Sunjoy L-GZ659PST User manual

Assembly Instructions
Item#: L-GZ659PST

IMPORTANT:
Please read and follow all safety statements, warnings, assembly instructions, use & care directions before
attempting to assemble.
1. When installing and assembling your gazebo, it is recommended that 2 or more adults are involved.
2. Do not use the unit during an electrical storm, as there is a remote chance of getting struck by lightening.
3. Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury, possibly even death.
4. Do not leave the gazebo assembled when there is a risk of high wind, as possible damage will occur to the
structure.
5. Never barbecue under this gazebo or use lanterns that contain naked flames.
6. This package contains small items and plastic bags that should be kept away from children.
7. Ensure that all connectors & poles are firmly secured in position fully. It is important to do so before use so
as to avoid collapsing or damage to the item, which could result in injury.
8. WARNING: Keep all flame and heat sources away from this tent fabric. This tent is made with fabric that
meets CPAI –84 specifications for flame resistance. It is not fire proof. The fabric will burn if left in continuous
contact with any flame source. The application of any foreign substance to the tent fabric may render the
Flame-resistant properties ineffective.
9. WARNING: Please take down the gazebo during strong wind. The manufacturer or retailer is not liable for
any loss of the product or other items due to the failure to take down the gazebo during strong wind.
WARNINGS:
1. Assembly Instructions must be followed.
2. Pegs supplied must be used to hold this gazebo in place when upright.
3. Warranty does not cover damage due to extreme weather conditions.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC.
This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact
with any flame source. The application of any foreign substance to the tent fabric may render the
flame-resistant properties ineffective.
This unit is heavy. Do not assemble this item alone.

Pole
A
4
Base
B
4
Base cover
C
4
Short beam 1
D
2
Short beam 2
E
2
Long beam 1
F
2
Long beam 2
G
2
Corner connector 1
H1
2
Corner connector 2
H2
2
Middle beam connector
J
4
Corner connector
K
4
Big top beam
L
4
Long arch beam
M
2
Short arch beam
N
2
Long mosquito pipe
O
4
Short mosquito pipe
P
4
Big top connector 1
Q1
2
Big top connector 2
Q2
2
Big top long bar
R
2
Big top short bar
S
2
Small top connector
T
1
Small top bar
U
4
Small canopy
V
1
Large canopy
W
1
Privacy panel
X
1
Mosquito netting
Y
1
Hook
Z
1
Parts List

Fig.1: Put the Base cover (C) on the bottom of Pole (A), then use Bolt (AA) and Flat washer (BB) to connect the
Base (B) and Pole (A).
Fig.2: Connect the Beam F (D) and Beam G (E) by using the bolt (CC) and Flat washer (BB).
Fig.3: Attach the Long(short) Beam to stand Pole (A) by using Bolt (CC) and Flat washer (BB).
。
AA
M6X15 Bolt
24PCS
BB
M6 Flat washer
72PCS
CC
M6X15 Bolt
40 PCS
DD
M6X25 Bolt
8PCS
Z
M6 Wrench
1 PC
Hardware Pack 1

Fig.4: Attach Mosquito pipe O (P) to Beam D (E,F,G) by Bolt (AA) and Flat washer (BB).
Fig.5: Attach Middle beam connector (J) to Beam D (E,F,G) by Bolt (CC) and Flat washer (BB)..
Fig.6: Attach Corner connector (K) to Beam D (E,F,G) by Bolt (DD) and Flat washer (BB).
。
`
AA
M6X15 Bolt
8 PCS
BB
M6 Flat washer
16 PCS
EE
M6X35 Bolt
4 PCS
FF
M6 Nut
4 PCS
Hardware Pack 2

Fig.10: Insert Big top beam (L) into Corner connector (H1&H2).
Fig.11: Attach Arch beam M (N) to Middle beam connector (J) by Bolt (EE), Flat washer (BB) and Nut (FF).
Fig.12: Attach Hook (Z) to Small top connector (T), then insert Small top bar (U) into Small top connector (T).
Put on the Small canopy (V).
Fig.13: Put on the Large canopy (W), do not spread. Attach the assembled small top to Big top.
HH
Φ6X260MM Peg
16 PCS
GG
Plastic tie
104 PCS
Hardware Pack 3
Fig.7: Connect Corner connector (H1&H2) and A by Bolt (AA) and Flat washer (BB).
Fig.8: Insert Big top long bar (R) and Big top short bar (S) into Big top connector 1 (Q1) and Big top connector
2 (Q2).
Fig.9: Insert Big top beam (L), Long arch beam (M), and Short arch beam (N) into the assembled frame.

USE & CARE
1. This Gazebo is not a permanent structure and should be disassembled & stored away after use.
2. Do not repack your gazebo until completely dry.
3. This Gazebo must be assembled by two adults or more.
4. This Gazebo must not be left erect in windy conditions.
Fig.14: Hanging Mosquito netting (Y) to Mosquito pipe P (O) by Plastic tie (GG).
Fig.15: Hanging Privacy panel (X) to the pole under Beam D (E, F, G) by Plastic
tie (GG).
Fig.16: Put up the Base cover (C), using Stake (HH) to fasten the gazebo.

Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials and
workmanship of your item provided the item is maintained with care and used only for personal, residential
purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1) year. We
don't reimburse for transportation or delivery costs, or compensate the individual or any outside party for
assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of
nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not
covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color,
or a similar style and color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.
Maintenance:
Our iron/steel components for garden accessories and patio items are coated with rust inhibiting paint that
protects it from rusting. However, due to the nature of iron, surface oxidation (rusting) will occur once these
protective coatings are scratched. This is a natural process and is not a defect! To minimize this condition, we
recommend care when assembling & handling the product to prevent scratching the paint. Should any
scratching or damage occur, we recommend immediate touch-up with rust inhibiting paint. Surface rust can
also be easily removed with a very light application of common cooking oil. If surface oxidation (rusting)
occurs and if no measure is taken to prevent this, the oxidation may start dripping on to deck or patio and
cause damaging stains, which may be difficult to remove. This can be prevented if measure is taken to keep
the product from oxidizing.
Important: Please do not return this product to the store. For technical assistance on assembly or
replacement parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am EST to 8:00 pm PST or fax
the replacement part form which is in the box to 1-740-283-3549 or Email [e-mail]
for assistance.
Made in China
