AVIANO GRILLGAZEBO
ASSEMBLY INSTRUCTION
ITEM#：A103000100
SKU#: 810461192
Live Chat
Live Chat
Contact US FIRST
*DO NOT RETURN YOUR PRODUCT TO THE STORE *
We have you in mind，let us help you！
24 / 7
[e-mail]
1-(866)-578-6569
Free
Toll
24 / 7
24 / 7
Live Chat
www.sunjoyonline.com
？Support

The limited warranty is extended to the original purchaser and applies to material and manufacturer’s
defect provided the item is maintained with care and used only for personal, residential purposes.
Safety Information
Two people are required for this
assembly.
Some parts may contain sharp edges. Wear
protective gloves.
When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.
Warranty: 1 Year
WHAT IS COVER?
IMPORTANT
KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE:
For outdoor use
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
WARNING: Keep all flame and heat sources away
from this gazebo fabric. This Gazebo ismade with
fabric that meets CPAI-84 specifications for flame
resistance. Itisnot fire proof. The fabric will burn
if left in continuous contact with any flame source.
The application of any foreign substance tothe
gazebo fabric may render the flame-resistant
properties ineffective.
Do not mix old and new batteries. Do not mix
alkaline, standard (Carbon - Zinc), or
rechargeable (Nickel - Cadmium) batteries. If you
find any noise, excessive temperature or leakage
from a battery, please discard. When not using the
unit for a considerable period of time, disconnect
the batteries from the unit for storage. If battery
power is weak during use, switch off the device
and dispose of batteries.
Country of Origin: China Production Number: 2020200002

3/ 9
IMPORTANT
How many people needed for the installation work
TOOLS NEEDED
Provided in hardware pack
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com

4/ 9
Parts List
Label Part Number Description Qty Part Image
A1P000200335 Post (1) 2
A2 Post (2) 1
A3 Post (3) with Bottle Opener
pre-assembled Cover 1
BBig beam 4
CBig connector 1
DSmall beam 4
ELong screen 2
FShort screen 2
G1 Glass Panel 1 1
G2 Glass Panel 2 1
HHook rack 1
JBig canopy 1
KSmall canopy 1
LHook 1
MLED light 4
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
P000200336
P000200337
P000601055
P000500850
P000601054
P000400704
P000400705
P002100218
P002100219
P005800142
P001100420
P001100421
P005800141
P006000006

5/ 9
Hardware Pack
Label Part Number Description Qty Add Part Image
IP005100242 Bolt 1 20 1
II Bolt 2 31
FF H070010008 6×230 mm Stake 80
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
P005100243

6/ 9
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
K
Fig 1. Attach the Long Screen (E)
and the Short Screen (F) to
Post (A1、A2、A3) with the
Bolt (I).
Fig 2. Attach the Big Beam (B) to
the Big Connector (C), attach
the Hook (L) to the Big
Connector (C).
Fig 3. Insert the lower connector
tube of the Big Beam (B)
into the upper tube of Post
(A1、A2、A3), then put the
Big Canopy (J) on big top,
do not fully spread.
I
E、F
A 1、A 2、A3
F
E
B
A 1、A 2、A3
B
B
C
B
LB

7/ 9
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
Fig 4. Attach the lower
connector tube of Small
beam (D) to the upper
tube of Big beam (B).
Fig 5. Extend the Small Canopy
(K) onto the small top by
fixing the canopy at four
corners of Small Beam (D).
Fig 6. Take off the back cover of
LED light (M), and match 3
pieces AAA batteries into
sockets. Attach back cover to
LED light (M).
Note: Batteries are not
included.
B
M
Fig 6-1. Hang the assembled LED light (M) into holes
of Big Beam (B) (Note: Pull down forward
tightly after LED lights hung into Beam holes).
G1
G2
J
H
B
D
J
D
K
KM

8/ 9
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
A1 A2 A3
FF
B
J
J
B
H
II II II
G2
I
G1、G2
Fig 9. Fix the gazebo to the lawn
by using the Stake (FF).
Fig 8. Insert the Glass Panel
(G1,G2) into the Post
(A1、 A2、 A3), then
attached them tightly
with the Bolt (I).
Attach the Hook (H)
to Glass Panel (G2)
with the Bolt (II).
Fig 7. Extend the Big Canopy (J)
onto the big top by fixing the
canopy at four corners of Big
Beam (B).
Fig 7-1.
FF

9/ 9
Our steel components for garden accessories and furniture are treated with rust inhibiting paint that protects it
from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur once these protective
coatings are scratched. This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the product to prevent scratching
the paint. Should any scratching or damage occur, we recommend immediate touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of common cooking oil. If surface oxidation
(rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping on to deck or patio
and caused damaging stains, which may be difficult to remove. This can be prevented if the above-mentioned
measures are taken to keep the product from oxidizing.
Use damp cloth to wipe off the stains as quickly as possible.
If necessary, wash with a mild solution of soap and water; rinse thoroughly and dry completely.
Periodically check and ensure that all bolts are well-tighten during use
Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for a
period of 1 year from the date of purchase, provided the item was factory-sealed at the time of purchase and is
maintained with care and used only for personal, residential purposes. Should any manufacturing defect arise within
this warranty period, Sunjoy Group will replace (at our option) any defective merchandise or parts upon proof of
purchase; however, transportation and delivery costs, as well as payments to a third party for assembly or disassembly
of the item, remain the responsibility of the purchaser. A purchaser of an "open box," previously-returned, or
"clearance" item, as well as original purchasers outside of the warranty period, may obtain replacement parts from
Sunjoy Group for products in current production, at nominal cost.
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature,
vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of
purchase (dated register receipt) is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an
implied warranty, the above exclusions and limitations may not apply. This warranty gives you specific rights, and you
may also have other rights, which vary from state to state.
Care and Maintenance
Exclusions:
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
Limited Manufacturer’s Warranty
