Sunjoy D-GZ841PST-C User manual

Assembly Instructions
Item# D-GZ841PST-C (PC Top)
Congratulations on your purchase of our SUNJOY 12’x10’ Hardtop Gazebo. Our clear, easy to
follow, step-by-step instructions will guide you through the assembly process from start to
finish.
●This unit is heavy. Do not assemble this item alone. 6-8 people are recommended for safe
assembly.
WARNING:
●Keep all children and pets away from assembly area. Children and pets should be supervised
when they are in the area of the Gazebo construction.
●Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
●Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the
product. Please read all instructions before assembly and use.
●Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
●Assemble on level ground.
IMPORTANT
Please do not return this product to the store. For technical assistance on assembly or replacement
parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am EST to 8:00 pm PST or fax the
replacement part form which is in the box to 1-740-283-3549 or Email [e-mail]
for assistance.

Big panel 1 A1 2
Big panel 2 A2 2
Small panel 1 B1 2
Small panel 2 B2 2
Fence C 8
Connector D 4
Top connector E 4
Lower connector F 4
Short beam1 G1 2
Short beam2 G2 2
Long beam1 G3 2
Long beam2 G4 2
Long top bar I1 2
Corner frame I2 2
Oblique beam J 4
Middle beam 1 K1 2
Middle beam 2 K2 2
PC piece 1 M1 4
PC piece 2 M2 4
PC piece 3 M3 4
PC piece 4 M4 4
PC piece 5 M5 4
PC piece 6 M6 2
PC piece 7 M7 2
Parts List

Big left cover N1 4
Big right cover N2 4
Middle cover N3 2
Small cover 1 O1 2
Small cover 2 O2 2
Left rail P1 4
Right rail P2 4
Middle rail P3 2
Center plate Q1 6
Corner plate Q2 8
Hook R 1
Small top connector S 1
Cover T 1
Small slanted beam U 4
Panel wall W 8
Long netting bar 1 W1 2
Long netting bar 2 W2 2
Short netting bar 1 W3 2
Short netting bar 2 W4 2
Cover flap 1 X1 2
Cover flap 2 X2 4
Cover flap 3 X3 4

BB M6 Flat washer 124 PCS
DD Nut 16PCS
FF M6X15 Bolt 64 PCS
GG M6X70 Bolt 16 PCS
LL M6X35 Bolt 16 PCS
HH M6X25 Bolt 12 PCS
Z M6 Wrench 2 PCS
Hardware Pack 1
Fig.1: Secure the fence (C) to the
panels (A1/A2/B1/B2) by using bolts
(FF) and flat washers (BB).
Fig.2: Connect big panel 1 (A1) and small panel 1 (B1) by using
bolts (JJ), flat washers (BB), repeat this for big panel 2 (A2) and
small panel 2 (B2).

Hardware Pack 2
Fig.3: Fix top connector (E) and
lower connector (F) onto short
beam / long beam (G1/G3) by
using bolts (GG), flat washers
Fig.4: Attach assembly beams
(G1/G2) to big panel 1 / big panel 2 /
small panel 1 / small panel 2 (A1/A2
/B1/B2) by using flat washers (BB),
bolts (FF) and bolt (LL) separately.
Fig.5: Secure the connector (D) to
the beams by using bolts (FF) and
flat washers (BB).
AA M6X15 Screw 24 PCS
BB M6 Flat washer 80 PCS
FF M6X15 Bolt 4 PCS
DD Nut 16 PCS
EE M6X20 Bolt 20 PCS
JJ M6X60 Screw 16 PCS

Fig.7: Fix oblique beam (J)
to corner frame (I2) by
using bolts (EE) and flat
washers (BB)
Fig.9: Attach middle beam 1
(K1) to (I2) by using by
using bolts (EE) and flat
washers (BB)
Fig.11: Attach the upper side of middle beam 2
(K2) to long top bar (I1) by using bolts (EE), flat
washers (BB)
Fig.13: Connect cover flap
(X2) to small slanted beam
(U) and fix small slanted
beam (U), cover flap 2
(X2), small top connector
(S) by using bolts (JJ), nuts
(DD), flat washers (BB)
Fig.15: Insert and screw
the hook (R) tightly into the
corresponding hole on the
small top connector (S).
Fig.6: Insert long top bar (I1) into corner frame (I2) and fix them by using bolts (AA) and flat washers (BB).
Fig.11-1: Attach the lower side
of middle beam 2 (K2) to lower
connector (F) by using bolts
(JJ), flat washers (BB), nuts
(DD).
Fig.12-1: Attach netting
bar1/2/3/4(W1/W2/W3/W4)
to middle beam 1/2 (K1/K2)
by using bolts (AA), flat
washers (BB).
Fig.12-2: Fix the other side
of netting bar 1/2/3/4
(W1/W2/W3/W4) to oblique
beam (J) by using bolts
(AA), flat washers (BB).
Fig.8:Connect cover flap 3 (X3)
to the lower end of oblique beam
(J) and fix oblique beam (J),
cover flap 3 (X3), top connector
(E) by using bolts (JJ), nuts (DD),
flat washers (BB)
Fig.10: Connect cover flap 1
(X1) to middle beam 1 (K1), and
fix cover flap 1 (X1) to middle
beam 1 (K1), lower connector
(F) by using bolts (JJ), nuts
(DD), flat washers (BB).
Fig.14: Fix small slanted
beam (U) and corner frame
(I2) by using bolts (FF), flat
washers (BB).
K2

