Sunjoy Royal Hardtop Gazebo User manual

1
Royal Hardtop Gazebo
Item#˖L-GZ066PST
Congratulations on your purchase of our SUNJOY Royal Hardtop Gazebo. Our clear, easy to follow,
step-by-step instructions will guide you through the assePbly process from start to finish.
WARNING:
zTHIS UNIT IS HEAVY! For safety, DO NOT assemble this item alone. 6 to 8 people are recommended for safe
assembly.
zKeep all children and pets away from assembly area. Children and pets should be supervised when they are in the
assembly area of the Gazebo.
zDo not assemble less than 6 ft / 1.8 m from any obstruction such as a fence, garage, house, overhanging branches,
laundry line or electrical wires.
zSome parts may contain sharp edges. Wear protective gloves.
zWhen assembling and using this product, basic safety precautions should always be followed to reduce the risk of
personal injury and damage to equipment. Please read all instructions before assembly and usage.
zFor outdoor use only. Install on level ground.
zCheck all bolts for tightness before and during usage.
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at 1-866-578-6569 from
8:30AM to 5:30PM EST, or email us at [email protected], or visit www.sunjoydirect.com for
assistance.

2
1A (x4) Left Rain Gutter
1B (x4) Right Rain Gutter
1C (x4) Straight Pole
Connector
1D (x4) Tilting ole
Connector
2A (x4) Top Tilting Pole 2B (x4) Top Straight Pole
2C (x4) Top Long Connector
(left) 2D (x4) Top Long Connector (right)
2E (x4) Top Short
Connector (left) 2F (x4) Top Short Connector(right)
2G (x1) Small Top Frame
3A (x1) Finial
3B (x1) Small Top cover
3C (x4) Small Top Roof
Sheet
3D (x4) Small Frame Corner
cover 3E (x4) Small Top Tilting
Pole
3F (x1) Center Fitting
4A (x4) Top Large Roof
Sheet(left)
4B (x4) Top Large Roof
Sheet(right)
4C (x4) Top Middle Roof
Sheet (left)
4D (x4) Top Middle Roof
Sheet(right) 4E (x4) Top Small Roof
Sheet t(right)
4F (x4) Top Small Roof
Sheet t(left)
4I (x16) Long Cover
Presser
4J(x8) Short Cover Presser 4K (x1) Hanger Pole
4L (x1) Hook
4M(x4) Upper Cover Peg
5A (x4) Large Roof Down
Cover 5B (x4) Large Roof Upper Cover
6A (x4) Column 6B (x4) Column Base
6C (x4) Base Protector
6D (x4) Column Top
6E (x4) L-Shaped Cover
Parts List NOTE: Please lay something underneath all the parts to avoid scratching.

3
Tools Required For Assembly (not included):
Phillips screwdriver
Hammer
Drill
Ladder (minimum 8.2 ft / 2.4 m)
Item Identification
For ease of identification, all parts are labeled to correspond to the step number in which the part is used. The Gazebo is designed to be
constructed in 6 main steps as outlined below.
STEP #1 – RAIN GUTTER
LL (x8) Bolt M6 x35mm
BB (x36) Flat Washer M6
CC (x8) Screw M6 x 15mm
KK (x20) Screw M6 x 15mm
WW (x2) Wrench M6
1. Insert Left Rain Gutter (1A) into Right Rain Gutter (1B),tighten with Screw (KK) and Flat Washer BB. (Fig.1) Note: Do not
tighten the other side.
2. Insert 1 of the rest Left Rain Gutter (1A) into baffle on assembled Right Rain Gutter(1B),tighten with Bolt (LL) and Flat
Washer (BB) .(Fig. 2)
3. Connect Straight Pole Connector (1C) with assembled Left Rain Gutter (1A) and Right Rain Gutter (1B), tighten with Flat
Washer (BB) and Screw (CC). (Fig 3)

4
STEP #2 – LARGE TOP FRAME
BB (x60) Flat Washer M6
KK (x48) Screw M6 x 15mm
DD (x12) Screw M6 x 55mm
EE (x12) Nut M6
1. Attach one end of Top Tilting Pole (2A) to Tilting Pole Connector (1D). Tighten with Screw (DD) ,Flat Washer (BB) and Nut EE. (Fig
4.1). Attach the other end of Top Tilting Pole (2A) to Small Top Frame (2G), tighten with Screw (KK) and Flat Washer (BB). (Fig 4.2)
2. Attach one end of Top Straight Pole (2B) to Straight Pole Connector (1C). (Fig 5.1)
Attach the other end of Top Straight Pole (2B) to Small Top Frame (2G) tighten with Screw (KK) and Flat
Washer (BB).(Fig 5.2)
Connect Tilting Pole Connector (1D) with assembled Left Rain Gutter (1A) and Right Rain Gutter (1B), tighten with Screw
(KK) and Flat Washer (BB).( Fig.3-1)

5
STEP #3 – SMALL FRAME
BB (x24) Flat Washer M6
KK (x12) Screw M6 x 15mm
DD (x4) Screw M6 x 55mm
EE (x4) Nut M6
FF (x8) Screw M6 x 40mm
1. Attached Small Top Tilting Pole (3E) to Center Fitting (3F), tighten with Screw (DD), Flat Washer (BB) and Nut (EE).
( Fig.7.1)
2. Attach the other end of Small Top Tilting Pole (3E) to Small Top Tilting Pole (3E) ,connect Small Top Tilting Pole(3E)
and Small Top Connector (2G) by Screws (KK) and Flat Washer (BB). (Fig 8.2)
3. Connect Top Short Connectors Left (2E) and Right (2F),Top Long Connectors Left (2C) and Right (2D) to Top Straight Poles
(2B) and Top Tilting Poles( 2A) by using Flat Washer (BB) and Screw (KK) (Fig 6.1,Fig 6.2) (Note: UP label should be facing up)

