake cover (S) and fix the stake slice by stake (GG).
Step4：

CUSTOMER SERVICE
Sunjoy Group warrants to the original purchaser that this item is free from
defects in workmanship and materials of your item provided the item was
factory-sealed at the time of purchase and is maintained with care and used
only for personal, residential purposes. The item is warranted to be free from
defects in material or workmanship for a period of 6 months. Should any
manufacturing defect arise within this warranty period, Sunjoy Group will repair
or replace (at our option) any defective merchandise upon proof of purchase;
however, transportation and delivery costs, as well as labor and material
charges to remove or replace parts, remain the responsibility of the purchaser.
A purchaser of an "open box," previously-returned, or "clearance" item, as well
as original purchasers outside of the warranty period, may obtain replacement
parts from Sunjoy Group for products in current production, at nominal cost.
If you are within the return policy that most stores have, you do have the option
of returning this item back to the store which you bought it from for an
exchange of the same item, or a refund of the purchase.
If you are within or beyond the return policy that most stores have, and need
tech. assistance or replacement parts, please call Sunjoy Group at 1(866)
578-6569 from 8:00 am EST to 8:00 pm PST or e-mail to
[email protected] or visit www.sunjoyonline.com to place your
order or fax your parts replacement order form together with the purchase
receipt to 1 [phone] for assistance.
