Sunjoy L-PB120PAL User manual

OWNER'S MANUAL
ITME: L-PB120PAL
Warning, Care & Maintenance
Read and follow all below statements and instructions before assembly.
Repeated assembly can weaken the locking ability of the hardware. Periodically
check all bolted connections on your product to make sure they are tight and secure.
Keep these instructions for future reference.
Some parts may contain sharp edges. Wear protective gloves as necessary.
This unit is heavy. Do not assemble it alone. 2 adults are needed for safe assembly.
Keep children and parts away from assembly area.
Do NOT over tighten any of the bolts or nuts. Ensure that the nuts are NOT put on
cross threaded before tightening.
When not in use, always clean, cover and then store the product in a dry location for a
longer life. Do NOT use strong detergent or abrasive cleaners.

Part List
No.
Part Description
Qty.
A
Chair back
1
B
Left arm
1
C
Right arm
1
D
Seat board
1
E
Support bar
1
AA
M6x35 Bolt
6
BB
M6 Spring washer
10
CC
M6 Flat washer
10
DD
M6x15 Bolt
4
EE
M6x15 Countersink hex bolt
2
FF
M6 Wrench
1
GG
Pad (Preassembled on B,C)
4
Step 1:
Fig.1: Attached Left arm (B) / Right arm (C) onto both
side of Support bar (E) with Bolt (DD), Spring washer
(BB), Flat washer (CC), by using Wrench (FF), don’t
tighten them in this step.
Fig.2: Connect both side of Seat board (D) with Left arm
(B) / Right arm (C) with Bolt (AA), Spring washer (BB),
Flat washer (CC), by using Wrench (FF), don’t tighten
them in this step.
Step 2:
Fig.1: Insert each side of Chair back (A) into
the hole of Left arm (B) / Right arm (C).
Fig.2: Tighten each side of Chair back (A) and
Left arm (B) / Right arm (C) with Countersink
hex bolt (EE) by using Wrench (FF). Then,
tighten all the bolts.
Go over all the assembly steps.
Step 1
Step 2

Limited Warranty:
This limited warranty is extended to the original purchaser and applies to defects in
materials and workmanship of your item provided the item is maintained with care and
used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of
1year. We don't reimburse for transportation or delivery costs, or compensate the
individual or any outside party for assembling or disassembling the product.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged
due to acts of nature, vandalism, misuse, or improper assembly are not covered.
Corrosion or rusting of hardware is not covered. Proof of purchase (dated register receipt)
is required for warranty claims. Warranty is to the original purchaser and is
non-transferable. Any replacement of warranted items will be in the original style and color,
or a similar style and color if the original is unavailable or has been discontinued.As some
states do not allow exclusions or limitations on an implied warranty, the above exclusions
and limitations may not apply. This warranty gives you specific rights, and you may also
have other rights, which vary from state to state.
Maintenance:
Our iron/steel components for garden accessories and furniture are coated with rust
inhibiting paint that protects it from rusting. However, due to the nature of iron, surface
oxidation (rusting) will occur once these protective coatings are scratched. This is a
natural process and is not a defect! To minimize this condition, we recommend care when
assembling & handling the product to prevent scratching the paint. Should any scratching
or damage occur, we recommend immediate touch-up with rust inhibiting paint. Surface
rust can also be easily removed with a very light application of common cooking oil. If
surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation
may start dripping on to deck or patio and cause damaging stains, which may be difficult to
remove. This can be prevented if measure is taken to keep the product from oxidizing.
Important: Please do not return this product to the store. For technical assistance on
assembly or replacement parts Please do not return this product to the store, call Sunjoy
Industries at 1(866) 578-6569 from 8:30 AM to 5:30 PM EST Monday to Friday or fax the
replacement part form which put into the package to (740)-283-3549 or Email
[e-mail] for assistance.
Made in China