6
STEP #4 – COLUMNS
AA (x48) Bolt M6 x 20mm
BB (x64) Flat Washer M6
JJ (x32) Spring Washer M6
KK (x16) Bolt M6 x 15mm
GG (x16) Stakes 8 x 250
QQ (x16) Expansion Bolt M6 x 70
3. Place Small Top Roof Sheet (3C) to Small Top Frame, securing them with Screw (KK) and Flat Washer (BB )
(Fig.8.1)..
4. Place Small Top Corner Cover (3D) to Small Top Roof Sheet (3C), securing them with Screw (FF) and Flat
Washer (BB) (Fig 8.2).
5. Attach Small Top Cover (3B) and Finial (3A) to Small Top Frame (3F) (Fig 8.3)
1. Slide Base Protector (6C) into Column (6A) before connecting to the Colum Base (6B)
Connect Column Base (6B) to Column (6A) with Bolt (AA), Spring Washer (JJ) and Flat Washer (BB). (Fig 9.1)
2. Fasten Column (6A) and Column Top (6D) with Bolts (AA), Spring Washers (JJ) and Flat Washers (BB). (Fig 9.2)

7
STEP #5 – ROOF PART 1
KK (x80) Bolt M6 x 15mm
FF (x8) Screw M6 x 40mm
BB (x88) Flat Washer M6
3. Attach assembled Column Top (6D) to Left Rain Gutter (1A) and Right Rain Gutter (1B), tighten with Bolt (AA) and Flat Washer
(BB). (Fig 10.1)
4. Attach Tilting Pole Connector (1D) to Column Top (6D), tighten with Bolt (KK) and Flat Washer (BB). (Fig 10.2)
5. Attach L-Shaped Cover (6E) to Column Top (6D), tighten with Bolt (KK) and Flat Washer (BB). (Fig 10.3)
6. Place the Stakes (GG) through the Column Base (6B) into the ground (Fig 11.1)
7. Drill 4 holes (Ħ10*80MM(min)) into the ground with a percussion drill. Align the Column Base (6B) with the
drilled holes and fasten with the Expansion Bolt (QQ).(Fig 11.2)
For Set Up on Soft Ground For Set Up on Hard Ground

8
1. Place Planter Hook (4L) to Hanger Pole (4K).(Fig 12.1)
2. Place Top Large Roof (4A) and Top Large Roof Sheet (4B) on Top Frame, fasten with Bolts (KK) and Flat Washer (BB).
(Fig 12.2, Fig 12.3) Repeat for remaining sides.
3. Attach Hanger Pole (4K) to Small Top Frame (2G) with Upper Cover Peg (4M) on, tighten with Bolt (KK) and Flat
Washer (BB).( Fig.12.4)
4. Attach the remaining Top Large Roves (4C),(4D),(4E),(4F) onto Top Tilting Poles (2A). (Fig 13.1)
5. Place the long Cover Presser (4l) and Short Cover Presser (4J) on the Top of Roof Sheets, tighten with Bolt (KK) and
Flat Washer (BB). (Fig 13.2)
6. Insert one end of Large Roof Upper Cover (5B) into holes on Small Top Tilting Pole (3E), pressed the other end
of Large Roof Down Cover (5A),Tighten with Screw (FF) and Flat Washer (BB). Assembly Completed!

9
Care & Maintenance
Steel components of garden accessories and furniture are treated with rust inhibiting paint. However, due to the nature of steel,
surface oxidation (rusting) will occur if this protective coating is scratched.
To minimize this condition, it is recommended that care be taken when assembling and handling the product, in order to prevent
the paint from being scratched.
Limited Warranty:
Sunjoy Industries warrants to the original purchaser that this item is free from defects in workmanship and materials for a period
of 2 year from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care
and used only for personal, residential purposes. Should any manufacturing defect arise within this warranty period, Sunjoy
Industries will repair or replace (at our option) any defective merchandise upon proof of purchase; however, transportation and
delivery costs, as well as payments to a third party for assembly or disassembly of the item, remain the responsibility of the
purchaser. A purchaser of an "open box," previously-returned, or "clearance" item, as well as original purchasers outside of the
warranty period, may obtain replacement parts from Sunjoy Industries for products in current production, at nominal cost.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature, vandalism,
misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of purchase (dated
register receipt) is required for warranty claims. Warranty is to the original purchaser and is non-transferable. Any replacement
of warranted items will be in the original style and color, or a similar style and color if the original is unavailable or has been
discontinued. As some states do not allow exclusions or limitations on an implied warranty, the above exclusions and limitations
may not apply. This warranty gives you specific rights, and you may also have other rights, which vary from state to state.
Back up hardware pack
AA (x2) Bolt M6 x 20mm
BB (x6) Flat Washer M6
CC (x2) Screw M6 x 15mm
DD (x1) Screw M6 x 55mm
EE (x2) Nut M6
FF (x1) Screw M6 x 40mm
JJ (x2) Spring Washer M6
KK (x4) Bolt M6 x 15mm
LL (x1) Bolt M6 x35mm
GG (x1) Stakes 8 x 250
QQ (x1) Expansion Bolt M6 x 70
