Sunjoy A102007203 User manual

CountryofOrigin:ChinaProductionNumber:XXXXXXXXXX














ASSEMBLY INSTRUCTION
ITEM#：A102007203
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
1-(866)-578-6569
[email protected]

2/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
Warning! Toreducetheriskofseriousinjury,readthefollowingsafetyinstructions
beforeassemblingandusingthegazebo.
Pleasecheckwithyourlocalgoverningauthority/localmunicipalcodesregarding
installationofstructuresbeforeassembl
y
.
Caution!Properplacementofyourgazeboisessential.
Donotplacetheproductunderneathelectricallines.
Keepchildrenawayduringassembly.
Thisproductcontainssmallpartswhichcanbeswallowedbychildren.
Keepfingersawayfromtheplaceswheretheycanbepinchedortrapped.
Donotattempttoassemblethegazeboifanypartsaremissing.















•Thisproductisintendedfordomesticoutdooruseonly.
•Theproductshouldbeplacedonflat,horizontalground.
•Ensureenoughclearancearoundtheproduct.Beforeassemblingtheproduct,findlevel
groundnotlessthan6'(1.8m)awayfromanystructuresorobstructions,suchasfences,
garages,houses,overhangingbranches,laundrylines,orelectricalwires.
•Thisgazeboisnottoberegardedaspartofabuilding/housestructure.Thegazeboistobe
anchoredontothegroundforaddedsafety.Donotassemblethegazeboontosoil/earth
ground.Itisbestadvisabletohavethegazebobuiltontoawoodendeckorconcreteground
forstability.Ifitistobebuildontoawoodendeck/ground,doensurethatthewooden
deck/groundhasastrongfoundation.Itisadvisabletouseappropriatefloorplugs(not
provided)toanchorthegazeboontothewooden/concreteground.
•Somestructuresmayrequiretwoormorepeopletoinstallsafely.Checkforunderground
utilitiesbeforediggingordrivingstakesintotheground.
•Duringinstallation,followallsafetywarningsprovidedwithyourtools,andusesafetyglasses.
•Incaseyousetupmorethanonegazebo,keepaminimumdistanceof10'(3m)betweenthe
gazebos.
•Anyassemblyormaintenanceoftheproductmustbecarriedoutbyadultsonly.
•Arrangenecessarymanpowerwhenassemblingormovingtheproduct.
•Somepartsmaycontainsharpedges.Wearprotectiveglovesifnecessary.
•Keepchildrenandpetsawaywhilesettingupthegazebo.
•Checkallnutsandboltsperiodicallytoensurebolts/nutsaretightened.
•Repairingandreplacingpartsshouldbedonebyaqualifiedtechnician.
•Thisgazeboisintendedfordecorativeandsunshadepurposesonly,anditisnotdesignedto
withstandharshweather,includinghighwinds,rain,andsnow.
•Donotlightanyfiresinsideorneartheproduct!
•Staycalmiffirebreaksout.Searchforthenearestexit.Donotreturntothegazebobefore
firemenallowyoutodoso.
•Donothangheavyweightsontheroofframe.
•Donotclimbontotheroofofthegazebo.Fallingoffthegazebocanresultinseriousinjury.
•Retaintheoriginalpackagingtostorethegazebo.



Important Safety Instructions

3/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
IMPORTANT:



•Pleasereadandunderstandthismanualbeforeanyassembly.Beforebeginningassemblyof
product,makesureallpartsarepresent.Comparepartswithpackagingcontentslist.
•Ifanypartismissing,orifyouhaveanyquestions,contacttheservicecentreat1‐(866)‐578‐6569
(tollfree).
•Whenassemblingwoodenparts,donotovertorquetheboltstoavoidsplittingthewood.See
imageillustration.
•Placeallpartsfromtheboxinaclearedareaandpositionthemonthefloorinfrontofyou.
•Removeallpackingmaterialsandplacethembackintothebox.Donotdisposeofthepacking
materialsuntilassemblyiscomplete.
•Readeachstepcarefullybeforebeginninganyassemblyandmakesureyouunderstandeachstep.
Ifyouaremissingapart,pleasecallourtoll‐freenumberforassistance1‐(866)‐578‐6569.
•Neededforassembly:（Thefollowingtoolsarenotincluded）


























