Sunjoy L-GZ340PST-3N-6 User manual

Item #: L-GZ340PST-3N-6
Assembly Instructions
IMPORTANT
Thank you very much for choosing Sunjoy Group.
Please take time toread these instructions thoroughly and follow each step carefully for safe and
easy operation. Keep this manual for future reference.
We would like to hear from you with any comments or suggestions. You can call us toll-free at
1-866-578-6569 anytime 24 hours / 7 days a week. You can also send the email to
[e-mail] or visit www.sunjoyonline.comto get tech. assistance or to place your
replacement part order form.
Production Number: 20183840
[email protected]
亚马逊邮箱要改，
最好是第一页整页
打出来改掉，贴得
很难看

Cautions:
1. Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of gazebo construction.
2. The area for assembly should not be less than 6 feet from any obstruction such as fence,
garage,house, overhanging branches, laundry line or electrical wires.
3. The unit is heavy. Don’t assemble alone. Six people are recommended for safe assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and use.
6. For outdoor use only. Install on level ground. 16 stakes are provided to secure the gazebo in
the ground. If you wish to secure the pavilion to a wood deck or concrete surface, use 16
anchors suited for these surfaces (anchors not included).
7. Check all bolts for tightness before and during usage
8. Pegs supplied must be used to hold this gazebo in place when upright.
9. Warranty does not cover damage due to extreme weather conditions.
10. Do not use candles, matches or open flames of any kind in or near item. Do not cook
inside.
11. Build campfires downwind and several meters away from a tent and be sure to fully
extinguish campfires before leaving a campsite or before retiring for the night.
12. Exercise extreme caution when using fuel-powered lanterns or heaters inside a tent and
use battery-operated lanterns whenever possible.
13. Extinguish or turn off all lanterns before going to sleep. Do not smoke in a tent.
Assembly Instructions:
Our clear, easy-to-follow, step-by-step instructions will guide you through the project from start
to finish. The final product will be a quality piece that will go together smoothly and give years
of enjoyment.
All you will need is a screwdriver, a hammer and two ladders of at least 8 feet (2.5 m) high (not
included).
Parts identification: For ease of identification, all parts are labeled to correspond to the Step
number in which the part is used.

Description No. Qty Image
Post A 4
Stake Slice B 4
Stake Cover C 4
Oblique Beam Connector
Middle Beam Connector
Corner Cross Beam
Long Cross Beam
Guide Rail H 8
Big top frame angle
Big top frame long bar
Oblique Beam
Middle Beam L 4
Short Left Beam
Short Right Beam
Middle Left Beam
Middle Right Beam
Left Cross Beam
Right Cross Beam
Small Top O 1
Hook P 1
Parts List
D 4
E 4
F 8
G 4
J1 2
J2 2
K 4
N1 4
N2 4
N3 4
N4 4
N5 4
N6 4
Part Number
P11178B01108
P11664A01108
P11552A01108
P10744A01108
P10840A01108
P11029D01108
P11030D01108
P12172A01108
P02309A01108
P02310A01108
P10336B01108
P10409B01108
P13034B01108
P13035B01108
P13036B01108
P13037B01108
P13038B01108
P13039B01108
P10040A01108
P12601C01108

Small Top Connector Q 1
Small Top Oblique Beam R 4
Small Top Oblique Beam
Cover S1 4
Big Top Oblique Beam
Cover S2 4
Small Top Cover T1 4
Big Top Cover T2 4
Middle Left Cover T3 4
Middle Right Cover T4 4
Small Left Cover T5 4
Small Right Cover T6 4
Presser U 8
Oblique Support V 4
AA Bolt M6X15 32 PCS
BB
CC Bolt M6X15 68 PCS
DD Bolt M6X25 16 PCS
Z Wrench M6 2 PC
Hardware Pack 1
P10144B01108
P10265A01108
P12063A01108
P12064A01108
P11980B01160
P11981B01160
P11982B01160
P11983B01160
P11984B01160
P11985B01160
P10644A01108
P11818B01108
116 PCS
Flat Washer M6
H09015C11
H19001C11
H02015C11
H02025C11
H00001C12

Fig.1: Put Stake Cover (C) to Post (A). Fix Stake Slice (B) to Post (A) by Bolt (AA) and Flat Washer (BB).
Fig.2: Put Oblique Beam Connector (D) to Post (A) and fix them by Bolt (CC) and Flat Washer (BB).
Fig.3: Insert Corner Cross Beam 1 (F) to Long Cross Beam (G) and fix them by Bolt (DD) and Flat Washer (BB).
Insert Corner Cross Beam 1 (F) to Long Cross Beam (G) and fix them by Bolt (CC) and Flat Washer (BB).
Fi
g
.4:
A
ttach Middle Beam Connector
(
E
)
to Lon
g
Cross Beam
(
G
)
and fix them b
y
Bolt
(
CC
)
and Flat Washer
(
BB
)
.
Fig.5: AttachCorner Cross Beam (F) to Post (A) by Bolt (CC) and Flat Washer (BB).
Fig.6: Attach Guide Rail (H) to Corner Cross Beam (F) (G)by Bolt (AA) and Flat Washer (BB).
Fig.7: Attach Oblique Support (V) to Corner Cross Beam (F) by Bolt (DD) and Flat Washer (BB).