Hardware Pack 3
AA M6X15 Screw 14 PCS
BB M6 Flat washer 16 PCS
HH M6X60 Bolt 2 PCS
Fig.16: Insert the PC piece
(M6/M7) into the rail on the small
slanted beam (U).
Fig.17: Insert the Small cover (O1 and O2)
into the lower of the PC piece 6/7 (M6 and
M7), then secure the corner plate (Q2) to
the small slanted beam (U) through three
holes with screws (AA) and flat washers
(BB).
Fig.18: Secure the cover (T) to the
small top connector (S) with bolts
(HH) and flat washers (BB)
Fig.19: Insert the PC piece 3/4
(M3/M4) into the middle beam
(K1/K2) and Oblique beam (J),
then insert the rails (P1/P2) into
it. Insert the PC piece 1/2
(M1/M2) into the middle beam
(K1/K2) and Oblique beam (J).
Repeat this step to install the
right roof pieces.
Fig.20: Insert the PC piece
5 (M5) into the middle
beam 2 (K2); then insert
the middle rail (P3) into it.
Insert the PC piece (M5)
into the middle beam 2
(K2).
Fig.21: Insert the cover (N1,
N2 and N3) into the lower of
PC pieces; then secure the
center plate (Q
1) to the
middle beam 2 (K2) through
three holes with screws
(AA) and flat washers (BB).
Fig.22: Secure the corner
plate (Q2) to the Oblique
beam (J) through three
holes with screws (AA) and
flat washers (BB).

IMPORTANT:
Hardware Pack 4
KK Φ6X260 Stake 16 PCS
Fig.24: Secure the whole gazebo
to the ground with stakes (KK).
Fig.23: Assemble the panel Wall
(W) by using velcro straps.

1. Keep all children and pets away from assembly area. Children and pets should be
supervised while gazebo is being assembled.
2. The assembled gazebo should be located at least 6 feet (2 m) from any obstruction such as
a fence, garage, and house, overhanging branches, laundry lines or electrical wires.
3. This unit is heavy. Do not assemble this item alone. Six people are recommended for safe
assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and use.
6. For outdoor use only. Install on level ground. 16 stakes are provided to secure the gazebo in
the ground. If you wish to secure the pavilion to a wood deck or concrete surface, use 16
anchors suited for these surfaces (anchors not included).
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some jurisdictions may
require permits for installation and use. Some special procedures may be valid in your area.
9. While this gazebo is manufactured to withstand strong force winds through only the supplied
ground stakes, securing the gazebo to a deck, concrete patio or a stronger base, in areas
subject to frequent severe weather should be considered.
NOTE: The gazebo’s roof and structure are not guaranteed against extreme weather
conditions (storms, high winds, etc.). If the gazebo is not dismantled for the winter, snow must
be cleaned off regularly. Any damage caused by snow accumulation is not covered by the
warranty.
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials
and workmanship of your item provided the item is maintained with care and used only for
personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1)
year. We don't reimburse for transportation or delivery costs, or compensate the individual or
any outside party for assembling or disassembling the product.
Items used for commercial, contract, or other non-residential purposes, or items damaged due
to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or
rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for
warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not
apply. This warranty gives you specific rights, and you may also have other rights, which vary
from state to state.
Exclusions:
Maintenance:

Our iron/steel components for garden accessories and patio items are coated with rust
inhibiting paint that protects it from rusting. However, due to the nature of iron, surface
oxidation (rusting) will occur once these protective coatings are scratched.
This is a natural
process and is not a defect! To minimize this condition, we recommend care when assembling
& handling the product to prevent scratching the paint. Should any scratching or damage occur,
we recommend immediate touch-up with rust inhibiting paint. Surface rust can also be easily
removed with a very light application of common cooking oil. If surface oxidation (rusting)
occurs and if no measure is taken to prevent this, the oxidation may start dripping on to deck or
patio and cause damaging stains, which may be difficult to remove. This can be prevented if
measure is taken to keep the product from oxidizing.
mportant: Please do not return this product to the store. For technical assistance on
assembly or replacement parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am
EST to 8:00 pm PST or fax the replacement part form which is in the box to 1-740-283-3549 or
Email [e-mail] for assistance.
Made in China