4/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com











































EXPLODED DRAWING

5/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
Parts List
Label Part Number Description Qty Part Image
08 P000200227 Post 4
10 P005000200 Arc Support 1 4
11 P005000201 Arc Support 2 4
03 P000400508 Outer Left Beam 4
04 P000400509 Outer Right Beam 4
05 P000400510 Inner Long Beam 4
06 P000400512
Inner Short Beam
1 (Short) 4
21 P000400960
Inner Short Beam
1 (Long) 4
B P006100177 Base Cover 4
C P000100338 Base 4
F P005600313 Middle
Decorative Plate 4
G P005600314 Corner
Decorative Plate 4
H1 P000601409
Big Roof Slanting
Beam 4
H2 P000501226
Slanting Beam
Connector 4

6/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
I1 P000601410
Big Roof Middle
Beam 4
I2 P000501227
Middle Beam
Connector 4
J3 P000601413
Big Roof Bottom
Left Beam 4
J4 P000601414
Big Roof Bottom
Right Beam 4
J6 P000601416
Big Roof Small
Beam 8
K3 P005700687
Mosquito Netting
Pipe 1 4
K4 P005700688
Mosquito Netting
Pipe 2 4
L2 P000501225 Big Roof Frame 4
M3 P000601408 Small Roof
Slanting Beam 4
N1 P000501275 Small Roof
Connector 1
O3 P000900104 Top Cover 1
P P005800001 Hook 1
Q P002200220 Roof Press Panel 8
S P000800248 Big Roof Slanting
Beam Cover 4
T P000800247
Small Roof
Slanting Beam
Cover
4
U5 P000700619 Small Roof Panel 4

7/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
V1 P000700621 Big Roof Left
Small Panel 4
V2 P000700622 Big Roof Right
Small Panel 4
W1 P000700626 Big Roof Middle
Left Small Panel 4
W2 P000700627 Big Roof Middle
Right Small Panel 4
X1 P000700624 Big Roof Middle
Left Panel 4
X2 P000700625 Big Roof Middle
Right Panel 4

8/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com

Hardware Pack
Label Part Number Description Qty Add Part Image
AA H010010276 Bolt M10*205 8 1
BB H050010020
Flat Washer
M6 165 9
CC H030050037 Screw M5*35 56 3
DD H040010004 Nut M6 8 1
EE H030050036 Screw M5*25 64 4
FF H010020011 Bolt M6*15 136 7
HH H010030083 Bolt M8*35 16 1
II H030030010 Bolt M8*35 16 1
JJ H010020016 Bolt M6*55 16 1
KK H010030084 Bolt M8*2524 2
LL H040050020
Non-slip Nuts
M10 8 1

MM H050010060 Flat Washer
M8 56 3


9/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
NN H050010059
Flat Washer
M10 24 2

OO H030010031 Screw
M10*80 8 1
PP H070010003 Stake Φ8*180 8 0
QQ H010020013 Bolt M6*35 5 1

RR H090990002 M3 Drill 2 0

SS H040050024 T-Nut
M8*20 16 1
VV H040050025 T-Nut
M8*8 24 2
Z1 H090010017 Wrench M6 2 0
Z2 H090030003 Allen Key M8 1 0
Z4 H090010015 Wrench M10 2 0


10/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
1
4X
16X
4X 4X

11/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
2
4X
16X 16X
4X
4X
16X
16X
4X

12/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
3
4X
4X
4X
8X 8X8X
4X

13/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
4
56X

14/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
5
16X
4X
10
Locatinghole

15/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
6
4X
12X 4X4X4X

16/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
















7
12X 4X4X4X 32X
4X

17/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
8
4X 4X
16X
16X
32X
Rt∠90
d1=d2
Assembly Tip on Step 8:
Please measure to make sure the length of d1 is equal to d2
before moving to next step to ensure a square frame and best
results. Keep the beam at right angles to the post, the post
at right angles to the ground, and keep the beam horizontal.

18/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
9
4X
4X 4X

19/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
10
16X 16X
4X

20/36
CountryofOrigin:ChinaCall1(866)578‐6569forassistance.
Orvisitusatwww.sunjoyonline.com
11
4X
8x 24x 8x 8x