AA Bolt M6X15 44 PCS
BB
CC Bolt M6X15 32 PCS
EE Bolt M6X55 20 PCS
GG Nut M6 20 PCS
Hardware Pack 2
Fig.8-1:Connect Big top frame
angle (J1)and Big top frame
long bar(J2) by Bolt (CC) and
Flat Washer (BB).
Fig.8-2: Attach the top of
Oblique Beam (K) to Big
Top Frame (J1) by Bolt (CC)
and Flat Washer (BB).
116 PCS
Flat Washer M6
H09015C11
H19001C11
H02015C11
H09055C11
H14001C11

Fig.9: Attach the bottom of Oblique Beam (K) to Oblique Beam Connector (D) by Bolt (EE), Flat Washer (BB)
and Nut (GG).
Fig.10: Attach the top of Middle Beam (L) to Big Top Frame by Bolt (CC) and Flat Washer (BB).
Fig.11: Attach the bottom of Middle Beam (L) to Middle Beam Connector (E) by Bolt (EE), Flat Washer (BB)
and Nut (GG).
Fig.12: Attach Short Left Beam (N1) & Middle Left Beam (N3) to Middle Beam (L) by Bolt (AA) and Flat
Washer (BB). Assemble Short Right Beam (N2) & Middle Right Beam (N4) in the same way.
Fig.13: Attach the other side of Short Right Beam (N2) & Middle Right Beam (N4) to Oblique Beam (K) by Bolt
(AA) and Flat Washer (BB). Assemble Short Left Beam (N1) & Middle Left Beam (N3) in the same way.
Fig.14: Attach one side of Left Cross Beam (N5) to Middle Beam (L) by Bolt (AA) and Flat Washer (BB).
Assemble Right Cross Beam (N6) in the same way.
Fig.15: Attach one side of Right Cross Beam (N6) to Oblique Beam (K) by Bolt (CC) and Flat Washer (BB).
Assemble Left Cross Beam (N5) in the same way.
Fig.16: Attach Small Top Oblique Beam (R) to Small Top Connector (Q) by Bolt (EE), Flat Washer (BB) and Nut
(GG). Assemble Hook (P) under Small Top Connector (Q).
Fig.17: Use Bolt (AA) and Flat Washer (BB)to attach the connector of
the Small Top Oblique Beam(R) on the connector of the Big
Top Frame(J1).

Hardware Pack 3
BB
AA
FF
HH Stake Φ8x260 16 PCS
II 1 PCS
Fig.18: Use Bolt (AA) and Flat Washer (BB) to fasten the small top cover (T1) on the Small Top Oblique
Beam (R).
Fig.19: Use Bolt (FF) and Flat Washer (BB) to fasten the Small Top Oblique Beam Cover (S1) on the Small
Top Oblique Beam (R).
Fig.20: Use M6 Globe Nut（II）and Flat Washer (BB) to fasten the Small Top Cover on the Small Top
Connector (Q).
Fig.21: See as below, Button up the Middle Right Cover (T4) on the Big Top Cover(T2). The Big Top Cover
will be arranged as two sides towards the middle buckled.
Flat Washer M6 73 PCS
Bolt M6x15 56 PCS
Bolt M6x40 16 PCS
M6 Globe Nut
H19001C11
H09015C11
H09040C11
P12402A01001
H15001C11

Fig.24: Use Bolt (AA) and Flat Washer (BB) to fasten the Left Presser (U) on the Big Top
Fig.25: Using the Stake (HH) to fix the Gazebo on the lawn.
Fig.22-1: Attach the Big Top Cover (T2) on the Big Top Frame (J1)(J2)by using Bolt(AA)and Flat Washer
(BB). Fig.22-2: Use Bolt(AA) and Flat Washer(BB) to fasten the Big Top Cover(T3、T4、T5、T6) on the
Oblique Beam(K).
Fig.23: Insert the Pilot Pin of the Big Top Oblique Beam Cover (S2) into the Small Top Oblique Beam(R),
then use Bolt(FF) and Flat Washer(BB) to fasten it on the Oblique Beam.

Care & Maintenance:
Our steel components for garden accessories and furniture are treated with rust inhibiting paint
that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will
occur once these protective coatings are scratched. This is not a defect and thus not covered
by the warranty.
To minimize this condition, we recommend care when assembling & handling the product to
prevent scratching the paint. Should any scratching or damage occur, we recommend
immediate touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of any rust removing solution,
we also recommend WD-40, which is readily available in all major stores. If no measure is taken
to prevent this, the oxidation may start dripping on to deck or patio and caused damaging stains,
which may be difficult to remove. This can be prevented if the above-mentioned measures are
taken to keep the product from oxidizing.
Limited Manufacturer’s Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials
and workmanship of your item provided the item is maintained with care and used only for
personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1)
year.We don't reimburse for transportation or delivery costs, or compensate the individual or
any outside party for assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due
to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or
rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for
warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not
apply. This warranty gives you specific rights, and you may also have other rights, which vary
from state to state.
