Assembly Instructions
Item#D-GZ007PST

2/ 7
Parts Name
No.
Qty.
Small Top
Connector
A
1
Hook
B
1
Small Top Bar
C
4
Large Top
Connector
D
1
Top Bar 1
E
4
Top Bar 2
F
4
Screen
G
8
Pole 1
H1
2
Pole 2
H2
2
Pole 3
H3
2
Pole 4
H4
2
Fence
I
4
Bar Top
J
2
Big Canopy
K
1
Small Canopy
L
1
Parts List

3/ 7
Hardware Pack 1
AA
M6*20 Screw
56 PCS
BB
M6 Flat Washer
56 pcs
Z1
M6 Wrench
1 PC
Fig.1 Attach Screen (G) to Pole
(H1, H2, H3, H4) by using Screw
(AA) and Flat washer (BB)
Fig.2 Attach Fence(I) to
Pole(H1,H2,H3,H4)and by using
Screw(AA)and Flat washer(BB)
Fig.3 Connect Bar Top (J) to Pole
(H3, H4) by using Screw (AA) and
Flat washer (BB).

4/ 7
Hardware Pack 2
BB
M6 Flat Washer
16pcs
CC
M6 Nut
8PCS
DD
M6*45 Screw
8pcs
Z2
M6 Wrench
1 PCS
Fig.4 Screw Hook (B) into Large
Top Connector (D), then insert
Top Bar 2(F) into Large Top
Connector (D).
Fig.5 Connect Top Bar 2(F) and
Pole (H1/H2/H3/H4) by using
Screw (DD), Flat Washer (BB)
and Nut (CC).
Fig.6 Insert Top Bar 1(E)
into Large Top Connector
(D).
Fig.7 Connect Top Bar 1(E) and
Pole (H1/H2/H3/H4) by using Screw
(DD) Washer (BB) and Nut (CC),
and Put Big Canopy (K) onto the big
top frame.
Fig.9 Insert Small Top Bar
(C) into Top Bar 1(E).
Fig.8 Insert Small Top Bar (C) into
Small Top Connector (A). Put Big
Canopy (K) onto the big top frame,
do not spread it out.

5/ 7
Hardware Pack 3
EE
Dia.6x180 Stake
16PCS
Fig.10 Lay out Small Canopy (L)
completely and tie it to Small Top
Bar(C).
Fig.11 Lay out Big Canopy (K)
completely, and then tie it to Top
Bar (E/F).
Fig.12 Secure the whole gazebo
to the ground with Dia.6x180
Stake (EE).

6/ 7
IMPORTANT:
1. Keep all children and pets away from assembly area. Children and pets should be
supervised when they are in the area of gazebo construction.
2. The area for assembly should not be less than 6 feet from any obstruction such as fence,
garage, house, overhanging branches, laundry line or electrical wires.
3. This unit is heavy. Do not assemble this item alone. Six people are recommended for safe
assembly.
4. Some parts may contain sharp edges. Wear protective gloves if necessary during assembly.
5. When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and use.
6. For outdoor use only. Install on level ground. Stakes are provided to secure the gazebo in
grass ground. If you wish to secure the gazebo to a wood deck or concrete surface, you will
need to purchase fasteners appropriate for these surfaces. These are readily available at your
local hardware store or home center.
7. Check all bolts for tightness before and during usage.
8. Please check your state and local regulations prior to purchasing. Some jurisdictions may
require permits for, or otherwise regulate, installation and use.
9. While this gazebo is manufactured to withstand gale force winds utilizing only the supplied
ground stakes, in areas subject to frequent severe weather, securing the gazebo to a deck,
concrete patio or footings should be considered.
10. Your gazebo has been engineered to accommodate winter snow loads incurred in most
areas. Removal of accumulated snow on the gazebo roof with a roof rake is recommended.
In areas that are regularly subject to blizzard conditions however, removal of the roof panel is
suggested. The assembled roof structure can simply be left intact until warmer conditions
return.
Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in materials
and workmanship of your item provided the item is maintained with care and used only for
personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of one (1) year. We don't reimburse for transportation or
delivery costs, or compensate the individual or any outside party for assembling or
disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged due
to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or
rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for
warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not
apply. This warranty gives you specific rights, and you may also have other rights, which vary
from state to state.

7/ 7
Maintenance:
Our iron/steel components for garden accessories and patio items are coated with rust
inhibiting paint that protects it from rusting. However, due to the nature of iron, surface
oxidation (rusting) will occur once these protective coatings are scratched. This is a natural
process and is not a defect! To minimize this condition, we recommend care when assembling
& handling the product to prevent scratching the paint. Should any scratching or damage occur,
we recommend immediate touch-up with rust inhibiting paint. Surface rust can also be easily
removed with a very light application of common cooking oil. If surface oxidation (rusting)
occurs and if no measure is taken to prevent this, the oxidation may start dripping on to deck or
patio and cause damaging stains, which may be difficult to remove. This can be prevented if
measure is taken to keep the product from oxidizing.
Important: Please do not return this product to the store. For technical assistance on
assembly or replacement parts. Please call Sunjoy Industries at 1-866-578-6569 from 8:00 am
EST to 8:00 pm PST or fax the replacement part form which is in the box to 1-740-283-3549 or
Email [e-mail] for assistance.
Made in China
2016-2
